Weslo Pursuit 102 Bike User manual

USER'S MANUAL
CAUT ON
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial
Number
Decal
Model No. WLEVEX12921
Serial No.
www.iconeurope.com
Visit our website at
QUEST ONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. f you
have questions, or if there are
missing parts, please call:
Or write:
CON Health & Fitness, Ltd.
Customer Service Department
Unit 4
Revie Road ndustrial Estate
Revie Road
Beeston
Leeds, LS118JG
UK
email: [email protected]
08457 089 009

2
TABLE OF CONTENTS
IMPORTANTPRECAUTIONS ................................................................2
BEFOREYOUBEGIN ......................................................................3
ASSEMBLY ...............................................................................4
HOWTOOPERATETHEEXERCISECYCLE....................................................8
MAINTENANCEANDTROUBLESHOOTING....................................................11
CONDITIONINGGUIDELINES...............................................................12
PARTLIST ..............................................................................14
EXPLODEDDRAWING ....................................................................15
ORDERINGREPLACEMENTPARTS ..................................................BackCover
1. Read all instructions in this manual before
using the exercise cycle. Use the exercise
cycle only as described in this manual.
2. t is the responsibility of the owner to ensure
that all users of the exercise cycle are ade-
quately informed of all precautions.
3. Use the exercise cycle indoors on a level sur-
face. Keep the exercise cycle away from
moisture and dust. Place a mat under the
exercise cycle to protect the floor.
4. nspect and properly tighten all parts regular-
ly. Replace any worn parts immediately.
5. Keep children under the age of 12 and pets
away from the exercise cycle at all times.
6. Wear appropriate clothing when exercising;
do not wear loose clothing that could become
caught on the exercise cycle. Always wear
athletic shoes for foot protection.
7. The exercise cycle should not be used by
persons weighing more than 115 kg (250 lbs.).
8. Always keep your back straight whilst using
the exercise cycle; do not arch your back.
9. f you feel pain or dizziness whilst exercising,
stop immediately and cool down.
10.The pulse sensor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
11. The exercise cycle is intended for home use
only. Do not use the exercise cycle in
a commercial, rental, or institutional setting.
WARN NG: Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. CON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
MPORTANT PRECAUT ONS
WARN NG: To reduce the risk of serious injury, read the following important precau-
tions before using the exercise cycle.

3
Congratulations for selecting the new WESLO®
PURSUIT 102 exercise cycle. Cycling is one of the
most effective exercises for increasing cardiovascular
fitness, building endurance, and toning the body. The
PURSUIT 102 exercise cycle offers a selection of fea-
tures designed to let you enjoy this healthful exercise
in the convenience and privacy of your home.
For your benefit, read this manual carefully before
you use the exercise cycle. If you have questions
after reading this manual, please call our Customer
Service Department at 08457 089 009. To help us
assist you, please note the product model number and
serial number before calling. The model number is
WLEVEX12921. The serial number can be found on a
decal attached to the exercise cycle (see the front
cover of this manual for the location of the decal).
Before reading further, please familiarise yourself with
the parts that are labeled in the drawing below.
Water Bottle Holder*
*No water bottle is included
Resistance Knob
REAR
FRONT
Seat
Adjustment Knob
Adjustment Knob
Pedal/Strap
Console
Pulse Sensor
Handlebar
R GHT S DE
BEFORE YOU BEG N

4
ASSEMBLY
Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing
materials. Do not dispose of the packing materials until assembly is completed.
Assembly requires the included tools and your own adjustable spanner , Phillips screw-
driver , and pliers .
Use the part drawings below to identify the small parts used in assembly. The number in parenthesis below
each drawing refers to the key number of the part, from the PART LIST on page 14. The second number refers
to the quantity needed for assembly. Note: Some small parts may have been pre-attached for shipping. f a
part is not in the parts bag, check to see if it has been pre-attached.
3/8” Nylon
Locknut (33)–4
M8 Nylon
Locknut (10)–3
M8 Flat
Washer (51)–3
M8 x 15mm Button
Screw (34)–3
3/8” x 65mm Carriage Bolt (30)–4
Curved
Washer (42)–3
Ground
Screw (27)–1
M5 x 12mm
Screw (49)–4
M8 Split
Washer (47)–3
1. Set the Front Stabiliser (2) in front of the Frame (1),
with the Wheels (23) on the side shown. Whilst another
person lifts the front of the Frame slightly, attach the
Front Stabiliser with two 3/8” x 65mm Carriage Bolts
(30) and two 3/8” Nylon Locknuts (33). Make sure that
the Front Stabiliser is turned so the Wheels are not
touching the floor.
2
23
23
33
30
1
1
2. Whilst another person lifts the rear of the Frame (1)
slightly, attach the Rear Stabiliser (6) with two 3/8” x
65mm Carriage Bolts (30) and two 3/8” Nylon Locknuts
(33).
30
6
1
2
33
33

