WIRTGEN VOGELE SUPER 1600-1 User manual

JOSEPH VÖGELE AG
Neckarauer Strasse 168-228
D-68146 Mannheim
Germany
Telephone: [phone] - 0
Fax: [phone] - 466
OPERATING INSTRUCTIONS
SUPER 1600-1 / 1800-1
09.82
Series
01.07.2005
Issue date
2039389_01_EN
Catalogue order number

Publisher Joseph Vögele AG
Neckarauer Strasse 168-228
D-68146 Mannheim
Germany
Telephone: + 49 (0) 6 21 / 81 05 - 0
Web site http: //voegele-ag.de
Document number BAL_0982_2039389_01_00_00_EN.doc
Issue date 01.07.2005
Copyright © 2005, Joseph Vögele AG
All parts of this documentation are protected by copyright. Any usage or
change outside the strict limits of copyright law is not allowed without the
agreement of Vögele AG and is an offence.
This statement applies particularly to duplication, translation, microfilming
and storage and processing in electronic systems.
Find manuals at https://best-manuals.com

TABLE OF CONTENTS
BAL_0982_2039389_01_00_00_EN.doc I
TABLE OF CONTENTS
TABLE OF CONTENTS ...................................................................................................I
1General...................................................................................................................1
1.00 Introduction ....................................................................................................................................1
1.00.01 Foreword...................................................................................................................................1
1.00.02 Changes / rights reserved.........................................................................................................3
1.00.03 Packaging and storage .............................................................................................................3
1.01 Markers and symbols used in these instructions ...........................................................................4
1.01.01 Markers, pictograms and symbols ............................................................................................4
1.01.02 Safety marker............................................................................................................................4
1.02 Usage.............................................................................................................................................6
1.02.01 Correct use................................................................................................................................6
1.02.02 Incorrect use .............................................................................................................................6
1.02.03 Residual hazards ......................................................................................................................7
1.03 Declaration of conformity ...............................................................................................................8
1.04 Noise and vibration information .....................................................................................................8
1.04.01 Road paver noise emissions measurement..............................................................................8
1.04.02 Noise information for the operator ............................................................................................9
1.04.03 Vibration information for the operator .....................................................................................10
1.05 Type plate ....................................................................................................................................10
1.06 Technical data..............................................................................................................................12
1.07 Personnel - qualifications and obligations....................................................................................12
1.08 General safety instructions ..........................................................................................................14
1.08.01 Safety manual .........................................................................................................................14
1.08.02 Documentation........................................................................................................................15
1.08.03 Protection of the environment.................................................................................................15
1.09 Personal safety equipment ..........................................................................................................15
1.10 Accessories..................................................................................................................................15
1.11 Hazard areas and workplaces .....................................................................................................17
1.11.01 Labelling diagram....................................................................................................................17
1.11.02 Labelling..................................................................................................................................20
2Description / operation .......................................................................................33
2.00 Description ...................................................................................................................................33
2.00.01 Chassis / safety features.........................................................................................................33
Find manuals at https://best-manuals.com

