Wilson Electronics SIGNALBOOST 811210 User manual

Amplifier
Installation
Guide
Warning: This manual contains
important safety and operating information.
Please read and follow the instructions
in this manual. Failure to do so could be
hazardous and result in damage to your
amplier.
!
SignalBoost™
Dual-Band
Cellular / PCS
Amplier
PART/MODEL# 811210
Contents:
Guarantee and Warranty · · · · · · · · · · · · · · · · · · · · · · · · 1
How it Works · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2
Before Getting Started · · · · · · · · · · · · · · · · · · · · · · · · · · 3
Installation Overview · · · · · · · · · · · · · · · · · · · · · · · · · · · 3
Installing the Antenna (Vehicle) · · · · · · · · · · · · · · · · · · · 4
Installing the SignalBoost™ Amplier (Vehicle) · · · · · · · 5
Installing the Antenna (Home/Ofce) · · · · · · · · · · · · · · · 6
Installing the SignalBoost™ Amplier (Home/Ofce) · · · 6
Installing the Universal Connector · · · · · · · · · · · · · · · · · 7
Powering Up the Amplier · · · · · · · · · · · · · · · · · · · · · · · 8
Warnings and Recommendations · · · · · · · · · · · · · · · · · 9
About Wilson Electronics · · · · · · · · · · · · · · · · · · · · · · · · 10
Amplier Specications · · · · · · · · · · · · · · · · · · Back Cover
Wilson
®
Electronics, Inc.

1
30-Day Money-Back Guarantee
All Wilson Electronics products are protected by Wilson’s 30-day money-back
guarantee. If for any reason the performance of any product is not acceptable,
simply return the product directly to the reseller with a dated proof of purchase.
1-Year Warranty
Wilson Electronics ampliers are warranted for one (1) year against defects in
workmanship and / or materials. Warranty cases may be resolved by returning the
product directly to the reseller with a dated proof of purchase.
Ampliers may also be returned directly to the manufacturer at the consumer’s
expense, with a dated proof of purchase and a Returned Material Authorization
(RMA) number supplied by Wilson Electronics. Wilson shall, at its option, either
repair or replace the product. Wilson Electronics will pay for delivery of the repaired
or replaced product back to the original consumer.
This warranty does not apply to any ampliers determined by Wilson Electronics
to have been subjected to misuse, abuse, neglect, or mishandling that alters or
damages physical or electronic properties.
RMA numbers may be obtained by phoning Technical Support at 866-294-1660.
Operation is subject to the following two conditions: (1) This device may not cause
interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of this device.
Disclaimer: The information provided by Wilson Electronics, Inc. is believed to
be complete and accurate. However, no responsibility is assumed by Wilson
Electronics, Inc. for any business or personal losses arising from its use, or for
any infringements of patents or other rights of third parties that may result from
its use.
Copyright © 2006 Wilson Electronics, Inc. All rights reserved.

2
Installation Instructions for the Following Wilson Amplier:
SignalBoost™ Dual-Band Cellular/PCS Amplier
Part / Model #811210
FCC ID: PWO819DA IC: 4726A-819DA
Patent Pending
The term “IC” before the radio certication number only signies that
Industry Canada technical specications were met.
Inside this Package
(antenna required - sold separately)
How it Works
Your new Wilson SignalBoost™ Amplier has been carefully engineered to signicantly
improve the performance of your cell phone or cellular data card in both vehicle and home/
ofce applications. Together with an antenna (sold separately), the amplier’s state-of-
the-art technology is designed to increase your signal up to 10 times, reduce disconnects
and dropouts, and increase data communication rates needed for 3G technologies. The
universal connector ts all cellular and PCS phones and data cards.
The antenna will collect the cell tower signal and send it through the cable to the amplier.
The signal is then boosted and sent through the extension cable to the universal connector
on your cell phone or data card, which then communicates with the improved signal. When
the cell phone or data card transmits, the signal goes through the universal connector
and the extension cable, is boosted by the amplier and broadcast back to the cell tower
through the antenna.
Wilson Electronics manufactures a wide variety of antennas and accessories to help you
customize your SignalBoost™ Amplier for your specic application. Several are shown
below. See your dealer or visit www.wilsonelectronics.com. NOTE: Use of this amplier
with an antenna gain higher than 6.12 dBi is in violation of FCC regulations for which the
offender is fully liable. All Wilson mobile antennas are 6.12 dBi or less.
SignalBoost™
amplier
12 V DC plug-in power
supply (vehicle)
Universal
connector
6‘ extension
cable
4-inch Mini
Magnet-Mount
Antenna
12-inch
Magnet-Mount
Antenna
Soft Carrying
Case
AC/DC Plug-In Power
Supply (home/ofce)
Window Bracket

