Wolf CI36560T/S User manual

Guía de uso y mantenimiento
Guide d’utilisation et d’entretien
Guida all’uso e alla manutenzione
Bedienungs- und Pflegeanleitung
Gids voor gebruik en onderhoud
使用和维护指南
Induction Cooktop
Use and Care Guide

2 | English
Contents
3Safety Precautions
6Induction Cooktop Features
6Cooktop Operation
Care Recommendations
9Troubleshooting
9Wolf Warranty
Induction Cooktop
Customer Care
The model and serial number are listed on the product
rating plate. Refer to page 6 for rating plate location. For
warranty purposes, you will also need the date of installa-
tion and name of your authorized Wolf dealer. Record this
information below for future reference.
If your product ever needs attention, be sure to use a Wolf
Factory Certified Service provider.
SERVICE INFORMATION
Model Number
Serial Number
Date of Installation
Certified Service Name
Certified Service Number
Authorized Dealer
Dealer Number
Important Note
To ensure this product is installed and operated as safely
and eciently as possible, take note of the following types
of highlighted information throughout this guide:
IMPORTANT NOTE highlights information that is especially
important.
CAUTION
Indicates a situation where minor injury or product
damage may occur if instructions are not followed.
WARNING
States a hazard that may cause serious injury or
death if precautions are not followed.

wolfappliance.com | 3
IMPORTANT INSTRUCTIONS
IMPORTANT NOTE: Read all safety instructions before using this
appliance.
• Read this use and care guide carefully before using your new
cooktop to reduce the risk of fire, electric shock, or injury to
persons.
• Ensure proper installation and servicing. This appliance must
be properly installed and grounded (earthed) by a qualified
technician. Have the installer show you the location of the
circuit breaker or fuse so that you know where to turn o
power.
• Warranty service must be performed by Wolf Factory Certified
Service.
• Before performing any service, disconnect the power supply
to the cooktop by switching o the circuit breaker or remov-
ing the fuse.
CAUTION
This appliance is for cooking purposes only. It must not be
used for other purposes such as heating a room. Doing so
may result in carbon monoxide poisoning.
GENERAL SAFETY PRECAUTIONS
WARNING
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory, or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the haz-
ards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
• This appliance cannot be operated by means of an external
timer or separate remote-control system.
• Wear proper apparel. Never let loose clothing or other flam-
mable materials come in contact with the elements while in
operation. Fabric may ignite and result in personal injury.
• Use only dry pot holders when removing pans from the cook-
top. Wet or damp pot holders on hot surfaces may result in
burns from steam. Do not let pot holders touch hot heating
elements.
Safety Precautions

4 | English
IMPORTANT INSTRUCTIONS
GENERAL SAFETY PRECAUTIONS
WARNING
The appliance and its accessible parts become hot during
use. Care should be taken to avoid touching heating ele-
ments. Children less than 8 years of age shall be kept away
unless continuously supervised.
• Select cookware of the proper size, material, and construc-
tion for the particular type of cooking being done. This unit
is equipped with heating elements of dierent size. Refer to
heating zones on page 6.
• Always turn pan handles inward so they do not extend over
adjacent work areas, heating elements, or edges of cooktop
to reduce the risk of burns, ignition of flammable materials,
and spillage due to unintentional contact with pan. Do not
turn handles toward the room, where they may be bumped
or easily hit.
• Never heat an empty pan. It may damage the cooktop or
cookware and overheat the unit.
• Do not heat cookware with water droplets on the outside of
the pan. The droplets may begin to boil and splatter. Cook-
ware should always be dry.
• Never use the cooktop to warm or heat a room.
• Do not use aluminum foil on the surface of the cooktop.
• When using the cooktop, do not touch the glass surface
directly above or adjacent to the heating elements or induc-
tion zones. The glass surface may become hot enough to
cause burns.
• After use, switch o the hob element by its control and do
not rely on the pan detector.
• Do not repair or replace any part of the appliance unless it
is specifically recommended in literature you received. All
service should be referred to Wolf Factory Certified Service.
• Do not block the cooling fan exhaust or intake vents. The
cooling fan automatically turns on to cool internal parts. It may
continue to run even after the cooktop has been turned o.
CAUTION
The cooking process has to be supervised. A short term
cooking process has to be supervised continuously.
Safety Precautions

