Westfield MKX130 Series Installation instructions

Part Number: 30797 R5
Revised: 1/6/2017
Read this manual before using product. Failure
to follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
GRAIN AUGERS
MKX130-84/94/114
ASSEMBLY & OPERATION
ORIGINAL INSTRUCTIONS

This product has been designed and constructed according to general engineering
standardsa. Other local regulations may apply and must be followed by the operator.
We strongly recommend that all personnel associated with this equipment be trained
in the correct operational and safety procedures required for this product. Periodic
reviews of this manual with all employees should be standard practice. For your
convenience, we include this sign-off sheet so you can record your periodic reviews.
a. Standards include organizations such as the American Society of Agricultural and Biological Engineers,
American National Standards Institute, Canadian Standards Association, International Organization for
Standardization, EN Standards, and/or others.
Date Employee Signature Employer Signature

New in this Manual
The following changes have been made in this revision of the manual:
Description Section
Tow bar design has been modified. Section 3.2.6. "Install the Boot Tow Bar"
(page 48)
Section 3.15. "Auger-to-Tractor Hookup"
(page 78)
Updated illustration to show new double
hose holder; step added for new hose
holder.
Section 3.10. "Connect the PTO
Driveline" (page 69)

30797 R5 5
WESTFIELD GRAIN AUGERS
MKX130-84/94/114
TABLE OF CONTENTS
1. Introduction .......................................................................................................................... 9
1.1. Overview ................................................................................................................ 10
1.1.1. Auger Power Source ................................................................................ 11
1.1.2. Grain Transfer Boot.................................................................................. 12
1.1.3. Grain Hopper............................................................................................ 13
1.1.4. Auger Tube Hydraulic Lift......................................................................... 15
2. Safety .................................................................................................................................. 17
2.1. General Safety Information .................................................................................... 17
2.2. Assembly Safety..................................................................................................... 18
2.3. Operation Safety .................................................................................................... 18
2.4. PTO Safety............................................................................................................. 20
2.5. Hydraulic Safety..................................................................................................... 21
2.6. Transport & Placement Safety ............................................................................... 22
2.7. Maintenance Safety................................................................................................ 22
2.8. Safety Decals......................................................................................................... 23
2.8.1. Decal Installation/Replacement................................................................ 23
2.8.2. Safety Decal Locations and Details.......................................................... 23
3. Assembly ............................................................................................................................ 37
3.1. General Assembly.................................................................................................. 37
3.2. Assemble the Auger Tube...................................................................................... 39
3.2.1. Identify and Arrange Auger Tube Sections............................................... 39
3.2.2. Install Hydraulic Lift Cylinders .................................................................. 42
3.2.3. Connect Auger Tubes ............................................................................. 43
3.2.4. Install the Track Shoe and Track Stop ..................................................... 44
3.2.5. Install the Boot on the Auger tube ............................................................ 45
3.2.6. Install the Boot Tow Bar ........................................................................... 48
3.2.7. Install the Discharge Spout....................................................................... 49
3.2.8. Set the Thrust Adjuster............................................................................. 49
3.2.9. Apply Logo and Model Decals on the Auger Tubes ................................. 50
3.3. Install Truss Support Towers and Truss Tubes...................................................... 51
3.4. Install Truss Cables................................................................................................ 58
3.5. Assemble the Frame.............................................................................................. 60
3.6. Assemble the Wheel Hub and Install Tires ............................................................ 62
3.7. Connect the Auger Tube to the Frame................................................................... 63
3.8. Install the Lift Cylinders and Cables ...................................................................... 65
3.9. Connect Hydraulic Hoses and Ball Valve............................................................... 66
3.10. Connect the PTO Driveline................................................................................... 69
3.11. Install the Low Profile Intake Hopper.................................................................... 70
3.12. Install the Hopper Lift Arm and Winch.................................................................. 73
3.13. Install the Hitch Jack ............................................................................................ 76
3.14. Install the Plastic Manual Container..................................................................... 77
3.15. Auger-to-Tractor Hookup...................................................................................... 78

