LX and LX-E SERIES PROVIDE EXCELLENT SOUND
PROJECTION, VOCAL PERFORMANCE AND BALANCED
MUSICAL REPRODUCTION
In the LX Series, the powerful LX-15B, LX-18B, LX-18MB and LX-218B sub bass
systems have been designed for use with large-scale LX-12, LX-15 and LX-215
systems to extend LF output power.
In demanding professional applications, the LX-15B and LX-18B, which feature an
internal two-way network, allow a four box system to be powered by one
amplifier. Tough industrial carpet covering provides durability and protection, and
contributes to the overall safety in the set-up and use of the LX systems.
The LX-E Series has the same model line up as the LX Series. The LX-E is finished in
a hardwearing, two-stage epoxy black paint finish and is constructed from premium
grade plywood for extra strength. Among the whole series, the LX-12E and LX-15E
have multiple mounting points for maximum flexibility when installing.
In comparison to the LX Series, the LX-E also has the same power ratings.
FEATURES
• High Performance, arrayable trapezoidal cabinets
• 50 mm Titanium diaphragm true compression driver for brilliant, natural HF
reproduction
• Large Elliptical Wave Guide Horn provides superior control over HF
coverage with reduced distortion, greater output and smoother frequency
response
• Cast frame, large voice coil woofers for sustained output capability and
minimal power compression under extended high power use.
• Heavily braced enclosure
• Dynamic, full range frequency response
• ProTech™ driver protection system
• Recessed metal jack plates with series Speakon™ type and 1/4" inputs
• Cast aluminum, 35mm pole adaptor for stand mounting
The information in this manual is subject to change without notice.
All rights to the mentioned trademarks reside with their respective companies.
All rights reserved © 2004Wharfedale Pro
Wharfedale Pro is a member of International Audio Group
www.wharfedalepro.com
Created from the ground up into the
demanding, high performance world of
professional audio,Wharfedale
Professional enjoys global success with
a range of great value, great sounding,
and innovative products.The
Wharfedale Professional philosophy is
simple:Value, Integrity and Performance
– VIP.
Since 1932,Wharfedale has been at the
forefront of loudspeaker technology –
these seventy years of experience in
the design and manufacture of audio
systems make Wharfedale Pro products
second to none.
We put in a lifetime of experience –
you get out a lifetime of performance.
EXTENSIVE LX & LX-E SERIES COVER THE HIGH-
PERFORMANCE SPECTRUM
The new LX and LX-E Series of loudspeakers each consist of nine models in total,
comprising five full ranges (with FOH and monitor systems in both 12 inch and 15
inch versions), and four sub bass cabinets (in both 15 inch and 18 inch versions).
Boasting distinctive style and features, these high powered, high performance
arrayable trapezoidal enclosures are capable of extremely high sound pressure
levels and exceptional sonic quality with wide dynamic range and bandwidth.
Both series have been developed with exceptional features including the large
elliptical Wave Guide horn, the use of cast-fame, large voice coil woofers for
sustained output capability and minimal power compression under extended
high-power use, and the ProTech™ protection system designed to protect the
HF unit, just to name a few.
In creating the LX Series, we set some basic parameters to design a range that
delivers without exception the performance, features and quality that our
customers demand. We also kept it simple; the LX-E range has a ‘systems’
approach, a range of models that can be used together to provide solutions for
nearly every audio challenge.
NEW LOOK, DISTINCTIVE FEATURES, HIGH STANDARD,
GREAT POWER AND MORE CHOICES.
Elliptical Wave Guide Horn (1.4” Exit)
In comparison to a conventional rectangular horn, the elliptical
Wave Guide offers superior control over HF coverage,
with reduced distortion, greater output and smoother
frequency response. The elliptical shape means that
there are no corners or parallel surfaces to distort,
diffract or reflect the sound – therefore the output is
smoother, cleaner and more consistent. Again, due to
the elliptical shape, mid to high frequencies are
diffused more efficiently.
Titanium 50mm Diaphragm, 1.4” Exit Compression Driver
The elliptical Wave Guide horn is coupled with a
50mm (2”) true compression driver designed
specially for the LX and LX-E Series. This titanium
diaphragm driver features a 1200g-magnet with a
3 5 m m ( 1 . 4 ” ) e x i t f o r b r i l l i a n t , n a t u r a l H F
reproduction.
Large
elliptical wave guide horn
provides superior control
over HF coverage
Large magnet structure
and tight construction
tolerances give accuracy,
high efficiency and
reliability
With enclosures built from a
combination of particle and MDF
in a black carpet finish, the LX is
ideal for use in live sound
applications.
With enclosures built from
plywood in a black paint finish,the
LX-E has extra features to make it
more suitable for the installation
market.
The LX and LX-E Series of
loudspeakers each consist of nine
models in total, comprising five full
ranges multipurpose systems (with
FOH and monitor systems in both 12
inch and 15 inch versions), and four sub
bass cabinets (in both 15 inch and 18
inch versions).
MULTIPURPOSE LOUDSPEAKER SYSTEM MULTIPURPOSE LOUDSPEAKER SYSTEM
SUBWOOFER RANGE
LX-12, LX-12E
Two-way. 12" high power woofer, elliptical wave guide horn with 2" (50mm) titanium diaphragm driver,
Trapezoidal enclosure, 12 X M10 rigging points for mounting (LX-12E only),
Continuous 400W/Music 800W power handling.
LX-12M, LX-12ME
Two-way monitor. 12" high power woofer, elliptical wave guide horn with 2" (50mm) titanium
diaphragm driver,
Continuous 350W/Music 700W power handling.
LX-15, LX-15E
Two-way, 15" high power woofer, elliptical wave guide horn with 2" (50mm) titanium diaphragm driver,
Trapezoidal enclosure, 12 X M10 rigging points for mounting (LX-15E only),
Continuous 400W/Music 800W power handling.
LX-15M, LX-15ME
Two-way monitor, 15" high power woofer, elliptical wave guide horn
with 2" (50mm) titanium diaphragm driver,
Continuous 350W/Music 700W power handling.
LX-215, LX-215E
Quasi 3-way, 15" high power woofer, elliptical wave guide horn with 2" (50mm)
titanium diaphragm driver, Trapezoidal enclosure,Two castors built in,
Continuous 700W/Music 1400W power handling.
LX-15B, LX-15BE
Super subwoofer, 15" driver, Two Speakon™ type connector, Crossover
with high pass output for mid/high (LX-15B only), Trapezoidal enclosure,
Pole mount adaptor,
Continuous 700W/Music 1400W power handling.
LX-18B, LX-18BE
Super subwoofer, 18" driver, Two Speakon™ type connector, Crossover with high pass output for
mid/high (LX-18B only), Trapezoidal enclosure, Pole mount adaptor,
Continuous 800W/Music 1600W power handling.
LX-218B, LX-218BE
Super subwoofer, 2 x18" (460mm) drivers with 4" (100mm) high temperature voice coils for
larger system set-ups, Two Speakon™ type connector, Rectangular enclosure,The birch ply
cabinet is fitted with substantial handles and 4x4" (100mm) castors (LX-218BE only),
Continuous 1600W/Music 3200W power handling.
LX-18MB, LX-18MBE
18" (460mm) modular two way modular cluster element super subwoofer, Two Speakon™ type
connector, Compact frontal dimensions, Co-axial por ts, Pole mount adaptor, Use in blocks of
four to provide astounding sub bass output levels
Continuous 800W/Music 1600W power handling
ProTech™ Driver Overload Protection System
Understanding that sound systems are often asked to perform beyond their original design
parameters, we have designed a smooth, progressive dynamic limiter/protection system that
is carefully tailored to each model. Overloads are limited and drivers are protected against
long term transient or peak conditions. The ProTech™ system progressively converts excess
power to heat and triggers a reduction in power to the HF driver. When the overload
condition is removed the system returns seamlessly to normal operation.
Sophisticated Crossovers Design
Each crossover in the LX and LX-E Series is built using the highest quality components
and designed specifically for that system, enabling smooth power and frequency
response control through the crossover region. The LX-15B and LX-18B feature integral
two-way networks that allow a four-box system to be powered by one amplifier.
Trapezoidal, Plywood and Composite Construction
The LX-E’s cabinet is constructed from plywood on all critical surfaces (where durability
is important) and wood composite where resonances need to be kept to a minimum.
The trapezoidal shape fur ther improves sonic accuracy by significantly reducing internal
flutter echoes and standing wave resonances that are often apparent in rectangular
shape cabinets.
Mounting points:
For maximum flexibility when installing, we have designed two specific models which
feature 12 x M10 rigging points allowing the cabinets to be flown or arrayed. The
LX-12E and LX-15E are fitted with these flying inserts.
Protective Finish
The LX is all finished using a tough, black industrial carpet offering exceptional
protection and durability for life on the road. The LX-E is coated with Duraguard™, an
abrasion resistant paint that creates a protective ‘skin’ around the cabinet. Both finishes
contribute to the overall safety in the set up and use.
Strong Grille, Square Handles and Castors
In order to provide maximum protection to the internal components of the
loudspeakers, the front grilles are full steel and 1.5mm thick. The square handles allow
the cabinets to be gripped securely and comfor tably, therefore making them easy to
move. Built-in castors are available on some larger units for ease of transpor tation.
Value, Integrity and Performance
BOTTOM VIEW LEFT SIDE VIEW FRONTVIEW RIGHT SIDE VIEW BOTTOM VIEWTOPVIEW
449.77
618.00
618.00
102.85 102.85
426.00
539.70
318.17
449.77
TOP VIEW FRONT VIEWLEFT SIDE VIEW RIGHT SIDE VIEWBOTTOM VIEW
493.00 493.00
592.08
592.08
685.50
685.50
685.50
500.00
113.41 113.41
BOTTOM VIEW FRONT VIEW
TOP VIEW
SIDE VIEW REAR VIEW
355.87
461.35
506.00
1138.00
TOPVIEW SIDE VIEW FRONTVIEW SIDE VIEWBOTTOM VIEW
650.00
545.00
545.00
REAR VIEWTOPVIEW SIDE VIEWFRONTVIEWSIDE VIEWBOTTOM VIEW
650.00 1041.00 650.00
541.00
541.00
TOP VIEW FRONT VIEWBOTTOM VIEW SIDE VIEW REARVIEW
(LX-15BE)
275.16
559.00
559.00
615.00
470.00
REAR VIEW
(LX-15B)
FRONTVIEWTOPVIEW BOTTOM VIEW SIDE VIEW REAR VIEW
(LX-18BE)
336.00
570.00
652.00
715.00
REAR VIEW
(LX-18B)
WP.LX.01.2005
Heavy duty
protective
steel grille
Built-in castors
for larger
enclosures
Secure square handles
Wharfedale International Limited
IAG House, Sovereign Court, Ermine Business Park,
Hungtingdon Cambs, PE29 6XU, England
IAG America Inc.
15 Walpole Park South, Walpole MA02081, USA
APPLICATIONS 2-way 2-way monitor 2-way 2-way monitor Quasi 3-way subwoofer  subwoofer subwoofer subwoofer
 50-20kHz 60-20kHz 40-20kHz 55-20kHz 40-20kHz 42-170Hz 38-150Hz 38-1.5kHz 30-1.5kHz
      (LX-15B) (LX-18B)
      42-2kHz 38-1.5kHz
      (LX-15BE) (LX-18BE)
SENSITIVITY 1w
@
1m (dB) 97 97 98 98 101 98 99 99 100
COVERAGE Horiz. 90 90 90 90
COVERAGE vert.  45˚ 45˚ 45˚ 45˚
POWER HANDLING (watts)
continuous 400 350 400 350 700 700 800 800 1600
music 800 700 800 700 1400 1400 1600 1600 3200
peak 1600 1400 1600 1400 2800 2800 3200 3200 6400
MAX SPL (dB) 129 128 130 129 135 132 134 134 138
SYSTEM IMPEDANCE 4 or 8 8 4 or 8 8 4 4 or 8 4 or 8 4 or 8 4
LF DRIVER
driver size 12" 12" 15" 15" 15" 15" 18" 18" 18"
H F SECTION
impedance (W) 8 8 8 8 8
coil size (mm/ins) 50 / 2" 50 / 2" 50 / 2" 50 / 2" 50 / 2"
exit size (mm/ins) 35 / 1.4" 35 / 1.4" 35 / 1.4" 35 / 1.4" 35 / 1.4"
diaphragm matl Titanium Titanium Titanium Titanium Titanium
protect type bulb bulb bulb bulb bulb
HF HORN
type Elliptical Elliptical Elliptical Elliptical Elliptical
CROSSOVER SECTION
crossover Frequency 1.8k 1.8k 1.8k 1.8k 1.8k 170Hz (LX-15B only) 150Hz (LX-18B only)
system Fb 50Hz 60Hz 40Hz 55Hz 40Hz 42Hz 38Hz 38Hz 30Hz
hi pass out      120Hz (LX-15B only) 120Hz (LX-18B only) 
ENCLOSURE TYPE
finish colour (LX) carpet black carpet black carpet black carpet black carpet black carpet black carpet black carpet black carpet black
finish colour (LX-E) paint black paint black paint black paint black paint black paint black paint black paint black paint black
construction materials (LX) MDF/particle MDF/particle MDF/par ticle MDF/particle MDF/particle MDF/par ticle MDF/particle MDF/particle MDF/particle
construction materials (LX-E) 15mm plywood 15mm plywood 15mm plywood 15mm plywood 18mm plywood 18mm plywood 18mm plywood 18mm plywood 18mm plywood
RIGGING HARDWARE
12 x M10 flying inserts
 no
12 x M10 flying inserts
 no no no no no no

