Wolf L Series SO30F User manual

L Series 30" Built-In Single Ovens
Model SO30F
Framed Door Style
The Wolf dual convection system
delivers unsurpassed flexibility and
control. Intuitive and easy to command
from the rotating control panel. Brilliant
halogen lights illuminate the beautiful
blue interior. Choose the framed or
unframed door style in classic stainless
steel. Our exclusive premium finishes,
platinum and carbon stainless, are avail-
able in unframed only. The 30" built-in
single oven pairs nicely with the Wolf
microwave, which is identical in width.
Accessories
Bake stone accessory, includes stone,
rack and peel
Two-piece broiler pan and temperature
probe
Set of three 30" oven racks
Dehydration racks with door stop
Accessories are available through your
Wolf dealer. To obtain local dealer information,
visit the Showroom Locator section of our
website, wolfappliance.com.
Rotating Glass Touch Control Panel
Classic CarbonPlatinum
Features
Framed and unframed door styles in
classic stainless steel finish—unframed
door style also available in platinum and
carbon finishes
Dual convection logic control system
Ten cooking modes—bake, roast, broil,
convection bake, convection roast,
convection broil, convection, bake stone
(accessory required), dehydrate (acces-
sory required) and proof
Rotating glass touch control panel
Cobalt blue porcelain oven interior
Three removable racks with full-extension
bottom rack and removable six-level rack
guide
Large viewing triple-pane window
Dual interior halogen lighting
Hidden bake element and recessed broil
element
Temperature probe and receptacle
Self-clean, delayed start and Sabbath
feature
Door hinge with hydraulic damper assures
smooth opening and closing of the door
This appliance is certified by Star-K to
meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.
Model Options SO30F/S SO30U/S SO30U/P SO30U/B
Door Style Framed Unframed Unframed Unframed
Stainless Steel Finish Classic Classic Platinum Carbon
Model SO30U
Unframed Door Style
Model SO30F/S shown—framed door style with classic stainless steel finish.
Also shown, Model CT30E/S electric cooktop and Model CTWH30 cooktop wall hood.

273/16"
(691)
OPENING
HEIGHT
281/2" (724)
OPENING WIDTH
5"
(127)
4"
(102)
24"min (610)
OPENING DEPTH
E E
E
E
33" (838)
RECOMMENDED CABINET WIDTH
30"min (762)
ELECTRICAL LOCATION
WITHIN OPENING
APPLIES ONLY TO
CABINETS DEEPER
THAN 24" (610)
E
E
5"
(127)
43/4"min (121)
33" (838)
RECOMMENDED CABINET WIDTH
30"min (762)
33/4"min (95)
36" (914)
STANDARD
FLOOR TO
COUNTER
HEIGHT
273/16"
(691)
OPENING
HEIGHT
281/2" (724)
OPENING WIDTH
4"
(102)
24"min (610)
OPENING DEPTH
ELECTRICAL
LOCATION WITHIN
OPENING APPLIES
ONLY TO CABINETS
DEEPER THAN 24" (610)
30" L Series Built-In Single Oven
Installation Notes
Complete installation specifications can be
found on our website, wolfappliance.com.
Unit dimensions may vary by ±
1
/ 8 ".
Dimensions in parentheses are in
millimeters unless otherwise specified.
Specifications
Overall Width 297/8"
Overall Height 271/2"
Overall Depth 24"
Oven Door Clearance 203/4"
Overall Oven Interior Capacity 4.5 cu ft
Oven Interior Dimensions
25" W x 161/2" H x 19" D
Recommended Cabinet Width 33"
Minimum Cabinet Width 30"
Minimum Cabinet Depth 24"
Minimum Base Support 250 lbs
Opening Width 281/2"
Opening Height 273/16"
Electrical Requirements 240/208 V AC
60 Hz, 30 amp circuit
Conduit 4' flexible 4-wire
Electrical Rating 5.1 kW at 240 V
3.8 kW at 208 V
Total Amps 21
Shipping Weight 273 lbs
Installation Specifications
Wall Application
Undercounter Installation
Overall Dimensions
IMPORTANT NOTE: Unless you are using cabinets deeper than 24", it is recommended that the
electrical supply be placed in an adjacent cabinet within reach of the conduit. Choose the location
shown in the illustrations that best suits your installation.
24" (610)
BEHIND FRAME
271/2"
(699)
283/16"
(716)
28"
(711)
297/8"
(759)
24"
(610)
POWER CORD
CHANNEL
OPEN OVEN DOOR
TOP VIEW
3"
(76)
203/4"
(527)
11/4"
(32)
17/8"
(48)
17/8"
(48)
RIGHT SIDE VIEW
261/16"
(662)
INSIDE
SIDE TRIM
