Winners Only SOLID FIXTOP T1-GL42R--O User manual

PARTS LIST
PART NO FIGURE DESCRIPTION Q'TY
Table Top
Leg 4 Pcs
1 Pc
1 Pc
Hardware Bag
2 Pcs
Shelf Panel 1 Pc
T1-GL42R--O-01
T1-GL42R--O-07
T1-GL42R--O-07
T1-GL42R--O-13
T1-GL42R--O-13
T1-GL42R--O-11
T1-GL42R--O-11
T1-GL42R--O-18
T1-GL42R--O-18
TFS-16492-QNNNWC1 MADE IN MALAYSIA
PAGE 1 OF 2
SOLID FIXTOP DINING TABLE
T1-GL42R--O
Mounting Plate

MADE IN MALAYSIA
HARDWARE PART :
NOTE : THE UNIT SHOULD BE ASSEMBLED BY 2 OR MORE PEOPLE.
PAGE 2 OF 2
TFS-16492-QNNNWC1
SOLID FIXTOP DINING TABLE
T1-GL42R--O
STEP 1
Place leg to the Shelf Panel and use Hex Bolt, Lock
Washer, Flat Washer and Wrench to tighten each Leg.
(Do not fully tighten yet.)
STEP 2
Turn the base Assembly upright. Attach Mounting Plate onto hanger
bolts, insert Flat Washers, Lock Washers and Hex Nuts onto the
hanger bolts. Fully tighten all Hex Nuts and Hex Bolt with the
Wrench provided.
4 pcs
Wrench Allen Key
1 pce 1 pce
Hex Nut Flat Washer Flat Washer
12 pcs
Lock Washer Lock Washer
12 pcs
8 pcs
Hex Bolt
8 pcs 8 pcs
8 pcs
JCBC Bolt
Hex Bolt
Lock
Washer
Flat
Washer
Wrench
STEP 4
Wrench
AllenKey
Hex Nut
JCBC Bolt
Flat Washer
Flat Washer
Lock Washer
Lock Washer
Base assembly
Adjust the levelers
to level the unit.
leveler
Place the Table Top upside down on a protective surface such as
carpet. Align and Attach Base Assembly to the Table Top.
Insert Flat Washer, Lock washer and JCBB Bolt through the
pre-drilled hole of the the Mounting Plate into the pre-drilled hole
of the base assembly.Then tighten the bolts by using Allen Key
provided .
CARE INSTRUCTION
~ Be sure to use the same type of polish consistenly.
Your furniture will appear cloudy or streaky if oil
based or wax based polishes are interchanged.
~ Spray your furniture surface evenly. Wipe in a
circular motion with a soft clean cloth.
IMPORTANT NOTE :
~ Please keep all hardware out of the reach of
children. Two or more people are needed for
assembly.
IMPORTANT NOTE :
1. Use only the hardware supplied.
2. Do not over-tighten bolts.
3. This item may require periodic tightening.