(LX-12E only)
 
(LX-15E only)
STAND ADAPTOR yes no yes no no yes yes yes yes
HANDLE
type square square square square square square square square square
quantity 2 2 2 2 3 2 4 2 4
GRILLE
thikness (mm) 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
type full steel full steel full steel full steel full steel full steel full steel full steel full steel
INPUT CONNECTOR
speakon™ NL4 type 2 2 2 2 2 2 2 2 2
paralle with input connector yes yes yes yes yes yes yes yes yes
hi pass out connector : no no no no no LX-15B only LX-18B only no no
CASTOR no no no no 2 no no no 4 (LX-218E only)
PRODUCT DIMS. (mm)
H 630 618 700 685.5 1138 615 715 545 541
W (front / rear) 396 / 269 426 / 426 470 / 319 500 / 500 506 / 356 470 / 275 570 / 336 545 / 545 1041 / 1041
D 396 450 450 493 461 559 652 650 650
WEIGHT (KG)
net (LX / LX-E) 26.5 / 27.8 21.5 / 22.5 33.5 / 34.6 28.4 / 29.5 59.0 / 60.6 33.5 / 35.6 45.5 / 47.9 39.0 / 40.4 67.5 / 70.8
gross (LX / LX-E) 28.1 / 30.4 23.1 / 25.1 35.7 / 38.3 30.6 / 32.9 63.2 / 66.8 36.3 / 40.1 48.7 / 52.9 42.2 / 44.6 74.4 / 78.9
LX & LX-E Series Technical Specifications
FREQUENCY RESPONSE
@ +/- 3 dB
 LX-12 / LX-12M / LX15 / LX15M / LX-215 / LX-15B / LX-18B / LX-18MB / LX218B /
 LX-12E LX-12ME LX15E LX15ME LX215E LX15BE LX-18BE LX18MBE LX218BE
MODEL
Secure
rigging points
(LX-12E & LX-15E only)
BOTTOM VIEW FRONT VIEW SIDE VIEW REAR VIEWTOP VIEW
268.60
396.00
630.00
396.00
396.00
* No rigging for LX-12
TOPVIEW FRONTVIEW SIDE VIEW REAR VIEWBOTTOM VIEW
319.37
450.00
470.00
700.00
* No rigging for LX-15 *No castors for LX-218B
Trapezoidal designs allow
more compact arrays and
sonic accuracy
Enclosures of the LX-E
constructed from premium
grade plywood for durability
Highly protective
Duraguard™
coating
(LX-E Series only)
Durable black
carpet covering
(LX Series only)
Page 6-7:
Page 4-5:
Page 2 & Page 3Cover & Back
LX and LX-E SERIES PROVIDE EXCELLENT SOUND
PROJECTION, VOCAL PERFORMANCE AND BALANCED
MUSICAL REPRODUCTION
In the LX Series, the powerful LX-15B, LX-18B, LX-18MB and LX-218B sub bass
systems have been designed for use with large-scale LX-12, LX-15 and LX-215
systems to extend LF output power.
In demanding professional applications, the LX-15B and LX-18B, which feature an
internal two-way network, allow a four box system to be powered by one
amplifier. Tough industrial carpet covering provides durability and protection, and
contributes to the overall safety in the set-up and use of the LX systems.
The LX-E Series has the same model line up as the LX Series. The LX-E is finished in
a hardwearing, two-stage epoxy black paint finish and is constructed from premium
grade plywood for extra strength. Among the whole series, the LX-12E and LX-15E
have multiple mounting points for maximum flexibility when installing.
In comparison to the LX Series, the LX-E also has the same power ratings.
FEATURES
• High Performance, arrayable trapezoidal cabinets
• 50 mm Titanium diaphragm true compression driver for brilliant, natural HF
reproduction
• Large Elliptical Wave Guide Horn provides superior control over HF
coverage with reduced distortion, greater output and smoother frequency
response
• Cast frame, large voice coil woofers for sustained output capability and
minimal power compression under extended high power use.
• Heavily braced enclosure
• Dynamic, full range frequency response
• ProTech™ driver protection system
• Recessed metal jack plates with series Speakon™ type and 1/4" inputs
• Cast aluminum, 35mm pole adaptor for stand mounting
The information in this manual is subject to change without notice.
All rights to the mentioned trademarks reside with their respective companies.
All rights reserved © 2004Wharfedale Pro
Wharfedale Pro is a member of International Audio Group
www.wharfedalepro.com
Created from the ground up into the
demanding, high performance world of
professional audio,Wharfedale
Professional enjoys global success with
a range of great value, great sounding,
and innovative products.The
Wharfedale Professional philosophy is
simple:Value, Integrity and Performance
– VIP.
Since 1932,Wharfedale has been at the
forefront of loudspeaker technology –
these seventy years of experience in
the design and manufacture of audio
systems make Wharfedale Pro products
second to none.
We put in a lifetime of experience –
you get out a lifetime of performance.
EXTENSIVE LX & LX-E SERIES COVER THE HIGH-
PERFORMANCE SPECTRUM
The new LX and LX-E Series of loudspeakers each consist of nine models in total,
comprising five full ranges (with FOH and monitor systems in both 12 inch and 15
inch versions), and four sub bass cabinets (in both 15 inch and 18 inch versions).
Boasting distinctive style and features, these high powered, high performance
arrayable trapezoidal enclosures are capable of extremely high sound pressure
levels and exceptional sonic quality with wide dynamic range and bandwidth.
Both series have been developed with exceptional features including the large
elliptical Wave Guide horn, the use of cast-fame, large voice coil woofers for
sustained output capability and minimal power compression under extended
high-power use, and the ProTech™ protection system designed to protect the
HF unit, just to name a few.
In creating the LX Series, we set some basic parameters to design a range that
delivers without exception the performance, features and quality that our
customers demand. We also kept it simple; the LX-E range has a ‘systems’
approach, a range of models that can be used together to provide solutions for
nearly every audio challenge.
NEW LOOK, DISTINCTIVE FEATURES, HIGH STANDARD,
GREAT POWER AND MORE CHOICES.
Elliptical Wave Guide Horn (1.4” Exit)
In comparison to a conventional rectangular horn, the elliptical
Wave Guide offers superior control over HF coverage,
with reduced distortion, greater output and smoother
frequency response. The elliptical shape means that
there are no corners or parallel surfaces to distort,
diffract or reflect the sound – therefore the output is
smoother, cleaner and more consistent. Again, due to
the elliptical shape, mid to high frequencies are
diffused more efficiently.
Titanium 50mm Diaphragm, 1.4” Exit Compression Driver
The elliptical Wave Guide horn is coupled with a
50mm (2”) true compression driver designed
specially for the LX and LX-E Series. This titanium
diaphragm driver features a 1200g-magnet with a
3 5 m m ( 1 . 4 ” ) e x i t f o r b r i l l i a n t , n a t u r a l H F
reproduction.
Large
elliptical wave guide horn
provides superior control
over HF coverage
Large magnet structure
and tight construction
tolerances give accuracy,
high efficiency and
reliability
With enclosures built from a
combination of particle and MDF
in a black carpet finish, the LX is
ideal for use in live sound
applications.
With enclosures built from
plywood in a black paint finish,the
LX-E has extra features to make it
more suitable for the installation
market.
The LX and LX-E Series of
loudspeakers each consist of nine
models in total, comprising five full
ranges multipurpose systems (with
FOH and monitor systems in both 12
inch and 15 inch versions), and four sub
bass cabinets (in both 15 inch and 18
inch versions).
MULTIPURPOSE LOUDSPEAKER SYSTEM MULTIPURPOSE LOUDSPEAKER SYSTEM
SUBWOOFER RANGE
LX-12, LX-12E
