Wholesale Interiors BBT5280 User manual

HARDWARE LIST
ITEM DESCRIPTION QTY
1 JCBC Bolt M6 x 50mm 4 PCS
2 WOOD SCREW M4 x 38mm 4 PCS
3 WOOD DOWEL M10 x 40mm 8 PCS
4M4 ALLEN KEY (BALL SHAPE) 1 PC
Read this instruction carefully. See hardware and furniture part list for guidance.
Be sure all parts are complete, before you assemble. Place all wooden furniture
parts on a clean and flat soft surface to prevent from being scratched.
Follow the figure to start assembling.
CAUTIONS :1. Do not FULLY - TIGHTEN the nut or nut bolt until all nut or bolt is ready assembed.
2. Do not OVER - TIGHTEN the nut or bolt to avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
Tool needed : Screwdriver & Hammer (not provided).
ASSEMBLY INSTRUCTIONS
MODEL : BBT5280 DINING CHAIR PAGE 1 OF 2
STEP A STEP B
x2
STEP 1 STEP 2
PART LIST
ITEM DESCRIPTION QTY
A CHAIR 1 PC
BLEG (L) 1 PC
CLEG (R) 1 PC
DSUPPORT RAIL (LONG) 1 PC
ESUPPORT RAIL (SHORT) 1 PC
E
D
C
E
D
1
4
3
LONG
SHORT
R

ASSEMBLY INSTRUCTIONS PAGE 2 OF 2
STEP A
STEP B x2
x4
STEP 3 STEP 4
STEP 5
B
2
A
2
4
1
Note : Follow the line drawing to assemble the chair leg.
L
R
L