TABLE OF CONTENTS
II BAL_0982_2039389_01_00_00_EN.doc
2.00.02 Control stand.......................................................................................................................... 58
2.00.03 Not used............................................................................................................................... 147
2.00.04 Power unit / engine .............................................................................................................. 147
2.00.05 Hydraulic oil supply .............................................................................................................. 168
2.00.06 Electrical system .................................................................................................................. 176
2.00.07 Not used............................................................................................................................... 188
2.00.08 Traction drive........................................................................................................................ 189
2.00.09 Not used............................................................................................................................... 190
2.00.10 Material transport ................................................................................................................. 190
2.00.11 Grade and slope unit............................................................................................................ 213
2.00.12 Not used............................................................................................................................... 213
2.00.13 Cleaning system (option) ..................................................................................................... 213
2.00.14 Screed attachment ............................................................................................................... 216
2.00.15 Not used............................................................................................................................... 229
2.00.16 Not used............................................................................................................................... 229
2.00.17 Not used............................................................................................................................... 229
2.00.18 Lubricating system ............................................................................................................... 230
2.00.19 Screed .................................................................................................................................. 232
3Maintenance ...................................................................................................... 233
3.00 Special safety instructions......................................................................................................... 233
3.01 Chassis / safety features ........................................................................................................... 233
3.02 Control stand ............................................................................................................................. 234
3.03 Not used .................................................................................................................................... 235
3.04 Power unit / engine.................................................................................................................... 235
3.04.01 Engine compartment ............................................................................................................ 235
3.04.02 Fuel supply........................................................................................................................... 245
3.04.03 Not used............................................................................................................................... 253
3.04.04 Air intake .............................................................................................................................. 254
3.04.05 Cooling system..................................................................................................................... 260
3.05 Hydraulic oil supply ................................................................................................................... 261
3.05.01 Tank ..................................................................................................................................... 262
3.05.02 Pump distribution gearbox ................................................................................................... 278
3.06 Electrical system ....................................................................................................................... 286
3.06.01 24 V power supply................................................................................................................ 286
3.06.02 Power supply / sockets ........................................................................................................ 289
3.06.03 Switch box............................................................................................................................ 289
Find manuals at https://best-manuals.com

TABLE OF CONTENTS
BAL_0982_2039389_01_00_00_EN.doc III
3.06.04 Heating performance and power supply .............................................................................. 289
3.06.05 Generator............................................................................................................................. 289
3.07 Not used.....................................................................................................................................295
3.08 Traction drive .............................................................................................................................295
3.08.01 Chassis ................................................................................................................................ 295
3.08.02 Traction drive ....................................................................................................................... 299
3.09 Not used.....................................................................................................................................308
3.10 Material transport .......................................................................................................................308
3.10.01 Push roller............................................................................................................................ 308
3.10.02 Material hopper .................................................................................................................... 308
3.10.03 Material conveyor unit.......................................................................................................... 308
3.10.04 Material distribution.............................................................................................................. 318
3.11 Grade and slope unit..................................................................................................................333
3.12 Not used.....................................................................................................................................333
3.13 Cleaning system.........................................................................................................................333
4Tables.................................................................................................................337
4.00 Technical data............................................................................................................................337
4.00.01 Weights ................................................................................................................................ 337
4.00.02 Operation ............................................................................................................................. 338
4.00.03 Dimensions .......................................................................................................................... 339
4.00.04 Recommendations for adjusting the compaction systems .................................................. 341
4.00.05 Power unit / engine .............................................................................................................. 342
4.00.06 Hydraulic oil supply .............................................................................................................. 343
4.00.07 Electrical system .................................................................................................................. 343
4.00.08 Traction drive ....................................................................................................................... 344
4.00.09 Material transport / distribution ............................................................................................ 344
4.00.10 Grade and slope unit............................................................................................................ 345
4.00.11 Screed combination ............................................................................................................. 345
4.01 Maintenance schedule ...............................................................................................................346
4.02 Tightening torques .....................................................................................................................348
4.03 Separate documentation............................................................................................................350
4.03.01 Documentation on the road paver ....................................................................................... 350
4.03.02 Supplier documentation ....................................................................................................... 350
4.03.03 Information ........................................................................................................................... 350
INDEX..........................................................................................................................351
Find manuals at https://best-manuals.com

TABLE OF CONTENTS
IV BAL_0982_2039389_01_00_00_EN.doc
CHANGES .................................................................................................................. 357
ANNEX........................................................................................................................ 359
Find manuals at https://best-manuals.com