5
3
9
43
19
45
1
13
Hole
Zip Tie
Adjustment
Holes
36
3. Whilst another person holds the Upright (13) in the
position shown, connect the Upper Wire (36) to the
Reed Switch Wire (43). Cut and remove the zip tie
holding the Reed Switch Wire to the Frame (1).
Next, connect the Resistance Cable (19) to the Lower
Cable (45) in the following way:
• See drawing A. Pull up on the metal bracket, and
insert the tip of the Resistance Cable (19) into the
wire clip on the Lower Cable (45) as shown.
• See drawing B. Firmly pull the Resistance Cable
(19) and slide it into the metal bracket on the Lower
Cable (45) as shown.
• See drawing C. Using pliers, squeeze the prongs on
the upper end of the metal bracket together.
Carefully pull the excess Upper Wire (36) out of the
top of the Upright (13), push the excess Cable (19, 45)
down into the Frame (1), and insert the Upright into the
Frame. Be careful to avoid pinching the Wires and
Cables. Next, align one of the adjustment holes in the
Upright with the indicated hole in the Frame. Insert the
Adjustment Knob (9) into the Frame and the Upright,
and turn the Knob clockwise until it is tight. Make sure
that the Knob is inserted through one of the
adjustment holes in the Upright.
4
4. The Console (16) requires three 1.5V AA batteries;
alkaline batteries are recommended. Insert three bat-
teries into the battery compartment. Make sure that
the batteries are oriented as shown by the mark-
ings inside the battery compartment.
16
Batteries
Be careful to
avoid pinching
the wires and
cables whilst
inserting the
Upright.
45 45
Metal
Bracket
B
A
45
19
19
19
C

6
7. Attach the Seat (12) to the Seat Post (5) with three M8
Flat Washers (51) and three M8 Nylon Locknuts (10).
Note: The Flat Washers and Nylon Locknuts may be
preattached to the underside of the Seat.
6. Whilst another person holds the Handlebar (15) near
the Upright (13), connect the console wire to the Upper
Wire (36). Insert the excess wire down into the Upright.
Attach the Handlebar to the Upright with three M8 x
15mm Button Screws (34), three M8 Split Washers
(47) and three Curved Washers (42). Be careful to
avoid pinching the wires.
15
36 34
47
13
42
47
34
34
42
6
Console Wire
7
51
12
51
10
10
5
5. Hold the Console (16) near the Handlebar (15).
Connect the ground wire to the Handlebar with the
Ground Screw (27). Insert the console wire into the
indicated hole in the Handlebar.
Move the Console (16) toward the Handlebar (15), at
the same time inserting the excess ground wire up into
the hole in the underside of the Console. Continue
until all of the excess ground wire is inside of the
Console. Attach the Console to the Handlebar with
four M5 x 12mm Screws (49). Be careful to avoid
pinching the wires.
16
5
Be careful to
avoid pinching
the wires.
Be careful
to avoid
pinching the
wires.
15
49
49
27
Ground
Wire
Hole
Console
Wire

7
10. Make sure that all parts are properly tightened before you use the exercise cycle. Note: After assembly is
completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
9. Identify the Left Pedal (24), which is marked with an
“L.” Using an adjustable spanner, firmly tighten the
Left Pedal counterclockwise into the left arm of the
Crank (20). Tighten the Right Pedal (not shown) clock-
wise into the right arm of the Crank. mportant:
Tighten both Pedals as firmly as possible. After
using the exercise cycle for one week, retighten the
Pedals. For best performance, the Pedals must be
kept tightened.
Adjust the left Pedal Strap (25) to the desired position,
and press the end of the Pedal Strap onto the tab on
the Left Pedal (24). Adjust the right Pedal Strap (not
shown) in the same way.
9
8. Turn the indicated Adjustment Knob (9) counterclock-
wise and remove it. Insert the Seat Post (5) into the
Frame (1). Align one of the adjustment holes in the
Seat Post with the indicated hole in the Frame. Insert
the Adjustment Knob into the Frame and the Seat Post,
and turn the Knob clockwise until it is tight. Make sure
that the Knob is inserted through one of the
adjustment holes in the Seat Post. 1
5
Hole
Adjustment
Holes
9
8
24
20
25
Tab