wolfappliance.com | 5
IMPORTANT INSTRUCTIONS
GENERAL SAFETY PRECAUTIONS
• Do not leave children alone or unattended in the area where
the cooktop is in use. Never allow children to sit or stand on
the appliance. Do not let children play with the cooktop.
• Do not store items of interest to children above or at the back
of the cooktop, as they could climb on the appliance to reach
items and be injured.
WARNING
Unattended cooking with fat or oil can be dangerous and
may result in fire. Never try to extinguish a fire with water.
Switch o the appliance and cover the flame with a lid or
fire blanket.
WARNING
If the hob surface cracks, turn o the appliance to avoid the
possibility of an electric shock.
WARNING
If the surface is cracked, switch o the appliance to avoid
the possibility of electric shock. Call Wolf Factory Certified
Service to repair the cooktop.
WARNING
Danger of fire: Do not store items on the cooking surfaces.
Do not store flammable materials near hot components or
let grease or other flammable substances accumulate on the
cooktop.
• Do not place metal objects such as knives, forks, spoons, and
lids on the cooking surface. They can get hot.
• Clean only those parts listed in this guide. A steam cleaner is
not to be used.
• Do not clean the cooktop while it is still hot. If using a damp
sponge or cloth, wait until the cooktop has cooled suciently
to prevent steam burns. A steam cleaner shall not be used.
Also, some cleaners give o noxious fumes when applied to
hot surfaces. Refer to Care Recommendations on page 8.
• Do not use a griddle/teppan-yaki, open roaster, or fish
poacher across two heating elements unless the bridge
element is turned on. This type of use without the bridge
element turned on could damage or crack the glass. Refer
to Bridge Element on page 8.
Safety Precautions

6 | English
Cooktop Features Cooktop Operation
On O
Touch and hold to turn on the touchscreen before use.
To turn o all of the elements at the same time, touch and
hold .
INDUCTION COOKTOP
In induction cooking, the electricity flows through a coil
to produce a magnetic field under the glass-ceramic
surface. When an induction-compatible pan is placed on
the cooktop, currents are induced in the pan and instant
heat is generated. Cookware made of magnetic materials,
such as cast iron or magnetic stainless steel is required for
induction cooking.
CAUTION
Cookware bottom must be flat, patternless and
cover the entire cooking zone.
ELEMENT RATING
76 cm COOKTOP W
279 mm 2600 / 3700 boost
(2) 203 mm 2100 / 3700 boost
152 mm 1400 / 2200 boost
91 cm COOKTOP W
279 mm 2600 / 3700 boost
(4) 203 mm 2100 / 3700 boost
Induction Cooktop Features
FEATURES
1Product Rating Plate (bottom of cooktop)
2Touchscreen
3Bridge Element
Induction Cooktop (model CI36560T/S shown)
1
32
Getting Started
We know you are eager to start cooking, but before you
do, please take some time to read this use and care guide.
To ensure all residual oil from the manufacturing process
has been removed, clean the cooktop thoroughly with hot
water and a mild detergent prior to use. Rinse and dry with
a soft cloth. Refer to Care Recommendations on page 8.
ON OFF
On O

wolfappliance.com | 7
Touchscreen
For initial start-up, touch and hold for one second.
The touchscreen utilizes touch technology to select power
level and other functions. Refer to the illustration below.
The touchscreen automatically locks after 30 seconds of
inactivity. Press and hold for three seconds to unlock
the touchscreen. The Auto Lock can be disabled in
Extended Options.
CAUTION
Do not place hot cookware directly over the
touchscreen.
ICON FUNCTION
Press and hold for three seconds to lock or unlock the
touchscreen.
Touch to set a timer.
Touch to pause operation (power level 0). Touch to
resume. The cooktop turns o after 10 minutes, if not
resumed.
Touch to access extended options.
Cooktop Operation
Touchscreen (76 cm cooktop shown)
EXTENDED OPTIONS
Touch to access the extended options, then touch the
desired option.
ICON FUNCTION
Select 12 hour or 24 hour clock.
Turn touchscreen auto lock on or o.
Select brightness and standby screen.
Select touchscreen volume.
Select: English, Spanish, French, Italian, German, Dutch,
or Chinese.
Reset all settings.
Cooktop Operation
POWER LEVEL
When an element is activated, a power level appears on
the touchscreen for that element. The lowest heat setting
is level 1 and the highest setting is level 9. The power level
is adjustable in half increments.
BOOST MODE
Boost mode boosts power on one element by diverting
power from an adjacent element. If the adjacent element is
on High, the power output will be reduced. The reduction
in power is displayed on the power level of the adjacent
element. Touch to activate boost mode.
Boost mode deactivates automatically after approximately
15 minutes of continuous operation and can be reactivated
if desired.
SETTING POWER LEVEL USES
Low 1–2 Dissolve gelatin, make pudding,
and infuse oil.
Low/Medium 2.5–3.5 Thaw frozen vegetables, make
oatmeal, and heat milk.
Medium 4–5.5 Make french toast and pancakes,
fry eggs, and heat cream sauces,
soups and gravies.
Medium/High 6–7.5 Saute, brown, steam, and fry.
High 8–9 Boil water, cook shellfish,
blanch vegetables, sear meat,
and canning.
Power level (91 cm cooktop shown)
INDUCTION ELEMENT
Setting controls:
1 To activate a heating element, touch the desired single
element on the touchscreen.
2 Touch the desired power level (1–9), or touch for
Boost.
3 To change the heat setting while the element is on,
touch the desired power level.
4 To turn an element o, double tap the desired element
on the touchscreen, or touch power level 0.
IMPORTANT NOTE: After activation, the control remains
gray until compatible cookware is placed on an element.
Without compatible cookware on an element, the control
turns o after 30 seconds.
ZONE TIMER
A zone timer automatically reduces the power level to 1
when the timer is complete.
Setting zone timer:
1 Touch for the desired element.
2 Set the duration.
3 Touch .
SENSOR COOKING
To select a sensor cooking mode, touch the desired
element on the touchscreen. Touch , then select the
desired mode. Refer to the chart below.
ICON FUNCTION USES
Warm Keep cooked, hot food warm.
Melt Melt butter, hold chocolate, and sauces.
Simmer Simmer sauces and steam rice.