Two-way. 12" high power woofer, elliptical wave guide horn with 2" (50mm) titanium diaphragm driver,
Trapezoidal enclosure, 12 X M10 rigging points for mounting (LX-12E only),
Continuous 400W/Music 800W power handling.
LX-12M, LX-12ME
Two-way monitor. 12" high power woofer, elliptical wave guide horn with 2" (50mm) titanium
diaphragm driver,
Continuous 350W/Music 700W power handling.
LX-15, LX-15E
Two-way, 15" high power woofer, elliptical wave guide horn with 2" (50mm) titanium diaphragm driver,
Trapezoidal enclosure, 12 X M10 rigging points for mounting (LX-15E only),
Continuous 400W/Music 800W power handling.
LX-15M, LX-15ME
Two-way monitor, 15" high power woofer, elliptical wave guide horn
with 2" (50mm) titanium diaphragm driver,
Continuous 350W/Music 700W power handling.
LX-215, LX-215E
Quasi 3-way, 15" high power woofer, elliptical wave guide horn with 2" (50mm)
titanium diaphragm driver, Trapezoidal enclosure,Two castors built in,
Continuous 700W/Music 1400W power handling.
LX-15B, LX-15BE
Super subwoofer, 15" driver, Two Speakon™ type connector, Crossover
with high pass output for mid/high (LX-15B only), Trapezoidal enclosure,
Pole mount adaptor,
Continuous 700W/Music 1400W power handling.
LX-18B, LX-18BE
Super subwoofer, 18" driver, Two Speakon™ type connector, Crossover with high pass output for
mid/high (LX-18B only), Trapezoidal enclosure, Pole mount adaptor,
Continuous 800W/Music 1600W power handling.
LX-218B, LX-218BE
Super subwoofer, 2 x18" (460mm) drivers with 4" (100mm) high temperature voice coils for
larger system set-ups, Two Speakon™ type connector, Rectangular enclosure,The birch ply
cabinet is fitted with substantial handles and 4x4" (100mm) castors (LX-218BE only),
Continuous 1600W/Music 3200W power handling.
LX-18MB, LX-18MBE
18" (460mm) modular two way modular cluster element super subwoofer, Two Speakon™ type
connector, Compact frontal dimensions, Co-axial por ts, Pole mount adaptor, Use in blocks of
four to provide astounding sub bass output levels
Continuous 800W/Music 1600W power handling
ProTech™ Driver Overload Protection System
Understanding that sound systems are often asked to perform beyond their original design
parameters, we have designed a smooth, progressive dynamic limiter/protection system that
is carefully tailored to each model. Overloads are limited and drivers are protected against
long term transient or peak conditions. The ProTech™ system progressively converts excess
power to heat and triggers a reduction in power to the HF driver. When the overload
condition is removed the system returns seamlessly to normal operation.
Sophisticated Crossovers Design
Each crossover in the LX and LX-E Series is built using the highest quality components
and designed specifically for that system, enabling smooth power and frequency
response control through the crossover region. The LX-15B and LX-18B feature integral
two-way networks that allow a four-box system to be powered by one amplifier.
Trapezoidal, Plywood and Composite Construction
The LX-E’s cabinet is constructed from plywood on all critical surfaces (where durability
is important) and wood composite where resonances need to be kept to a minimum.
The trapezoidal shape fur ther improves sonic accuracy by significantly reducing internal
flutter echoes and standing wave resonances that are often apparent in rectangular
shape cabinets.
Mounting points:
For maximum flexibility when installing, we have designed two specific models which
feature 12 x M10 rigging points allowing the cabinets to be flown or arrayed. The
LX-12E and LX-15E are fitted with these flying inserts.
Protective Finish
The LX is all finished using a tough, black industrial carpet offering exceptional
protection and durability for life on the road. The LX-E is coated with Duraguard™, an
abrasion resistant paint that creates a protective ‘skin’ around the cabinet. Both finishes
contribute to the overall safety in the set up and use.
Strong Grille, Square Handles and Castors
In order to provide maximum protection to the internal components of the
loudspeakers, the front grilles are full steel and 1.5mm thick. The square handles allow
the cabinets to be gripped securely and comfor tably, therefore making them easy to
move. Built-in castors are available on some larger units for ease of transpor tation.
Value, Integrity and Performance
BOTTOM VIEW LEFT SIDE VIEW FRONTVIEW RIGHT SIDE VIEW BOTTOM VIEWTOPVIEW
449.77
618.00
618.00
102.85 102.85
426.00
539.70
318.17
449.77
TOP VIEW FRONT VIEWLEFT SIDE VIEW RIGHT SIDE VIEWBOTTOM VIEW
493.00 493.00
592.08
592.08
685.50
685.50
685.50
500.00
113.41 113.41
BOTTOM VIEW FRONT VIEW
TOP VIEW
SIDE VIEW REAR VIEW
355.87
461.35
506.00
1138.00
TOPVIEW SIDE VIEW FRONTVIEW SIDE VIEWBOTTOM VIEW
650.00
545.00
545.00
REAR VIEWTOPVIEW SIDE VIEWFRONTVIEWSIDE VIEWBOTTOM VIEW
650.00 1041.00 650.00
541.00
541.00
TOP VIEW FRONT VIEWBOTTOM VIEW SIDE VIEW REARVIEW
(LX-15BE)
275.16
559.00
559.00
615.00
470.00
REAR VIEW
(LX-15B)
FRONTVIEWTOPVIEW BOTTOMVIEW SIDE VIEW REAR VIEW
(LX-18BE)
336.00
570.00
652.00
715.00
REAR VIEW
(LX-18B)
WP.LX.01.2005
Heavy duty
protective
steel grille
Built-in castors
for larger
enclosures
Secure square handles
Wharfedale International Limited
IAG House, Sovereign Court, Ermine Business Park,
Hungtingdon Cambs, PE29 6XU, England
IAG America Inc.
15 Walpole Park South, Walpole MA02081, USA
APPLICATIONS 2-way 2-way monitor 2-way 2-way monitor Quasi 3-way subwoofer  subwoofer subwoofer subwoofer
 50-20kHz 60-20kHz 40-20kHz 55-20kHz 40-20kHz 42-170Hz 38-150Hz 38-1.5kHz 30-1.5kHz
      (LX-15B) (LX-18B)
      42-2kHz 38-1.5kHz
      (LX-15BE) (LX-18BE)
SENSITIVITY 1w
@
1m (dB) 97 97 98 98 101 98 99 99 100
COVERAGE Horiz. 90 90 90 90
COVERAGE vert.  45˚ 45˚ 45˚ 45˚
POWER HANDLING (watts)
continuous 400 350 400 350 700 700 800 800 1600
music 800 700 800 700 1400 1400 1600 1600 3200
peak 1600 1400 1600 1400 2800 2800 3200 3200 6400
MAX SPL (dB) 129 128 130 129 135 132 134 134 138
SYSTEM IMPEDANCE 4 or 8 8 4 or 8 8 4 4 or 8 4 or 8 4 or 8 4
LF DRIVER
driver size 12" 12" 15" 15" 15" 15" 18" 18" 18"
H F SECTION
impedance (W) 8 8 8 8 8
coil size (mm/ins) 50 / 2" 50 / 2" 50 / 2" 50 / 2" 50 / 2"
exit size (mm/ins) 35 / 1.4" 35 / 1.4" 35 / 1.4" 35 / 1.4" 35 / 1.4"
diaphragm matl Titanium Titanium Titanium Titanium Titanium
protect type bulb bulb bulb bulb bulb
HF HORN
type Elliptical Elliptical Elliptical Elliptical Elliptical
CROSSOVER SECTION
crossover Frequency 1.8k 1.8k 1.8k 1.8k 1.8k 170Hz (LX-15B only) 150Hz (LX-18B only)
system Fb 50Hz 60Hz 40Hz 55Hz 40Hz 42Hz 38Hz 38Hz 30Hz
hi pass out      120Hz (LX-15B only) 120Hz (LX-18B only) 
ENCLOSURE TYPE
finish colour (LX) carpet black carpet black carpet black carpet black carpet black carpet black carpet black carpet black carpet black
finish colour (LX-E) paint black paint black paint black paint black paint black paint black paint black paint black paint black
construction materials (LX) MDF/par ticle MDF/par ticle MDF/particle MDF/par ticle MDF/particle MDF/par ticle MDF/particle MDF/particle MDF/particle
construction materials (LX-E) 15mm plywood 15mm plywood 15mm plywood 15mm plywood 18mm plywood 18mm plywood 18mm plywood 18mm plywood 18mm plywood
RIGGING HARDWARE
12 x M10 flying inserts
 no
12 x M10 flying inserts
 no no no no no no