8
HOW TO OPERATE THE EXERC SE CYCLE
HOW TO ADJUST THE SEAT POST
For effective exer-
cise, the seat
should be at the
proper height. As
you pedal, there
should be a slight
bend in your knees
when the pedals
are in the lowest
position. To adjust
the height of the
seat, first turn the
indicated knob
counterclockwise
and remove it. Next, slide the seat post up or down and
align one of the adjustment holes in the seat post with
the indicated hole in the Frame. Insert the knob into the
frame and the seat post, and turn the knob clockwise
until it is tight. Make sure that the knob is inserted
through one of the adjustment holes in the seat
post.
HOW TO ADJUST THE UPR GHT
The upright can be
adjusted to the
height that is the
most comfortable
for you. To adjust
the upright, first
turn the indicated
knob counterclock-
wise and remove it.
Next, slide the
upright up or down
and align one of the
adjustment holes in
the upright with the
indicated hole in the frame. Insert the knob into the
frame and the upright, and turn the knob clockwise until
it is tight. Make sure that the knob is inserted
through one of the adjustment holes in the
upright.
HOW TO ADJUST THE PEDAL STRAPS
To adjust the pedal
straps, first pull the
ends of the straps
off the tabs on the
pedals. Adjust the
straps to the
desired position,
and press the ends
of the straps back
onto the tabs.
HOW TO ADJUST THE PEDAL NG RES STANCE
To increase the
resistance of the
pedals, turn the
resistance knob
clockwise; to
decrease the resis-
tance, turn the knob
counterclockwise.
mportant: Stop
turning the knob
when turning
becomes difficult,
or damage may
result.
Strap
Tab
Upright
Knob
Hole
Seat Post
Knob
Hole
Seat
Resistance
Knob

9
FEATURES OF THE CONSOLE
The easy-to-use console features six modes that pro-
vide instant exercise feedback during your workouts.
The modes are described below.
Speed—This mode displays your pedalling
speed, in kilometres per hour or miles per hour.
Time—This mode displays the elapsed time.
Note: If you stop pedalling for a few seconds,
the time mode will pause.
Distance—This mode displays the distance you
have pedalled, in kilometres or miles.
Calorie—This mode displays the approximate
number of calories you have burned.
Heart Rate—This mode displays your heart rate
when you use the pulse sensor.
Scan—This mode displays the speed, time, dis-
tance, calorie, and heart rate modes, for a few
seconds each, in a repeating cycle. Note: The
heart rate mode will be displayed only when the
pulse sensor is being used.
HOW TO OPERATE THE CONSOLE
Make sure there are batteries in the console (see
BATTERY REPLACEMENT on page 11). If there is a
thin sheet of clear plastic on the console, remove it.
Follow the steps below to operate the console.
1. To turn on the power, press the ON/RESET button
or begin pedalling. The entire display will briefly
appear; the console will then be ready for use.
2. Select one of the modes:
Scan mode—
When the power
is turned on, the
scan mode will be
selected automati-
cally. A mode indi-
cator will appear
below the scan
symbol to show
that the scan
mode is selected,
and a second
mode indicator will show which mode is currently
displayed. Note: If you have selected a different
mode, repeatedly press the MODE button to select
the scan mode again.
Speed, time, dis-
tance, or calorie
mode—To select
one of these
modes for continu-
ous display,
repeatedly press
the MODE button.
The mode indica-
tors will show
which mode is selected. Make sure there is not a
mode indicator below the scan symbol.
Note: The console can display speed and dis-
tance in either kilometres or miles. To change
the unit of measurement, press the ON/RESET
button for about five seconds. The letters km/h or
mph will appear in the display to show which unit of
measurement is selected. When the batteries are
replaced, it may be necessary to reselect the
desired unit of measurement.
Mode Indicators

10
3. Measure your heart rate, if desired.
To measure your
heart rate, stop
pedaling and
place your thumb
on the pulse sen-
sor as shown. Do
not press too
hard, or the cir-
culation in your
thumb will be
restricted and
your pulse will
not be detected.
After a few seconds, the heart-shaped indicator in
the display will flash steadily, two dashes will
appear, and then your heart rate will be shown.
Hold your thumb on the pulse sensor for about 15
seconds for the most accurate reading.
If the displayed heart rate appears to be too high or
too low, or if your heart rate is not displayed, lift
your thumb off the pulse sensor for a few seconds.
Then, place your thumb on the pulse sensor as
described above.
Make sure you are applying the proper amount of
pressure to the pulse sensor. Try the pulse sensor
several times until you become familiar with it.
Remember to sit still whilst measuring your heart
rate.
4. To reset the display at any time, press the
ON/RESET button.
5. To turn off the power, simply wait for a few minutes.
The console has an “auto-off” feature. f the
pedals are not moved and the console buttons
are not pressed for a few minutes, the power
will turn off automatically to save the batteries.
WARN NG: The pulse sensor
is not a medical device. Various factors
may affect the accuracy of heart rate read-
ings. The pulse sensor is intended only as
an exercise aid in determining heart rate
trends in general.
Pulse Sensor
