Wiseup GL1200 User manual

User Guide
Model Number: GL1200
1. PRODUCT OVERVIEW
1. Mini USB Port
2. Camera Lens
3. Indicator Light
2. WHAT’S IN THE BOX
-Glasses Camera
-USB Cable
-DC5V Charging Adapter
3. OPERATION
>> Please make sure your camera is fully charged before using.
>> Please make sure the Micro SD card is securely fitted into the SD card slot on
your camera. Camera will not work without a Micro SD card. We suggest you use an
SDHC Class 10 Micro SD card.
[Note]: If no Micro SD card is fitted into the camera, the indicator light will flash red 10 times and then
shut down automatically.
3.1. POWER ON/OFF
3.1.1 Power on the camera by holding down the Power button for 2 seconds. The
indicator light will be turned on blue for 2 seconds and then glow solid red, indicating
the camera has entered into standby mode.
3.1.2 Power off the camera by holding down the Power button for 3 seconds. The
indicator light will flash blue twice and then go out.
[Note]: The camera will shut down automatically if it is in standby mode without any operation more
than 1 minute.
3.2. VIDEO RECORDING
3.2.1 Power on the camera by holding down the Power button for 2 seconds. The
indicator light will be turned on blue for 2 seconds and then glow solid red, indicating
the camera has entered into standby mode.
3.2.2 Press the record button for 2 seconds to start video recording. The indicator
light will flash red 3 times and then go out.
3.2.3 Press the record button again to stop video recording. The indicator light will
flash blue twice and glow solid red, indicating the camera is back to standby mode.
[Note]:
1). Video files will be saved automatically every 10 minutes.
2). Low battery will shorten video file length.
3). Video Resolution: 1920x1080P Video Format: AVI
3.3. CAMERA/STILL PHOTOGRAPHY
3.3.1 Power on the camera by holding down the power button for 2 seconds. The
indicator light will be turned on blue for 2 seconds and then glow solid red, indicating
the camera has entered into standby mode.
3.3.2 Press the photo button once to take a picture, the indicator light will flash red
once and then back to solid red, indicating that the camera is back to standby mode.
3.4. VIDEO/PHOTO FILE UPLOADS
3.4.1 When the camera is powered off, remove the Micro SD card from the camera
and insert it into a card reader.
3.4.2 Insert the card reader into a proper PC computer USB port.
3.4.3 Removable disk driver appears.
3.4.4 All of your files can be accessed in the photo and video folders.
3.5. SET THE DATE/TIME STAMP
3.5.1 When the camera is powered off, remove the Micro SD card from the camera
and insert it into a card reader.
3.5.2 Insert the card reader into a proper PC computer port.
3.5.3 Removable disk drive folder appears.
3.5.4 Click on the drive in the root directory and inside the root directory, create a
“time.txt” file.
3.5.5 Input the current date and time in the “time.txt” file with the correct format:
Year.Month.Date Hour:Minute: Second (For example: 2016.03.12 17:04:59).）,
Save this file.
3.5.6 Restart the camera and the system will upgrade the program automatically.
4. CHARGING
4.1. Connect the camera to an external AC power supply with the AC to DC charger
adapter.
4.2. The indicator light will keep flashing red during the charging process, it will glow
solid blue when the battery is fully charged.
4.3. It would take about 2 hours to obtain a full charge.
4. Micro SD Card Slot
5. Power/Record/Photo Button
-Glasses Pouch
-Lens Cleaning Cloth
