Weltem Icen WPC-7000 User manual

1
Owner’s Manual WPC-7000 / 9000
Please read and save these instructions. Read carefully before attempting to assemble, install, oper-
ate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions
could result in personal injury and / or property damage! Retain instructions for future reference.
Weltem Portable Air Condioners feature spot cooling for large areas
where cooling of the enre area is not praccal. A dedicated spot cool-
ing thermostat controls the unit in this applicaon.
These air condioners can also be used in smaller areas for room cooling.
A control panel provides ease of use and contains a self-diagnosc func-
on and display, showing operang modes, room and set temperatures,
and faults.
If an abnormal operaon occurs, a visual display of the fault is shown.
Caster wheels are included for easy portability. Suitable applicaons in-
clude: a factory or work place, industrial kitchen, computer room, emer-
gency cooling, outdoor event, etc.
Aer unpacking the unit, carefully inspect unit for any damage that may have occurred during
transit. Check for any loose, missing, or damaged parts.
DescripƟon
Unpacking
Portable Air Conditioners
WPC-7000/WPC-9000
Figure 1
Owner’s Manual
SpecificaƟons
WPC-7000 / 9000
Model No. Power Supply Ph-V-Hz Cooling Capacity
Btu/h
Power Con-
sumpon Was
Rated Cur-
rent Amps
EER Btu/
Wh
WPC-7000 Single Phase,
208 / 230V, 60Hz
28,000 / 29,000 3300 15.1/ 14.8 9.3
WPC-9000 36,000 / 37,000 4400 20 / 19 10.6
Model No. Nema Plug Power Cord
Gauge AWG
Power Cord
Length 
Dimensions
W x H x D - in. (mm)
WPC-7000 6-20p 12
10
22.1 x 47.3 x 29.5
(560 x 1200 x 750)
WPC-9000 6-30p 10 26 x 54.3 x 34.8
(660 x 1380 x 885)
Model No. Weight (Net / Gross)
Lbs(kg)
Condensate tank
Gallons(Liters)
No. of Cool Air
Outlets Pcs
Ambient temperature
range °F( °C)
WPC-7000 216 / 234 lbs.(98 / 106 kg) 3.17 (12) 3 64~113 (18~45)
WPC-9000 253 / 271 lbs. (115 / 123 kg)

2
Owner’s Manual WPC-7000 / 9000
SpecificaƟons (ConƟnued)
Model No. Seng temperature
(Room cool mode) °F( °C)
Seng temperature
((Spot cool mode) °F( °C)
WPC-7000 64~86 (18~30) 32~86 (0~30)
WPC-9000
Model No. Applicaon Area
(Room cool mode) ²(m²)
Refrigerant
Type / oz(g)
Design Pressure -
Hi/Low Psig
WPC-7000 743 (70) R-410A / 44.5(1260) 450 / 280
WPC-9000 1300 (100) R-410A / 61(1730) 450 / 250
Model No. Indoor Air Flow
(High/Low)CFM(CMH)
Wheels
pcs / diameter
Hot Air Duct Diameter
In.(mm)
Maximum Duct
Length (m)
WPC-7000 741 / 635 (1259 / 1078) 4 / 102mm 16 (400) 60 (18)
WPC-9000 882 / 776 (1499 / 1318)
Safety Devices
Compressor overload protector, An-freezing thermis-
ter, Full drain tank switch, Automac restart (Power
interrupon), Compressor me delay program, High
pressure switch
Features
Temperature control, Self-diagnosc funcon, Two
speed fan, Oponal drain pump kit, Washable filters, °F(
°C) display, Off-mer
General Safety InformaƟon
Please read this manual carefully for instrucons on correct installaon and usage. Please read
all safeguards.
1. Transport and store the unit in an upright posion only. Leave unit in an upright posion for at
least 3 hours before first use.
2. Always place the unit on an even, level surface.
3. Ensure the unit is connected to a grounded power supply of the correct rang / capacity.
4. The unit will cool when the room temperature is between 18°C (64°F) ~ 45°C(113°F) depend-
ing on the thermostat seng.
5. DO NOT use this unit for funcons other than those described in this instrucon manual.
6. DO NOT lt the unit.
7. DO NOT cover or obstruct the unit’s inlet and outlet grilles.
8. DO NOT use the unit in areas where it will be exposed to rain or water.
9. NEVER unplug the unit while it is operang.
DO NOT use the unit in wet environments, such as a laundry room, to avoid
the risk of electrical shock.

