1Overview
The following information will guide the installer through simple set up and programming of a Control4 system to
display video from Wirepath™ IP Cameras or Encoders on a Control4 interface.
These instructions will work with IP cameras or encoders with any released firmware. Please read the entire
document before performing any setup of the IP Camera, Encoder or the Control4 system.
1.1 Products Covered
WPS-300-ENC-1IP 1 Channel Encoder
WPS-300-ENC-4IP 4 Channel Encoder
WPS-500-PTZ-IP PTZ IP Indoor Camera
WPS-750-BUL-IP Bullet IP Outdoor Camera
WPS-750-DOM-IP Dome IP Outdoor Camera
1.2 Contacting Technical Support
Phone:
[phone]
[phone]
Email:
[e-mail]
2Before Beginning
Before you begin, have the following items at hand so that the installation can be performed efficiently:
Wirepath IP Camera or Encoder with the most recent firmware version, installed on the local network.
Control4 System and Project
Control4 Composer software with the latest Driver library and knowledge of the use of the software
Network Router
Network Switch (if needed)
Software, Drivers, and Documents from the SnapAV Website
oOwner’s Manual for the Wirepath™ IP Camera or Encoder being installed
oIP Camera/Encoder Quick Start Guide
oRouter Setup Document (Appropriate to the router being used)
oControl4 IP Camera Drivers

WPS-IP Control4 Driver Setup and Configuration
pg. 4
www.snapav.com Support: 866.838.5052
3IP Camera/Encoder Setup
3.1 IP Camera/Encoder Connections
Connect all cameras/encoders to the network switch or router. For instructions on mounting and wiring, please see the
documentation that was included with the camera/encoder. The diagram below illustrates the typical wiring and
devices that will be used in the installation.
1Gbps Router
VIDEO INPUTS VIDEO OUTPUTS AUDIO OUTAUDIO INPUTS
1
2
3
4
1
2
1
2
3
4
3
4
ETHERNET
12V DC 1.5A
INPUT
RS-232
Wirepath IP Encoder
Internet
AC
Power
Wirepath
Analog
Bullet
Wirepath
Analog
Dome
1Gbps Switch
WPS-750-BUL-IP WPS-750-DOM-IP
WPS-500-PTZ-IP
3.2 IP Camera/Encoder Network Settings
After the IP devices are installed, network and user setup must be completed for each camera or encoder on the
network. This section covers the settings that should be made in the device, and what information will be needed
during setup in Control4 Composer.
3.2.1 Network Setup
Sections 9 and 10 in all Wirepath IP Camera and Encoder manuals address the use of the IP Installer software to find
devices, and the basic network setup of a device. Follow these instructions to set up access, and be sure to record the
following information from each device for use in Control4 Composer:
oIP Address or URL (no default, depends on network IP address settings in the router)
oHTTP Port (default: 80)
oUsername (default: admin)
oPassword (default: admin)
Important Note for WPS-750-BUL-IP and WPS-750-DOM-IP cameras: If the Access List feature is being utilized to control
which IP addresses may access the camera, the IP address of your Control4 processor must be added for streaming to
work. See section 12.5.3-Access List in the camera manual for more information.
4Router Setup
After setting up the IP Cameras/Encoders network settings, the router may need to be setup for port forwarding so that it can be
seen on the network. Download the Router Setup document appropriate for the brand of router being used from the SnapAV
website. Should a document for the brand being used not appear in the list, refer to that router’s owner’s manual for setting up
port forwarding.

WPS-IP Control4 Driver Setup and Configuration
pg. 5
© 2013 Wirepath™ Surveillance
5Control4 System Programming
The following information outlines the basic steps for configuring Wirepath™ IP Cameras or Encoders on a Control4 system. A
working knowledge of the Composer Software and experience configuring Control4 is required. Do not attempt these steps
without first gaining a working knowledge of Control4 system configuration.
5.1 IP Camera/Encoder Channel Viewing (Video Driver)
1. Download the Control4 Wirepath IP Camera/Encoder Video Drivers from the SnapAV website.
The ZIP file contains 2 drivers:
camera_ip_http_wirepath_camera_01
This driver provides Video Only, while it may be used for the WPS-500-PTZ-IP it does not provide any PTZ controls. We
recommend that this driver not be used with the WPS-500-PTZ-IP.
Note: This Video Only driver is the same as the drivers released for Wirepath Analog DVR channel streaming, so they
may be installed already if you have integrated other Wirepath products with Control4 in the past.
camera_ip_http_wirepath_camera_ptz
This driver provides Video & PTZ Control, while it may be used with the IP Dome, and Bullet, it will show the PTZ controls on
the image even though the camera does not have control. We recommend that this driver is used for the WPS-500-PTZ-
IP only.
2. Extract the drivers to Documents>Control4>Drivers. This directory may be different based on the version of Windows used or
if it was changed from default by a user.
For IP Cameras or 1-Channel IP Encoders, there is one driver file (Camera 01 or Camera PTZ) that is used to access any one
IP Camera/Encoder on the network. If you want to view multiple IP Cameras, simply repeat the instructions below using this
same driver each time.
For the 4-Channel IP Encoder, all four drivers (“Camera 01” through “Camera 04”) must be installed and used.
3. Open the latest version of Composer.
4. Connect to Director on Local Network (Controller).
5. Select the desired room under System Design.
6. Under My Drivers, Right Click the IP Cameras folder.
7. Select Add Driver.
8. In the Select the Driver window, select the manufacturer –Wirepath Surveillance.
9. Sort the list by name and find the “Wirepath Surveillance Camera 01” driver.
10. Double click to add –the camera will now appear in My Drivers under IP Cameras.
Note: If you are configuring for a 4-Channel IP Encoder, repeat Steps 6 through 10 above for all four numbered Camera
drivers.
11. Select a room for the camera.
12. Under My Drivers/IP Cameras, double-click the desired camera driver to add it to the room. Place the camera in the
project room where it is physically located for easy identification. Rename all cameras by room to further aid in
identification (for example, “Den IP Cam”, “Patio Enc Cam”).
Note: If you are configuring for a 4-Channel IP Encoder, select the Camera driver corresponding to the desired Encoder
Channel.