3
Before Getting Started
This guide will help you properly install Wilson’s dual-band, SignalBoost™ amplier. It is
important to read through all of the installation steps for your particular application
prior to installing any equipment. Read through the instructions, visualize where all
the equipment will need to be installed and do a soft installation before mounting any
equipment. If you do not understand the instructions in full, please contact Wilson Technical
Support at 866-294-1660.
Installation Overview
The following steps provide a summary of the amplier/antenna installation process
using the optional mini magnet-mount antenna. However, they are not a substitute for the
complete installation instructions on the following pages, which you should read thoroughly.
If you are using a different antenna, follow the specic instructions that come with it.
STEP 1 Install the Antenna
For a vehicle installation, attach the antenna in the center of the vehicle’s roof and run the
cable through the door to the amplier. For a home or ofce installation, attach the antenna
to the optional window bracket, afx the bracket to a window with the suction cups and run
the cable to the amplier. (See pages 4 and 6 for details and RF safety warnings.)
STEP 2 Install the Amplier
Position the amplier in a well-ventilated location away from direct sunlight. Run the cable
from the antenna and attach it to the FME-Male connector labeled “outside antenna” on the
amplier. (See pages 5 and 6 for details.)
STEP 3 Attach the Universal Connector
Attach the universal connector cable to the FME-Male connector labeled “Universal
Connector” on the amplier. Attach the other end of the cable to your cell phone or cellular
data card with the supplied VELCRO®. (See page 7 for details.)
STEP 4 Power up the Amplier
IMPORTANT! Before connecting the power supply, ensure that both the antenna cable and
the universal connector cable are connected. (See page 8 for details.)
Mobile Installation Diagram Home/Ofce Installation Diagram
SIGNALBOOST™
Amplifier
Cell Phone
Connection
Antenna
(sold separately)
Window Bracket
(sold separately)
AC Power Supply
(sold separately)
SIGNALBOOST™
Amplifier
Laptop
Connection
Antenna
(sold separately)
Cigarette
Power Supply
SIGNALBOOST™
Amplifier

4
Installing the Antenna
To receive the best cell signal, select a location in the center of the vehicle’s roof at least 12
inches away from any other antennas and free of obstructions.
The antenna must be installed vertically.
Signal performance will be degraded if the
antenna is not vertical.
The antenna cable may be run through the
door to the amplier.
The antenna cable is small enough to easily
tuck under the door seal or plastic molding.
For a more professional-looking installation,
the antenna cable may be run under the
door seal. Carefully pull down the door
seal. Run the cable through the seal
and push the seal back into place. This
prevents constant wear and tear on the
cable as the door opens and closes.
Carefully
Pull Down
Door Seal
Run Cable
Under
Seal
Tuck Cable
Under Seal
Vehicle Installation
Warning: The antenna used with this
amplier must have a separation distance of at
least 11 inches from all persons.
!

5
Installing the Wilson SignalBoost™ Amplier
Warning: Do not plug in the DC
power supply until the antenna and universal
connector cables are attached to the amplier.
!
Select a location to install the amplier that
is away from excessive heat, direct sunlight
or moisture and that has proper ventilation.
Recommended installation locations are:
• Under the seat
• Under the dash
Run the cable from the antenna and attach
it to the FME-Male connector labeled
“outside antenna” on the amplier.
Attach the universal connector cable to the
extension cable and attach the extension
cable to the FME-Male connector labeled
“Universal Connector” on the amplier.
Then attach the universal connector to your
cell phone or data card.
Vehicle Installation