630797 R5
WESTFIELD GRAIN AUGERS
MKX130-84/94/114
TABLE OF CONTENTS
4. Transport............................................................................................................................. 81
4.1. Transport Procedure............................................................................................... 81
5. Placement ........................................................................................................................... 85
5.1. Placement Procedure............................................................................................. 85
5.2. Positioning Tractor for Right-angle Drive Operation............................................... 90
5.3. Lowering the auger .............................................................................................. 91
6. Operation ............................................................................................................................ 93
6.1. Operator Controls................................................................................................... 93
6.2. Pre-Operation......................................................................................................... 95
6.2.1. Checklist................................................................................................... 95
6.2.2. PTO Drive................................................................................................. 96
6.2.3. Hydraulics................................................................................................. 96
6.3. Operating Procedures ............................................................................................ 97
6.3.1. Initial Start-Up........................................................................................... 97
6.3.2. Normal Start.............................................................................................. 98
6.3.3. Normal Shutdown..................................................................................... 99
6.3.4. Emergency Stop / Full-Tube Restart ...................................................... 100
6.3.5. Lowering & Completion........................................................................... 100
6.3.6. Reverser Operation ................................................................................ 101
7. Maintenance and Storage................................................................................................ 105
7.1. Maintenance Intervals .......................................................................................... 105
7.2. Fluids and Lubricants ........................................................................................... 106
7.3. Maintenance Procedures...................................................................................... 106
7.3.1. Visual Inspection..................................................................................... 106
7.3.2. Hydraulic Hose and Coupler Inspection ................................................. 107
7.3.3. Machine Greasing................................................................................... 107
7.3.4. Hopper Lift Cable Inspection .................................................................. 110
7.3.5. Winch and Pulley Servicing.................................................................... 110
7.3.6. Swing Tube Coupler Chain Servicing..................................................... 111
7.3.7. Boot and Hopper Chain Drive Servicing................................................. 111
7.3.8. Upper/Lower Gearbox Oil Level ............................................................. 113
7.3.9. Speed Reducer Gearbox Oil Levels....................................................... 113
7.3.10. Machine Cleaning................................................................................. 114
7.3.11. Tire Pressure Check............................................................................. 114
7.3.12. Wheel Bearings Repack....................................................................... 114
7.3.13. Wheel Bolt Tightening........................................................................... 114
7.3.14. Truss Cable Adjustment ....................................................................... 114
7.3.15. Changing Upper/Lower Gearbox Oil..................................................... 115
7.3.16. Changing the Speed Reducer Gearbox Oil.......................................... 115
7.4. Storage................................................................................................................. 116

30797 R5 7
WESTFIELD GRAIN AUGERS
MKX130-84/94/114
TABLE OF CONTENTS
8. Troubleshooting............................................................................................................... 117
9. Appendix........................................................................................................................... 119
9.1. Specifications....................................................................................................... 119
9.2. Bolt Torque Values............................................................................................... 120
Warranty................................................................................................................................ 123

830797 R5
WESTFIELD GRAIN AUGERS
MKX130-84/94/114

WESTFIELD - GRAIN AUGERS 1. INTRODUCTION
MKX130-84/94/114
30797 R5 9
1.Introduction
Thank you for purchasing a Westfield grain auger. Before using, please read this
manual and understand the various features of the equipment and precautions
for efficient and safe operation.
Keep this manual handy for frequent reference and to review with new
personnel. A sign-off form is supplied on the inside front cover to record your
safety reviews. Call your local distributor or dealer if you need assistance or
additional information.
This manual should be regarded as part of the equipment. Suppliers of both new
and second-hand equipment are advised to retain documentary evidence that
this manual was provided with the machine.
Serial Number:
*Serial number is located on the lower tube.

1. INTRODUCTION WESTFIELD - GRAIN AUGERS
MKX130-84/94/114
10 30797 R5
1.1. OVERVIEW
MKX130 augers are equipped with standard features that include a hydraulically
controlled main auger tube lift, a low-profile grain hopper (left or right side
operation), service access doors, and a PTO shaft for auger power.
Available option kits include:
• Hydraulic Winch
• Hydraulic Power Swing for Hopper
• Electric Power Swing for Hopper
• Right Angle Drive
• 540 RPM PTO Reverser
• 1000 RPM PTO Drive and Reverser
Figure 1.1 MKX130 Series Auger (84’ model shown)

WESTFIELD - GRAIN AUGERS 1. INTRODUCTION
MKX130-84/94/114
30797 R5 11
1.1.1. AUGER POWER SOURCE
The power source for the auger is a standard 540 RPM tractor PTO (see Figure
1.2). An optional Right-Angle PTO Drive kit allows the auger to be powered by a
tractor positioned at a 90 degree angle to the auger (Figure 1.3).
An optional 1000 RPM PTO Drive kit provides a speed reducer that allows use
with 1000 RPM PTO tractors, as well as reverser capability that is used to rotate
the auger flightings in the reverse direction (transferring grain in the auger tube
back to the hopper).
An optional 540 RPM Reverser kit provides a similar reverser capability for
540 RPM PTO connections.
Figure 1.2 Standard PTO
Figure 1.3 Right Angle PTO Drive Kit

