Wolf e Series User manual

E Series Ovens Installation Guide

E SERIES OVENS
Contents
3E Series Ovens
4Specications
10 Installation
11 Troubleshooting
Features and specications are subject to change at any
time without notice. Visit wolfappliance.com/specs for the
most up-to-date information.
2 | Wolf Customer Care 800.222.7820
Important Note
To ensure this product is installed and operated as safely
and efciently as possible, take note of the following types
of highlighted information throughout this guide:
IMPORTANT NOTE highlights information that is especially
important.
CAUTION indicates a situation where minor injury or product
damage may occur if instructions are not followed.
WARNING states a hazard that may cause serious injury or
death if precautions are not followed.
IMPORTANT NOTE: Throughout this guide, dimensions in
parentheses are millimeters unless otherwise specied.
IMPORTANT NOTE: Save these instructions for the local
electrical inspector.

wolfappliance.com | 3
E SERIES OVENS
Product Information
Important product information including the model and
serial number are listed on the product rating plate. The
rating plate is located below the control panel on the right.
The oven door must be open to view the rating plate. Refer
to the illustration below.
If service is necessary, contact Wolf factory certied service
with the model and serial number. For the name of the
nearest Wolf factory certied service or for questions
regarding the installation, visit the contact & support section
of our website, wolfappliance.com or call Wolf customer
care at 800-222-7820.
Rating plate location.
RATING
PLATE

4 | Wolf Customer Care 800.222.7820
SPECIFICATIONS
COMBINATION INSTALLATIONS
Wolf built-in ovens are designed and agency approved for
installation with Wolf cooktops, microwaves and warming
drawers only. The nominal width of the oven should match
the nominal width of the cooktop. A built-in oven cannot be
installed below a Wolf rangetop.
For typical combination installations, refer to the Wolf
Design Guide.
The single oven may be installed next to another E series
single oven. You must allow for a 11/2"(38) space between
oven openings. A separate inner wall is required for each
oven between openings.
Installation Requirements
The E series oven can be installed in a standard or ush
inset application. If a cooktop is being installed above an
oven, a minimum of 1/4"(6) is required between units. Loca-
tion of the electrical supply within the oven opening may
require additional cabinet depth.
Finish the edges of the opening. They may be visible when
the door is open.
For standard installations, face trim will overlap stiles and
rails. Refer to the chart below.
For ush inset installations, a minimum 1/4"(6) reveal is
required on all sides. To ensure consistent reveals, each
corner of the opening must be exactly 90°.
INSTALLATION REQUIREMENTS
BASE SUPPORT MIN
Single Oven 250 lb (115 kg)
Double Oven 400 lb (181 kg)
TRIM OVERLAP
Top 1/2"(13)
Bottom 1/8"(3)
Sides 11/16"(17)

wolfappliance.com | 5
SPECIFICATIONS
Electrical
Installation must comply with all applicable electrical codes.
Locate the electrical supply ush with the back wall and
within the shaded area shown in the illustrations on the
following pages. For ease of installation, the electrical
supply for the oven can be placed in an adjacent cabinet
within reach of the conduit.
Performance may be compromised if the electrical supply is
less than 240 volts.
The oven is supplied with a conduit consisting of two
insulated hot lead conductors and a bare ground conductor.
The wiring diagram covering the control circuit is provided
with the oven.
ELECTRICAL REQUIREMENTS
SINGLE OVEN
Electrical Supply grounded, 240/208 VAC, 60 Hz
Service 30 amp dedicated circuit
Conduit 4' (1.2 m)
Total Amps 21
Max Connected Load 5.1 kW
Min Supply Wire L1, L2, ground—10 AWG
DOUBLE OVEN
Electrical Supply grounded, 240/208 VAC, 60 Hz
Service 50 amp dedicated circuit
Conduit 5' (1.5 m)
Total Amps 37
Max Connected Load 8.9 kW
Min Supply Wire L1, L2, ground—10 AWG
WARNING
The complete appliance must be properly grounded at
all times when electrical power is applied.
Grounding through the neutral conductor is prohibited
for new branch-circuit installations (1996 NEC); mobile
homes and recreational vehicles, or where local codes
prohibit grounding through the neutral conductor.
If aluminum house supply wiring is utilized, splice the
appliance copper wire to the aluminum house wiring
using special connectors design and agency certied
for joining copper and aluminum. Follow the connector
manufacturer's recommended procedure carefully.
Improper connection can result in a re hazard.
Rating plate location.
RATING
PLATE

