Ceramic Heater
HT015
User Manual
ImportantSafetyInformation
Must be supplied with 220V-240V~/50Hz.
The plug must be plugged into an appropriate outlet that is
installed and grounded in accordance with all local law and
regulations.
Do not modify the plug provided with the appliance. If it does
not fit the outlet, please consult with a qualified electrician
for advice.
Follow all the safety precautions listed below for safety and
to reduce the risk of injury or electrical shock.
Read all the instructions carefully before using this
appliance and keep then for future reference.
Retain the manual. If you pass the product to a third
party, make sure to include this manual.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do
not play with the Appliance.
Unplug the appliance during cleaning.
2
WARNING: In order to avoid overheating, do not
cover the heater.
The heater must not be located immediately below a
socket outlet or other appliance.
Do not use this heater in the surroundings of a bath, a
shower or a swimming pool.
Stop using immediately when water splash into product,
otherwise, it
may have electric shock hazard.
Do not use in wet area such as bathroom.
Make sure no water inside the product before you use it.
If the supply cord is damaged, it must be replaced by the
manufacturer,
qualified persons in order to avoid a
hazard.
CAUTION
-
some parts of this product can
become very hot and may
cause burns. Particular
attention has to be given where children and
vulnerable people are present.
WARNING
: Do not use this heater in small rooms
when they are
occupied by persons not capable of
leaving the room on their own, unless constant
supervision is provided.
In order to use the product more conveniently and avoid
any danger caused
by wrong operation, please pay
attention to the notices.
Turn it off and remove plug until the product stops
3
working and cool
down completely before clean the
unit.
Please do not pull out the power plug by pulling the power
cord. It may cause the power cord damage or electric
shock.
If there is abnormal smell or noise when uses the
product, please
stop
using and pull out the power cord
immediately.
Please don't put heavy unit onto the power cord or fold
the power cord. It
may lead to electric shock.
Please don't have the wind blow to the children directly
for a long time.
It
may influence the children's health.
Please don't touch the plug by wet hands
Please don't put the wood or metal stick into the air inlet
or outlet. It may
lead to electric shock, or product
damage.
Place the appliance on a stable and flat surface to avoid
it tipping over or
being knocked over.
Do not use it on outdoor areas.
This appliance is for household use only.
Do not immerse the appliance or the electrical cord or
plug in liquids.
Do not use the heater in front of or close to an open
window.
Store the appliance away from direct sunlight and out
4
of the reach of children.
Do not use the appliance for any purpose not expressly
specified in this manual.
This appliance must be attended at all times when it is
switched on.
Do not insert any objects into the heater.
Do not put clothes or towels directly on the heater or use it
to dry laundry.
When using the Ceramic heater, keep combustible
materials or explosive objective, away from Ceramic heater.
Do not place the appliance close to children or pets. Never
let children operate this appliance. Close supervision is
necessary when this is used near children.
Do not touch hot surface when in use.
Do not share the same circuit receptacle with others
appliances, otherwise may have burn hazard.
Do not use extension cord.
Do not operate the appliance with a damaged cord or plug.
Send the heater to a suitably qualified or appointed service
agent for inspection and repair.
Unplug heater if it fails to operate properly and inform
customer service center.
Do not use the heater near animals or plants.
Dispose of packaging properly.
5
Persons (including children) with reduced physical, sensory
or mental capabilities, or any individual lacking experience
and knowledge should be supervised or given instruction by
a person responsible for their safety when they using this
appliance. Unless being supervised, children can't use this
appliance.
The heater only for personal use, not for heating any liquids
or other danger things.
Disconnect power plug from power supply when the
appliance is not in use for a long period of time.
Do not use this heater with a programmer, timer,
separate remote-control system or any other device
that switches the heater on automatically, since a fire
risk exists if the heater is covered or positioned
incorrectly.
Do not place the power cord on hot surface when
using.
Do not pull the power supply cord to remove it from the
socket. Do not twist or press the power supply cord,
and make sure it is not broken.
6
A. Features
1. Use the high quality PTC heating element, can be automatically trimming
power according to the change of the environment temperature, No
oxidation characteristics make it has a longer service life;
2. Two gear knobs, for power selection& heat adjustment;
3. Using the DC cooling fan, low noise;
4. With tip-over switch, and double over-heating protection (thermostat,
temperature fuse), use more safe.
5. Swing, automatic air supply with wide- angle, wind downy, heat evenly
6. Drip protection function (IP21)
B. Components Description
Product structure
1. Temperature control knob
2. Power selection knob
3. Panel
4. Front net
5. PTC support
6. Front enclosure
7. Base
8. Back enclosure
9. Filter
10.Filter grille
11. Oscillation bracket
7
Display & Operation panel
C. Product operation instruction
Functions and instructions
1. Please refer to the Important Safety Information, and make sure the
power outlet meeting the requirement before insert the plug to connect the
power;
(1) Plug in the power cord, products into electricity state;
(2) It is energized by spinning power selection knob (High Swing / High / Low /
Low Swing) and the “Temperature control knob” for required temperature
settings (To operate the heater, temperature control knob must be in
clockwise rotation until “tak” sound to be heard);
(3) Required temperature setting can be determined by spinning temperature
control knob to your required temperature position; the interior
temperature will be gradually rose.
a. During the use process, the heater will automatically maintain the set
temperature. When the indoor temperature reaches the set
8
temperature, heater will automatically shut down, when the indoor
temperature is lower than the set temperature, heater automatically
open again, cycle in order to keep the temperature needed for you.
b. Temperature control knob rotation within a specified range of operation,
the knob should not travel beyond the scope of effective instruction, in
order to avoid damage the knob, and affect the machine function.
(4) Rotary “Power selection knob” for different gear;
a. Five gears and the function are: high power + swing / high power
/power off/low power /low power + swing;
b. Stop using this unit please make "power selection knob" in “OFF”
position.
"Power knob" use effective stroke is: from "high power + swing" to "low power
+ swing" rotating within the scope of operation, when the gear knob in "high
power + swing" position, do not continue to force left-hand, in "low power +
swing" position, do not continue to force right hand. In order to avoid damage
the knob, influence the machine function
D. Safety warning and matters needing attention
In order to avoid the danger of wrongdoing and more convenient to use
the machine, in the form of graphic below several points for attention are
presented. Under the condition of the familiar with graphic content below, read
the product instruction manual.
ƽ Symbolic meaning
9