3
Owner’s Manual WPC-7000 / 9000
General Safety InformaƟon (ConƟnued)
10. DO NOT place any foreign objects on the unit.
11. DO NOT operate the unit with wet or damp hands.
12. DO NOT allow chemical substances to come into contact with the unit.
13. DO NOT operate the unit in the presence of flammable substances or vapors such as alcohols,
pescides, gasoline, etc.
14. DO NOT use the plug to start and to stop the unit. Always use the control panel to start and
to stop the unit.
15. Always turn offthe unit when it is not in use and unplug the power plug from the electrical
outlet.
16. Always turn the unit offand unplug the main power plug from the electrical outlet before
cleaning, moving or performing maintenance.
17. AVOID the use of adapter plugs or extension cords. If it is necessary to use an extension cord
or an adapter plug to operate the unit, ensure that they are correctly rated for the applica-
on. Consult a local qualified lectrician and all local electrical codes to ensure proper setup.
Any extension cord used with this device must be rated for a minimum of 20A.
18. DO NOT unplug the unit by pulling on the electrical cord. Keep electrical cord away from heat
sources and always completely unroll the cord to avoid overheang. If the power cord be-
comes damaged, a qualified service agent, qualified electrician, or similarly qualified person
must replace it, in order to avoid a hazard or shock.
19. The filters must be used with the product at all mes. When the filters are removed for clean-
ing, always ensure that the unit has been turned offand unplugged from the electrical outlet.
20. Regularly clean the filters to maintain efficiency. If the filters are not cleaned regularly, the
units output performance and efficiency will decline and energy consumpon will increase.
21. DO NOT operate the unit with a damaged power cord or plug, aer it malfuncons, has been
dropped or damaged.
22. Only use in the upright posion on an even, flat surface. Unit must be posioned at least 24
inches (60 cm) from the nearest object in any direcon.
23. Stop operaon immediately if abnormal noise or odor is noced. Contact a local service
center.
24. Appliance is not to used by children or persons with reduced physical, sensory or mental
capabilies, or lack of experience and knowledge, unless they have been given supervision or
instrucon.
25. Children being supervised not to play with appliance.
26. That the appliance shall be installed in accordance with naonal wiring regulaons.
27. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
SAVE THESE INSTRUCTIONS
DO NOT operate the unit in explosive or flammable environments.
DO NOT operate a unit with a damaged power cord.

4
Owner’s Manual WPC-7000 / 9000
Assembly
COMPONENT PARTS
((%#*(-,%,"(+
*(','#!",##/
#+)%1(',*(%(*
() '0"-+,2'!
.)(*,(*3%,*
-#* (*(''+,/,*,'$
(''+,/,*,'$,*%.%#+
+'+',"-'#,()*4('#++,())
/"','$#+ -%%'%*&/#%%
#+)%1&),1,",'$'*)%,(
*+-&()*4('
$(-,,"(*"(%* *(&
,"++(*1(0
%,"(*"(%*(',"
$+#( #*('#4('*
++*/+'%(+#'+#
( ++(*1(0/#,"(*"(%*
,(#'+,%%,"(*"(%*(',"
#*('#4('*++"(/'#'#!-*
&(.((%#*(-,%,"(++ *(&*,('
%,"((%#*(-,%,"(++('," *(',,()
( #*('#4('*
++*/+'%(+#'+#( (0/#,"
((%#*(-,%,"(++,(#'+,%%,"((%#*(-,%,"(++
(',"#*('#4('*++"(/'#'#!-*
POWER CORD HOLDER
DISCHARGE DUCTS/SUPPLY AIR DUCT
Figure 2
Figure 3
Figure 5
$'##/
(''+*3%,*
(/*(*"(%*
+,*
%,*#%++)'%
&(.,",() '0"-+,
2'! *(&*,('
%,",() '0"-+,2'!
(',",()( #*('#4('*
++*/+'%(+#'+#
( (0/#,",",() '0"-+,
2'!,(#'+,%%,",() '
0"-+,2'!('#*('#4('*
++"(/'#'#!-*5
TOP FAN EXHAUST FLANGE
Figure 4

