Wine cellr WC18FGBK5 User manual

VERSIONFRANÇAISEP.23
Instruction manual
















Models:
WC18FGBK5 (1 zone)
WC32FGDZ5 (2 zones)
WC46FGDZ5 (2 zones)
WC94FGB5 (2 zones)
WC194FGB5 (1 zone)
PLEASE READ THIS MANUAL CAREFULLY BEFORE INSTALLATION AND USE.

2

Table of contents


INFORMATION/SAFETY INSTRUCTIONS 3 to 4
Beforeusingyourdevice 3
Importantsafetyinstructions 3
Pre-installationtips 4
INSTALLATION 5to10
Measurementsanddimensions 5
Installingthehandle 8
Reversingthedoor 8
Bottlelayoutandstorage 10
OPERATION 10to16
Winecabinetoperation 10
DisplaypanelWC18FGBK5 10
DisplaypanelWC46FGDZ5 11
Display panel WC32FGDZ5, WC94FGB5, WC194FGB5 12
Ideal temperature for serving your wine 15
Lock 15
How to remove a telescopic shelf 16
MAINTENANCE 17to18
Cleaning the wine cabinet 17
Filterchange 17
Poweroutage 17
Energy Saving Tips 18
TROUBLESHOOTING 18to20
YOURWINECELL’RWARRANTY 20to22
LimitedWarranty 20
Terms&Exclusions 21
Contactus 22
Registrationcard 22
Model and serial number of the unit 22


3

INFORMATION/SAFETY INSTRUCTIONS
Before using your device
• Remove inner and outer packing material.
• Allow the appliance to stand upright for approximately 24 hours before plugging it
in to avoid complications in the cooling system.
• Use a soft cloth with warm water to clean the inside and outside.
Important safety instructions
Before using the appliance, please position and install it properly according to the
specifications in the manual. To avoid the risk of fire, electric shock or injury when using
the unit, please read and follow the precautions suggested in this manual.
• Never clean any part of the unit with flammable liquids that may cause a fire or
explosion hazard.
• Do not store gas or other flammable products near the appliance.
• Do not plug or unplug the appliance when your hands are wet.
• Unplug the appliance or disconnect the power supply before making a service call,
servicing or cleaning the appliance. Failure to do so may result in electric shock or
death.
• Do not attempt to replace or repair any parts on the appliance unless specified in
the manual or refer servicing to a qualified technician.
• The front of the appliance must not be obstructed in any way to ensure adequate
ventilation.
• This appliance is designed and intended for use by persons who are familiar with the
operation of electrical appliances. All other persons (including children) must be
supervised or instructed in advance by a person responsible for their safety.
• Children must be supervised not to play with the appliance.
• Do not use solvent-based or abrasive cleaners inside the appliance, as these may
discolour the interior.
• Do not use this unit for any purpose other than recommended.
• The use of an extension cord is not recommended by the manufacturer and may be
dangerous.
• When disposing of the appliance, be sure to remove the door and leave the shelves
in place to prevent children from climbing inside. Make sure that the cooling and
heating circuit at the bottom rear of the unit is not damaged. The symbol on the
product or on its packaging indicates that this appliance is not a product to be
disposed of in the household waste, but rather should be taken to an appropriate
recycling facility for electrical appliances.

4

Pre-installation tips
This appliance is designed for flush-mounted or freestanding installation
• The appliance is intended to be used exclusively for the storage of wine.
• Place your wine cabinet on a flat floor strong enough to support it when fully loaded.
• It is important that the appliance is level to operate properly (check with a level
from left to right and front to back). You can adjust the feet of the appliance to level
it.
• Make sure that there are enough people to move and install the appliance to prevent
damage to the appliance or people. When moving the appliance, do not tilt it more
than 45 degrees.
• The appliance must be installed away from heat sources such as heating system,
radiator, oven. Direct sunlight can affect the acrylic coating and heat sources can
increase the energy use of the wine cabinet. Cold and extreme ambient
temperatures can also cause malfunctions of the appliance.
• Avoid placing the appliance in damp locations.
• Once in its location, wait 24 hours before plugging in the appliance.
• Make sure that the voltage/current indicated on the label matches your supply
voltage. Plug the appliance into a 3-pin socket, do not remove the grounding rod.
Do not use an adapter and do not use an extension cord.
• It is recommended to plug the wine cabinet into a power bar with surge protector.
• It is recommended to provide a separate circuit for your appliance.
• The fuse (or circuit breaker) size should be 15 A or greater.
• Any questions regarding the power supply and/or grounding should be directed to
an electrician or an authorized service center.







