Wincor Nixdorf KA19 User manual

KA19
Cash Drawer
User Guide

Ihre Meinung/ Your
opinion:
Uns interessiert Ihre Meinung
zu dieser Druckschrift.
Schicken Sie uns bitte eine
Information, wenn Sie uns
kontruktive Hinweise geben wollen:
Dafür bedanken wir uns im voraus.
Mit freundlichen Grüßen
Wincor Nixdorf GmbH & Co. KG
Dokumentation RD PD1
Wernerwerkdamm 16
Gebäude 36
D-13629 Berlin
Fax: ++49 30 386 43065
We would like to know your
opinion on this publication.
Please send us a copy of this page
if you have any contructive criticism.
We would like to thank you in
advance for your comments.
With kind regards,

Herausgegeben von/Published by Wincor Nixdorf GmbH & Co. KG
D-33094 Paderborn
Printed in Singapore 01750048959A

KA19
Cash Drawer
User Guide
Edition January 2000

Copyright© Wincor Nixdorf GmbH, & Co. KG, 2000
The reproduction, transmission or use of this document or its contents is not
permitted without express authority.
Media GXm™ is a registered trademark of the National Semiconductor Corporation
Linux™ is a registered trademark of Linus Torvalds
Pentium™ is a registered trademark of the Intel Corporation
MS-DOS™, Windows 95™, Windows 98™, Windows NT™ and Windows CE™ are
registered trademarks of the Microsoft Corporation
BEETLE™ is a registered trademark of Wincor Nixdorf GmbH

Contents
Manufacturers Certification ................1
FCC-Class A Declaration .........................1
Care of the KA19 .............................2
Warranty..................................2
Recycling the KA19 ............................3
Before switching on the System ......................4
Unpacking and checking the System ..................4
Cabling of the KA19 ..........................4
TheKA19CashDrawer..................5
General ..................................5
Summary of features ..........................6
Setting up the cash drawer ........................6
Emergency opening ............................6
Activating the cassette cash drawer ...................6
The money compartments ................7
The bank note compartments .......................7
The coin trays ...............................7
Connection system ....................8
Technical data .......................9
Appendix .........................10
Installation instructions..........................10
Installation ................................10

Manufacturers Certification
The device complies with the requirements of the EEC
directive 89/336/EEC with regard to ‘Electromagnetic
compatibility" and 73/23/ECC “Low Voltage Directive”.
Therefore, you will find the CE mark on the device or packaging.
FCC-Class A Declaration
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense.
Le présent appareil numérique ne génère pas de bruits radioélectriques
dépassant les limites applicable aux appareils numériques de la “Class A”
prescrites dans le Règlement sur le brouillage radioélectrique édicté par le
ministère des Communications du Canada.
1
FCC-CLASS A DECLARATION

Care of the KA19
Clean your KA19 at regular intervals with a suitable commercially available
surface cleaner. Make sure that the power plug is disconnected, connector
cables are unplugged and that no liquid finds its way into the device.
Warranty
Wincor Nixdorf guarantees a limited warranty engagement for 12 months
beginning with the date of delivery. This warranty engagement covers all
those damages which occur despite a normal use of the product.
Damages because of
nImproper or insufficient maintenance,
nImproper use of the product or unauthorized modifications of the
product,
nInadequate location or surroundings
will not be covered by the warranty.
All parts of the product which are subject to wear and tear are not included
in the warranty engagement. Please order spare parts at the Wincor Nixdorf
customer service.
CARE OF THE KA19
2

Recycling the KA19
Environmental protection does not begin when
it comes time to dispose of the KA19; it begins
with the manufacturer. This product was
designed according to our internal norm
“Environmental conscious product design and
development”
The KA19 is manufactured without the use of CFCs und CCHS and is
produced mainly from reusable components and materials.
The processed plastics can, for the most part, be recycled. Even the
precious metals can be recovered, thus saving energy and costly raw
materials.
Please do not stick labels onto plastic case parts. This would help us to
re-use components and material.
You can protect our environment by only switching on your equipment when
it is actually needed. If possible, even avoid the stand-by-mode as this
wastes energy, too. Also switch your equipment off when you take a longer
break or finish your work.
At this time, there are still some parts that are not reusable. Wincor Nlxdorf
guarantees the environmentally safe disposal of these parts in the Siemens
Recycling Center, which is certified pursuant to ISO 9001.
So don’t simply throw your KA19 on the scrap heap when it has served its
time, but take advantage of the environmentally smart, up-to-date recycling
methods!
Please contact your competent branch or the Recycling Center Paderborn
(for European countries) for information on how to return and re-use devices
and disposable materials under the following fax number:
Fax: [phone]
The center is always ready to answer any questions you may have about
Wincor Nixdorf GmbH environmental protection policies. We look forward to
your fax.
3

Before switching on the System
Unpacking and checking the System
Unpack the parts and check to see whether the delivery matches the
information on the delivery note.
If damage has occurred during shipping or if the package contents do not
match the delivery note, promptly inform your Wincor Nixdorf sales outlet.
Transport the device only in its original packaging (to protect it against
impact and shock).
Cabling of the KA19
Always make sure that the system is switched off when you do cabling
works.
Important Note
First connect the signal cable with the cash drawer. Then connect it to the
host system (BEETLE or printer).
Before switching on the System
4