5
Owner’s Manual WPC-7000 / 9000
Assembly (ConƟnued)
InstallaƟon
MOVING THE UNIT
PLUGGING IN THE UNIT
Unlock the casters and push the unit using the side handles to a flat, level surface and set the
caster brakes to the locked posion.
Check the prongs and surface of the power cord plug for dust/dirt. If dust and/or dirt are pres-
ent, wipe offwith a clean, dry cloth.
Check the power cord, plug and prongs for damage or excess play.
If any damage or excess play is found, contact a qualified repair technician or a qualified electri-
cian to perform replacement or repair of the power cord, plug or prongs.
NOTE: Make sure the AC outlet is free of dirt, dust, oil, water, or any other foreign material. The
unit is equipped with an approved NEMA plug configuraon (WPC-7000: 6-20P / WPC-
9000:6-30P). The appropriate outlet must be used for each plug type.
WARNINGS REGARDING PROPER LOCATION FOR INSTALLATION
Do not use the unit in explosive environments or in areas where flammable
gas leakage may occur.
Do not use the unit in areas where it will be exposed to rain or water.
Do not use the unit in a corrosive atmosphere.
Do not use the unit above 18°C(64°F) ~ 45°C(113°F).
Do not install the unit on uneven or sloping surface. The unit may roll or
topple over even if the casters are set to the locked posiƟon.
If the power cord or plug is damaged, repair should only be performed by
qualified electrical personnel.
Do not connect / disconnect the power cord or aƩempt to operate buƩons
with wet hands. This could result in electrical shock.
An ambient air adapter can be purchased separately. Air adapter fits over
the condenser to duct condenser air to the unit to improve cooling ef-
ficiency.
1. Remove air adapter from carton.
2. Place air adapter on the rear of air condioner.
3. Use screws (enclosed inside of box with air adapter) to install the adapter
on the air condioner as shown in Figure 6.
Figure 6
AMBIENT AIR ADAPTER (OpƟonal)

6
Owner’s Manual WPC-7000 / 9000
OperaƟon
CONTROL PANEL
1. POWER BUTTON: Acvates unit when POWER BUTTON is pressed. (Fan starts on low speed). If
power buon is pressed during operaon, unit stops.
2. BLOWER BUTTON: Changes fan speed from (Low) to (High) when pressed.
3. SPOT/COOL BUTTON: Acvates compressor and begins producing cool air 5 seconds aer but-
ton is pressed. Regulates temperature based on outlet cool air temperature.
4. ROOM/COOL BUTTON: Acvates compressor and produces cool air 5 seconds aer buon is
pressed. Regulates temperature based on inlet ambient air temperature.
5. SET TEMP BUTTONS: Change target temperature/data value by +/- 1. Change data value by +/-
10 by pressing connually. Press the SET TEMP BUTTONS to set temperature. Upper buon is
to heighten temperature and Lower buon is to lower temperture.
6. ALARM: Alarm indicator lights (blinks) and indicates abnormal system operaon. If Alarm oc-
curs, compressor stops.System operaon stops when ALARM light is acvated (blinks) longer
than 3 minutes.
7. CURRENT TEMP: Displays current room temperature in display in Fahrenheit. (In Room
Cool Mode only). SPOT/COOL Mode – Displays outlet (cool air) temperature during normal
operaons. In order to change °F to °C, press SPOT/COOL and ROOM/COOL buons together
for 2 seconds. C will blink 2 mes and Figure will change to °C. ALARM codes blink and are
displayed when abnormal operaon occurs.
NOTE: Canadian version shows the temperature in Celsius first when you turn on the unit.
8. TARGET TEMP: displays the unit set temperature for ROOM/COOL mode only.
OFF-TIMER: Enter to Timer Seng Mode if you press BLOWER Buon and SPOT/COOL Buon
together for1 seconds. Press UP/DOWN Buon to set the mer unl it shows the figure you want
to set. Aer 5 seconds,the figure will be memorized and the compressor will stop aer the me set.
AUTO RESTART: If the unit goes offdue to an electrical interrupon, the unit will automacally
restart when the power resumes.
Figure 7
1 2
5
3 4
6
87

