INSTALLATION INSTRUC T IONS
Page 1 of 4
FCB CROSS BAR
⚫Please read the instruction completely before installation
⚫The figures here are for reference only and may have slight differences with the actual product
you as we may upgrade the product occasionally. The fitting methods will not have changed.
⚫Mild soap may be used also to clean the Product.
⚫Please periodically check and retighten all the hardware
NO.
QTY
NAME
○
1
2
Cross Bar
○
2
4
Bracket Of FCB Cross Bar
○
3
4
Plastic cover
PART#PW02127001
Parts list
Care and Cleaning
Before Installation

INSTALLATION INSTRUC T IONS
Page 2 of 4
○
4
4
Plastic gasket 2
○
5
2
Key(Plastic)
○
6
8
Self tapping screw ST6*16
○
7
1
Allen wrench S=5
Step 1：Try to attach cross bar brackets ○ 2 and test if the base matches your roof rails，If it
doesn’t，it is necessary to replace plastic gasket to No.2○ 4：
As below, use Key○ 5 to release the cover; use ○ 7 allen wrench S=5 to remove the bolt for the
replacement of gasket and restore the cover back after that.
Installation Steps
1
2

INSTALLATION INSTRUC T IONS
Page 3 of 4
Step 2: As below, assemble brackets○ 2 together with the cross bar ○ 1；
Step 3：
3-1、Adjust distance of two cross bar on the roof and place it to perfect position according to its size:
3-2、Using○ 7 allen wrench S=5 to fasten the bolts on the brackets for the cross bar fixing.
3-3、Optional: if there are holes in your roof rail already, you can use ○ 7allen wrench S=5 to fasten the
brackets to those holes using the existing holes on the bracket. You may use ○ 6self-tapping screw ST6*16
Remember to replace the plastic cover back with the key○ 5
3-5、Place plastic cover ○ 3 to both end of the cross bar
3-6、Please keep the key○ 5 and ○ 7allen wrench S=5 in your possession
3-7、Installation complete
3
4
NOTICE： PLEASE KEEP THE BOLTS
LOOSE. THIS ALLOWS THE
BRACKETS ○ 2 TO BE
ASSEMBLED WITH THE CROSS BAR
○
1SMOOTHLY.
1
2

INSTALLATION INSTRUC T IONS
Page 4 of 4
Any damages and losses caused by improper installation and application, goes beyond our quality
warranty.
NOTE
○
7
○
2
○
6fasten the brackets with self-tapping screws.
○
