WeTek Air User manual
v1.3 | 2016
user manual
TABLE OF CONTENTS
1. INTRODUCTION
1.1. Important safety information
1.2. Precautions
2. PRODUCT OVERVIEW
3. GET STARTED
3.1. Gift-box Contents
3.2. Installation Requirements
3.3. Connections
3.4. Remote Contol Unit
4. SPECIFICATIONS
5. CONNECTING
6. FURTHER ASSISTANCE
7. WARRANTY
INTRODUCTION
Before using your WeTek Air, please read carefully all the useful information pro-
vided in this manual. It will help you and will alert you to necessary safety precau-
tions preceding its first usage.
1. IMPORTANT INFORMATION FOR THE USERS
1.1 Important safety information
Read, follow and keep these instructions.
• Do not use this device near water.
• Clean only with a dry cloth.
• Do not block any of the ventilation openings.
• Install in accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves
or other apparatus (including amplifiers) that produce heat.
• Protect the power cord from being walked on or pinched particularly at the
plug, receptacles and the point where they exit from the device.
• Only use accessories included within this package or recommended by the
manufacturer.
• Unplug this device during lightning storms or when unused for long periods of
time.
WARNING: To reduce the risk of fire or electric shock, do not expose this device to
rain or moisture.
This symbol indicates “dangerous voltage” inside the product that
presents a risk of electric shock or personal injury.
This symbol indicates important instructions accompanying the
product.
1.2. Precautions
Please read these precautions before operating this unit.
a) Power cord protection
To avoid any malfunctions of the unit, and to protect against electric shock, fire or
personal injury, please observe the following:
• Hold the plug firmly when connecting or disconnecting the power cord.
• Keep the power cord away from heating appliances.
• Never put heavy objects hover the power cord.
• Do not attempt to repair the power cord in any way.
• Never make or change connections with the power switched on.
b) Placement
Avoid placing the unit in areas of:
• Direct sunlight or heating radiators.
• High temperature over or high humidity (over 90%).
• Dust as the internal parts may be seriously damaged.
c) Non-use periods
When the unit is not being used, turn it o. If it is unused for a long period of time,
the unit should be unplugged from the power source.
d) No fingers or other objects inside
• Touching internal parts of this unit is dangerous and may cause serious dam-
age to the unit.
• Do not attempt to disassemble the unit. Do not put any foreign object in this
unit.
e) Keep away from water
Keep the unit away from ower vases, tubs, sinks, etc. If liquids are spilled into the
unit, serious damage could occur.
2. PRODUCT OVERVIEW
Subscription-Free
Watch major broadcast networks, local news and sports.
Watch & Record
Never miss a show! Record any TV channel while watching a dierent one.
Movies & TV Shows
Access your favorite streaming apps.
Voice Search
Use voice search to easily find the content you’re looking for.
Chromecast built-in
Cast movies, shows and photos from your phone, tablet or computer to
the TV.
Gaming
Immerse yourself in arcade racing, 3D battles, and beautiful adventures
alone or online multiplayer.
Expandable
Watch content directly from your hard-drive, ash-drive or your camera’s
microSD card. You can also use them for extra storage.
3. GET STARTED
3.1. Gift-box Contents
Before you install your WeTek Air, check that all the accessories have been sup-
plied.
1. WeTek Air device
2. Remote Control Unit
3. Regional power supply units
4. HDMI cable
5. Quick start guide
3.2. Installation Requirements
Your WeTek Air can be installed correctly when accompanied by:
• TV, monitor or projector with HDMI port or alternatively with composite input
ports (standard A/V).
• Two AAA batteries for the Remote Control Unit
• Internet network connection
• Ethernet cable (optional)
• Optical cable (S / PDIF) (optional)
• Coaxial cable (optional)
• MicroSD card for external storage (optional)
CAUTION: Do not expose the batteries or the remote control with batteries in places too hot (direct
sunlight, fire, etc.).
NOTE: Key functions may vary according to operating system and running program.
3.3. Connections
1. Micro SD port (up to 128 Gb)
2. Power button
TurnonandoyourWeTekAirdirectlybypressingthisbutton.Alternativelyyou
candoitwiththeRCU.
