Wolf SRT366 User manual

36" Seale Burner Rangetops
The patente , ual-stacke seale gas
burners of our new seale burner rangetop
take control to a new level. Two levels,
really. The upper-tier burner elivers
maximum heat transfer at higher settings;
the lower-tier continuous flame ably
han les the subtleties of simmering an
melting. The Wolf exclusive infrare char-
broiler an infrare gri le ensure this
rangetop stan s out from the rest in
performance an also beauty. Available in
natural or LP gas.
FEATURES
•Stainless steel exterior finish with island
trim included.
•Optional infrared charbroiler and infrared
griddle configurations.
•Distinctive red control knobs—black
knobs optional.
•latinum bezels surround all knobs—
chrome or brass bezels optional.
•Dual-stacked, sealed burners, all with
simmer capabilities and automatic
reignition at all settings.
•Melt feature on 9,200 Btu burner.
•orcelain-coated cast iron continuous
grates.
Dual-stacked
sealed burner.
Model SRT366
Model SRT364C
Model SRT364G
SURFACE FEATURES
Mo el SRT366 SRT364C SRT364G
Surface Burners
15,000 Btu high / 950 Btu simmer 533
Surface Burner
9,200 Btu high / 325 Btu simmer 111
Infrared Charbroiler – 16,000 Btu •
Infrared Griddle – 15,000 Btu •
Model numbers are for natural as sealed burner ran etops, add (-LP) to the model number for LP as.
ACCESSORIES
•Stainless steel risers in 5" and 10",
or 20" riser with shelf.
•Black control knobs.
•Chrome or brass bezels.
•orcelain-cast wok grate and single
burner grate.
•orcelain-cast two-burner S-grate.
•Hardwood cutting board
(griddle model only).
•Griddle cleaning kit.
Accessories are available throu h your authorized
Wolf dealer. For local dealer information, visit the
find a showroom section of our website,
wolfappliance.com.
Model SRT366 shown.
This appliance is certified by Star-K
to meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.

357/8"(911) 241/4"(616)
121/2"
(318)
5"
RISER
171/2"
(445)
10"
RISER
271/2"
(699)
20"
RISER
281/2"(724)
81/2"(216)
TO COOKING
SURFACE
71/2"
(191)
91/4"
(235)
INSTALLATION NOTES
•A riser is required for installations
against a combustible surface.
•A Wolf pro wall, chimney, island ventila-
tion hood or hood liner is recommended.
•For L gas installations above 8,600' a
high altitude conversion kit is required.
For natural gas installations above
10,250', contact your authorized Wolf
dealer.
Unit dimensions may vary by ±1/8".
36" (914)
OPENING WIDTH
30" (762) TO 36" (914)
TO BOTTOM OF
VENTILATION HOOD**
*Minimum clearance from rough opening to combustible materials up to 18" (457) above countertop.
**36" (914) minimum clearance, 44" (1118) for charbroiler, from countertop to combustible materials without ventilation hood.
NOTE: For island installations, 12" (305) minimum clearance from back of rangetop to combustible rear wall above countertop.
6" (152) TO
COMBUSTIBLE*
6" (152) TO
COMBUSTIBLE*
18" (457) min
36" (914)
FLOOR TO
COUNTERTOP
16" (406)
PLATFORM
TOP VIEW
EG
16"
(406)
4"
(102)
BACKWALL
GAS AND ELECTRICAL
THROUGH BOTTOM OF
PLATFORM
PLATFORM
13" (330)
max
PLATFORM
71/2"(191)
OPENING
HEIGHT
SPECIFICATIONS
Exterior Finish Stainless Steel
Overall Width 357/8"
Overall Height
(to cooking surface) 81/2"
Overall Depth 281/2"
Opening Width 36"
Opening Height
(to countertop) 71/2"
Opening Depth 24"
Electrical Requirements 110/120 V AC
50/60 Hz, 15 amp circuit
ower Cord 6' cord with grounded plug
Shipping Weight 190–220 lbs
INSTALLATION SPECIFICATIONS
OVERALL DIMENSIONS
36" Seale Burner Rangetops
Dimensions in parentheses are in
millimeters unless otherwise specified.
©Wolf Appliance, Inc. all ri hts reserved. Features and specifications are subject to chan e at any time without notice. 1/10