8 | English
Care RecommendationsCooktop Operation
Care Recommendations
CLEANING
Stainless steel Use a nonabrasive stainless steel cleaner and apply with a soft lint-free cloth. To bring out the natural luster, lightly
wipe the surface with a water-dampened microfiber cloth followed by a dry polishing chamois. Always follow the
grain of stainless steel.
Touchscreen and
Glass-ceramic
surface
Allow to cool. Use a spray degreaser to remove fingerprints and a non-abrasive Ceran®cooktop cleaner for food
soil. Do not allow any item that could melt to come in contact with the glass-ceramic surface when hot. Remove
cooked-on debris with the provided razor blade scraper.
Cooktop Operation
BRIDGE ELEMENT
The bridge element provides an oblong heating area
for use with a griddle/teppan-yaki, open roaster, or fish
poacher.
To preheat a griddle/teppan-yaki, set the bridge element
power level to High for five minutes, then reduce for
cooking.
IMPORTANT NOTE: Boost mode is not available for bridge.
CAUTION
A griddle/teppan-yaki, open roaster, or fish poacher
should not be used when the bridge element is o or
with any other combination of heating elements.
Setting bridge:
1 Touch the desired single element on the touchscreen.
2 Touch the desired power level (1–9).
3 Touch , then touch .
TIMER
The timer can be set in one-minute increments up to
9 hours and 59 minutes. The timer is independent from
the cooktop.
Setting timer:
1 Touch .
2 Scroll to adjust the duration in hours or minutes, then
touch .
3 The timer chimes with one minute left and completes
the countdown in seconds.
4 When complete, the timer chimes, then flashes. Touch
to cancel.
HOT SURFACE INDICATOR
appears on the touchscreen and indicates the surface
may be hot, even when the cooktop is o.