General
Introduction
BAL_0982_2039389_01_00_00_EN.doc 1
1 General
1.00 Introduction
In this section you, as the operator, will find important instructions on the
operation of the road paver and the use of these operating instructions.
1.00.01 Foreword
This VÖGELE machine is a product from the wide range of VÖGELE road
construction machinery.
The extensive experience of VÖGELE as well as the latest production and
test methods guarantee the very high reliability of your machine. The op-
erating instructions belong with the machine!
These operating instructions are only valid in conjunction with the
safety manual. Please note:
These operating instructions were written for the operator and the mainte-
nance engineer on the construction site.
These operating instructions are intended to place these people in the po-
sition to be able to operate the machine safely and to use its features to
the full.
They also provide instructions on the function of important attachments
and systems.
Specific terms are used in these operating instructions. To avoid misun-
derstandings, you should always use the same terms.
Only qualified, instructed and trained personnel are allowed to work on
this machine.
The operating instructions, the safety manual and the stipulations and re-
gulations applicable in the place of use must be observed (e.g. accident
prevention regulations).
The use of these operating instructions will make it easier for you:
• To familiarise yourself with the machine.
• To avoid malfunctions due to incorrect operation.
Observing the operating instructions:
• Will help to prevent hazards.
• Will increase reliability in use on the construction site.
• And - if driving on public roads is allowed - will increase the service life
of the machine (only wheeled pavers).
• Will reduce maintenance costs and downtimes.
Always keep these operating instructions at hand, e.g. in the machine's
toolbox or in the holder provided.
Find manuals at https://best-manuals.com

General
Introduction
2 BAL_0982_2039389_01_00_00_EN.doc
Should you receive further information on the machine from us, these in-
structions are also to be observed and attached to the operating instruc-
tions (e.g. additional technical information).
If you do not understand the operating instructions or specific sections,
you should ask us before you start the related activity.
Joseph Vögele AG is not liable for the safe function of the machine:
• On use other than normal use.
You cannot make any claims under the warranty in case of:
• Operating errors.
• Incorrect maintenance.
• Incorrect greases, oils or fuel.
• Use for purposes that are not stated in the operating instructions.
The warranty and liability conditions in the general terms and conditions
published by Joseph Vögele AG are not extended by the above instruc-
tions.
We reserve the right to make changes without notice as a result of techni-
cal development.
Information and illustrations in these operating instructions are not allowed
to be copied, distributed, or used for the purposes of competition.
Translations are undertaken to the best of our knowledge. No liability can
be accepted for translation errors or any resulting consequences; also not
in the case that the translation was made by us or was commissioned by
us.
The German text is and remains definitive for all liability claims and claims
under the warranty.
All legal rights related to copyright are expressly reserved.
We wish you every success with your VÖGELE machine!
Joseph Vögele AG
Neckarauer Strasse 168- 228
D-68146 Mannheim
Germany
NOTE There are separate operating instructions for the tractor and screed. A
functional machine (in the context of the machinery directive) is only
produced on the permissible combination of road paver and screed.
The respective operating instructions are always related and both sets of
operating instructions are always to be observed together with the safety
manual.
Find manuals at https://best-manuals.com

General
Introduction
BAL_0982_2039389_01_00_00_EN.doc 3
Service telephone:
[phone]
[phone]
[phone]
About these instructions Before you start using the road paver, you must have read and under-
stood these instructions.
These instructions are intended to familiarise you with basic
tasks/activities on the road paver.
These instructions contain important instructions on the safe and correct
use of the road paver.
Observing the instructions will help:
• To prevent hazards.
• To reduce repair costs and downtimes.
• To increase the reliability and service life of the road paver.
Irrespective of these instructions, the laws, regulations, directives and
standards applicable in the country and place of use must be observed.
The usage of the road paver is described in these instructions.
A copy of these instructions must be available to the operator at all
times.
These operating instructions are only valid in conjunction with safety ma-
nual 2600980260 or 2600980270.
A copy of this safety manual must be available to the operator at all
times.
1.00.02 Changes / rights reserved
We make every effort to ensure these operating instructions are correct
and up to date. To maintain our technological lead, it may be necessary to
make changes to the product and its operation without prior notice. The
product and its operation may then differ from these operating instruc-
tions. We accept no liability for malfunctions, failures and any resulting
damage.
Therefore you must also observe any additional information supplied!
1.00.03 Packaging and storage
To ensure adequate protection during shipment, the accessories have
been carefully packed.
On receipt of the goods, the packaging and the goods should be checked
for damage.
In the case of damage, the machines are not allowed to be placed in op-
eration! Damaged cables and connectors are also a safety risk and must
not be used under any circumstances!!!
In this case please contact your VÖGELE supplier.
Find manuals at https://best-manuals.com