6
Installing the Antenna
To receive the best cell signal, select a window location at least 12 inches away from any
radio or television antennas and free of obstructions.
Using the suction cups, position the
mounting bracket on the window at a height
convenient to where the amplier will be
located, then attach the antenna to the
bracket.
The antenna must be installed vertically.
Signal performance will be degraded if the
antenna is not vertical.
Select a location to install the amplier that
is away from excessive heat, direct sunlight
or moisture and that has proper ventilation.
Recommended installation locations are:
• On a desk or table top
• In a bookshelf
• On the oor
Run the cable from the mini magnet-mount
antenna and attach it to the FME-Male
connector labeled “outside antenna” on the
amplier.
Attach the universal connector cable to the
extension cable and attach the extension
cable to the FME-Male connector labeled
“Universal Connector” on the amplier.
Then attach the universal connector to your
cell phone or data card.
Home/Ofce Installation
Installing the Wilson SignalBoost™ Amplier
Warning: Do not plug in the AC power
supply until the outside antenna and universal
connector cables are attached to the amplier.
!
Warning: The antenna used with this
amplier must have a separation distance of at
least 11 inches from all persons.
!

7
Installing the Wilson Universal Connector
The universal connector must be placed
directly on the cell phone or cellular data
card to work properly. Attach the universal
connector to the cell phone or cellular data
card with the VELCRO®included in the
package.
The universal connector and extension
cable included in the package are long
enough to reach the amplier location. This
allows for ease and convenience of use.
To adjust the universal connector for the
best signal, go to a weak signal location
where your cell phone registers only 1-2 bars
without the universal connector connected.
(Be sure the amplier is turned off when
checking for low signal.) Then, attach the
universal connector to the phone, power up
the amplier and you should see a signal
improvement of 2 or more bars.
Note: Many phones take up to 20 seconds
to reset the bar indicator.
To maximize performance, attach the universal
connector as close as possible to the original
antenna on your cell phone or cellular data card.
For cell phones with no external antenna, place
the universal connector on the back, upper left-
hand corner of the phone. (Figure 1)
For cell phones with an external antenna, place
the universal connector directly below the
phone’s original antenna. (Figure 2)
Many of the hands-free cradles have a built-in
antenna with a pigtail. If using a hands-free
device or cell phone cradle, the universal
connector may be directly connected to the
phone cradle or to the pigtail.
Amplier 6’ Extension
Cable Universal Connector
Figure 1 Figure 2
To Amplier
Cellular data card

8
Powering up the Amplier
Make sure both the outside antenna and
universal connector cables are connected
before powering up the amplier.
For vehicle use, connect the power cable
from the DC plug-in power supply to the
amplier input marked “Power” and insert
the large end into DC power socket (the
cigarette lighter outlet).
For home or ofce use, connect the cable
from the AC/DC plug-in power supply (sold
separately) to the amplier input marked
“Power” and insert the plug end into a
standard wall outlet.
The amplier may remain on all the time.
However, leaving the amplier on in a
vehicle when it is not running can discharge
the battery in a day or two.
A good option is to power the amplier
through the ignition switch so the amplier
is turned on and off with the vehicle.
NOTE: The aluminum casing of the SignalBoost™ amplier will adjust very quickly to the
ambient temperature of its environment. For example, in the summer, when the inside of
a car can reach 140 degrees Fahrenheit, the amplier temperature may be 150 degrees
or higher. The casing will be hot to the touch, similar to a metal door handle or steering
wheel. Such high temperatures will not damage the amplier, nor do they pose a re risk.
As recommended in these instructions, when installing the amplier in a vehicle, select a
location with adequate ventilation, such as under the seat or dashboard. Keep the area
free of items that could block air ow to the amplier.
Carefully insert the power cable.
IMPORTANT: Do not power up the
amplier unless the antenna and universal
connector cables are attached to the
amplier.
Warning: Use only Wilson power
supply units. Use of a non-Wilson
product may damage your equipment.
!
12 V DC power supply (included)
AC/DC power supply (not included)

9
Warnings and Recommendations
Warning: Do not plug the amplier directly into the cell phone or cellular
data card using an antenna adapter. It will damage the cell
phone or cellular data card.
Warning: Do not plug in the power supply until the antenna and universal
connector cables are attached to the amplier.
Warning: RF Safety: The antenna must be installed with a separation of
at least 11 inches from nearby persons and must not be located
or operating in conjunction with any other antenna or amplier.
Use of this amplier with an antenna gain higher than 6.12 dBi
is in violation of FCC regulations for which the offender is fully
liable. All Wilson mobile antennas are 6.12 dBi or less.
Recommended amplier installation locations for a vehicle are:
• Under the seat
• Under the dash
Power the amplier through the ignition switch so the amplier is turned on and
off with the vehicle.
Recommended amplier installation locations for a home or ofce are:
• On a desk or table top
• In a bookshelf
• On the oor
9