wolfappliance.com | 9
Wolf Appliance International Limited Warranty
FOR RESIDENTIAL USE
FULL TWO YEAR WARRANTY*
For two years from the date of original installation, this Wolf Appliance product warranty covers all parts and labor to repair or
replace, under normal residential use, any part of the product that proves to be defective in materials or workmanship. All service
provided by Wolf Appliance under the above warranty must be performed by Wolf Factory Certified Service, unless otherwise speci-
fied by Wolf Appliance, Inc. Service will be provided during normal business hours.
LIMITED FIVE YEAR WARRANTY
For five years from the date of original installation, Wolf Appliance will repair or replace the following parts that prove to be defective
in materials or workmanship: stainless steel briquette trays, gas valves, drip pans, electronic control boards and electric heating ele-
ments. If the owner uses Wolf Factory Certified Service, the service provider will repair or replace these parts with the owner paying
for all other costs, including labor. If the owner uses non-certified service, the owner must contact Wolf Appliance, Inc. (using the
information below) to receive repaired or replacement parts. Wolf Appliance will not reimburse the owner for parts purchased from
non-certified service or other sources.
For more information regarding your Wolf product warranty, contact your authorized Wolf dealer. Warranties must comply to all
country, state, city, local and or ordinance.
*Stainless steel (doors, panels, handles, product frames and interior surfaces) are covered by a limited 60-day parts and labor warranty
for cosmetic defects.
Warranty
Sub-Zero, Sub-Zero & Design, Sub-Zero & Snowflake Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, Wolf, Wolf &
Design, Wolf Gourmet, W & Design, red colored knobs, Cove, and Cove & Design are registered trademarks and service marks of Sub-Zero Group, Inc. and its subsidiaries.
All other trademarks are property of their respective owners in the United States and other countries.
Troubleshooting
SERVICE
• Maintain the quality built into your product by contact-
ing Wolf Factory Certified Service.
• When contacting service, you will need the model and
serial number of your product. Both numbers are listed
on the product rating plate. Refer to page 6 for rating
plate location.
• For warranty purposes, you will also need the date of
installation and name of your authorized Wolf dealer.
This information should be recorded on page 2.
SERVICE (FOR AUSTRALIA ONLY)
• Yearly maintenance is recommended.
• Maintain the quality built into your product by contact-
ing Wolf Factory Certified Service.
• When contacting service, you will need the model and
serial number of your product. Both numbers are listed
on the product rating plate. Refer to page 6 for rating
plate location.
• For warranty purposes, you will also need the date of
installation and name of your authorized Wolf dealer.
This information should be recorded on page 2.
• For Australia only, contact:
Sub-Zero Group Australia Pty Ltd
Level 10, 469 La Trobe Street
Melbourne Victoria 3000
Phone [phone]
subzero-wolf.com.au
SERVICE (FOR UNITED KINGDOM ONLY)
• Sub-Zero & Wolf Ltd
9 The Street, Heybridge, Maldon, Essex, CM9 4XB
020 8418 3800
[email protected]
www.subzero-wolf.co.uk
Troubleshooting
OPERATION
Cooktop does not operate.
• Verify power is on.
• Verify electrical power to the cooktop and home circuit
breaker is on.
• The cooktop is locked. Touch and hold to unlock.
• The cooktop automatically turns o after a specified
duration of continual use. Refer to the chart below.
AUTOMATIC SHUT-OFF
POWER LEVEL DURATION
1–2 8 hours
2.5–5.5 6 hours
6–6.5 / Sensor Cooking 4 hours
7–9 2 hours
Cooktop temperature issue.
• Contact Wolf Factory Certified Service.
ERROR CODE DESCRIPTION ACTION
07 Controls Over
Temp
• Turn o the cooktop,
remove cookware, and allow
to cool completely.
09 Coil Over Temp • Remove cookware from the
aected zone and allow the
zone to cool completely.
• Verify the vents under the
cooktop are not blocked.
15 Power Supply • Turn power o at the circuit
breaker. Wait 10 minutes, then
turn the breaker back on.
50 Stuck Key • Clean the cooktop controls.
• Turn power o at the circuit
breaker. Wait 10 minutes, then
turn the breaker back on.
102 Generator Over
Temp
• Turn o the cooktop,
remove cookware, and allow
to cool completely.

2 | Español
Contenido
3Precauciones de seguridad
6Características de las placas de inducción
6Funcionamiento de la placa
Recomendaciones de mantenimiento
9Solución de problemas
9Garantía de Wolf
Placa de inducción
Atención al cliente
La información relativa al número de serie y el modelo se
muestra en la placa de datos del producto. Consulte la
página 6 para ver la ubicación de la placa de datos. Para
cuestiones relacionadas con la garantía, también necesita
saber la fecha de instalación y el nombre de su distribuidor
autorizado de Wolf. Guarde la siguiente información para
tenerla como referencia en el futuro.
Si alguna vez su producto necesita asistencia, asegúrese de
acudir a un servicio técnico autorizado de Wolf.
INFORMACIÓN DE SERVICIO
Número de modelo
Número de serie
Fecha de la instalación
Nombre del servicio certificado
Número del servicio certificado
Distribuidor autorizado
Número del distribuidor
Aviso importante
Para garantizar que este producto se instala y funciona de
la forma más eficaz y segura posible, tenga en cuenta la
información que se destaca en esta guía:
AVISO IMPORTANTE resalta información que es
especialmente importante.
PRECAUCIÓN
Indica una situación en la que se pueden sufrir
heridas leves o provocar daños al producto si no se
siguen las instrucciones especificadas.
ADVERTENCIA
Indica peligro de que se produzcan heridas
personales graves o incluso puede provocar
la muerte si no se siguen las precauciones
especificadas.