General
Markers and symbols used in these instructions
4 BAL_0982_2039389_01_00_00_EN.doc
If the machines are not placed in operation immediately after unpacking,
they must be protected against moisture and dirt.
1.01 Markers and symbols used in these instructions
The markers and symbols in these instructions are intended to help you to
use the instructions and the machine quickly and safely.
1.01.01 Markers, pictograms and symbols
Advanced Organizer
The Advanced Organizer provides you with a brief introduction to the
contents of the section that follows.
NOTE Note
A note provides you with information on the most effective and most prac-
tical utilisation of the machine and these instructions.
¾
Actions
The defined sequence of actions will make it easier for you to correctly
and safely use the machine.
3
Result
Here you will find a description of the result of a sequence of actions.
1.01.02 Safety marker
The safety marker provides a visible indication of a source of a hazard.
The safety markers in all the technical documentation comply with the
harmonised standard EN 61310 part 2: Safety of machinery. Indication,
marking and actuation. Requirements for marking and EU directive
92/58/EEC - minimum requirements for the provision of safety and/or
health signs at work.
Warning marker
Warning of a general hazard
This warning marker is used before activities during which risks could
arise for several reasons.
Warning of hazardous electrical voltage
This warning marker is used before activities during which there are
risks of an electric shock, possibly with fatal consequences.
Find manuals at https://best-manuals.com

General
Markers and symbols used in these instructions
BAL_0982_2039389_01_00_00_EN.doc 5
Warning of suspended load
This warning marker is used before activities during which there are
risks due to falling objects, possibly with fatal consequences.
Warning of rotating parts
This warning marker is used before activities during which there are
risks due to rotating parts of the machine, possibly with fatal conse-
quences.
Warning of slipping hazard
This warning marker is used before activities during which there are
risks due to slipping, possibly with fatal consequences.
Warning of tripping hazard
This warning marker is used before activities during which there are
risks due to tripping, possibly with fatal consequences.
Warning of crushing hazard
This warning marker is used before activities during which there are
risks due to crushing, possibly with fatal consequences.
Warning of hot surface
This warning marker is given before activities during which there are
risks due to hot surfaces.
Warning of batteries
This warning marker is given before activities during which there are
risks due to a corrosive liquid.
Warning of inflammable substances
This warning marker is used before activities during which there are
risks due to inflammable substances, possibly with fatal consequences.

General
Usage
6 BAL_0982_2039389_01_00_00_EN.doc
Warning of potentially explosive substances
This warning marker is used before activities during which there are
risks due to potentially explosive substances, possibly with fatal conse-
quences.
Warning of toxic substances
This warning marker is used before activities during which there are
risks due to toxic substances, possibly with fatal consequences.
1.02 Usage
1.02.01 Correct use
The road paver is state of the art and complies with the applicable safety
regulations at the time it was placed on the market in the context of its
correct use.
It was not possible to prevent foreseeable misuse or residual hazards by
design means without restricting correct functionality.
The road paver is designed:
• For paving road surfaces in layers using construction materials.
The road paver is only intended for industrial use on closed construction
sites.
The road paver must be operated in accordance with the requirements in
the technical documentation.
Any incorrect use and all activities on the road paver that are not de-
scribed in these instructions represent unauthorised misuse beyond the
bounds of the manufacturer's liability.
1.02.02 Incorrect use
If the road paver is used incorrectly, the manufacturer's warranty is void
and the operating organisation carries sole responsibility.
Incorrect uses are:
• Carrying people.
• Leaving the control stand during work
• Placing in operation / usage of the road paver from outside the control
stand.
• Using the road paver with the floor folded up.
• Spraying with high-pressure cleaners or fire extinguishing equipment.
• Removal of safety features.
• Failure to observe maintenance intervals.
• Failure to take measurements and perform tests for the early detection
of damage.
• Failure to replace wearing parts.

