Wenglor OY2TA104P0150E User manual

EN
OY2TA104P0150E
High-Performance Distance Sensor
Operating Instructions
Translation of the Original Operating Instruction
Subject to change without notice
Available as PDF version only
Status: 03.09.2019
www.wenglor.com

2
EN
Table of Contents
1. Proper Use 4
2. Safety Precautions 4
2.1. Safety Precautions 4
2.2. Laser/LED warning 4
2.3. Approvals and IP Protection 4
3. Technical Data 5
3.1. Connecting the Sensors 6
3.2. Housing Dimensions 7
3.3. Control Panel 8
3.4. Complementary Products 9
4. Mounting Instructions 9
5. Initial Operation 9
5.1. Operation using a controller without EDS file use 9
5.2. Default Settings 10
6. Functional Overview OLED-Display 11
6.1. Run 13
6.2. Display 13
6.2.1. Display Mode 13
6.2.2. Display Intensity 14
6.3. Filter 14
6.4. Laser 14
6.5. I/O Test 15
6.6. Network 16
6.7. Language 16
6.8. Info 16
6.9. Reset 17
6.10. Password 17

3
7. Detailed description of the object models for EtherNet/IPTM devices 18
7.1. Identity object (0x01) 18
7.2. Message router object (0x02) 19
7.3. Assembly object (0x04) 20
7.4. Connection manager object (0x06) 21
7.5. Port object (0xF4) 22
7.6. TCP/IP interface object (0xF5) 23
7.7. Ethernet link object (0xF6) 24
7.8. QoS object (0x48) 25
7.9. Vendor-specific object (0x64) 26
7.9.1. Configuration assemblies 26
7.9.2. Static input assembly 26
7.9.3. Vendor object 27
8. Web-based configuration 29
8.1. Opening the administration interface 29
8.2. Page layout 32
8.3. General device 33
8.4. Device Settings 33
8.5. Measured Value Settings 34
8.6. Device Test 35
9. Maintenance Instructions 35
10. Proper Disposal 35
11. EU Declaration of Conformity 35

4
EN
1. Proper Use
This wenglor product has to be used according to the following functional principle:
High-performance distance sensors which use the principle of transit time measurement determine the dis-
tance between the sensor and the object according to the principle of transit time measurement. These sensors
have a large working range and are therefore able to detect objects over large distances.
Selected sensors are distinguished by WinTec (wenglor interference free technology). This technology allows
black or shiny surfaces to be reliably detected even in extremely inclined positions. It is possible to mount sev-
eral sensors next to or across from each other without them influencing each other.
2. Safety Precautions
2.1. Safety Precautions
• This operating instruction is part of the product and must be kept during its entire service life.
• Read this operating instruction carefully before using the product.
• Installation, start-up and maintenance of this product has only to be carried out by trained personal.
• Tampering with or modifying the product is not permissible.
• Protect the product against contamination during start-up.
• These products are not suited for safety applications.
2.2. Laser/LED warning
Class Laser 1 (EN 60825-1)
Observe all applicable standards and safety precautions.
2.3. Approvals and IP Protection
RoHS
LASER CLASS 1
EN 60825-1:2014

5
3. Technical Data
Order Number OY2TA104P0150E
Working Range 0,1...10,1 m
Linearity Deviation 20 mm
Reproducibility 7 mm
Light Source Laser (red)
Output Rate 330/s
Wave Length 660 nm
Service Life (Tu = 25 °C) 100000 h
Max. Ambient Light 5000 Lux
Laser Class (EN 60825-1) 1
Beam Divergence < 2 mrad
Light Spot Diameter see table 1
Port Type 100BASE-TX
PoE Class 1
Response Time < 10 ms
Temperature Range –25...50 °C
Reverse Polarity Protection yes
Protection Class III
Adjustment Menu (OLED)
Housing Plastic
Degree of Protection IP68
Connection M12×1, 8-pin
Webserver yes
Control Panel No. X2, T10
Interface EtherNet/IPTM
Light Spot Diameter
Working Distance 0 10 m
Light Spot Diameter 5 mm < 20 mm
Table 1