(LX-12E only)
 
(LX-15E only)
STAND ADAPTOR yes no yes no no yes yes yes yes
HANDLE
type square square square square square square square square square
quantity 2 2 2 2 3 2 4 2 4
GRILLE
thikness (mm) 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
type full steel full steel full steel full steel full steel full steel full steel full steel full steel
INPUT CONNECTOR
speakon™ NL4 type 2 2 2 2 2 2 2 2 2
paralle with input connector yes yes yes yes yes yes yes yes yes
hi pass out connector : no no no no no LX-15B only LX-18B only no no
CASTOR no no no no 2 no no no 4 (LX-218E only)
PRODUCT DIMS. (mm)
H 630 618 700 685.5 1138 615 715 545 541
W (front / rear) 396 / 269 426 / 426 470 / 319 500 / 500 506 / 356 470 / 275 570 / 336 545 / 545 1041 / 1041
D 396 450 450 493 461 559 652 650 650
WEIGHT (KG)
net (LX / LX-E) 26.5 / 27.8 21.5 / 22.5 33.5 / 34.6 28.4 / 29.5 59.0 / 60.6 33.5 / 35.6 45.5 / 47.9 39.0 / 40.4 67.5 / 70.8
gross (LX / LX-E) 28.1 / 30.4 23.1 / 25.1 35.7 / 38.3 30.6 / 32.9 63.2 / 66.8 36.3 / 40.1 48.7 / 52.9 42.2 / 44.6 74.4 / 78.9
LX & LX-E Series Technical Specifications
FREQUENCY RESPONSE
@ +/- 3 dB
 LX-12 / LX-12M / LX15 / LX15M / LX-215 / LX-15B / LX-18B / LX-18MB / LX218B /
 LX-12E LX-12ME LX15E LX15ME LX215E LX15BE LX-18BE LX18MBE LX218BE
MODEL
Secure
rigging points
(LX-12E & LX-15E only)
BOTTOM VIEW FRONT VIEW SIDE VIEW REAR VIEWTOP VIEW
268.60
396.00
630.00
396.00
396.00
* No rigging for LX-12
TOPVIEW FRONTVIEW SIDE VIEW REAR VIEWBOTTOM VIEW
319.37
450.00
470.00
700.00
* No rigging for LX-15 *No castors for LX-218B
Trapezoidal designs allow
more compact arrays and
sonic accuracy
Enclosures of the LX-E
constructed from premium
grade plywood for durability
Highly protective
Duraguard™
coating
(LX-E Series only)
Durable black
carpet covering
(LX Series only)
Page 6-7:
Page 4-5:
Page 2 & Page 3Cover & Back
LX and LX-E SERIES PROVIDE EXCELLENT SOUND
PROJECTION, VOCAL PERFORMANCE AND BALANCED
MUSICAL REPRODUCTION
In the LX Series, the powerful LX-15B, LX-18B, LX-18MB and LX-218B sub bass
systems have been designed for use with large-scale LX-12, LX-15 and LX-215
systems to extend LF output power.
In demanding professional applications, the LX-15B and LX-18B, which feature an
internal two-way network, allow a four box system to be powered by one
amplifier. Tough industrial carpet covering provides durability and protection, and
contributes to the overall safety in the set-up and use of the LX systems.
The LX-E Series has the same model line up as the LX Series. The LX-E is finished in
a hardwearing, two-stage epoxy black paint finish and is constructed from premium
grade plywood for extra strength. Among the whole series, the LX-12E and LX-15E
have multiple mounting points for maximum flexibility when installing.
In comparison to the LX Series, the LX-E also has the same power ratings.
FEATURES
• High Performance, arrayable trapezoidal cabinets
• 50 mm Titanium diaphragm true compression driver for brilliant, natural HF
reproduction
• Large Elliptical Wave Guide Horn provides superior control over HF
coverage with reduced distortion, greater output and smoother frequency
response
• Cast frame, large voice coil woofers for sustained output capability and
minimal power compression under extended high power use.
• Heavily braced enclosure
• Dynamic, full range frequency response
• ProTech™ driver protection system
• Recessed metal jack plates with series Speakon™ type and 1/4" inputs
• Cast aluminum, 35mm pole adaptor for stand mounting
The information in this manual is subject to change without notice.
All rights to the mentioned trademarks reside with their respective companies.
All rights reserved © 2004Wharfedale Pro
Wharfedale Pro is a member of International Audio Group
www.wharfedalepro.com
Created from the ground up into the
demanding, high performance world of
professional audio,Wharfedale
Professional enjoys global success with
a range of great value, great sounding,
and innovative products.The
Wharfedale Professional philosophy is
simple:Value, Integrity and Performance
– VIP.
Since 1932,Wharfedale has been at the
forefront of loudspeaker technology –
these seventy years of experience in
the design and manufacture of audio
systems make Wharfedale Pro products
second to none.
We put in a lifetime of experience –
you get out a lifetime of performance.
EXTENSIVE LX & LX-E SERIES COVER THE HIGH-
PERFORMANCE SPECTRUM
The new LX and LX-E Series of loudspeakers each consist of nine models in total,
comprising five full ranges (with FOH and monitor systems in both 12 inch and 15
inch versions), and four sub bass cabinets (in both 15 inch and 18 inch versions).
Boasting distinctive style and features, these high powered, high performance
arrayable trapezoidal enclosures are capable of extremely high sound pressure
levels and exceptional sonic quality with wide dynamic range and bandwidth.
Both series have been developed with exceptional features including the large
elliptical Wave Guide horn, the use of cast-fame, large voice coil woofers for
sustained output capability and minimal power compression under extended
high-power use, and the ProTech™ protection system designed to protect the
HF unit, just to name a few.
In creating the LX Series, we set some basic parameters to design a range that
delivers without exception the performance, features and quality that our
customers demand. We also kept it simple; the LX-E range has a ‘systems’
approach, a range of models that can be used together to provide solutions for
nearly every audio challenge.
NEW LOOK, DISTINCTIVE FEATURES, HIGH STANDARD,
GREAT POWER AND MORE CHOICES.
Elliptical Wave Guide Horn (1.4” Exit)
In comparison to a conventional rectangular horn, the elliptical
Wave Guide offers superior control over HF coverage,
with reduced distortion, greater output and smoother
frequency response. The elliptical shape means that
there are no corners or parallel surfaces to distort,
diffract or reflect the sound – therefore the output is
smoother, cleaner and more consistent. Again, due to
the elliptical shape, mid to high frequencies are
diffused more efficiently.
Titanium 50mm Diaphragm, 1.4” Exit Compression Driver
The elliptical Wave Guide horn is coupled with a
50mm (2”) true compression driver designed
specially for the LX and LX-E Series. This titanium
diaphragm driver features a 1200g-magnet with a
3 5 m m ( 1 . 4 ” ) e x i t f o r b r i l l i a n t , n a t u r a l H F
reproduction.
Large
elliptical wave guide horn
provides superior control
over HF coverage
Large magnet structure
and tight construction
tolerances give accuracy,
high efficiency and
reliability
With enclosures built from a
combination of particle and MDF
in a black carpet finish, the LX is
ideal for use in live sound
applications.
With enclosures built from
plywood in a black paint finish,the
LX-E has extra features to make it
more suitable for the installation
market.
The LX and LX-E Series of
loudspeakers each consist of nine
models in total, comprising five full
ranges multipurpose systems (with
FOH and monitor systems in both 12
inch and 15 inch versions), and four sub
bass cabinets (in both 15 inch and 18
inch versions).
MULTIPURPOSE LOUDSPEAKER SYSTEM MULTIPURPOSE LOUDSPEAKER SYSTEM
SUBWOOFER RANGE
LX-12, LX-12E