General
Usage
BAL_0982_2039389_01_00_00_EN.doc 7
• Failure to perform maintenance and repair work.
• Incorrectly performed maintenance and repair work.
1.02.03 Residual hazards
The residual hazards were analysed and evaluated prior to the start of the
design and planning for the road paver.
Residual hazards that cannot be avoided by design means during
the entire life cycle of the road paver include:
• Hazards that may result in fatality.
• Hazards that may result in injury.
• Pollution.
• Damage to the road paver.
• Damage to other property.
• Performance limitations or limitations on functionality.
You can avoid existing residual hazards by implementing and ob-
serving these requirements in practice:
• The special warnings on the road paver.
• The general safety instructions in these instructions.
• The special warnings in these instructions.
• The instructions in the safety manual.
• The operating organisation's instructions on operation.
Hazards that may result
in fatality / hazards that
may result in injury
Hazards that may result in fatality / hazards that may result in injury can
arise on the road paver due to:
• Misuse.
• Incorrect operation.
• Transport.
• Missing safety features.
• Faulty or damaged parts.
• Operation/usage by untrained personnel / personnel who have not
been instructed.
Pollution Pollution can arise due to the road paver in case of:
• Incorrect operation.
• Oils, greases or fuel (lubricants, etc.).
• Noise emissions.
Damage to the road
paver
Damage can be caused to the road paver due to:
• Incorrect operation.
• Failure to observe operating and maintenance requirements.
• Unsuitable oils, greases or fuel.

General
Declaration of conformity
8 BAL_0982_2039389_01_00_00_EN.doc
Damage to other
property
Damage can be caused to other property in the area where the road
paver is operating due to:
• Incorrect operation.
Performance limitations
or limitations on
functionality
Performance limitations or limitations on the functionality of the road pa-
ver can arise due to:
• Incorrect operation.
• Incorrect maintenance and repair.
• Unsuitable oils, greases or fuel.
1.03 Declaration of conformity
The declaration of conformity is part of the documentation provided sepa-
rately by Vögele AG and will be handed over to you on the delivery of the
road paver.
The CE marking on the road paver is part of the type plate.
The pictogram indicates conformity with the applicable EU directives
that relate to the product - that is the road paver - and that require a
CE marking.
1.04 Noise and vibration information
1.04.01 Road paver noise emissions measurement
Measurement and procedure in accordance with the EU directive
2000/14/EC and the harmonised standard prEN 500-6.
Various screeds are used on the SUPER 1600-1 and SUPER 1800-1 road
pavers.
The noise emissions of the SUPER 1600-1 and SUPER 1800-1 road pa-
vers depend on the type of screed supplied.
The noise emissions of the SUPER 1600-1 and SUPER 1800-1 road pa-
vers are summarised in the following table.