6
EN
3.1. Connecting the Sensors
OY2TA104P0150E
001
Legend
Wire Colors according to IEC 60757
Platinum measuring resistor
not connected
Test Input
Test Input inverted
Trigger Input
Ground for the Trigger Input
Analog Output
Ground for the Analog Output
Block Discharge
Valve Output
Valve Control Output +
Valve Control Output 0 V
Synchronization
Ground for the Synchronization
Receiver-Line
Emitter-Line
Grounding
Switching Distance Reduction
Ethernet Receive Path
Ethernet Send Path
Interfaces-Bus A(+)/B(–)
Emitted Light disengageable
Magnet activation
Input confirmation
Contactor Monitoring
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
Grey
White
Pink
Green/Yellow
Supply Voltage +
Supply Voltage 0 V
Supply Voltage (AC Voltage)
Switching Output (NO)
Switching Output (NC)
Contamination/Error Output (NO)
Contamination/Error Output (NC)
Input (analog or digital)
Teach Input
Time Delay (activation)
Shielding
Interface Receive Path
Interface Send Path
Ready
Ground
Clock
Output/Input programmable
Power over Ethernet
Safety Input
Safety Output
Signal Output
Ethernet Gigabit bidirect. data line (A-D)
Encoder 0-pulse 0-0 (TTL)
Encoder A/A (TTL)
Encoder B/B (TTL)
Encoder A
Encoder B
Digital output MIN
Digital output MAX
Digital output OK
Synchronization In
Synchronization OUT
Brightness output
Maintenance
reserved
PT

7
3.2. Housing Dimensions
1 = Transmitter Diode
2 = Receiver Diode

8
EN
3.3. Control Panel
23 20 22
60
X2
85
48
78
T13
20 = Enter button
22 = up button
23 = down button
60 = display
78 = module status
85 = link/act LED
48 = network status
Description Status Function
MS (Module Status)
Off –
Green off Operate status
Green flashing Standby
Red Serious error
Red flashing Device error
NS (Network Status)
Off No IP address
Green off CIP connection
Green flashing IP configured, no CIP connection
Red Duplicated IP address
Red flashing CIP connection timeout
L/A
Off No connection established
Green Device connected, connection established
Green flashing Device connected, connection established, communication ac-
tive

9
3.4. Complementary Products
wenglor offers Connection Technology for field wiring.
Suiting Mounting Technology No.
340
Suiting Connection
Technology No.
50
S81
Protection Housing Set ZST-NN-02
Midspan Adapter Z0029
Switch with PoE ZAC50xN0x
4. Mounting Instructions
When using the Sensor, follow the corresponding electrical and mechanical regulations, standards and safety
rules. The Sensor must be protected against mechanical influence. The Sensor has optimum extraneous light
qualities when the background is within the working range.
5. Initial Operation
5.1. Operation using a controller without EDS file use
If you want to commission the device when connected to a control system, please perform the following steps
as described by means of example:
• Connect the sensor to a switch with PoE using a suitable cable M12×1; 8-pin. If using a switch without PoE
please use the adapter (Z0029) for the adequate supply voltage. Once the supply voltage has been estab-
lished the display at the sensor will start.
• Create a new project in the controller
• Add a new module to this project
• When selecting the communication module “General Ethernet module” should be used
• The properties of the new module should match the connection parameters of the relevant product. In the
example of the sensor the communication format selected should be “Data SINT”. To be able to access the
sensor in the network an IP address must be assigned in addition. In delivery condition this is requested by
the product via a DHCP server.
• Creating the Config Assembly (not mandatory). Default Config = I/O ports to input, active performance moni-
toring, all ports are released for PoE
• After the program has been created, connect to the controller and load program
For a detailed description for different controllers and for installation of the files or project planning of the
network refer to the help files of the relevant controller. wenglor provides a short exemplary instruction for com-
missioning of an EtherNet/IPTM device (www.wenglor.com Product World Product search (Enter the
product number) Download General instructions).

10
EN
5.2. Default Settings
OCPxxxP0150P
Display Mode Process
Intensity Screensaver
Filter 1
Laser ON
Network
IP-Address 192.168.100.1
Subnet Mask 255.255.255.0
DHCP DHCP OFF
Std Gateway 192.168.100.254
MAC Address (See type plate on the product)
Language English
Password Activate Off
Change 0
