WilTec SUNSUN Skimmer CSP-40 User manual

Operation Manual
Skimmer CSP-40
51191
Illustration similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.

© by WilTec Wildanger Technik GmbH Item 51191 Page 2
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
The information contained in this document may alter at any time without previous notice. It is prohibited
to copy or spread any parts of this document in any way without prior written allowance. All rights re-
served.
The WilTec Wildanger Technik GmbH cannot be held accountable for any possible mistakes in this
operating manual, nor in the diagrams and figures shown.
Even though, the WilTec Wildanger Technik GmbH has undergone biggest possible efforts to ensure
that the operating manual is complete, faultless and up to date, mistakes cannot be entirely avoided.
If you should find a mistake or wish to make a suggestion for improvement, we look forward to hearing
from you.
Send an e-mail to:
[email protected]
or use our contact form:
https://www.wiltec.de/contacts/
The most recent version of this manual in various languages can be found in our online shop via:
https://www.wiltec.de/docsearch
Our postal address is:
WilTec Wildanger Technik GmbH
Königsbenden 12
52249 Eschweiler
Germany
Do you wish to pick goods up? Our pick-up address is:
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
Germany
To shorten the waiting time and allow for a rapid on-site transaction, we ask you to call us previously or
placing your order via the webshop.
E-mail: [e-mail]
Tel:[phone]
Fax: [phone]
To return orders for exchange, repair or for other purposes, please use the following address. Attention!
To allow for a smooth execution of your complaint or return, it is important to contact our customer
service team before returning the goods.
Returns Department
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
E-mail: [email protected]o
Tel:[phone]
Fax: [phone]

© by WilTec Wildanger Technik GmbH Item 51191 Page 3
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
Introduction
Thank you for purchasing this quality product. To minimize the risk of injury we urge that our clients
take some basic safety precautions when using this device. Please read the operation instruc-
tions carefully and make sure you have understood its content.
Keep these operation instructions safe.
Safety instructions
ATTENTION:
The device is not intended for use by persons (including children) with impaired or limited physical,
sensory and mental abilities or lack of experience and/or real knowledge, unless they are supervised by
a person responsible for their safety or you follow the instructions made by this person how to use the
device correctly. Children should be supervised to make sure they do not play with the device
ATTENTION:
•Run a visual inspection of the device before every use. Do not use the device if the safety
installations are damaged or worn out. Never override safety regulations.
•Use the device exclusively according to the intended purpose stated in the instructions for use.
•You are responsible for the safety of the working environment.
•The device cannot be installed in the drinking water circuit.
•Apply/mount the hoses and hose clamps.
WARNING:
Carefully read all the safety guidelines and the instructions. Keep the instructions and the safety
guidelines in a safe place in case you need them in the future.
Wear resistance
•The temperature of the liquid pumped should not exceed +35 ℃in permanent operation.
•The filter is exclusively designed and intended for filtering garden ponds.
•The filter is not suitable for filtrating water whose temperature exceeds 40 ℃or falls below 8 ℃.
•The filter is not frost-resistant! Therefore, it is recommended not to use the filter in winter!
Technical specifications
Max. pond surface (㎡)
40
Max. pond volume (ℓ)
100,000
Recommended flow rate (ℓ⁄h)
8,000–16,000
Height adjustability (㎜)
650–850
Max. water level tolerance (㎜)
100

© by WilTec Wildanger Technik GmbH Item 51191 Page 4
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
Drawings concerning use
Opening
Size

© by WilTec Wildanger Technik GmbH Item 51191 Page 5
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
Assembling
51191
Flow rate
(ℓ⁄h)
8000–16,000
Pond sur-
face (㎡)
40

© by WilTec Wildanger Technik GmbH Item 51191 Page 6
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
Rotation angle
Placing
Adjustable height

© by WilTec Wildanger Technik GmbH Item 51191 Page 7
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
Cleaning

© by WilTec Wildanger Technik GmbH Item 51191 Page 8
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
Parts list and exploded view
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part, of this instruction
manual require the written permission of WilTec Wildanger Technik GmbH.
№.
Name
1
Big buoy
2
Filter basket
3
Filter cartridge
4
Nut 1
5
Fixing rubber
6
Expansion pipe
7
Cardan joint
8
Nut 2
9
Bottom
10
Flange
11
Outlet
12
Outlet gasket
13
Fixing Nut
