Access®5000 Raceway System
INSTALLATION INSTRUCTIONS
Installation Instruction No.: 40478R5 – Updated July 2005
Wiremold Electrical Systems conform to and should be installed
and properly grounded in compliance with requirements of
the current National Electrical Code, Canadian Electrical Code or
codes administered by local authorities.
All electrical products may represent possible shock or fire
hazard if improperly installed or used. Wiremold electrical
products are UL listed. Made for interior use only and should
be installed in conformance with current local and/or the
National Electrical Code.
The Access 5000 Series Raceway is made up of three components: Base, Cover and Trim Cover. The Trim Cover is to
be used for decorative purposes only.
El conducto para cables Access Serie 5000 se compone de tres elementos: Base, cubierta y moldura de la cubierta.
La moldura de la cubierta se usa sólo con fines decorativos. La moldura de la cubierta no deberá usarse como un
compartimento adicional para cableado.
Le chemin de câbles Access de la série 5000 est composé de trois éléments : base, cache et moulure. Cette dernière
remplit une fonction purement esthétique. Elle ne doit pas être utilisée comme un logement de câbles supplémentaire.