Two-way. 12" high power woofer, elliptical wave guide horn with 2" (50mm) titanium diaphragm driver,
Trapezoidal enclosure, 12 X M10 rigging points for mounting (LX-12E only),
Continuous 400W/Music 800W power handling.
LX-12M, LX-12ME
Two-way monitor. 12" high power woofer, elliptical wave guide horn with 2" (50mm) titanium
diaphragm driver,
Continuous 350W/Music 700W power handling.
LX-15, LX-15E
Two-way, 15" high power woofer, elliptical wave guide horn with 2" (50mm) titanium diaphragm driver,
Trapezoidal enclosure, 12 X M10 rigging points for mounting (LX-15E only),
Continuous 400W/Music 800W power handling.
LX-15M, LX-15ME
Two-way monitor, 15" high power woofer, elliptical wave guide horn
with 2" (50mm) titanium diaphragm driver,
Continuous 350W/Music 700W power handling.
LX-215, LX-215E
Quasi 3-way, 15" high power woofer, elliptical wave guide horn with 2" (50mm)
titanium diaphragm driver, Trapezoidal enclosure,Two castors built in,
Continuous 700W/Music 1400W power handling.
LX-15B, LX-15BE
Super subwoofer, 15" driver, Two Speakon™ type connector, Crossover
with high pass output for mid/high (LX-15B only), Trapezoidal enclosure,
Pole mount adaptor,
Continuous 700W/Music 1400W power handling.
LX-18B, LX-18BE
Super subwoofer, 18" driver, Two Speakon™ type connector, Crossover with high pass output for
mid/high (LX-18B only), Trapezoidal enclosure, Pole mount adaptor,
Continuous 800W/Music 1600W power handling.
LX-218B, LX-218BE
Super subwoofer, 2 x18" (460mm) drivers with 4" (100mm) high temperature voice coils for
larger system set-ups, Two Speakon™ type connector, Rectangular enclosure,The birch ply
cabinet is fitted with substantial handles and 4x4" (100mm) castors (LX-218BE only),
Continuous 1600W/Music 3200W power handling.
LX-18MB, LX-18MBE
18" (460mm) modular two way modular cluster element super subwoofer, Two Speakon™ type
connector, Compact frontal dimensions, Co-axial por ts, Pole mount adaptor, Use in blocks of
four to provide astounding sub bass output levels
Continuous 800W/Music 1600W power handling
ProTech™ Driver Overload Protection System
Understanding that sound systems are often asked to perform beyond their original design
parameters, we have designed a smooth, progressive dynamic limiter/protection system that
is carefully tailored to each model. Overloads are limited and drivers are protected against
long term transient or peak conditions. The ProTech™ system progressively converts excess
power to heat and triggers a reduction in power to the HF driver. When the overload
condition is removed the system returns seamlessly to normal operation.
Sophisticated Crossovers Design
Each crossover in the LX and LX-E Series is built using the highest quality components
and designed specifically for that system, enabling smooth power and frequency
response control through the crossover region. The LX-15B and LX-18B feature integral
two-way networks that allow a four-box system to be powered by one amplifier.
Trapezoidal, Plywood and Composite Construction
The LX-E’s cabinet is constructed from plywood on all critical surfaces (where durability
is important) and wood composite where resonances need to be kept to a minimum.
The trapezoidal shape fur ther improves sonic accuracy by significantly reducing internal
flutter echoes and standing wave resonances that are often apparent in rectangular
shape cabinets.
Mounting points:
For maximum flexibility when installing, we have designed two specific models which
feature 12 x M10 rigging points allowing the cabinets to be flown or arrayed. The
LX-12E and LX-15E are fitted with these flying inserts.
Protective Finish
The LX is all finished using a tough, black industrial carpet offering exceptional
protection and durability for life on the road. The LX-E is coated with Duraguard™, an
abrasion resistant paint that creates a protective ‘skin’ around the cabinet. Both finishes
contribute to the overall safety in the set up and use.
Strong Grille, Square Handles and Castors
In order to provide maximum protection to the internal components of the
loudspeakers, the front grilles are full steel and 1.5mm thick. The square handles allow
the cabinets to be gripped securely and comfor tably, therefore making them easy to
move. Built-in castors are available on some larger units for ease of transpor tation.
Value, Integrity and Performance
BOTTOM VIEW LEFT SIDE VIEW FRONTVIEW RIGHT SIDE VIEW BOTTOM VIEWTOPVIEW
449.77
618.00
618.00
102.85 102.85
426.00
539.70
318.17
449.77
TOP VIEW FRONT VIEWLEFT SIDE VIEW RIGHT SIDE VIEWBOTTOM VIEW
493.00 493.00
592.08
592.08
685.50
685.50
685.50
500.00
113.41 113.41
BOTTOM VIEW FRONT VIEW
TOP VIEW
SIDE VIEW REAR VIEW
355.87
461.35
506.00
1138.00
TOPVIEW SIDE VIEW FRONTVIEW SIDE VIEWBOTTOM VIEW
650.00
545.00
545.00
REAR VIEWTOPVIEW SIDE VIEWFRONTVIEWSIDE VIEWBOTTOM VIEW
650.00 1041.00 650.00
541.00
541.00
TOP VIEW FRONT VIEWBOTTOM VIEW SIDE VIEW REARVIEW
(LX-15BE)
275.16
559.00
559.00
615.00
470.00
REAR VIEW
(LX-15B)
FRONTVIEWTOPVIEW BOTTOMVIEW SIDE VIEW REAR VIEW
(LX-18BE)
336.00
570.00
652.00
715.00
REAR VIEW
(LX-18B)
WP.LX.01.2005
Heavy duty
protective
steel grille
Built-in castors
for larger
enclosures
Secure square handles
Wharfedale International Limited
IAG House, Sovereign Court, Ermine Business Park,
Hungtingdon Cambs, PE29 6XU, England
IAG America Inc.
15 Walpole Park South, Walpole MA02081, USA
APPLICATIONS 2-way 2-way monitor 2-way 2-way monitor Quasi 3-way subwoofer  subwoofer subwoofer subwoofer
 50-20kHz 60-20kHz 40-20kHz 55-20kHz 40-20kHz 42-170Hz 38-150Hz 38-1.5kHz 30-1.5kHz
      (LX-15B) (LX-18B)
      42-2kHz 38-1.5kHz
      (LX-15BE) (LX-18BE)
SENSITIVITY 1w
@
1m (dB) 97 97 98 98 101 98 99 99 100
COVERAGE Horiz. 90 90 90 90
COVERAGE vert.  45˚ 45˚ 45˚ 45˚
POWER HANDLING (watts)
continuous 400 350 400 350 700 700 800 800 1600
music 800 700 800 700 1400 1400 1600 1600 3200
peak 1600 1400 1600 1400 2800 2800 3200 3200 6400
MAX SPL (dB) 129 128 130 129 135 132 134 134 138
SYSTEM IMPEDANCE 4 or 8 8 4 or 8 8 4 4 or 8 4 or 8 4 or 8 4
LF DRIVER
driver size 12" 12" 15" 15" 15" 15" 18" 18" 18"
H F SECTION
impedance (W) 8 8 8 8 8
coil size (mm/ins) 50 / 2" 50 / 2" 50 / 2" 50 / 2" 50 / 2"
exit size (mm/ins) 35 / 1.4" 35 / 1.4" 35 / 1.4" 35 / 1.4" 35 / 1.4"
diaphragm matl Titanium Titanium Titanium Titanium Titanium
protect type bulb bulb bulb bulb bulb
HF HORN
type Elliptical Elliptical Elliptical Elliptical Elliptical
CROSSOVER SECTION
crossover Frequency 1.8k 1.8k 1.8k 1.8k 1.8k 170Hz (LX-15B only) 150Hz (LX-18B only)
system Fb 50Hz 60Hz 40Hz 55Hz 40Hz 42Hz 38Hz 38Hz 30Hz
hi pass out      120Hz (LX-15B only) 120Hz (LX-18B only) 
ENCLOSURE TYPE
finish colour (LX) carpet black carpet black carpet black carpet black carpet black carpet black carpet black carpet black carpet black
finish colour (LX-E) paint black paint black paint black paint black paint black paint black paint black paint black paint black
construction materials (LX) MDF/par ticle MDF/par ticle MDF/particle MDF/par ticle MDF/particle MDF/par ticle MDF/particle MDF/particle MDF/particle
construction materials (LX-E) 15mm plywood 15mm plywood 15mm plywood 15mm plywood 18mm plywood 18mm plywood 18mm plywood 18mm plywood 18mm plywood
RIGGING HARDWARE
12 x M10 flying inserts
 no
12 x M10 flying inserts
 no no no no no no

