West Elm hudson 5 drawer dresser User manual

hudson 5 drawer dresser
assembly instructions
Page 1 of 38407108/8407074/ 8687238 - 11/06
A B
C
! Tools required:
! Do not throw away packaging materials until assembly is complete.
! Assemble this item on a soft surface, such as cardboard or carpet, to protect nish.
! Proper assembly of this item requires 2 people.
bolt 6x screw 8x
allen key 1x

hudson 5 drawer dresser
assembly instructions
Page 2 of 38407108/8407074/ 8687238 - 11/06
1. Before starting assembly, take out all accessories inside large bottom drawer. Then place the chest upside down on a smooth,
scratch-free surface.
2. Attached each metal leg by aligning it on the pre-drilled holes underneath the chest . Insert bolts (A) into the leg beam as
shown and tighten using the allen key (C). Then insert screws (B) into the plate and tighten using a phillips head screwdriver.
CARE INSTRUCTION
Hardware may loosen over time. Periodically check that all connections are tight.
Wipe with a soft, dry cloth. To protect nish, avoid the use of chemicals and household cleaners.

hudson 5 drawer dresser
assembly instructions
Page 3 of 38407108/8407074/ 8687238 - 11/06
OVER BALANCE. To prevent injury and property damage from unexpected tipping of furniture, we highly recommend
installation of the overbalance protection hardware included with this product.
1. Attach the mounting brackets horizontally to the top back edge of the furniture. Insert the
2. Determine where the furniture is to be placed and mark location on the wall for the other
mounting bracket screw holes. It should be placed approximately 2” below the bracket mounted
to the furniture.
3. Attach the mounting brackets vertically to the wall by inserting the long screws provided through
the holes in the bracket and tightening securely using screwdriver.
short screws through the holes in the bracket and tighten securely using screwdriver.
4. Place the furniture so the brackets on the back edge are in line with the brackets on the wall.
5. Lace an end of the nylon restraint strap down through each bracket. Bring both ends together
and slide the thin end of the strap through the receiving end of the strap until snug.
6. Check to make sure the strap is securely laced and locked to the brackets.
back side
wall
