Wincor Nixdorf KA21 User manual

KA21
Cassette Cash Drawer
Product Manual

Wincor Nixdorf International GmbH
Documentation R&D SAT11
Wohlrabedamm 31
D-13629 Berlin
E-Mail: [e-mail]
Order-No.: 01750050189G

KA21
Cassette Cash Drawer
Product Manual
Edition March 2015

All brand and product names mentioned in this document are trademarks of their respective owners.
Copyright © Wincor Nixdorf International GmbH, 2015
The reproduction, transmission or use of this document or its contents is not permitted without
express authority. Offenders will be liable for damages. All rights, including rights created by patent grant or
registration of a utility model or design, are reserved. Delivery subject to availability; technical modifications
possible.

Contents
Contents................................................................................5
Introduction ..........................................................................1
Warranty................................................................................... 1
Important Note......................................................................... 1
About This Manual.................................................................... 2
Manufacturer’s Declaration and Approval ............................... 2
FCC-Class A Declaration ............................................................ 2
Recycling the KA21.................................................................... 3
Care of the KA21 ....................................................................... 4
Accessories Kit .......................................................................... 4
The KA21 Cassette Cash Drawer ............................................5
General ..................................................................................... 5
Summary of Features................................................................ 6
Setting up the Cash Drawer ...................................................... 6
Release the Cash Drawer .......................................................... 6
Emergency Manual Release...................................................... 7
Activating the Cassette Cash Drawer........................................ 8
Strengthen the Spring Tension of the Cover............................. 8
Available Variants ..................................................................... 9
The Money Compartments.................................................. 10
Interface Box ....................................................................... 12
Loosen the Interface Box from the Base Plate........................ 12
Connection System.............................................................. 13
PIN Assignment Base Plate 24V / RJ12 Connector.................. 13
Appendix............................................................................. 14
Technical Data......................................................................... 14
Mounting the Base Plate......................................................... 14
Mounting the Flap for the Banknote Compartment of the KA21-5
................................................................................................ 16

KA21 Product Manual 1
Introduction
The KA21 Cassette Cash Drawer is a small, space-saving drawer with a
hinged cover, designed as a desktop model. Thanks to its compact
construction and upward opening cover, the cash drawer has a small
footprint.
It can be connected directly to the cash drawer interface provided on the
BEETLE systems.
Warranty
Wincor Nixdorf guarantees generally a warranty engagement for 12
months beginning with the date of delivery. This warranty engagement
covers all those damages which occur despite a normal use of the product.
Damages because of
improper or insufficient maintenance,
improper use of the product or unauthorized modifications of the
product,
inadequate location or surroundings
will not be covered by the warranty.
For further information of the stipulation look at your contract.
All parts of the product which are subject to wear and tear are not
included in the warranty engagement.
Please order spare parts at the Wincor Nixdorf customer service.
Important Note
First connect the signal cable with the cash drawer. Then connect it to the
host system (BEETLE or printer)!

2 KA21 Product Manual
About This Manual
This documentation is intended to help you to work with the KA21
cashdrawer and to serve as a reference work.
Notes in the manual are marked by this symbol.
This symbol is used for warnings.
The type and scope of application programs depend on the customer’s
own selection; therefore, software will not be discussed further in this
manual.
Manufacturer’s Declaration and Approval
The device complies with the requirements of the
European directives 2004/108/EC with regard to
“Electromagnetic compatibility”.
Therefore, you will find the CE mark on the device or
packaging.
FCC-Class A Declaration
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and canradiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense.
Modifications not authorized by the manufacturer may void users
authority to operate this device.

KA21 Product Manual 3
This class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003
du Canada.
Recycling the KA21
Environmental protection does not begin when it comes time to dispose of
the KA21; it begins with the manufacturer. This product was designed
according to our internal norm “Environmental conscious product design
and development”.
The KA21 is manufactured without the use of CFCs und CCHS and is
produced mainly from reusable components and materials. The processed
plastics can, for the most part, be recycled. Even the precious metals can
be recovered, thus saving energy and costly raw materials.
Please do not stick labels onto plastic case parts. This would help us to
re-use components and material. You can protect our environment by only
switching on your equipment when it is actually needed. If possible, even
avoid the stand-by-mode as this wastes energy, too. Also switch your
equipment off when you take a longer break or finish your work.
At this time, there are still some parts that are not reusable.
Wincor Nixdorf guarantees the environmentally safe disposal of these
parts in the Recycling Center, which is certified pursuant to ISO 9001 and
14001.
So don’t simply throw your KA21 on the scrap heap when it has served
its time, but take advantage of the environmentally smart, up-to-date
recycling methods.
Please contact your competent branch or the Recycling Center Paderborn
(for European countries) for information on how to return and re-use
devices and disposable materials under the following fax number:
E-Mail: [e-mail]
We look forward to your message.

4 KA21 Product Manual
Care of the KA21
Clean your KA21 at regular intervals with a suitable commercially available
surface cleaner. Make sure that the power plug is disconnected, connector
cables are unplugged and that no liquid finds its way into the device.
Accessories Kit
The KA21 is delivered with an accessories kit containing:
1 key set (to lock and unlock the cash drawer with the lock at the
front),
1 bank-note holder (to be sticked on the KA21).

KA21 Product Manual 5
The KA21 Cassette Cash Drawer
General
The KA21 Cassette Cash Drawer is a small, space-saving drawer with a
hinged cover, designed as a desktop model. Thanks to its compact
construction and upward opening cover, the cash drawer has a very
small footprint, thus allowing a variable arrangement of the working
environment.
The hinged cover’s wide opening angle makes coins and bank notes easily
accessible.
The essential components of the cash drawer are the base plate and the
electronic unit it accommodates, the plastic housing, the coin/ bank note
trays and the electromechanical lock.
KA21 Cassette Cash Drawer