5

INSTALLATION
Measurements and dimensions
The cut-out dimensions shown below allow door clearance and access to the sliding shelves
when the wine cabinet is installed as a flush-mounted appliance.
Your wine cabinet has been manufactured with a zero-clearance door, so no additional
space is required to accommodate door swing when building your cabinets.
These cut-out dimensions indicate the minimum space required for your wine cabinet to
function as intended.
Note that the plug on the socket requires 38 mm of clearance at the rear when plugged in
and the handle is a maximum of 45 mm deep, depending on the model.
WC18FGBK5

6

WC32FGDZ5
WC46FGDZ5

7

WC94FGB5

WC194FGB5

8

Installing the handle (WC18FGBK5 and WC46FGDZ5 only)
1. Move the door seal behind the handle with your finger. In some models, plastic caps
cover the screws; remove them to expose the screws.
2. Insert the screws into the pre-drilled holes in the handle.
3. Install the handle and tighten the screws.
4. Replace the seal and the door caps.
Reversing the door (WC18FGBK5 and WC46FGDZ5 only)
Before you start
Make sure the wine cabinet is level. Seal the shelves with tape to prevent movement during
the process. The door of this appliance can be installed to open on the left or right side. To
reverse the movement of your wine cabinet door and open it on the opposite side, please
follow the instructions and diagram below.
1. Open the door and unscrew the screws of the lower hinge.

9

2. Remove the door from the top hinge, remove the metal pin and remove it.
3. Use a small flat head screwdriver to lift and remove the plastic cap on the upper
center (locking hole) of the door and insert it into the lower center hole, rotate the door
180 degrees (counterclockwise) so that the top becomes the bottom.
4. Unscrew the upper and lower hinge.

5. Dislodge the plastic caps on the left side of the cabinet and change them to the right
side.
6. Install on the opposite side the left hinges included as accessories with the instruction
manual.

10

7. Screw the metal pin under the door, then install the door by retracting it into the
upper hinge and then into the lower hinge. Replace the screws of the support bar at the
bottom to secure the door.
Bottle layout and storage
Your wine cabinet has been designed to safely store a maximum number of
bottles. We recommend that you follow the tips below to optimize loading.
• Remove the tape from the shelves once the appliance is stable and ready for storage.
• Place the bottles evenly to avoid concentrating the weight in one place. Bottles should
not touch the back of the wine cabinet. Your wine cabinet has been designed to store large
bottles such as Pinot Noir and Champagne. These larger bottles reduce the number of
bottles you can place on a shelf. Make sure that not all bottles are grouped together at the
top or bottom of the wine cabinet for optimal cooling.
• Pull out only one telescopic shelf at a time. Never try to pull more than one telescopic
shelf at a time.
OPERATION
Wine cabinet operation
Your wine cabinet has a control panel with display on the front of the door. It includes
several functions that allow you to control the temperatures of both the upper and lower
zones of your wine cabinet.
Display panel model: WC18FGBK5

11

Display panel model: WC46FGDZ5
ON & OFF button
Switches the wine cabinet on or off.
Press and hold for 3 seconds.
Press lightly to activate standby mode.
Light
Switches the interior lighting on and off (3 options)
Control Panel (padlock)
WC18FGBK5: Press both left buttons simultaneously for 3 seconds to lock or unlock the control
panel.
WC46FGDZ5: Press the padlock button for 3 seconds to unlock the control panel.
Display window
Displays set and actual temperature as well as operation icons.
Temperature increase (+)
Increases the set temperature.
Decrease in temperature (-)
Reduces the set temperature.
Temperature in Celsius or Fahrenheit
By simultaneously pressing the + and - controls with the locked panel changes the
temperature display to Fahrenheit or Celsius.

