Windsor Saber Cutter series Installation guide

WINDSOR
MAINTENANCE
86393100
01) Dump & clean
recovery tank
05) Remove dome
(Air out recovery tank)
04) Plug in battery
02) Remove squeegee, rinse,
inspect blades for wear/
tear. (if damaged or worn
ip squeegee blade)
06) Turn off machine 07) Wipe down outside
of tank
03) Empty solution tank
Saber Cutter SerieS

WINDSOR
MAINTENANCE
00000000
WINDSOR
OPERATION
86393100
01) Inspect squeegee blade
for wear or torn blades
05) Transport to work area
(press green handles to
move forward) Ready
to scrub
04) Turn on machine
02) Inspect Pads
(Recommended changing
at 1/4” thickness)
06) (Make sure pads are wet
before scrub deck is lowered)
Increase water. Lower speed.
Press green button to engage
brush and solution.
03) Fill solution tank
07)
Lower Scrub Deck
Saber Cutter SerieS

WINDSOR
MAINTENANCE
00000000
WINDSOR
OPERATION
86393100
08) Lower squeegee arm
11) REVERSE: Hold white
button and green handle
to go in reverse
12) TURNING SCRUBBER
Decrease speed before
turn and pull on handle of
the side you are turning
13) DOUBLE SCRUB: (Used for
heavily soiled areas) Turn
off vacuum, make multiple
passes and turn on vacuum for
last pass
14) DEEP SCRUB
Lock the scrub deck
handle into the notch
09) Turn on vacuum and Press
accelerator handles
(Green)
10) Adjust speed to desired
pace
Saber Cutter SerieS