(LX-12E only)
 
(LX-15E only)
STAND ADAPTOR yes no yes no no yes yes yes yes
HANDLE
type square square square square square square square square square
quantity 2 2 2 2 3 2 4 2 4
GRILLE
thikness (mm) 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
type full steel full steel full steel full steel full steel full steel full steel full steel full steel
INPUT CONNECTOR
speakon™ NL4 type 2 2 2 2 2 2 2 2 2
paralle with input connector yes yes yes yes yes yes yes yes yes
hi pass out connector : no no no no no LX-15B only LX-18B only no no
CASTOR no no no no 2 no no no 4 (LX-218E only)
PRODUCT DIMS. (mm)
H 630 618 700 685.5 1138 615 715 545 541
W (front / rear) 396 / 269 426 / 426 470 / 319 500 / 500 506 / 356 470 / 275 570 / 336 545 / 545 1041 / 1041
D 396 450 450 493 461 559 652 650 650
WEIGHT (KG)
net (LX / LX-E) 26.5 / 27.8 21.5 / 22.5 33.5 / 34.6 28.4 / 29.5 59.0 / 60.6 33.5 / 35.6 45.5 / 47.9 39.0 / 40.4 67.5 / 70.8
gross (LX / LX-E) 28.1 / 30.4 23.1 / 25.1 35.7 / 38.3 30.6 / 32.9 63.2 / 66.8 36.3 / 40.1 48.7 / 52.9 42.2 / 44.6 74.4 / 78.9
LX & LX-E Series Technical Specifications
FREQUENCY RESPONSE
@ +/- 3 dB
 LX-12 / LX-12M / LX15 / LX15M / LX-215 / LX-15B / LX-18B / LX-18MB / LX218B /
 LX-12E LX-12ME LX15E LX15ME LX215E LX15BE LX-18BE LX18MBE LX218BE
MODEL
Secure
rigging points
(LX-12E & LX-15E only)
BOTTOM VIEW FRONT VIEW SIDE VIEW REAR VIEWTOP VIEW
268.60
396.00
630.00
396.00
396.00
* No rigging for LX-12
TOPVIEW FRONTVIEW SIDE VIEW REAR VIEWBOTTOM VIEW
319.37
450.00
470.00
700.00
* No rigging for LX-15 *No castors for LX-218B
Trapezoidal designs allow
more compact arrays and
sonic accuracy
Enclosures of the LX-E
constructed from premium
grade plywood for durability
Highly protective
Duraguard™
coating
(LX-E Series only)
Durable black
carpet covering
(LX Series only)
Page 6-7:
Page 4-5:
Page 2 & Page 3Cover & Back
LX and LX-E SERIES PROVIDE EXCELLENT SOUND
PROJECTION, VOCAL PERFORMANCE AND BALANCED
MUSICAL REPRODUCTION
In the LX Series, the powerful LX-15B, LX-18B, LX-18MB and LX-218B sub bass
systems have been designed for use with large-scale LX-12, LX-15 and LX-215
systems to extend LF output power.
In demanding professional applications, the LX-15B and LX-18B, which feature an
internal two-way network, allow a four box system to be powered by one
amplifier. Tough industrial carpet covering provides durability and protection, and
contributes to the overall safety in the set-up and use of the LX systems.
The LX-E Series has the same model line up as the LX Series. The LX-E is finished in
a hardwearing, two-stage epoxy black paint finish and is constructed from premium
grade plywood for extra strength. Among the whole series, the LX-12E and LX-15E
have multiple mounting points for maximum flexibility when installing.
In comparison to the LX Series, the LX-E also has the same power ratings.
FEATURES
• High Performance, arrayable trapezoidal cabinets
• 50 mm Titanium diaphragm true compression driver for brilliant, natural HF
reproduction
• Large Elliptical Wave Guide Horn provides superior control over HF
coverage with reduced distortion, greater output and smoother frequency
response
• Cast frame, large voice coil woofers for sustained output capability and
minimal power compression under extended high power use.
• Heavily braced enclosure
• Dynamic, full range frequency response
• ProTech™ driver protection system
• Recessed metal jack plates with series Speakon™ type and 1/4" inputs
• Cast aluminum, 35mm pole adaptor for stand mounting
The information in this manual is subject to change without notice.
All rights to the mentioned trademarks reside with their respective companies.
All rights reserved © 2004Wharfedale Pro
Wharfedale Pro is a member of International Audio Group
www.wharfedalepro.com
Created from the ground up into the
demanding, high performance world of
professional audio,Wharfedale
Professional enjoys global success with
a range of great value, great sounding,
and innovative products.The
Wharfedale Professional philosophy is
simple:Value, Integrity and Performance
– VIP.
Since 1932,Wharfedale has been at the
forefront of loudspeaker technology –
these seventy years of experience in
the design and manufacture of audio
systems make Wharfedale Pro products
second to none.
We put in a lifetime of experience –
you get out a lifetime of performance.
EXTENSIVE LX & LX-E SERIES COVER THE HIGH-
PERFORMANCE SPECTRUM
The new LX and LX-E Series of loudspeakers each consist of nine models in total,
comprising five full ranges (with FOH and monitor systems in both 12 inch and 15
inch versions), and four sub bass cabinets (in both 15 inch and 18 inch versions).
Boasting distinctive style and features, these high powered, high performance
arrayable trapezoidal enclosures are capable of extremely high sound pressure
levels and exceptional sonic quality with wide dynamic range and bandwidth.
Both series have been developed with exceptional features including the large
elliptical Wave Guide horn, the use of cast-fame, large voice coil woofers for
sustained output capability and minimal power compression under extended
high-power use, and the ProTech™ protection system designed to protect the
HF unit, just to name a few.
In creating the LX Series, we set some basic parameters to design a range that
delivers without exception the performance, features and quality that our
customers demand. We also kept it simple; the LX-E range has a ‘systems’
approach, a range of models that can be used together to provide solutions for
nearly every audio challenge.
NEW LOOK, DISTINCTIVE FEATURES, HIGH STANDARD,
GREAT POWER AND MORE CHOICES.
Elliptical Wave Guide Horn (1.4” Exit)
In comparison to a conventional rectangular horn, the elliptical
Wave Guide offers superior control over HF coverage,
with reduced distortion, greater output and smoother
frequency response. The elliptical shape means that
there are no corners or parallel surfaces to distort,
diffract or reflect the sound – therefore the output is
smoother, cleaner and more consistent. Again, due to
the elliptical shape, mid to high frequencies are
diffused more efficiently.
Titanium 50mm Diaphragm, 1.4” Exit Compression Driver
The elliptical Wave Guide horn is coupled with a
50mm (2”) true compression driver designed
specially for the LX and LX-E Series. This titanium
diaphragm driver features a 1200g-magnet with a
3 5 m m ( 1 . 4 ” ) e x i t f o r b r i l l i a n t , n a t u r a l H F
reproduction.
Large
elliptical wave guide horn
provides superior control
over HF coverage
Large magnet structure
and tight construction
tolerances give accuracy,
high efficiency and
reliability
With enclosures built from a
combination of particle and MDF
in a black carpet finish, the LX is
ideal for use in live sound
applications.
With enclosures built from
plywood in a black paint finish,the
LX-E has extra features to make it
more suitable for the installation
market.
The LX and LX-E Series of
loudspeakers each consist of nine
models in total, comprising five full
ranges multipurpose systems (with
FOH and monitor systems in both 12
inch and 15 inch versions), and four sub
bass cabinets (in both 15 inch and 18
inch versions).
MULTIPURPOSE LOUDSPEAKER SYSTEM MULTIPURPOSE LOUDSPEAKER SYSTEM
SUBWOOFER RANGE
LX-12, LX-12E
