Rev1 2-16 2452358
For poles with outer diameters between 1"to 1-1/8"
Designed
for RV use
INSTALLATION MANUAL
WARNING: DO NOT USE THE LADDER MOUNT AS A STEP!
SATELLITE TV ANTENNA
LADDER MOUNT MT-4000
MT-4000 CONTENTS
A•Extension Tube (1)
B•Ladder Bracket (2)
C•Mounting Plate (1)
D•Hardware Bag (1)
For a complete list of all compatible antennas, visit
www.winegard.com/mounts
C
B (Left & Right Bracket)
A
E F G HIJ K
E•Locking Bolt (1)
F•Carriage Bolt (8)
G•Nylock Nut (8)
H•Flat Washer (8)
I•Lock Washer (1)
J•Dome Screw w/blue
coating (6)
K•Rubber Foot Screw
w/blue patch (4)
D•Hardware Bag Contents:
Manual disponible en español
en www.winegard/support
Manuel disponible en français
au www.winegard/support
|
2”
MT-4000 Ladder Mount Assembly:
Determine how far from the ladder or mounting
pole you will need the antenna. Use Figure 1 to
determine which of the mounting holes will best
meet your application.
1) Line up the two holes in the left mounting
bracket shown in Figure 1 with the two holes
on the extension tube that will work best for
your application.
2) From the flat or outside of the left mounting
bracket, insert a carriage bolt into each of
the two holes you lined up in Step 1. Refer
to Figure 2.
3) Place the right mounting bracket on the
extension tube so that the bolts you inserted
in Step 2 extend through the holes in the right
mounting bracket. Place a flat washer and
thread one of the nylock nuts onto each of
these bolts.
DO NOT TIGHTEN AT THIS TIME!
4) Install the mounting plate by lining up the two
holes shown in Figure 3 with the two holes on
the top of the extension tube.
NOTE: The mounting plate may be installed with either
surface facing up.
With the holes lined up, insert a carriage bolt
into each of the holes so that the head of the
bolt is on top of the mounting plate.
5) Place a flat washer and thread one of the nylock
nut onto each of the two bolts holding the
mounting plate to the extension tube. Tighten
these nuts, making sure they are snug, see
Figure 4.
Mounting
holes
Line up these two holes
with extension tube.
Extends from 19.5” to 23.5” in
2” increments. (3 positions -
Extended, Mid, Retracted).
FIGURE 1
FIGURE 2
FIGURE 3
FIGURE 4
Carriage
bolts
Carriage bolts
Carriage bolts
Locking bolt alignment
Installing the Ladder Mount:
WARNING: The MT-4000 Ladder Mount with antenna
installed weighs 20 lbs. Verify that your mounting pole
can support this weight while you travel.
1) Spread the left and right mounting brackets
apart to allow the ladder mount to slide onto
the rail of the ladder or mounting pole.
2) Insert two carriage bolts into the top two holes
shown in Figure 5. Place a flat washer and
thread a nylock nut onto each bolt. Move the
ladder mount to the desired height. When the
ladder mount is in place, tighten the two nuts
until they are snug.
3) Tighten the nuts holding the brackets and extension
tube together. Make sure these nuts are snug.
4) Insert the last two carriage bolts into the bottom
two holes. Place a flat washer and thread a
nylock nut onto each of these bolts and tighten
the nuts until they are snug.
Attaching the Antenna on the Ladder Mount:
1) Disconnect the power and coax cables from the
base of the antenna.
2) Remove the dome screws with a Phillips
screwdriver, and lift off the dome. Locate and
remove the security loop nuts, remove the
security loop and reattach the dome using
the new dome screws included with the
ladder mount.
3) Remove rubber feet from dome and reinstall
using new rubber foot screws included in the
ladder mount.
4) Set the antenna on the mounting plate, lining
up the feet of the antenna so that they fit into
the holes in the mounting plate.
NOTE: Locate the hole in the base of the antenna and line
it up with the hole in the mounting plate for the locking
bolt before attaching the antenna, see Figure 6.
5) Twist the antenna to rotate the feet into the slots
that hold the antenna in place while travelling.
6) Slide the lock washer onto the threads of the
locking bolt.
NOTE: To rotate the cable connections
180o, simply flip the mounting plate over
and install it in the opposite direction.
FIGURE 5
FIGURE 6
WARNINGS:
• The MT-4000 Ladder Mount with the antenna installed
weighs 20 lbs. Verify that your mounting pole can support
this weight while you travel.
• The antenna needs a clear view of the southern sky. The
vehicle will either need to park with the ladder mount
facing south or the ladder mount will need to be installed
high enough to allow the antenna to see over the vehicle.
• The antenna is for stationary use only and will
not function while the vehicle is in motion.
• All nylock nuts for the ladder mount MUST be tight to
prevent them from vibrating loose while the vehicle is
in motion.
