Whitehall Manufacturing Dignity Suite WHD-SHV10 Instruction manual

INSTALLATION, OPERATION & MAINTENANCE MANUAL WHD-SHV
WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
TM
Dignity Suite Recessed
Shelf Assembly
®
TM
LIGATURE RESISTANT RECESSED CORTERRA
SOLID SURFACE SHELF ASSEMBLY
WHD-SHV15
(Shown mounted vertically)
WHD-SHV10
(Shown mounted vertically)
6900-221-001 Revised: 08/24/2021

INSTALLATION, OPERATION & MAINTENANCE MANUAL WHD-SHV
2
WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
2
SIDE VIEW
FRONT VIEW
D-SHV10 TECHNICAL DIMENSIONS
1. SHELF FRAME ASSEMBLY
2. SHELF BACK PANEL
NOTES:
3. MOUNTING FRAME ASSEMBLY
8"
[203]
12"
[305]
10 1
4"
[260]
1
237
[946]
61
2"
[165]
41
2"
[114]
3
38"
[965]
1
4"
33
4"
[95]
11"
[279]
11"
[279]

INSTALLATION, OPERATION & MAINTENANCE MANUAL WHD-SHV
3
WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
3
SIDE VIEW
FRONT VIEW
11"
[279]
12"
[305]
15 1
4"
[387]
D-SHV15 TECHNICAL DIMENSIONS
1
2
13"
[330]
2. SHELF BACK PANEL
3. MOUNTING FRAME ASSEMBLY
NOTES:
1. SHELF FRAME ASSEMBLY
37
[946]
61
2"
[165]
41
2"
[114]
3
38"
[965]
1
4"
33
4"
[95]
11"
[279]

INSTALLATION, OPERATION & MAINTENANCE MANUAL WHD-SHV
4
WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
4
373
8"
[959]
9
[241]
1
2"
D-SHV10 FIXTURE ANCHORING
1
2Install Shelf Frame Assembly into Mounting Frame
Assembly and ensure Middle Mounting Clips engage.
Shelf Frame Assy.
Mounting Frame Assy.
Finished Wall
2
1
3
Install 10” x 38” Mounting Frame Assembly into Blockout Area and Secure
using Installer Provided Fasteners (12) Places. Ensure frame is level.
Finished Wall
Mounting Frame Assembly
Blockout Area
2
1
3
Installer Provided Fasteners
to suit wall conditions
4
1
2
3
4
BLOCKOUT
BLOCKOUT
MIN.
Wall Depth
41
2"
[114]
1
2
3
N O T E : A c c e s s a b i l i t y
standards may dictate
shelf height for reach
range. Verify requirements.

INSTALLATION, OPERATION & MAINTENANCE MANUAL WHD-SHV
5
WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
5
D-SHV10 FIXTURE ANCHORING
3
Back Panel Mounting Clip
Magnetic Latch
Frame Mounting Channel
2
1
3
4Secure Magnetic Latch using Magnet Key (Provided) by
engaging Latch and moving it in one of two directions
depicted by the arrows below.
Magnetic Latch
Frame Mounting Channel
Magnet Key (Provided)
2
1
3
Align the Back Panel Mounting Clips onto Top and Bottom the Frame Mounting Channels
and ensure the Magnetic Latch is at the starting position. Ensure Middle Mounting
Channels align with Back Panel Mounting Channels.
Shelf Assembly
4
FRONT VIEW
2
1
3
3
4
DETAIL A DETAIL B
A
B
1
2
3
2
3
MAGNET KEY
(PROVIDED)
(NOT TO SCALE)
NOTE: IF MOUNTED HORIZONTALLY,
USE MAGNET KEY TO ENGAGE LATCH
AND MOVE TOWARDS THE DIRECTION
OF GRAVITY TO ENSURE THE FIXTURE
IS SECURE.

INSTALLATION, OPERATION & MAINTENANCE MANUAL WHD-SHV
6
WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
6
1
2
3
D-SHV15 FIXTURE ANCHORING
1
Shelf Frame Assy.
Mounting Frame Assy.
Finished Wall
2
1
3
Install 15” x 38” Mounting Frame Assembly into Blockout Area and Secure
using Installer Provided Fasteners (12) Places. Ensure frame is level.
Finished Wall
Mounting Frame Assembly
Blockout Area
2
1
3
Installer Provided Fasteners
to suit wall conditions
4
N O T E : A c c e s s a b i l i t y
standards may dictate
shelf height for reach
range. Verify requirements.
1
BLOCKOUT
3
8"
[959]
37
14
[375]
1
2"BLOCKOUT
3
4
Wall Depth
MIN.
41
2"
[114]
2Install Shelf Frame Assembly into Mounting Frame
Assembly and ensure middle Mounting Clips Engage.

INSTALLATION, OPERATION & MAINTENANCE MANUAL WHD-SHV
7
WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
7
FRONT VIEW
3
3
4
2
1
D-SHV15 FIXTURE ANCHORING
4Secure Magnetic Latch using Magnet Key (Provided) by engaging Latch and
moving it in one of two directions depicted by the arrows below.
Magnetic Latch
Frame Mounting Channel
Magnet Key (Provided)
2
1
3
Shelf Assembly
4
3
MAGNET KEY
(PROVIDED)
(NOT TO SCALE)
3
Back Panel Mounting Clip
Magnetic Latch
Frame Mounting Channel
2
1
3
Align the Back Panel Mounting Clips onto Top and Bottom the Frame Mounting Channels
and ensure the Magnetic Latch is at the starting position. Ensure Middle Mounting
Channels align with Back Panel Mounting Channels.
DETAIL A DETAIL B
A
B
1
2
3
2
NOTE: IF MOUNTED HORIZONTALLY, USE MAGNET KEY TO ENGAGE LATCH AND
MOVE TOWARDS THE DIRECTION OF GRAVITY TO ENSURE THE FIXTURE IS SECURE.

INSTALLATION, OPERATION & MAINTENANCE MANUAL WHD-SHV
8
WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
8
MAINTENANCE
CORTERRA SOLID SURFACE
Surface damage, such as minor chips, scratches, burn marks and graffiti can be repaired with
a fine grit abrasive cleanser, such as a Scotch-Brite pad or fine grit sandpaper. For more
serious physical damage caused by vandals, an Acorn Solid Surface Repair Kit is available.
Contact the factory for details. Refer to drawing #9927-160-002.
Corterra should be kept clean at all times. If maintained, Corterra surfaces will retain their new,
clean appearance indefinitely. Wash with a non-abrasive all purpose cleaner and water, then
rinse. Wipe dry. (Never use cleaners with strong chemicals such as toilet bowl cleaners, rust
removers, ceramic cook top cleaners, laquer thinners or oven cleaners). To remove persistent
stains use a Scotch Brite pad and an abrasive cleaner or a solution of household bleach and
water (1 part water to 1 part bleach).
Acorn's densified solid surface material is composed of recycled solid-surface polymer resin,
aluminum trihydrate and fillers. It is resistant to stains, impact and burns and complies with
ANSI Z124.3. It is attractive, durable and easy to maintain.
ROUTINE CLEANING
REPAIRING SURFACE DAMAGE
CARE, CLEANING, AND REPAIR OF CORTERRA SOLID SURFACE