12

Display panel model: WC32FGDZ5 / WC94FGB5 / WC194FGB5
a) Control panel and temperature setting
POWER:
●Press this button to turn on the control panel; the lights will turn on.
●To turn off your wine cabinet during cleaning or an extended absence, simply
press this button again and the wine cabinet will turn off.
After the appliance beeps, press and hold the power button for 10 seconds and
your wine cabinet will turn itself off. Once the wine cabinet is turned off, please
allow 5 minutes before turning it on again. This reduces excessive wear and tear
on the compressor.
UNLOCK: Press this button for 3 seconds to unlock the control panel.
LIGHT: Your wine cabinet is equipped with 3 lighting options: red, blue or a red
and blue cycle where the colours change every 10 seconds. Press the light button
once and the lights will run for a 10 second cycle, alternating between red and blue.
Press again and the color will change to blue. Press again and the color will change
to red. Finally, by pressing a fourth time, the lights will turn off.
°C/°F: Press to change the temperature display in Fahrenheit or Celsius.
SELECTION: Press the select button to choose the zone (up or down if 2
zones).
TEMP. UP: Press this button to increase the temperature by 1 degree.
TEMP. DOWN: Press this button to lower the temperature by 1 degree.

13

NOTICE:
The control panel locks automatically after 15 seconds of inactivity. Be sure to unlock
the control panel before adjustment. With the exception of the power button, all other
buttons and lights will turn off after 15 seconds of inactivity.
(b) Temperature display (1 zone)
Set temperature
Actual temperature
(c) Temperature display (2 zones)
Upper zone
Lower zone
When the control panel is unlocked, the temperature display will show the preset
temperature and when the control panel is locked, the actual temperature is displayed.
IMPORTANT:
For the appliance to operate at an optimal level, the upper zone should be 4 to 7
degrees Celsius colder than the lower zone.
TEMPERATURE RANGE SELECTION  (for 1 zone model):
Press this button to change the temperature range by choosing between E, F,
H or L and wait 3 seconds to confirm your choice.
The temperature of your wine cabinet is, by default, set to E, the ideal
temperature for the storage of red wine.
NOTE: The L range allows you to go as low as the freezing point. If you choose this range
and select 0
o
C as the temperature, your bottles may freeze and damage/degrade the
contents.
Screen Temperature range
E 41-72
o
F (5-22 ℃)
F 36-68
o
F (2-20
o
C)
H 50-66
o
F (10-19
o
C)
L 32-68
o
F (0-20
o
C)

14

TEMPERATURE RANGE SELECTION (for 2 zone model):
Press this button to change the temperature range by choosing between E, F, H
or L and wait 3 seconds to confirm your choice.
The temperature of your wine cabinet is, by default, set to E, the ideal
temperature for the storage of red wine.
or
The display window can be set to the OFF position for a more discreet appearance. Your
wine cabinet will continue to operate but the display screen will not be visible. You can
check the temperature of your wine cabinet by pressing the power button.
To change the display window to ON or OFF, press the °C/°F button for 5 seconds while
the control panel is locked. Once the ON/OFF button flashes, press °C/°F a second time
to access the interface option. The ON light will display the data on the screen
permanently and the OFF light will turn the screen off. Leave the control panel untouched
for 5 seconds to confirm your option.
NOTICE:
Temperatures may vary if the interior lighting is on or depending on the position of the
bottles.
Before you start:
The wine cabinet must be installed in a location where the ambient temperature is between
60-80 °F or 15-27 °C. If the ambient temperature is outside this recommendation, the
performance of the wine cabinet may be affected. Installing your appliance in extremely
cold or hot conditions may cause temperature fluctuations inside your wine cabinet.
Screen Temperature range
upper zone
Temperature range
lower zone
E 41-54oF (5-12℃) 54-72oF (12-22℃)
F 36-54oF (2-12oC) 54-68oF (12-20oC)
H 41-54oF (5-12oC) 46-66oF (8-19oC)
L 36-50oF (2-10oC) 54-72oF (12-22oC)