1. INTRODUCTION WESTFIELD - GRAIN AUGERS
MKX130-84/94/114
12 30797 R5
1.1.2. GRAIN TRANSFER BOOT
The grain transfer boot is located at the bottom of the main auger tube, and
contains gearing for power transfer as well as flights for transferring grain.
PTO driveline connection (including connection to the optional 540 RPM PTO
Reverser and 1000 RPM PTO Drive) is provided on the back of the boot, above
the tractor hitch (and hitch jack).
The ball valve used to raise or lower the main auger tube is located on the side of
the boot (see figure below), as is the manual winch used to raise and lower the
grain hopper (see section 6.1. for further information on auger controls).
Several access hatches are provided for maintenance and repair, as well as an
overflow panel on the swing-arm spout head and a clean-out hatch at the bottom
of the boot.
Figure 1.4 Grain Transfer Boot
GRAIN TRANSFER BOOT
SWING ARM SPOUT HEAD
OVERFLOW PANEL
PTO DRIVELINE
HITCH
HITCH JACK
SPOUT HEAD
SERVICE COVER
CLEAN-OUT HATCH MANUAL WINCH (HOPPER)
BALL
VALVE

WESTFIELD - GRAIN AUGERS 1. INTRODUCTION
MKX130-84/94/114
30797 R5 13
1.1.3. GRAIN HOPPER
The low-profile grain hopper is designed to be rolled into position to receive grain
for transfer through the boot to the auger discharge spout. Ground clearance can
be adjusted by raising or lowering the position of the hopper wheel axles (see
“Install the Low Profile Intake Hopper” on page 70).
The grain hopper must be lifted and secured for transport using the hopper lift
arm, winch (hydraulic or manual operation, according to the installed option), and
transport chain and hook (see Figure 1.6).
The grain hopper provides service to the side of the auger that it is installed on,
but the hopper, lift arm, and winch can be quickly reconfigured to install the
hopper on the other side if required.
Do not approach, open or close the maintenance hatch located on the transition
between the swing are tube and the hopper unless all power to the auger is
locked out.
DANGER
Rotating Auger Hazard
Contact with rotating flighting will result in
amputation or severe laceration.
DO NOT operate with guards removed or
modified.
Keep hands and feet away from rotating
auger.
Tie up long hair and remove jewellery.
DO NOT wear loose-fitting clothing or items
that could become caught.
Shut off and lock out the power source before
unplugging or cleaning.

1. INTRODUCTION WESTFIELD - GRAIN AUGERS
MKX130-84/94/114
14 30797 R5
Figure 1.5 Grain Hopper
Figure 1.6 Grain Hopper Lifted into Transport Position
INTAKE HOPPER
FLIGHTS AND
SWING ARM
MAINTENANCE HATCH
SPOUT HEAD
MAIN AUGER TUBE
BOOT FLIGHT GUARDING
WINCH CABLE AND HOOK
SAFETY CHAIN AND HOOK
HOPPER LIFT ARM

WESTFIELD - GRAIN AUGERS 1. INTRODUCTION
MKX130-84/94/114
30797 R5 15
1.1.4. AUGER TUBE HYDRAULIC LIFT
The auger tube is raised and lowered using two single-acting hydraulic cylinders
powered by the hydraulic supply of the connected tractor. The main auger tube is
raised by extending the cylinders, and lowered by allowing the cylinders to
retract. (see Figure 1.7).
A hydraulic ball valve mounted on the side of the grain pick-up boot controls flow
of hydraulic fluid to the lift cylinders, and with appropriate use of the hydraulic
controls on the connected tractor, allows the main auger tube to be raised,
lowered, or locked at a specific height during operation (see “Operator Controls”
on page 93).
Figure 1.7 Auger Tube Hydraulic Lift Cylinders