Two-way. 12" high power woofer, elliptical wave guide horn with 2" (50mm) titanium diaphragm driver,
Trapezoidal enclosure, 12 X M10 rigging points for mounting (LX-12E only),
Continuous 400W/Music 800W power handling.
LX-12M, LX-12ME
Two-way monitor. 12" high power woofer, elliptical wave guide horn with 2" (50mm) titanium
diaphragm driver,
Continuous 350W/Music 700W power handling.
LX-15, LX-15E
Two-way, 15" high power woofer, elliptical wave guide horn with 2" (50mm) titanium diaphragm driver,
Trapezoidal enclosure, 12 X M10 rigging points for mounting (LX-15E only),
Continuous 400W/Music 800W power handling.
LX-15M, LX-15ME
Two-way monitor, 15" high power woofer, elliptical wave guide horn
with 2" (50mm) titanium diaphragm driver,
Continuous 350W/Music 700W power handling.
LX-215, LX-215E
Quasi 3-way, 15" high power woofer, elliptical wave guide horn with 2" (50mm)
titanium diaphragm driver, Trapezoidal enclosure,Two castors built in,
Continuous 700W/Music 1400W power handling.
LX-15B, LX-15BE
Super subwoofer, 15" driver, Two Speakon™ type connector, Crossover
with high pass output for mid/high (LX-15B only), Trapezoidal enclosure,
Pole mount adaptor,
Continuous 700W/Music 1400W power handling.
LX-18B, LX-18BE
Super subwoofer, 18" driver, Two Speakon™ type connector, Crossover with high pass output for
mid/high (LX-18B only), Trapezoidal enclosure, Pole mount adaptor,
Continuous 800W/Music 1600W power handling.
LX-218B, LX-218BE
Super subwoofer, 2 x18" (460mm) drivers with 4" (100mm) high temperature voice coils for
larger system set-ups, Two Speakon™ type connector, Rectangular enclosure,The birch ply
cabinet is fitted with substantial handles and 4x4" (100mm) castors (LX-218BE only),
Continuous 1600W/Music 3200W power handling.
LX-18MB, LX-18MBE
18" (460mm) modular two way modular cluster element super subwoofer, Two Speakon™ type
connector, Compact frontal dimensions, Co-axial por ts, Pole mount adaptor, Use in blocks of
four to provide astounding sub bass output levels
Continuous 800W/Music 1600W power handling
ProTech™ Driver Overload Protection System
Understanding that sound systems are often asked to perform beyond their original design
parameters, we have designed a smooth, progressive dynamic limiter/protection system that
is carefully tailored to each model. Overloads are limited and drivers are protected against
long term transient or peak conditions. The ProTech™ system progressively converts excess
power to heat and triggers a reduction in power to the HF driver. When the overload
condition is removed the system returns seamlessly to normal operation.
Sophisticated Crossovers Design
Each crossover in the LX and LX-E Series is built using the highest quality components
and designed specifically for that system, enabling smooth power and frequency
response control through the crossover region. The LX-15B and LX-18B feature integral
two-way networks that allow a four-box system to be powered by one amplifier.
Trapezoidal, Plywood and Composite Construction
The LX-E’s cabinet is constructed from plywood on all critical surfaces (where durability
is important) and wood composite where resonances need to be kept to a minimum.
The trapezoidal shape fur ther improves sonic accuracy by significantly reducing internal
flutter echoes and standing wave resonances that are often apparent in rectangular
shape cabinets.
Mounting points:
For maximum flexibility when installing, we have designed two specific models which
feature 12 x M10 rigging points allowing the cabinets to be flown or arrayed. The
LX-12E and LX-15E are fitted with these flying inserts.
Protective Finish
The LX is all finished using a tough, black industrial carpet offering exceptional
protection and durability for life on the road. The LX-E is coated with Duraguard™, an
abrasion resistant paint that creates a protective ‘skin’ around the cabinet. Both finishes
contribute to the overall safety in the set up and use.
Strong Grille, Square Handles and Castors
In order to provide maximum protection to the internal components of the
loudspeakers, the front grilles are full steel and 1.5mm thick. The square handles allow
the cabinets to be gripped securely and comfor tably, therefore making them easy to
move. Built-in castors are available on some larger units for ease of transpor tation.
Value, Integrity and Performance
BOTTOM VIEW LEFT SIDE VIEW FRONTVIEW RIGHT SIDE VIEW BOTTOM VIEWTOPVIEW
449.77
618.00
618.00
102.85 102.85
426.00
539.70
318.17
449.77
TOP VIEW FRONT VIEWLEFT SIDEVIEW RIGHT SIDE VIEWBOTTOM VIEW
493.00 493.00
592.08
592.08
685.50
685.50
685.50
500.00
113.41 113.41
BOTTOM VIEW FRONT VIEW
TOP VIEW
SIDE VIEW REAR VIEW
355.87
461.35
506.00
1138.00
TOPVIEW SIDE VIEW FRONT VIEW SIDE VIEWBOTTOM VIEW
650.00
545.00
545.00
REAR VIEWTOPVIEW SIDE VIEWFRONT VIEWSIDE VIEWBOTTOMVIEW
650.00 1041.00 650.00
541.00
541.00
TOP VIEW FRONT VIEWBOTTOM VIEW SIDE VIEW REARVIEW
(LX-15BE)
275.16
559.00
559.00
615.00
470.00
REAR VIEW
(LX-15B)
FRONTVIEWTOP VIEW BOTTOM VIEW SIDE VIEW REARVIEW
(LX-18BE)
336.00
570.00
652.00
715.00
REAR VIEW
(LX-18B)
WP.LX.01.2005
Heavy duty
protective
steel grille
Built-in castors
for larger
enclosures
Secure square handles
Wharfedale International Limited
IAG House, Sovereign Court, Ermine Business Park,
Hungtingdon Cambs, PE29 6XU, England
IAG America Inc.
15 Walpole Park South, Walpole MA02081, USA
APPLICATIONS 2-way 2-way monitor 2-way 2-way monitor Quasi 3-way subwoofer  subwoofer subwoofer subwoofer
 50-20kHz 60-20kHz 40-20kHz 55-20kHz 40-20kHz 42-170Hz 38-150Hz 38-1.5kHz 30-1.5kHz
      (LX-15B) (LX-18B)
      42-2kHz 38-1.5kHz
      (LX-15BE) (LX-18BE)
SENSITIVITY 1w
@
1m (dB) 97 97 98 98 101 98 99 99 100
COVERAGE Horiz. 90 90 90 90
COVERAGE vert.  45˚ 45˚ 45˚ 45˚
POWER HANDLING (watts)
continuous 400 350 400 350 700 700 800 800 1600
music 800 700 800 700 1400 1400 1600 1600 3200
peak 1600 1400 1600 1400 2800 2800 3200 3200 6400
MAX SPL (dB) 129 128 130 129 135 132 134 134 138
SYSTEM IMPEDANCE 4 or 8 8 4 or 8 8 4 4 or 8 4 or 8 4 or 8 4
LF DRIVER
driver size 12" 12" 15" 15" 15" 15" 18" 18" 18"
H F SECTION
impedance (W) 8 8 8 8 8
coil size (mm/ins) 50 / 2" 50 / 2" 50 / 2" 50 / 2" 50 / 2"
exit size (mm/ins) 35 / 1.4" 35 / 1.4" 35 / 1.4" 35 / 1.4" 35 / 1.4"
diaphragm matl Titanium Titanium Titanium Titanium Titanium
protect type bulb bulb bulb bulb bulb
HF HORN
type Elliptical Elliptical Elliptical Elliptical Elliptical
CROSSOVER SECTION
crossover Frequency 1.8k 1.8k 1.8k 1.8k 1.8k 170Hz (LX-15B only) 150Hz (LX-18B only)
system Fb 50Hz 60Hz 40Hz 55Hz 40Hz 42Hz 38Hz 38Hz 30Hz
hi pass out      120Hz (LX-15B only) 120Hz (LX-18B only) 
ENCLOSURE TYPE
finish colour (LX) carpet black carpet black carpet black carpet black carpet black carpet black carpet black carpet black carpet black
finish colour (LX-E) paint black paint black paint black paint black paint black paint black paint black paint black paint black
construction materials (LX) MDF/par ticle MDF/par ticle MDF/particle MDF/par ticle MDF/par ticle MDF/particle MDF/particle MDF/particle MDF/particle
construction materials (LX-E) 15mm plywood 15mm plywood 15mm plywood 15mm plywood 18mm plywood 18mm plywood 18mm plywood 18mm plywood 18mm plywood
RIGGING HARDWARE
12 x M10 flying inserts
 no
12 x M10 flying inserts
 no no no no no no