6 | Wolf Customer Care 800.222.7820
SPECIFICATIONS
E Series Single Oven
STANDARD INSTALLATION
E
5"
(127)
E
E
4"
(102)
FRONT VIEW
SIDE
VIEW
NOTE: Location of electrical supply within opening may require additional cabinet depth.
Dashed line represents profile of unit
.
24" (610)
OPENING
DEPTH
TOP VIEW
271/4"
(692)
OPENING
HEIGHT
281/2" (724)
OPENING WIDTH

wolfappliance.com | 7
SPECIFICATIONS
E Series Double Oven
STANDARD INSTALLATION
E
5"
(127)
4"
(102)
E
E
FRONT VIEW
SIDE
VIEW
NOTE: Location of electrical supply within opening may require additional cabinet depth.
Dashed line represents profile of unit
.
493/4"
(1264)
OPENING
HEIGHT
24" (610)
OPENING
DEPTH
281/2" (724)
OPENING WIDTH
17" (432)
TYPICAL
TOP VIEW

8 | Wolf Customer Care 800.222.7820
SPECIFICATIONS
E
5"
(127)
4"
(102)
FRONT VIEW
SIDE
VIEW
*W
ill be visible and should be finished to match cabinetry.
**1"
(25) for professional and transitional models and 11/4"(32) for contemporary model.
NOTE: Location of electrical supply within opening may require additional cabinet depth.
Dashed line represents profile of unit
.
283/8"
(721)
FLUSH INSET
HEIGHT
3/4"(19)
3/8" (10)
15/16" (24)
25" (635)
FLUSH INSET
DEPTH
FINISHED
CLEATS*
303/8" (772)
FLUSH INSET WIDTH
1" (25)
OR
11/4" (32)**
TOP VIEW
39" (981)
TYPICAL
E
E
E Series Single Oven
FLUSH INSET INSTALLATION

wolfappliance.com | 9
SPECIFICATIONS
E Series Double Oven
FLUSH INSET INSTALLATION
E
5"
(127)
4"
(102)
E
E
FRONT VIEW
SIDE
VIEW
*W
ill be visible and should be finished to match cabinetry.
**1"
(25) for professional and transitional models and 11/4"(32) for contemporary model.
NOTE: Location of electrical supply within opening may require additional cabinet depth.
Dashed line represents profile of unit
.
507/8"
(1292)
FLUSH INSET
HEIGHT
17" (432)
TYPICAL
3/4"(19)
3/8" (10)
15/16" (24)
303/8" (772)
FLUSH INSET WIDTH
25" (635)
FLUSH INSET
DEPTH
FINISHED
CLEATS*
1" (25)
OR
11/4" (32)**
TOP VIEW

10 | Wolf Customer Care 800.222.7820
Preparation
Before moving the oven, protect any nished ooring and
secure the oven door(s) closed to prevent damage.
Use an appliance dolly to move the unit near the opening.
Remove and recycle packing materials. Do not lift or carry
the oven by the door handle.
CAUTION
Do not lift the oven by the door handle. This will
damage the oven door and hinges.
OVEN DOOR REMOVAL
To lighten the load or to t through a door way, the oven
door(s) can be removed. Only remove if necessary. Door
removal should only be done by a certied installer or
service technician.
To remove, open the door completely. Rotate both hinge
latches forward to the open position, then lift the door up
and out. Refer to the illustration below.
To reinstall, insert door hinges into the frame openings, then
rotate hinge latches to the closed position.
INSTALLATION
Electrical Connection
WARNING
Verify power is disconnected from the electrical box
before proceeding.
With the oven positioned directly in front of the opening,
feed the conduit through the opening in the cabinet platform
(if applicable). Depending on local codes, connect the oven
to the electrical supply following these steps for a three-wire
or four-wire system:
1Connect the black appliance wire to the black (L1) power
supply wire in the electrical box.
2Connect the red appliance wire to the red (L2) power
supply wire in the electrical box.
3Connect the ground appliance wire to the green/ground
house grounding wire in the electrical box.
4For a four-wire system, leave the white neutral wire in the
house electrical box unconnected. Seal with a wire cap.
CLOSED
OPEN
Oven door removal.
