Wilfa JUICEMASTER FRESH User manual

JUICEMASTER FRESH
SLOW JUICER SJ1B-500
EN ·Instruction manual DE ·Anleitung
NO ·Bruksanvisning NL ·Instructies
SE ·Bruksanvisning PL ·Instrukcje
DK ·Betjeningsvejledning FR ·Instructions
FI ·Käyttöohje

2

NO
SE
DK
FI
EN
NL
PL
FR
LES ALLE ANVISNINGER FØR BRUK
LÄS IGENOM ALLA INSTRUKTIONER INNAN PRODUKTEN ANVÄNDS
LÆS ALLE VEJLEDNINGER INDEN BRUG
LUE OHJEET HUOLELLISESTI ENNEN KÄYTTÖÄ
LEES VÓÓR GEBRUIK ALLE INSTRUCTIES
PRZED UŻYCIEM ZAPOZNAĆ SIĘ ZE WSZYSTKIMI ZALECENIAMI
PRENEZ CONNAISSANCE DE TOUTES LES INSTRUCTIONS AVANT UTILISATION
DE
LESEN SIE DIE ANLEITUNG VOR DEM GEBRAUCH GRÜNDLICH DURCH
READ ALL INSTRUCTIONS BEFORE USE

4
INSTRUCTION MANUAL ·JUICEMASTER FRESH
EN

5
EN
SLOW JUICER ·SJ1B-500
CONTENTS
6 IMPORTANT SAFETY INSTRUCTIONS
8 PRODUCT OVERVIEW
9 BEFORE FIRST USE
9 ASSEMBLING AND HOW TO USE
11 SUGGESTION GRADES FOR NORMAL FRUITS
12 DISASSEMBLY AND CLEANING
13 TIPS AND TRICKS
13 TROUBLESHOOTING
14 GUARANTEE
15 PRODUCT SPECIFICATIONS
15 SUPPORT AND SPARE PARTS
15 RECYCLABILITY

6
INSTRUCTION MANUAL ·JUICEMASTER FRESH
EN
IMPORTANT SAFETY INSTRUCTIONS
• Read this instruction manual thoroughly before
use and save it for future reference. It is also
available at our website; wilfa.com.
• This appliance shall not be used by children. Keep
the appliance and its cord out of reach of children.
Appliances can be used by persons with reduced
physical, sensory, or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and if they understand
the hazards involved. Children shall not play with
the appliance.
• Switchofftheapplianceanddisconnectfromsupply
before changing accessories or approaching parts
that move in use.
• Always disconnect the appliance from the supply
if it is left unattended and before assembling,
disassembling or cleaning.
• This product is intended for indoor, non-industrial,
non-commercial, household use only.
• Always unplug the appliance after use and before
cleaning.

7
SLOW JUICER ·SJ1B-500
EN
• If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
• Place the appliance on a flat and stable surface.
Avoid contacting moving parts.
• The use of attachments not recommended or sold
by the manufacturer may cause fire, electric shock,
or injury.
• Do not let power cord hang over edge of table or
counter.
• Do not put your fingers or other objects into the
juicer while it is in operation, if food becomes
lodged in opening, use food pusher or another
piece of fruit or vegetable to push it down. When
this method is not possible, turn the motor off and
disassemble juicer to remove the remaining food.
• Always make sure juicer locking clip is locked in
position while juicer is in operation.
• Do not operate the machine for more than
20 minutes at a time. Do not operate the appliance
when the drum is empty.

8
INSTRUCTION MANUAL ·JUICEMASTER FRESH
EN
PRODUCT OVERVIEW
1. Adjustable Ring
2. Drum Cap
3. Juice Strainer
4. Screw
5. Pusher
6. Food tray
7. Drum
8. Juice outlet/ Drip-stop
9. Power/Reverse Button
10. Main Body
11. Lock
12. Pulp Cup
13. Juice Cup
14. Cleaning Brush
1
7
2
8
3
9
4
10
5
11
13
6
12
14

9
SLOW JUICER ·SJ1B-500
EN
On/off button: The appliance starts to work
when you press the on/off button and will stop
automatically after 20 minutes. If you need to stop
the appliance earlier, simply press the button again.
Reverse button: Press and hold this button and
the screw will turn in the opposite direction.
Lock: Press in the lock button, turn the drum and
pull it from the main body.
Place the drum up against the main body in
unlocked position.
Connect the drum to the main body by turning it
until you hear a click sound.
Insert the screw axle into the hole in the main body
and push it all the way in.
BEFORE FIRST USE
• Remove all packaging.
• Keep the packaging away from children.
• Disassemble the juicer (see disassembly and cleaning).
• Wash all removable parts thoroughly.
• Do not wash the main body.
ASSEMBLING AND HOW TO USE
REV
ON/OFF
Lock

10
INSTRUCTION MANUAL ·JUICEMASTER FRESH
EN
Insert the juice strainer into the groove on the
drum and push it all the way in.
Screw the drum cap onto the drum
counterclockwise and until tight.
Screw the adjustable ring onto the drum cap until
tight. The adjustable ring has settings from 1-5,
where 1 is suited for soft ingredietns, and 5 is suit-
ed for hard ingredients.
Place the food tray securely to the drum.
Note: Food tray will make it more convenient when
feeding food into the drum, especially for small
food such as grapes.
Place the juice cup into the groove that on the
main body.
Place the pulp cup under the pulp outlet, next to
the juice cup.
Plug in the power cord.