(LX-12E only)
 
(LX-15E only)
STAND ADAPTOR yes no yes no no yes yes yes yes
HANDLE
type square square square square square square square square square
quantity 2 2 2 2 3 2 4 2 4
GRILLE
thikness (mm) 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
type full steel full steel full steel full steel full steel full steel full steel full steel full steel
INPUT CONNECTOR
speakon™ NL4 type 2 2 2 2 2 2 2 2 2
paralle with input connector yes yes yes yes yes yes yes yes yes
hi pass out connector : no no no no no LX-15B only LX-18B only no no
CASTOR no no no no 2 no no no 4 (LX-218E only)
PRODUCT DIMS. (mm)
H 630 618 700 685.5 1138 615 715 545 541
W (front / rear) 396 / 269 426 / 426 470 / 319 500 / 500 506 / 356 470 / 275 570 / 336 545 / 545 1041 / 1041
D 396 450 450 493 461 559 652 650 650
WEIGHT (KG)
net (LX / LX-E) 26.5 / 27.8 21.5 / 22.5 33.5 / 34.6 28.4 / 29.5 59.0 / 60.6 33.5 / 35.6 45.5 / 47.9 39.0 / 40.4 67.5 / 70.8
gross (LX / LX-E) 28.1 / 30.4 23.1 / 25.1 35.7 / 38.3 30.6 / 32.9 63.2 / 66.8 36.3 / 40.1 48.7 / 52.9 42.2 / 44.6 74.4 / 78.9
LX & LX-E Series Technical Specifications
FREQUENCY RESPONSE
@ +/- 3 dB
 LX-12 / LX-12M / LX15 / LX15M / LX-215 / LX-15B / LX-18B / LX-18MB / LX218B /
 LX-12E LX-12ME LX15E LX15ME LX215E LX15BE LX-18BE LX18MBE LX218BE
MODEL
Secure
rigging points
(LX-12E & LX-15E only)
BOTTOM VIEW FRONT VIEW SIDE VIEW REAR VIEWTOP VIEW
268.60
396.00
630.00
396.00
396.00
* No rigging for LX-12
TOPVIEW FRONT VIEW SIDE VIEW REAR VIEWBOTTOMVIEW
319.37
450.00
470.00
700.00
* No rigging for LX-15 *No castors for LX-218B
Trapezoidal designs allow
more compact arrays and
sonic accuracy
Enclosures of the LX-E
constructed from premium
grade plywood for durability
Highly protective
Duraguard™
coating
(LX-E Series only)
Durable black
carpet covering
(LX Series only)

Other manuals for LX-E Series

1

This manual suits for next models

17

Other Wharfedale Pro Speakers System manuals

Wharfedale Pro VS series User manual

Wharfedale Pro

Wharfedale Pro VS series User manual

Wharfedale Pro Vista 100 User manual

Wharfedale Pro

Wharfedale Pro Vista 100 User manual

Wharfedale Pro Delta-10 Guide

Wharfedale Pro

Wharfedale Pro Delta-10 Guide

Wharfedale Pro RS10 User manual

Wharfedale Pro

Wharfedale Pro RS10 User manual

Wharfedale Pro RS-10 User manual

Wharfedale Pro

Wharfedale Pro RS-10 User manual

Wharfedale Pro FOCUS-12 Guide

Wharfedale Pro

Wharfedale Pro FOCUS-12 Guide

Wharfedale Pro Achromatic WA-T8 User manual

Wharfedale Pro

Wharfedale Pro Achromatic WA-T8 User manual

Wharfedale Pro FOCUS-12M User manual

Wharfedale Pro

Wharfedale Pro FOCUS-12M User manual

Wharfedale Pro Diva 55 Guide

Wharfedale Pro

Wharfedale Pro Diva 55 Guide

Wharfedale Pro Atlantic AT-100 User manual

Wharfedale Pro

Wharfedale Pro Atlantic AT-100 User manual

Wharfedale Pro TITAN Series Guide

Wharfedale Pro

Wharfedale Pro TITAN Series Guide

Wharfedale Pro Achromatic series User manual

Wharfedale Pro

Wharfedale Pro Achromatic series User manual

Wharfedale Pro WLA-25 Guide

Wharfedale Pro

Wharfedale Pro WLA-25 Guide

Wharfedale Pro WLA Series User manual

Wharfedale Pro

Wharfedale Pro WLA Series User manual

Wharfedale Pro Link-800 User manual

Wharfedale Pro

Wharfedale Pro Link-800 User manual

Wharfedale Pro Titan 12 ACTIVE Guide

Wharfedale Pro

Wharfedale Pro Titan 12 ACTIVE Guide

Wharfedale Pro RS-10 User manual

Wharfedale Pro

Wharfedale Pro RS-10 User manual

Wharfedale Pro Titan 12 ACTIVE User manual

Wharfedale Pro

Wharfedale Pro Titan 12 ACTIVE User manual

Wharfedale Pro Titan 8 Passive User manual

Wharfedale Pro

Wharfedale Pro Titan 8 Passive User manual

Wharfedale Pro LA-15 User manual

Wharfedale Pro

Wharfedale Pro LA-15 User manual

Wharfedale Pro DX-1HCP User manual

Wharfedale Pro

Wharfedale Pro DX-1HCP User manual

Wharfedale Pro WLA Series User manual

Wharfedale Pro

Wharfedale Pro WLA Series User manual

Wharfedale Pro WLA25SF User manual

Wharfedale Pro

Wharfedale Pro WLA25SF User manual

Wharfedale Pro Achromatic WA-T4 User manual

Wharfedale Pro

Wharfedale Pro Achromatic WA-T4 User manual

Popular Speakers System manuals by other brands

BBK FSA-1806 Service manual

BBK

BBK FSA-1806 Service manual

JVC CA-MXK50R instructions

JVC

JVC CA-MXK50R instructions

Magnavox MHT860 user manual

Magnavox

Magnavox MHT860 user manual

Thiel CS 7.2 Owner's Information

Thiel

Thiel CS 7.2 Owner's Information

JBL ES25C Specification sheet

JBL

JBL ES25C Specification sheet

Samsung HW-B660 Full manual

Samsung

Samsung HW-B660 Full manual

Ozaki EM928 instructions

Ozaki

Ozaki EM928 instructions

Peavey Stadia II Specifications

Peavey

Peavey Stadia II Specifications

EAW MK5166e Specifications

EAW

EAW MK5166e Specifications

PSB CustomSound CW262 Specifications

PSB

PSB CustomSound CW262 Specifications

Yamaha NX-B02 - Portable Speakers - 10 Watt owner's manual

Yamaha

Yamaha NX-B02 - Portable Speakers - 10 Watt owner's manual

Subzero AMPLIFIER Series user manual

Subzero

Subzero AMPLIFIER Series user manual

Louroe Electronics AP-1TB Installation and operating instructions

Louroe Electronics

Louroe Electronics AP-1TB Installation and operating instructions

Samsung HW-R530 Full manual

Samsung

Samsung HW-R530 Full manual

Samsung HW-NW700 user manual

Samsung

Samsung HW-NW700 user manual

Sony SS-XB5A instructions

Sony

Sony SS-XB5A instructions

Sven 354 Operation manual

Sven

Sven 354 Operation manual

LEM T5A owner's manual

LEM

LEM T5A owner's manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