1. INTRODUCTION WESTFIELD - GRAIN AUGERS
MKX130-84/94/114
16 30797 R5

WESTFIELD - GRAIN AUGERS 2. SAFETY
MKX130-84/94/114
30797 R5 17
2.Safety
2.1. GENERAL SAFETY INFORMATION
The Safety Alert symbol identifies important safety messages on the product and
in the manual. When you see this symbol, be alert to the possibility of personal
injury or death. Follow the instructions in the safety messages.
Why is SAFETY important?
• Accidents disable and kill.
• Accidents cost.
• Accidents can be avoided.
SIGNAL WORDS: Note the use of the signal words DANGER, WARNING,
CAUTION, and NOTICE with the safety messages. The appropriate signal word
for each message has been selected using the definitions below as a guideline.
DANGER
Indicates an imminently hazardous situation
that, if not avoided, will result in serious injury
or death.
WARNING
Indicates a hazardous situation that, if not
avoided, could result in serious injury or
death.
CAUTION
Indicates a hazardous situation that, if not
avoided, may result in minor or moderate
injury.
NOTICE
Indicates a potentially hazardous situation that, if not
avoided, may result in property damage.

2. SAFETY WESTFIELD - GRAIN AUGERS
MKX130-84/94/114
18 30797 R5
YOU are responsible for the SAFE use and maintenance of your equipment.
YOU must ensure that you and anyone else who is going to work around the
equipment understands all procedures and related SAFETY information
contained in this manual.
Remember, YOU are the key to safety. Good safety practices not only protect
you, but also the people around you. Make these practices a working part of your
safety program.
Important: Below are general instructions that apply to all safety practices. Any instructions
specific to a certain safety practice (e.g., Operational Safety), can be found in the
appropriate section. Always read the complete instructional sections and not just
these safety summaries before doing anything with the equipment.
• It is the equipment owner, operator, and maintenance personnel's responsi-
bility to read and understand ALL safety instructions, safety decals, and man-
uals and follow them when assembling, operating, or maintaining the
equipment. All accidents can be avoided.
• Equipment owners must give instructions and review the information initially
and annually with all personnel before allowing them to operate this product.
Untrained users/operators expose themselves and bystanders to possible
serious injury or death.
• Use this equipment for its intended purposes only.
• Do not modify the equipment in any way without written permission from the
manufacturer. Unauthorized modification may impair the function and/or
safety, and could affect the life of the equipment. Any unauthorized modifica-
tion of the equipment voids the warranty.
• Do not allow any unauthorized person in the work area.
2.2. ASSEMBLY SAFETY
• Read and understand the assembly instructions to get to know the sub-
assemblies and hardware that make up the equipment before proceeding to
assemble the product.
• Do not take chances with safety. The components are large, heavy, and can
be hard to handle. Always use the proper tools, stands, jacks, and hoists for
the job.
• Always have two or more people assembling the equipment. Because of the
weight, do not attempt assembly alone.
2.3. OPERATION SAFETY
• Have another trained person nearby who can shut down the auger in case of
accident. Always work with a second trained person around augers.
• Do not operate with any of the safety guards removed.
• Keep body, hair, and clothing away from moving parts. Stay away from intake
during operation.
• Inspect lift cable before using auger. Replace if frayed or damaged. Make
sure it is seated properly in cable sheaves and cable clamps are secure.

WESTFIELD - GRAIN AUGERS 2. SAFETY
MKX130-84/94/114
30797 R5 19
• Operate auger on level ground free of debris. If ground is uneven, anchor the
auger to prevent tipping or upending.
• Augers are not insulated. Keep away from electrical lines. Electrocution can
occur without direct contact.
• Support the discharge end and/or anchor the intake end before operating to
prevent upending.
• Do not use auger as a hoist.
• Empty auger before raising or lowering.
• Lower auger at completion of operation or when not in use. Auger could drop
rapidly in case of cable break or hydraulic failure (where applicable).
• Keep the work area clean and tidy.
• Do not get on or beneath auger when raising or lowering intake hitch jack, or
when auger is supported by hitch jack.
• Do not operate auger with the service or cleanout doors open or unlatched.

2. SAFETY WESTFIELD - GRAIN AUGERS
MKX130-84/94/114
20 30797 R5
Figure 2.1
2.4. PTO SAFETY
• Never use a PTO driveline without a rotating shield in good working order.
• Ensure PTO driveline is securely attached at both ends before operating.
• Before starting tractor, turn power to PTO to the off position (where applica-
ble).
• Keep body, hair, and clothing away from rotating PTO driveline.
• Ensure the PTO driveline shields turn freely on the PTO driveline.
BIN
