WIRTGEN Hamm 3000 Series Manual

Service Training
3410-3411
Release 2011-02-01

EN ENEN
SERVICE TRAINING
3410-3411
2194850 2194850 2194850
H206
SERVICE TRAINING
3410-3411
SERVICE TRAINING
3410-3411
H206H206

01 - View
02 - Operator´s manual / maintenance
03 - Illustrations - mechanics
04 - Illustrations - electrics
05 - Illustrations hydraulics
06 - Electric circuit diagrams
07 - Hydraulic circuit diagrams
08 - Manuals
09 - Suppliers documentation
10 - Machine data
11 - Transportation data
12 - Appendix

a

# 2067359
Drive diagram – 3000 series
1 / 3
Hydraulic-Training
3205 – 3307

# 2067359
Drive diagram – 3000 series
2 / 3
Hydraulic-Training
3410 – 3520 HT

# 2067359
Drive diagram – 3000 series
3 / 3
Hydraulic-Training
3625 HT

# 2114845
View 3410-3411 – H179
View 1 / 16
List of types „Series 3000“
H188 H189 H179 H180 H176 H177
3205 3307 3410 3412 3516
3411 3414 3518
3520
3205 P 3307 P 3410 P 3412 P 3516 P
3411 P 3414 P 3518 P
3520 P
3307 VIO 3412 VIO
3414 VIO
3307 HT 3412 HT 3516 HT 3625 HT
3414 HT 3518 HT
3520 HT
3307 HT P 3412 HT P 3516 HT P
3414 HT P 3518 HT P
3520 HT P
3307 HT VIO 3412 HT VIO
3414 HT VIO
HAMMTRONIC STANDARD

# 2114845
View 3410-3411 – H179
View 2 / 16
3307 HT VIO
3307 HT VIO
Type designation e.g. 3307
Series 3000
Assembly
Operating weight [t]HAMMTRONIC
Vibration- / Oscillation drum
P
P
Padfoot
A
A
Asphalt version

# 2114845
View 3410-3411 – H179
View 3 / 16
View of the machine from the left
Vibration drive
(optional vib.
frequency sensor)

# 2114845
View 3410-3411 – H179
View 4 / 16
Vibration motor
High pressure port B
High pressure port A
Leakage
Integrated
scavenge valve

# 2114845
View 3410-3411 – H179
View 5 / 16
View of the machine from the right
Switch box
Battery box
Axle drive
motor (2-speed)
(optional speed sensor)
Axle with self
locking differential
Drum drive motor (2 versions)
-radial piston (2-speed)
-axial piston (2-speed) with
reduction transmission

# 2114845
View 3410-3411 – H179
View 6 / 16
Drum drive motors
Version 1 (radial piston motor) Version 2 (axial piston motor)
Integrated
scavenge valve
Scavenge valve in engine compartment
(next to brake release valve, page 12/17)

# 2114845
View 3410-3411 – H179
View 7 / 16
Diesel engine
Machinen type
Engine type BF4M2012C
Cooling system Water
Engine output ISO 9249 98 kW
(133 HP)
Cubic capacity 4038 cm³
Max. torque 493 Nm
3410-3414
3410 - 3414
BF 4 M 2012 C
Turbocharged
Four stroke engine
Number of cylinders
Cooling type
Series
Stroke [cm]
Intercooler

# 2114845
View 3410-3411 – H179
View 8 / 16
• Air intake on the highest
point of the engine hood
• Long sound absorbing
distance
• No heat short circuit
• High cooling
performance
• Longevity of components
•Lownoiselevel
• Free access to the
coolers
Cooling air
intake
Engine (cooling air duct)
Noise absorbing
bulkhead
Hydraulic oil cooler
Water cooler
Intercooler
Exhaust

# 2114845
View 3410-3411 – H179
View 9 / 16
Engine compartment (left side) 3410-3411 Coolant compensator tank
Coolant level sensor
Engine oil filter
Fuel pump
Engine oil filler neck
Twin fuel filter
Steering and
feed pump
Test port and refill connection
steering pump
max. 175 bar

# 2114845
View 3410-3411 – H179
View 10 / 16
Engine compartment (left side) 3410-3411
Main filter for drive
and vibration system
Drive pump
Vibration
pump
Fuel pre-filter with
water separator
Filter indicator main filter
Manual pump / fuel
Water level sensor
fuel pre-filter
Additional
fuel pre-filter