• The locking bolt MUST be in place and tight while the
antenna is installed on the ladder mount.
Locking bolt
7) Thread the locking bolt into the hole in the
bottom of the mounting plate and into the
matching hole in the base of the antenna to
keep the unit from rotating back out of the slots
holding the antenna in place.
8) Connect the ladder mount’s coax and power
cables to the antenna.
To remove the antenna, simply reverse these steps.
WARNING: Failure to follow these instructions may lead
to property damage, personal injury, and/or death.
Winegard Company • 3000 Kirkwood Street • Burlington, IA 52601 • 1-800-288-8094 • Fax 319-754-0787 • www.winegard.com
Printed in U.S.A. ©2015 Winegard Company Rev1 2/16 2452358
Disclaimer: Although every effort has been made to ensure that the information in this manual is correct and complete, no company shall
be held liable for any errors or omissions in this manual. Information provided in this manual was accurate at time of printing. If the antenna
mount does not function as expected, please contact Winegard Company at help@winegard.com or 1-800-788-4417, or visit our website at
www.winegard.com.
WINEGARD MOBILE PRODUCTS LIMITED WARRANTY
(2 YEARS PARTS; 1 YEAR LABOR)
Winegard Company warrants this product against defects in materials or workmanship for a period of two (2) years from the date of original
purchase. During year one (1) of such warranty, Winegard Company will also pay authorized labor costs to an authorized Winegard dealer
to repair or replace defective products. No warranty claim will be honored unless at the time the claim is made, Customer presents proof of
purchase to an authorized Winegard dealer (to locate the nearest authorized Winegard dealer, contact Winegard Company, 3000 Kirkwood
Street, Burlington, Iowa 52601, Telephone 800-288-8094 or visit www.winegard.com). Customer must provide proof of purchase with a dated
sales receipt for the Winegard product to verify the product is under warranty. If the date of purchase cannot be verified, the warranty period
shall be considered to begin thirty (30) days after the date of manufacture.
If a defect in material or workmanship is discovered, Customer may take the product to an authorized Winegard dealer for service. Customer
must provide proof of purchase to verify the product is under warranty. If the product is brought to an authorized Winegard dealer for service
prior to expiration of year one (1) of the warranty period and a defect in material or workmanship is verified by Winegard Technical Services,
Winegard Company will cover the Winegard dealer’s labor charges for warranty service. The Winegard dealer must contact Winegard Technical
Services in advance for pre-approval of the service. Approval of the service is at the sole discretion of Winegard Company.
Alternatively, Customer may ship the product prepaid to Winegard Technical Services (located at 2736 Mt. Pleasant Street, Burlington, Iowa
52601, Telephone 800-788-4417). Customer must return the product along with a brief description of the problem and provide Winegard
Technical Services with Customer’s name, address, and phone number. Customer must also provide proof of purchase to verify the product is
under warranty. If the product is returned before the expiration of the warranty period, Winegard Company will (at its option) either repair or
replace the product.
This Limited Warranty does not apply if the product has been damaged, deteriorates, malfunctions or fails from: improper installation, misuse,
abuse, neglect, accident, tampering, modification of the product as originally manufactured by Winegard in any manner whatsoever, removing
or defacing any serial number, usage not in accordance with product instructions or acts of nature such as damage caused by wind, lightning,
ice or corrosive environments such as salt spray and acid rain. This Limited Warranty also does not apply if the product becomes unable to
perform its' intended function in any way as a result of the television signal provider making any changes in technology or service.
RETURN AUTHORIZATION POLICY
A Return Material Authorization (RMA) is required prior to returning any product to Winegard Company or Winegard Warranty Services under
this warranty policy. Please call our Technical Services Department at 800-788-4417 or send an email to [email protected] to obtain
the RMA number. Please furnish the date of purchase when requesting an RMA number. Enclose the product in a prepaid package and write
the RMA number in large, clear letters on the outside of the package. To avoid confusion or misunderstanding, a shipment(s) without an RMA
number(s) or an unauthorized return(s) will be refused and returned to Customer freight collect.
WINEGARD COMPANY DOES NOT ASSUME ANY LIABILITIES FOR ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, MADE BY ANY OTHER
PERSON.
ALL OTHER WARRANTIES WHETHER EXPRESS, IMPLIED OR STATUTORY INCLUDING WARRANTIES OF FITNESS FOR A PARTICULAR
PURPOSE AND MERCHANTABILITY ARE LIMITED TO THE TWO YEAR PERIOD OF THIS WARRANTY.
In states that do not allow limitations on implied warranties, or the exclusion of limitation of incidental or consequential damages, the above
limitations or exclusions do not apply.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion of limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you.
This warranty gives Customer specific legal rights. Customer may also have other rights that may vary from state to state.
SATELLITE RECEIVER WARRANTY
See manufacturer’s limited warranty policy.
WS-MOBWARREV3
