Whispbar K301W Operation and installation manual

K301W
Fitting Kit
EN Fitting Instructions for Basic Carrier
x 2 x 1 x 1 x 4
x 2 x 1 x 1
Revision No: 8H 1

Fitting Kit K301W
MAX kgs (lbs)
W/P WHD
Chevrolet
Captiva 7, 5dr SUV 06-14 EU 50 kgs (110 lbs) 50 kgs (110 lbs)
Captiva 7, 5dr SUV 06-14 CN 50 kgs (110 lbs) 50 kgs (110 lbs)
Captiva 7, 5dr SUV 06-15 ZA 50 kgs (110 lbs) 50 kgs (110 lbs)
Captiva, 5dr SUV 12-14 US 50 kgs (110 lbs) 50 kgs (110 lbs)
Captiva, 5dr SUV 16-+ ZA 60 kgs (132 lbs) 60 kgs (132 lbs)
Captiva, 5dr SUV 16-+ CN 60 kgs (132 lbs) 60 kgs (132 lbs)
Holden
Captiva 7, 5dr SUV Oct 06-15 NZ 50 kgs (110 lbs) 50 kgs (110 lbs)
Captiva 7, 5dr SUV Oct 06-15 AU 50 kgs (110 lbs) 50 kgs (110 lbs)
Captiva LS, 5dr SUV 16-+ NZ 60 kgs (132 lbs) 60 kgs (132 lbs)
Captiva LS, 5dr SUV 16-+ AU 60 kgs (132 lbs) 60 kgs (132 lbs)
Saturn
Vue, 5dr SUV 08-09 US 50 kgs (110 lbs) 50 kgs (110 lbs)
2

Fitting Kit K301W
X
A B C 1 2 3
Captiva 7, 5dr SUV 06-14 (EU) -200mm 500mm - 830mm 796mm -
-7 -7/8ths" 19 11/16ths" - 32 11/16ths" 31 5/16ths" -
Captiva 7, 5dr SUV 06-14 (CN) -200mm 500mm - 830mm 796mm -
-7 -7/8ths" 19 11/16ths" - 32 11/16ths" 31 5/16ths" -
Captiva 7, 5dr SUV 06-15 (ZA) -200mm 500mm - 830mm 796mm -
-7 -7/8ths" 19 11/16ths" - 32 11/16ths" 31 5/16ths" -
Captiva 7, 5dr SUV Oct 06-15 (NZ) -200mm 500mm - 830mm 796mm -
-7 -7/8ths" 19 11/16ths" - 32 11/16ths" 31 5/16ths" -
Captiva 7, 5dr SUV Oct 06-15 (AU) -200mm 500mm - 830mm 796mm -
-7 -7/8ths" 19 11/16ths" - 32 11/16ths" 31 5/16ths" -
Captiva LS, 5dr SUV 16-+ (NZ) -120mm 580mm - 815mm 785mm -
-4 -3/4ths" 22 13/16ths" - 32 1/16ths" 30 7/8ths" -
Captiva LS, 5dr SUV 16-+ (AU) -120mm 580mm - 815mm 785mm -
-4 -3/4ths" 22 13/16ths" - 32 1/16ths" 30 7/8ths" -
Captiva, 5dr SUV 12-14 (US) -200mm 500mm - 830mm 796mm -
-7 -7/8ths" 19 11/16ths" - 32 11/16ths" 31 5/16ths" -
Captiva, 5dr SUV 16-+ (ZA) -120mm 580mm - 815mm 785mm -
-4 -3/4ths" 22 13/16ths" - 32 1/16ths" 30 7/8ths" -
Captiva, 5dr SUV 16-+ (CN) -120mm 580mm - 815mm 785mm -
-4 -3/4ths" 22 13/16ths" - 32 1/16ths" 30 7/8ths" -
Vue, 5dr SUV 08-09 (US) -200mm 500mm - 830mm 796mm -
-7 -7/8ths" 19 11/16ths" - 32 11/16ths" 31 5/16ths" -
3

Fitting Kit EN
K301W
First Time Installation
●Remove parts from inside the package and
check. Contact your dealer if any parts are
missing or damaged.
●This kit fits type A, B, C and D.
●These instructions show type A crossbar
fitted. They also apply to type B, C and D.
NOTE: Clamp images in these instructions may
not be representative of the clamps in this kit
4

Fitting Kit EN
K301W
●Use keys to remove covers.
●Use hex screwdriver to reverse adjusting
screw 10 turns.
●Press adjusting screw and pull crossbar
legs out. Refer to the crossbar instructions
for crossbar adjustment method.
●Ensure each end of the crossbar is
adjusted equally.
5

Fitting Kit EN
K301W
Fitment
●Place crossbar on vehicle. Minimum
recommended spacing between the bars is
700mm (27 1/2") (unless otherwise stated).
●Clamps directly to edge of roof under the
doors
●Please check the front of this manual for
information relating specifically to your
vehicle.
●It is important to put the pads in the correct
position on the vehicle.
●Letters refer to the pad part numbers and
position.
●Pad Part Number:
A = 219A
●Refer to the underside of the pad for the
part number.
6

Fitting Kit EN
K301W
●Place rubber pads (supplied with fitting kit)
on the vehicle roof. Pad may vary in shape
to that shown.
●Make sure the pad fits into the holes
underneath the foot.
●Remove locking screw.
7

Fitting Kit EN
K301W
●Apply protective strip as shown.
Trim if required.
●It is important to put the clamps in the
correct position on the vehicle.
●Letters refer to the part numbers stamped
on clamps.
●Clamp Part Number:
A = A181
B = A182
C = A183
●Attach clamp to each leg. NOTE; clamps
may have labels showing their positions on
the vehicle (For example; "Front Right").
8

Fitting Kit EN
K301W
●Refit locking screw so that it goes through
the hole in the clamp. Do not begin to
tighten the locking screw.
●Adjust the legs on the crossbar so that they
are positioned equally from the ends of the
crossbar, and the clamps engage firmly on
the body work of the vehicle.
●Tighten adjusting screw to 3 Nm (2.2 ft lb)
hand tight.
9

Fitting Kit EN
K301W
●Tighten locking screw on both legs evenly,
3 Nm (2.2 ft lb).
●Check crossbar is securely attached to the
vehicle.
●Use keys to fit and lock covers
10