15

NOTICE:
If the appliance is unplugged, breaks down or is disabled, you must wait 5 minutes
before restarting it. Attempting to restart before this time may prevent the wine cabinet
from starting.
When you use your wine cabinet for the first time or restart it after a power failure for
a long period of time, there will be a difference of a few degrees for the first few hours
of operation between the temperature you choose and the temperature shown on the
display. After a few hours the temperature will normalize to the temperature shown on
the display.
The control panel has a "sleep mode" function to hide the control buttons and display digits.
If you gently/shortly press the "on/off " button, all the control buttons will turn off; then,
if you gently touch one of the buttons, the whole panel will turn on again.
You also have the option of turning off the temperature digit display when the control panel
goes into sleep mode while locked. Simply press and hold the LIGHT button for 3 seconds;
the temperature digits will darken.
Ideal temperature for serving your wine
Although the optimal storage temperature is generally considered to be between 53-57°F
or 12-14°C, different varieties of wine have different recommended tasting temperatures
for optimal taste. The recommended temperature ranges for serving different grape
varieties are listed below.
Note:
If the appliance is unplugged, loses power or is turned off, you must wait 5
minutes before restarting it. The compressor will not restart before this delay
and the wine cabinet will not be able to cool down before this 5 minute wait.
When you use the wine cabinet for the first time or if you restart it after a long
period of shutdown, there will be a variation of a few degrees between the
temperature you select and the temperature indicated on the control panel for
the first hours of operation. After a few hours of operation, the temperature will
normalize to the selected temperature.
Lock
This appliance comes with a key lock.
The keys are located inside the plastic bag containing the user manual. To unlock the
door, insert the key into the lock and turn counterclockwise.
To lock the door, simply reverse the operation, making sure the metal pin is fully
engaged. Then, remove the key and place it in a safe place for safekeeping.
59-65 °F
15-18 °C
45-52 °F
7-11 °C
40-45 °F
4-7 °C
Champagnes
White wines
Red wines

16

Models with 94 bottles or more Models with less than 94 bottles
How to remove a telescopic shelf
1. Remove all bottles.
2. Pull the shelf out as far as it will go
3. Hold one of the telescopic shelves with one hand and with the other hand, gently lift
the front of the shelf by the front tab, then push backwards to unlock the rear hook.
4. Repeat on the other side.


17

MAINTENANCE
Cleaning the wine cabinet

Close the wine cabinet and unplug it. Remove the bottles and shelves inside.

Clean interior surfaces with a sponge and baking soda.
• The solution is 2 tablespoons mixed with 1 litre of warm water.

Wash the shelves with mild soap.

Remove excess water from the sponge or cloth before cleaning the control panel or
electrical parts.

Clean the outside of the cabinet with warm water, a cloth, and mild soap. For stainless
steel grills and doors, use a cleaner specially designed for this type of surface.

Vacuum the front grille and the back of the appliance twice a year.
• Make sure the power is turned off before cleaning.

It is recommended to clean the appliance thoroughly inside and out once a year to
maximize the longevity of the wine cabinet and the finish of the various materials.
Filter change
The active carbon filter should be replaced once a year. It
preserves the efficiency of your wine cabinet. To remove it,
grasp the rim with your fingers and turn it to the left or
right, pulling slightly until the holes in the panel and the
plastic pins on the filter are aligned. To replace it, align and
retract the plastic pins, then rotate to lock it in place.

Power outage

• Most power outages are resolved within a few hours. This should in no way affect the
temperature of your wine cabinet, if you minimize the opening of the door. If the power
outage persists for a long period of time, you must take the necessary measures to
protect your bottles.

• If the appliance is unplugged, loses power or is turned off, you must wait 5 minutes
before restarting it. The compressor will not restart before this delay and the wine
cabinet will not be able to cool down before this 5 minute wait.



18

Energy Saving Tips

• The wine cabinet should be located in the coldest part of the room, away from heat-
producing appliances and out of direct sunlight.
• Regularly check that the door is properly closed and that the door seal sticks to the
wine cabinet.
• Fill the wine cabinet as much as possible (min. 50%); the more the contents, the
more stable the temperature will be and the compressor will run less often.
TROUBLESHOOTING
Many common problems can be solved very easily. Follow the troubleshooting tips below
if you encounter any problem:
No. PROBLEM CAUSES & SOLUTIONS
Check if it is plugged in.
The cellar is not turned ON.
The circuit is closed or a fuse is blown.
It should be the only device plugged into the outlet. It is
recommended to provide a 15 amp circuit dedicated
exclusively to the cellar.
Check the temperature parameters on the control.
The outdoor environment requires cooler temperature
settings on the control.
The door is often open.
The door is not completely closed.
The door seal does not close well.
3
The temperature of my cellar
often varies from 3-4 degrees.
Is this no rmal?
This is normal: sli
g
ht differences in temperature are necessary
for the proper functioning of the cellar. When the cellar begins
a defrost cycle, the temperature rises a little. When the
refrigeration system turns on again, the temperature cools
down.
These changes are taking place over short periods and their
influences are too small to affect the conservation of the
wine. The liquid tends to maintain an average temperature.
Is your cellar filled to at least 50% of its capacity? Has yo ur
cellar been running for more than 48 hours?
Your cellar is installed near a heat so urce (heater, door,
window, stove, etc.
)
.
The door is not completely closed.
The door seal does not close well.
1 My cellar is not working.
2 My cellar is not co oling enough.
4
My cellar do es not maintain its
temperature and the
compressor often starts.