10
About Wilson Electronics
Wilson Electronics, Inc. has been a leader in the wireless communications
industry for nearly 40 years. The company designs and manufactures ampliers,
antennas and related components that signicantly improve cellular telephone
signal reception and transmission in a wide variety of applications, both mobile
and in-building.
With extensive experience in antenna and amplier research and design, the
company’s engineering team uses a state-of-the-art testing laboratory, including
an anechoic chamber and network analyzers, to ne-tune antenna designs and
performance. For its ampliers, Wilson uses a double electrically insulated RF
enclosure and cell site simulators for compliance testing.
Wilson ampliers feature patent-pending Smart Technology™ that enables them
to automatically adjust their power based on cell site requirements. By preventing
oscillation, signal overload and interference with other users, these Smart
Technology™ ampliers improve network coverage areas without compromising
the carrier’s system.
All products are engineered and assembled in the company’s 50,000-square-foot
headquarters in St. George, Utah. Wilson has product dealers in all 50 states as
well as Canada and Mexico, Central and South America.
INCREASE
YOUR
BARS

Amplier Specications
Dual Band
800/1900 MHz Specications
Model Number 811210
Connectors FME-Male
Impedance (input/output) 50 Ohms
Dimensions 5 x 3.5 x 1.2 inch or 12.7 x 8.9 x 3 cm
Weight 1.03 lbs or 0.468 kg
Frequency 824-894 MHz / 1850-1990 MHz
1Passband Gain (nominal)
800 MHz (uplink/downlink) 26 dB / 26 dB
1900 MHz (uplink/downlink) 26 dB / 26 dB
220 dB Bandwidth (nominal)
800 MHz (uplink/downlink) 53 MHz / 62 MHz
1900 MHz (uplink/downlink) 112 MHz / 110 MHz
³Power output for single cell phone (uplink) 800 MHz 1900 MHz
CDMA +33.0 dBm +29.3 dBm
GSM +34.3 dBm +30.3 dBm
EDGE +34.1 dBm +30.2 dBm
AMPS +30.1 dBm
Power output for single received channel
(downlink) 800 MHz 1900 MHz
CDMA +5.1 dBm +6.8 dBm
GSM +3.2 dBm +4.4 dBm
EDGE +3.2 dBm +4.6 dBm
AMPS +3.2 dBm
4Power output for multiple
received channels (downlink).
The maximum power is reduced by
the number of channels:
Number of
channels
Maximum Power
800 MHz 1900 MHz
2 +1.0 dBm +1.7 dBm
3-2.5 dBm -1.8 dBm
4-5.0 dBm -4.3 dBm
5-7.0 dBm -6.3 dBm
6 -8.5 dBm -7.8 dBm
Noise Figure (typical) 3.5 dB nominal
Isolation uplink/downlink more than 50 dB
Power Requirements 12 V, 2 A (subject to uplink power)
Notes:
1. Nominal gain is the maximum gain at any frequency in the passband.
2. Nominal bandwidth is the difference between two frequencies that are adjacent to the passband where the amplication is 20 dB
lower than the passband amplication. One of the frequencies is lower than the passband and the other is higher.
3. The Manufacturer’s rated output power of this equipment is for single carrier operation. For situations when multiple carrier
signals are present, the rating would have to be reduced by 3.5 dB, especially where the output signal is re-radiated and can
cause interference to adjacent band users. This power reduction is to be by means of input power or gain reduction and not by
an attenuator at the output of the device.
4. The maximum power for 2 or more simultaneous signals will be reduced by 6 dB every time the number of signals is doubled.
Wilson
®
Electronics, Inc.
3301 East Deseret Drive, St. George UT 84790
For additional Technical Support visit
www.wilsonelectronics.com
Phone: [phone] Fax: [phone]
AIG SB 006 / 10.20.06