General
Noise and vibration information
BAL_0982_2039389_01_00_00_EN.doc 9
These figures are the sound pressure level LWA referred to 1 pW:
Sound pressure level [dB(A) / 1 pW]
Screed SUPER 1600-1 SUPER 1800-1
AB 500 TV 106 106
AB 500 TP 1 110 110
AB 500 TP 2 110 110
AB 600 TV 106 106
AB 600 TP 1 110 110
AB 600 TP 2 110 110
SB 250 TV 108
SB 250 TP 1
SB 250 TP 1
Tab. 1.1: Guaranteed sound pressure levels
NOTE It is not allowed to make any changes to the road paver that will result in
an increase in the noise emissions!
• Wear your personal safety equipment (e.g. ear defenders).
• Read and observe the safety manual.
• Do not make any changes to the road paver.
1.04.02 Noise information for the operator
Emission value referred to the operator's position as per prEN 5006.
Measurement and procedure in accordance with EN ISO 11201.
SUPER 1600-1 and SUPER 1800-1 road pavers
Sound pressure level LpA [dB(A)]
• Operator's position left/right 85.0 dB(A).
• Hopper left/right 84.0 dB(A).
• Floor left/right 86.0 - 88.0 dB(A)
NOTE It is not allowed to make any changes to the road paver that will result in
an increase in the noise emissions!
• Wear your personal safety equipment (e.g. ear defenders).
• Read and observe the safety manual.
• Do not make any changes to the road paver.
• The permissible sound pressure level of 85 dB(A) may be exceeded
when working on the road paver, in the immediate vicinity of the road
paver and on the control stand.

General
Type plate
10 BAL_0982_2039389_01_00_00_EN.doc
1.04.03 Vibration information for the operator
SUPER 1600-1 and SUPER 1800-1 road pavers
Whole body vibration
If the machine is used correctly, the weighted effective values for the ac-
celeration of entire body vibration at the operator's position and the outer
control panels of aw = 0.5 m/s² - in the context of EN 1032: 2003 - are not
exceeded.
Hand-arm vibration
If used correctly, the weighted effective values for the acceleration of
hand-arm vibration of ahw = 2.5 m/s² - in the context of EN 1032: 2003 -
are not exceeded.
1.05 Type plate
Fig. 1.1: Type plate and vehicle identification number
1 Right side trim panel 3 Vehicle identification
number
2 Type plate
The data on the road paver are punched on the type plate (2).
The type plate is riveted to the right side trim panel (1), in the direction of
travel.
The vehicle identification number (3) is punched on the front chassis wall -
in the direction of travel of the road paver.
1 23

General
Type plate
BAL_0982_2039389_01_00_00_EN.doc 11
Fig. 1.2: Type plate
1 Right side trim panel 2 Type plate
All the information is of documentary value and is not allowed to be chan-
ged or rendered illegible.
Enter the data on the type plate in the following table.
Description Data
1. Series / type
2. Machine I.D No.
3. Year of Manufacture
4. Output kW / min-1
5. Output kW / min-1
Front -
6. Admissible
Axle Load Rear -
7. Admissible Total Weight -
8. Operating Weight
9. Maximum Operating Weight)
Tab. 1.2: Data on the type plate
If you have questions on the road paver or want to order spare parts, you
must always provide the following information:
• Series / Type (item 1).
• Machine I.D. No. (item 2).
• Year of Manufacture (item 3).
Read the separate operating instructions from the engine manufacturer to
identify the position of the engine type plate.
1 2

General
Technical data
12 BAL_0982_2039389_01_00_00_EN.doc
Enter engine manufacturer, engine type and engine number in the follow-
ing table:
Description Data
1. Hersteller (Manufacturer)
2. Bauart (Engine type)
3. Motornummer (Engine num-
ber)
Tab. 1.3: Data on the engine type plate
When ordering wearing parts or spare parts for the diesel engine, you
must provide the following additional information:
• Engine manufacturer.
• Engine type.
• Engine number.
NOTE Original spare parts and accessories authorised by the manufacturer
will aid safety. The use of other parts can render void any liability for the
resulting consequences.
TIP Use only original Vögele spare parts and accessories.
1.06 Technical data
The technical data on the road paver are given in section 4.00.
1.07 Personnel - qualifications and obligations
Only appropriately authorised personnel are allowed to perform any activi-
ties on the road paver.
The authorised personnel must:
• Be at least 18 years of age.
• Be physically and mentally fit to undertake the activity.
• Be trained in first aid and be able to provide first aid.
• Have read and understood the safety manual.
• Be able to apply and implement the safety manual in practice.
• Be familiar with and able to apply accident prevention regulations and
safety instructions on the road paver.
• Be appropriately trained and instructed on how to react in case of a
malfunction.
• Have the physical and mental faculties to be able to perform his/her
responsibilities, tasks and activities on the road paver.
• Be appropriately trained and instructed for his/her responsibilities,
tasks and activities on the road paver.

