Wildview Infrared Xtreme STC-TGL5IR User manual

STC-TGL5IR
User’s Manual
Toll Free Customer Support 1-888-304-6125
www.wildviewcam.com
Version 6.0 09/15

STC-TGL5IR
www.wildviewcam.com Toll Free 888-304-6125
2
For Customer Service or Warranty Information Call Toll Free
888-304-6125
WILDVIEW
P.O. Box 535189
Grand Prairie, Texas 75053-5189
Wildview Limited Warranty
Your Wildview scouting camera is covered by a One Year Limited
Warranty on parts and labor from the date of original purchase, and
purchases must be made through an authorized dealer. The warranty
covers defects in workmanship and materials. The warranty does not
apply to units, which have been damaged or abused intentionally or
unintentionally. A purchase from individuals or unauthorized internet
sites such as eBay voids the warranty.
Tampering with or altering the unit will void the warranty. Any
unauthorized service will void warranty. Original sales receipt must be
produced for any warranty service and a Return Authorization (RA)
number must be obtained from customer service at 888-304-6125 prior to
returning product.

STC-TGL5IR
www.wildviewcam.com Toll Free 888-304-6125
3
Manual Contents
Camera overview 4
Camera kit contents 6
Battery and memory Installation 7
Definitions 11
Programming 13
Mounting the camera 15
Viewing images 19
Saving and Deleting images 21
Memory compatibility chart 24
Technical Specs 25
General Information 28
Image Capacity Chart 30
Moon Phase Chart 32

STC-TGL5IR
www.wildviewcam.com Toll Free 888-304-6125
4
Camera overview
Front view Side view

STC-TGL5IR
www.wildviewcam.com Toll Free 888-304-6125
5
Open view image with major parts indication

STC-TGL5IR
www.wildviewcam.com Toll Free 888-304-6125
6
Camera kit contents
STC-TGL5IR Digital Scouting Camera
User Manual
USB cable
Strap

STC-TGL5IR
www.wildviewcam.com Toll Free 888-304-6125
7
Battery & memory installation
The Wildview Camera is designed to operate using two different types
of battery power options.
NOTE: Always have camera in the OFF position when installing or
removing batteries. Removing battery while the camera is in operation
may damage the camera.
Batteries “C” cell
The internal battery compartment accepts 4 “C” cell batteries. Be sure
to use high quality brand name alkaline batteries. Install batteries with
correct polarity (+/-) as noted inside the battery compartment.
Warning: Do not use a different Voltage lead
acid battery other than the one specified in
this section. Doing so will damage the camera
and will void the warranty.

STC-TGL5IR
www.wildviewcam.com Toll Free 888-304-6125
8
The camera is equipped with an external power jack designed to
accept a barrel plug cable that attaches to a sealed lead acid battery.
(sold separately). This will enhance the camera’s field life. Battery
cable and complete 12V Lead Acid battery kits are available wherever
Wildview scouting cameras are sold, or call toll free 888-304-6125.
Only Wildview external battery accessories are recommended.
Insert the external battery barrel plug into the DC 12V jack on
the bottom of camera housing.
Turn the camera power on.
The camera will automatically switch to external power when it
is connected, even if the internal batteries are installed.
Please make sure the voltage and polarity (+/-) are correct
before connection. Incorrect voltage or polarity (+/-) will
damage the camera.

STC-TGL5IR
www.wildviewcam.com Toll Free 888-304-6125
9
Memory Options
Your Wildview scouting camera is equipped with the following:
The camera is also equipped with an expandable media card slot
capable of accepting up to 2GB* SD card (sold separately). With
no memory card inserted into the slot, the camera will use the built
in SDRAM memory to store images. If an SD card is inserted into
the slot, then the camera will bypass the built in memory and utilize
the SD memory. The front counter display will show the number of
images in the built in memory, unless the expansion card is
inserted at which point the front counter will only display the
number of images stored in the expansion card.
Model
SDRAM
STC-TGL5IR
32MB

STC-TGL5IR
www.wildviewcam.com Toll Free 888-304-6125
10
Inserting SD card
Make sure camera is in the OFF position whenever adding or
removing memory.
Insert SD memory card in to the SD card slot completely and in
the correct direction, as shown by the SD picture shown on
inner housing.
To remove the SD memory card, depress the SD card and pull
out the card gently.
SD cards must be clean (no images from other sources).
If you are using the SD card from other cameras, please
make sure to format the SD card in your computer prior to
use in the camera. New cards are good to use straight
from the package.
If installed SD card with lock, camera will show LOC on the
display, please slide the lock switch to unlock location
then reinstall the SD card.
