WisyCom MTP60 Instruction manual

QUICK USER GUIDEQUICK USER GUIDE
Main Accesories (for an updated and exhaustive list look into wisycom web)
MPRLBP: rechargeable Lithium-ion
battery 1500 mAh 3,7V/5,55 Wh
Cameron Sino part number: CS-WMR500SL
ACMMTP: battery charger capable of
charging up to 4 MTP60 simultaneously
PHA48: Plug on for XLR 3 adapter ca-
pable of providing +48V Phantom power.
CAL48: Cable to connect an MTP60/40S to
a PHA48 to use microphone with Phantom
PHA60: XLR3 power with 12/18/48V
Phantom with lemo connector for Tx con-
nection and hooks for easy pole attachment
CAD30: Cable adapter, with AF male con-
nector and 1 + 1 female connectors (for MIC
and PTT button)
BCL60: spring loaded belt clip
BCLW60: wire belt clip reversible
ISTR-MTP60 #MTPxx Quick user guide v4.00
(*)The Wisycom microphone pocket transmitter model MTP60 complies with the following requirements:
FCC (Federal Communications Commission) Part 74. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operations. Changes or modication not ex-
pressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment. FCC ID can be found inside the battery compartment.
(**) EN This device complies with Industry Canada license-exempt RSS-123 and RSS-210 standard. Ope-
ration is subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation of the de-
vice. This radio transmitter IC: 11967A-MTP60 has been approved by Industry Canada to operate with the
antenna types listed below with the maximum permissible gain and required antenna impedance for each
antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum
gain indicated for that type, are strictly prohibited for use with this device.
FR Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts
de licence RSS-123 et RSS-210. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil
ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectri-
que subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Le présent émetteur
radio IC: 11967A-MTP60 a été approuvé par Industrie Canada pour fonctionner avec les types d’anten-
ne énumérés ci-dessous et ayant un gain admissible maximal et l’impédance requise pour chaque type
d’antenne. Les types d’antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal
indiqué, sont strictement interdits pour l’exploitation de l’émetteur.
Antenna types (50 Ohm impedance, max gain 2.1dBi):AWF30-B1-507: band 470 - 547 MHz, AWF30-
B1-590: band 547 - 663 MHz, AWF30-B8-950: band 940 - 960 MHz.
This equipment complies has been evaluated for and shown compliant with the FCC and ISED RF Expo-
sure limits. The unit of measurement for RF exposure is Specic Absorption Rate (SAR). The FCC SAR
limits for is 1.6W/Kg per 1g of tissue
The maximum SAR levels tested has been shown to be 1.2 W/kg at head with 0mm of separation distance
from the body.
This device operates on a no-interference, no-protection basis. Should the user seek to obtain protection
from other radio services operating in the same TV bands, a radio license is required. For further details,
consult Innovation, Science and Economic development Canada’s Client Procedures Circular CPC-2-1-
28, Voluntary Licensing of License-Exempt Wireless Microphones in TV Bands.
Conformity
RADIO Directive 2014/53/
EU Radio Equipment
Directive (RED)
FCC-ID: POUMTP60
IC: 11967A-MTP60
MTP60MTP60
This guide is intended to assist you with initial quick setup and
operation of your Wisycom product.
You can refer to Wisycom Autorized Distributors for technical Sup-
port and information about service and repairs available in your
area or contact us directly by email.
Serial Number: Purchase Date:
WISYCOM ITALY
Via Tiepolo 7/E
35019 Tombolo (PD) - ITALY
[phone]
[email protected]
[email protected]
WISYCOM USA
5228 Eisenhower Avenue
Alexandria, VA 22304 - USA
+1 (888) WISYCOM
[phone]
[email protected]
[email protected]
Download Documentation and Firmware
Get latest user manual, tips, specications,
rmware & software on the download page:
wisycom.com/products/d/MTP60
Keep up with Wisycom online
Follow us on Facebook and Instagram. You
can also subscribe on Youtube for more.
wisycom.com/social
Product Registration and Warranty
Register your product to extend your warranty
and receive update on latest rmware:
wisycom.com/registration
IC

SEL
EXIT
GAIN
CH
REC
ON
OFF
MENU
SEL
EXIT
GAIN
CH
REC
ON
OFF
MENU
IR Port
Quickly IR sync with legacy receivers.
Activate by going to IRDA screen
Antenna Connector (*) Type Lemo
SEL / ON
Push to switch ON the device. Push together with
GAIN/UP to enter the main MENU. When in menu
single push to save and conrm selections.
SD Card slot
Micro SD card for internal recording.
Quickly enter recording menu by pressing GAIN+CH
EXIT / OFF
Log press to switch the unit OFF.
Short press to step back into menu
Press together with SEL/ON to mute/unmute the
audio
Ch Shortcut/Down
Short press to access channel/group/frequency menu
and/or scroll down while into the menu.
Long press it with EXIT/OFF to lock the front panel
Gain Shortcut/Up
Push to quickly access gain setup frequency
menu and/or scroll up while into the menu.
Recording Status Led
Fixed red when recording has started
Charging Led
Battery compartment
Select battery type in the menu to optimise
battery life.
Mic Input
Load a mic PRESET to suit your
wiring or enter the Audio menu
USB-C
To Connect with Wisycom Manager
Audio LED
OFF: Audio is muted
GREEN: Audio is enabled
RED: Audio is peaking
RF/Power LED
OFF: MTP60 is OFF
GREEN: Transmission is ON
RED: Transmission is OFF
RED SLOW BLINK: battery < 25%
RED FAST BLINK: battery < 12%
Press together to open
Transmitter name
Frequency
Group
Channel Audio bar
Tx PWR status
Battery
status
IRDA port
Locked
icon
RF level
in mW
Bluetooth Icon
Recording Icon
Label Code Band MHz
Antenna type (*)
507 AWF30-B1-507 470-547
590 AWF30-B1-590 547-663
552 AWF30-B3-552 510-595
646 AWF30-B3-646 595-698
710 AWF30-710 663-760
796 AWF30S-796 760-832
808 AWF30-BP-808 806-810
950 AWF30-B8-950 940-960
1K1 AWF30-B6-1K1 960-1160
Mic Mode Pinout
2 W 1 = GND / 3 = AF
2 W+B 1 = GND / 3 = AF+5,5 V
3 W 1 = GND / 2 = 5,5 V / 3 = AF
2 W & P 1 = GND / 2 = 3,1 V Ph / 3 = AF
2 W+B & P 1 = GND / 2 = 3,1 V Ph / 3 = AF + 5,5 V
INSTRUMENT 1 = GND / 3 = AF (High impedance)