19

No. PROBLEM CAUSES & SOLUTIONS
The room temperature is warmer than normal.
A lot of content has been added to the cellar.
The door is opened too often.
The temperature is not well adjusted.
Is your cellar plugged in?
The circuit is closed or a fuse is blown.
The light is closed, use the control panel to turn it on (see
Operations sectio n).
Check if the unit is level.
Make sure that no part inside your cellar (shelf / rail) or in the
back, near the compressor, is not loose (pipes that rub on
metal, broken fastener, etc.).
Noise can come from the coolant, which is normal.
At the end of each cycle, you can hear a gurgling sound
caused by the coolant.
The expansion and contraction of the interior walls can cause
creaking noises.
The unit is not level.
The installation measures were not respected, leaving too
much space between the cellar and the cabinets and
amplifying the noise of the compressor and the fan at the
back.
The ceiling height and the siz e of the room (open area) may
also increase the sound (echo effect).
The unit is not level.
The door was reversed and installed inco rrectly.
The door is open but the lock is lo cked.
The gasket is dirty.
Shelves are improperly installed on the rails or bottles that are
too large or improperly placed prevent a shelf from closing.
Adjust the leveling feet at the front until the do or is equal to
the cellar.
The hinge screws are not tight enough; replace the door
equal to the box and tighten the screws.
11 A shelf in my cellar is not level. Make sure that the shelf is properly secured on its rails.
8My cellar seems to be making
too much noise.
9The door does not close
properly.
10 The door of my cellar is not
equal to the box.
5My cellar auto matically clo ses
ON / OFF frequently.
6 The light does not work.
7 Too much vibration.

20

YOUR WINE CELL’R WARRANTY

The appliance must have been used under the normal conditions recommended by the
manufacturer. Proof of the date of original purchase is required to obtain warranty
service, as well as the serial number of the appliance (white sticker inside, bottom
right; e.g.: 2020010123, see p.22). All warranty repairs are carried out by our authorized
repair center, taking into account the conditions and exclusions described below. Warranty
applicable in Canada only.
2-year limited warranty on parts and labour
Wine Cell'R will provide, at its discretion, all parts that prove to be defective due to a defect
in material or workmanship and will also provide, free of charge, labour and repair services
to replace said defective parts, and this, 2 years from the date of purchase.
3-year limited compressor warranty
During the first 2 years of the warranty (from the date of purchase), Wine Cell'R will replace
the defective compressor free of charge for parts and labour, as long as the appliance has
been installed and used according to the instructions supplied with the appliance.
During the third year of the warranty, Wine Cell'R will only replace the compressor. The
costs of labor, transportation or other costs will be at the expense of the purchaser. In the
event that the appliance must be returned to the shop, the cost of the transfer and return
home will be at the expense of the purchaser.
An extended warranty may be available for an additional cost at the time of purchase.
Please check with your dealer for details.
No. PROBLEM CAUSES & SOLUTIONS
Check that the drain is in the evaporation tray at the back of
the cellar. If so, during very humid periods, you may need to
soak up the excess water in the pan.
Make sure the cellar is leveled from front to back and left to
right.
13 Water collects inside my cellar.
This is a phenomenon observed especially in summer due to
humidity. Check that the door seal is watertight. During very
humid weather, it is recommended to sponge off the excess
water that forms inside your cellar and if necessary in the
back pan near the compressor.
14 There is frost on back wall of
my cellar.
This is a very normal phenomenon when water vapours
freeze. However, when the cooling cycle ends, the ice melts
and runs down the drain. These drops normally evaporate.
15
There is steam / humidity
between the thermal windows
of my cellar.
During very wet periods, mainly in summer, this can happen.
16
The digital display shows HH or
LL and a continuous beep is
heard.
The temperature sensor is non-functional and must be
replaced.
12 There is water on the floor of
my cellar.