7
Owner’s Manual WPC-7000 / 9000
Maintenance
FILTER CLEANING (See Figures 8 and 9)
There are two filters in the unit. The evaporator filter is located at the front of the unit. The
condenser filter is located at the side of the unit.
1. loosen up 2 bolts on the front filter guard.
2. Slide filter up and use a vacuum cleaner to remove the dust from the filter.
3. If the filter is heavily covered with dust and dirt, warm water and mild soap or neutral deter-
gent may be used to wash the filter. Do not use any other chemicals to clean filter, as they will
likely damage the filter.
4. Dry the filter in a shaded area before replacing it. Do not operate the unit without the filter
installed and the filter guard in the closed posion.
5. Replace the clean filter and close the filter guard.
6. To clean the condenser filter, liup on the side filter from the middle bar slightly and then
angle the filter outwards from the boom and remove.
7.Use the same cleaning procedure as above (3 – 5).
8. To replace the condenser filter, place the top of the filter in the guide and slide the filter up
unl the boom of the filter clears the frame. Then push the boom of filter into the guide
and let filter gently fall inside the guide.
NOTE: For effecve cooling clean the filter at least every 2 weeks.
– For your convenience, record the complete model number and product name (located on the
Product Idenficaon Plate), the purchase date, purchase locaon, serial number, and war-
ranty period in the table below.
– Also, aach your purchase receipt as proof of purchase to this instrucon manual for future
reference.
– To ensure your product is covered by warranty, the complete faulty product along with your
original purchase receipt must be provided at the place of purchase.
Do not operate without the filter fiƩed.
Do not operate the unit with a damaged cord or plug, aŌer the unit malfunc-
Ɵons, or if the unit has been dropped or damaged.
!

!


!

 
!




Figure 8 – Removing Filters Figure 9 – Removal of Dust

8
Owner’s Manual WPC-7000 / 9000
Maintenance (ConƟnued)
– To ensure your product is covered by warranty, the complete faulty product along with your
original purchase receipt must be provided at the place of purchase.
Product Portable Air CondiƟoner
Model No.
Date of Purchase
Place of Purchase
Serial No.
Period of Warranty
Customer: Please read and keep this
manual for future reference and keep
sales receipt as proof of purchase.
SPRING REPLACEMENT (See Figure 10)
SELF-DIAGNOSTIC CODES (See Table 1)
The alarm light is acvated if abnormal operaon occurs, and a code is displayed on the control
panel. The compressor and condenser fan motor will stop operang. The evaporator fan will con-
nue to run for 3 minutes. If the fault is recfied within 3 minutes, the unit will resume opera-
on. If the fault persists for more than 3 minutes, the evaporator fan also stops. The fault must
be recfied before the unit can resume normal operaon.
There are two springs on the rear of condensate water tank guide.
1. Release the screw on the spring hook.
2. Take offthe spring hook, and then pull out the opposite spring
hook from hole in the condensate water tank guide.
3. Replace with a new spring in reverse order.
4. Repeat this cycle for the other spring.
Figure 10 – The process of
spring replaccement

9
Owner’s Manual WPC-7000 / 9000
SELF-DIAGNOSTIC ALARM CODES
Alarm Display Problem Cause Correcve Acon
Frost prevenon
sensor and Abnormal
temperature sensor
value
• Indoor heat
exchanger tempera-
ture too low
• TH3 temperature
sensor has a loose
or broken connec-
on
• Do not use the air
condioner if ambient
temperature is lower
than 18°C (64°F)
• Contact a qualified
service agent
Refrigerant high
pressure switch
• Blocked air filter
• Blocked / kinked
exhaust duct
• Ambient tempera-
ture is too high
• Clean air filter
• Ensure exhaust duct is
not blocked / kinked
• Do not use the air
condioner if ambient
temperature is higher
than 45°C (113°F)
Abnormal tempera-
ture sensor value
TH1(Outlet) tem-
perature sensor has
a loose or broken
connecon
Contact a qualified service
agent
Abnormal tempera-
ture sensor value
TH2(Inlet) tem-
perature sensor has a
loose or
broken connecon
Contact a qualified service
agent
Compressor over-
loaded
• Ambient tempera-
ture is too high
• Unstable voltage
supply
• Defecve compres-
sor
• Do not use the air
condioner if ambient
temperature is higher
than 45°C (113°F)
• Contact a qualified
service agent
• Replace compressor
Condensate water
level alarm Condensate tank is full
• Empty the water tank
• Aer installaon of the
water tank, press the
SPOT/COOL or ROOM/
COOL buon to resume
operaon
Drain pump alarm
Drain pump defecve
or improper hose con-
necon (including kink
or blockage)
• Check the aconnecon
and hose
• Replace drain pump
Table 1- Alarm Codes

10
Owner’s Manual WPC-7000 / 9000
Wiring Diagram
DRAIN
PUMP
(option)
RELAY
RELAY
Figure 11 - Circuit Wiring Diagram