General
Personnel - qualifications and obligations
BAL_0982_2039389_01_00_00_EN.doc 13
• Have understood and be able to practically implement the technical
documentation related to his/her responsibilities, tasks and activities on
the road paver.
• Be physically and mentally suited and have read and understood the
safety manual.
Prior to placing the road paver in operation, read:
• The operating instructions on the road paver and the screed.
• The safety manual.
They must be appointed by the employer / organisation to drive the road
paver.
Follow the instructions given below!
• Familiarise yourself with the equipment fitted to the road paver.
• Only drive the road paver when you have fully familiarised yourself with
the controls and method of operation.
• Familiarise yourself with your working area.
• Only use the road paver for the purpose intended.
• Use suitable lifting gear for fitting heavy extensions or accessories.
• Wear your safety equipment, e.g. safety shoes and ear defenders.
• If defects are found on the safety devices, inform the supervisor with-
out delay.
• If other defects are found that compromise the safe operation of the
road paver, inform the supervisor without delay.
• In case of defects that endanger people, shut down the road paver
immediately.
• If unauthorised modifications and changes to the road paver are found
that compromise the safe operation of the road paver, inform the su-
pervisor without delay.
• Ensure the road paver is always in roadworthy condition.
• Ensure the dates for regular safety inspections are observed.
• Observe the following items attached to the road paver:
– Safety markings.
– Markings for the protection of the health.
– Safety instructions.
• Read the additional safety regulations and instructions prepared by the
operating organisation / employer for special situations.
• Check the completeness and legibility of the
– Safety markings.
– Markings for the protection of the health.
– Safety instructions (signs, labels, pictograms).
• Prior to starting work, obtain information on

General
General safety instructions
14 BAL_0982_2039389_01_00_00_EN.doc
– First aid.
– The emergency services (paramedics, fire brigade, helicopter).
• Ensure a first aid box is available with the contents as required by the
regulations.
Assistant
Assistants are always required if the driver does not have adequate visibil-
ity of the road or path.
It is only allowed to employ people to assist road pavers who also:
• Have been instructed on assisting (the road paver).
• Have demonstrated successful attendance at the training course.
• Have demonstrated their skills to the employer.
• Can be expected to reliably tackle the tasks given to them.
They must be appointed by the operating organisation / employer to assist
the road paver.
To avoid misunderstandings, the unambiguous hand signals in accor-
dance with German BG regulation "Sicherheits- und Gesundheitsschutz-
kennzeichnung am Arbeitsplatz" (Health and safety markings in the work-
place) (BGV A 8) should be used.
Observe the instructions given below!
• Familiarise yourself with the dimensions of the road paver and the low-
loader!
• Wear warning clothing in case of visual contact!
• Assistance can be by radio (e.g. on loading using the crane) or by
hand signals (e.g. on reversing the road paver)!
• The meaning of the signals must be clarified beyond doubt between
driver and assistant.
The service personnel are responsible for ensuring that:
• The safety markers and instructions on the road paver are in legible
condition.
• The road paver is protected against unauthorised use.
• Repairs are discussed with the manufacturer.
• The road paver is only operated when it is fully functional and in cor-
rect working order.
1.08 General safety instructions
1.08.01 Safety manual
Read the safety manual 2600980260 or 2600980270 provided separately
by Vögele AG.