Status Led:
O - The power cord is disconnected
Red - WeTek is in standby mode
Blue - WeTek is on and the boot image should appears on the screen
3. Coaxial signal
4. USB
5. Ethernet
6. Optical / S/PDIF
7. HDMI
8. Power
3.4. Power Adaptor
WeTek Air is available with a set of interchangeable plugs to accommodate standard
wall sockets in multiple countries. Before using the AC adapter, you need to install
the correct plug according to your country socket.
3.5. RCU
GENERAL FUNCTIONS
Channel
ON/OFF
Mute
Alphanumeric
Voice search
Home
Directional
Volume
Back space
Apps
OK
Shortcuts
Back
MEDIA FORMATS Video processing H264, H265 up to
4k@60Hz
Video codecs H.265, H.264 AVC, H.264
MVC, MPEG-4 ASP, VC-1,
AVS, MPEG-2, MPEG-1
Video containers MKV, WMV, MPG, MPEG,
DAT, AVI, MOV, ISO, MP4,
RM and JPG
Audio codecs MP3, AAC, WMA, RM,
FLAC, Ogg, Dolby Digital,
Dolby Digital Plus, DTS
SIZE AND WEIGHT Height 1,4 inches (35 mm)
Width 6,2 inches (157 mm)
Depth 4,6 inches (117 mm)
Weight 7,5 ounces (213 g)
MODULAR TUNER Europe Digital Terrestrial and
Cable Television
[DVB-T/T2/C]
World Satellite Television
[DVB-S2]
North America* Over-the-Air Television
[ATSC]
Cable Television
*Availablesoon
4. SPECIFICATIONS
HARDWARE Device Name WeTek Air
Processor (CPU) Quad Core ARM Processor
RAM 2 GB DDR4
Storage 16 GB eMMC
(extendable with USB hard
drive)
Resolution 4Kp60 UHD 10-bit HEVC /
HDR-10
Ports and Interfaces HDMI® 2.0a
802.11ac MIMO dual band
wireless (2.4/5 Ghz)
Ethernet (10/100 Mbit/s)
Bluetooth 4.1
2x USB 2.0
MicroSD
IR receiver
Power (12V – 1.5A power
adapter)
Other Zigbee radio
SOFTWARE Operating System Android 8.0 OreoTM
POWER
CONSUMPTION
When in standby <2.2W (typical)
when streaming <5.0W (typical)
5. CONNECTING
Before you connect your WeTek Air to your TV/monitor or projector please ensure
that it is placed on a at and stable surface.
Now that your WeTek is in position, please refer to the below diagram.
1. Connect WeTek Air to a TV using the HDMI digital output.
2. Connect the Ethernet cable to the router and device, or use a wireless access.
3. If you have an external sound system, connect the optical output.
4. Connect the power supply to your WeTek.
5. Connect the remote inserting two AAA batteries (not included).
6. Connect the device using the power button and wait for the boot animation.
Follow the Wizard to configure your WeTek.
6. FURTHER ASSISTANCE
This manual does not end here. To help you further improve your user experience,
you can access additional information, tutorials, quick guides assistance, screens,
forums and more, visiting support.wetek.com.
If you find any problem, please give us the opportunity to address it before
returning this product. Most technical support questions can be answered through
our knowledge base or online support service.
Note:SomesupportoperationsmayrequirethatyouhaveaccesstoaPCwithWindows7orhigher,
anavailableserialport(oraserial-USBconverter),aswellasaTelnet/SSHclientsoftwarelikePutty.
7. WARRANTY
In order to find all Warranty & Return Terms regarding WeTek Air please access
consumers.wetek.com/terms-and-conditions .
NOTE: The warranty will be voided if installed any non-ocial ROM or recovery. To
proceed with any return/refund process, the WeTek Air needs to have the original
software installed.
Android and Android TV are trademarks of Google LLC. All product names, logos, and brands are property of their respec-
tive owners. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are registered trade-
marks of Dolby Laboratories.
wetek.com
V1901
