M Series Built-In Ovens
Four striking looks are just the beginning. Superior perfor-
mance features include our advanced Dual VertiCross™
convection fan system, touch-screen controls, convenient
preset cooking programs and improved interior lighting.
There is more usable space inside for deliciousness on a
grand scale. M series ovens can be installed in a standard
or ush inset application.
M SERIES OVENS
UPPEROVEN LOWEROVEN
M SERIES OVENS
TRANSITIONAL
ICBSO30PM/S/PH
ICBSO30CM/B
ICBSO30TM/S/TH
ICBDO30PM/S/PH
ICBDO30CM/B
ICBDO30TM/S/TH
PROFESSIONAL
CONTEMPORARY
ICBSO30CM/S
ICBDO30CM/S
BUILT-IN OVENS COOKTOPS | COFFEE RANGES | RANGETOPS VENTILATION

4 | English
M SERIES OVENS
M Series Built-In Ovens
TRANSITIONAL SINGLE OVEN
TRANSITIONAL DOUBLE OVEN
OPEN OVEN DOOR
584 mm
BEHIND FRAME
723
mm 686
mm
65
mm
46 mm
543
mm
22
mm
36 mm
CONDUIT
CHANNEL
218
mm
51 mm
759 mm
OPEN OVEN DOOR
584 mm
BEHIND FRAME
1291
mm 1254
mm
65
mm
46 mm
543
mm
22
mm
36 mm
CONDUIT
CHANNEL
218
mm
51 mm
759 mm
VENTILATION RANGES | RANGETOPS COOKTOPS | COFFEE BUILT-IN OVENS

wolfappliance.com | 5
M SERIES OVENS
M Series Built-In Ovens
PROFESSIONAL SINGLE OVEN
OPEN OVEN DOOR
584 mm
BEHIND FRAME
723
mm 686
mm
83
mm
46 mm
543
mm
22
mm
36 mm
CONDUIT
CHANNEL
218
mm
51 mm
759 mm
OPEN OVEN DOOR
584 mm
BEHIND FRAME
1291
mm 1254
mm
759 mm
46 mm
543
mm
83
mm
22
mm
36 mm
CONDUIT
CHANNEL
218
mm
51 mm
UPPEROVEN LOWEROVEN
PROFESSIONAL DOUBLE OVEN
BUILT-IN OVENS COOKTOPS | COFFEE RANGES | RANGETOPS VENTILATION

6 | English
M SERIES OVENS
OPEN OVEN DOOR
584 mm
BEHIND FRAME
1291
mm 1254
mm
46 mm
543
mm
22
mm
36 mm
CONDUIT
CHANNEL
218
mm
51
mm
759 mm
OPEN OVEN DOOR
584 mm
BEHIND FRAME
723
mm 686
mm
46 mm
543
mm
22
mm
36 mm
CONDUIT
CHANNEL
218
mm
51
mm
759 mm
M Series Built-In Ovens
CONTEMPORARY SINGLE OVEN—STAINLESS STEEL
CONTEMPORARY DOUBLE OVEN—STAINLESS STEEL
VENTILATION RANGES | RANGETOPS COOKTOPS | COFFEE BUILT-IN OVENS

wolfappliance.com | 7
M SERIES OVENS
OPEN OVEN DOOR
584 mm
BEHIND FRAME
1291
mm 1254
mm
46 mm
543
mm
25
mm
36 mm
CONDUIT
CHANNEL
218
mm
51 mm
759 mm
OPEN OVEN DOOR
584 mm
BEHIND FRAME
723
mm 686
mm
46 mm
543
mm
25
mm
36 mm
CONDUIT
CHANNEL
218
mm
51 mm
759 mm
M Series Built-In Ovens
CONTEMPORARY SINGLE OVEN—BLACK GLASS
CONTEMPORARY DOUBLE OVEN—BLACK GLASS
BUILT-IN OVENS COOKTOPS | COFFEE RANGES | RANGETOPS VENTILATION

8 | English
M SERIES OVENS
Planning Information
The M series oven can be installed in a standard or ush
inset application. If a cooktop is being installed above an
oven, a minimum of 6 mm is required between units. Loca-
tion of the electrical supply within the oven opening may
require additional cabinet depth.
Finish the edges of the opening. They may be visible when
the door is open.
For standard installations, face trim will overlap stiles and
rails. Refer to the chart below.
For ush inset installations, a minimum 3 mm reveal is
required on all sides. To ensure consistent reveals, each
corner of the opening must be exactly 90°.
INSTALLATION REQUIREMENTS
BASE SUPPORT MIN
Single Oven 115 kg
Double Oven 181 kg
TRIM OVERLAP
Top 25 mm
Bottom 0 mm
Sides 18 mm
DUAL INSTALLATION
Two 76 cm single M series ovens can be installed side by
side in a standard or ush inset application. A dual instal-
lation kit is required. To maintain appropriate airow, the
ovens must be installed into one opening. Any cosmetic or
structural material placed between the ovens will impede
airow and is not recommended. Refer to illustrations on the
following pages.
The dual installation kit is available through an authorized
Wolf dealer.
ELECTRICAL
Installation must comply with all applicable electrical codes
and be properly grounded (earthed).
Locate the electrical supply ush with the back wall and
within the shaded area shown in the illustration for your spe-
cic installation on the following pages. For ease of instal-
lation, the electrical supply for the oven can be placed in an
adjacent cabinet within reach of the conduit.
Performance may be compromised if the electrical supply is
less than 220 volts.
The oven is supplied with a single phase and 3-phase
convertible power inlet box. The wiring diagram covering the
control circuit is provided with the oven.
ELECTRICAL REQUIREMENTS
SINGLE OVEN SINGLE PHASE 3-PHASE
Required Power Supply 220-240 V AC
50/60 Hz
380-415 V AC
50 Hz
Maximum Connected Load 4.2–4.8 kW 3.0–3.6 kW
DOUBLE OVEN SINGLE PHASE 3-PHASE
Required Power Supply 220-240 V AC
50/60 Hz
380-415 V AC
50 Hz
Maximum Connected Load 8.4–9.6 kW 4.2–4.8 kW
VENTILATION RANGES | RANGETOPS COOKTOPS | COFFEE BUILT-IN OVENS

wolfappliance.com | 9
M SERIES OVENS
M Series Single Oven
STANDARD INSTALLATION
E
127
mm
E
E
102
mm
FRONT VIEW
SIDE
VIEW
NOTE: Location of electrical supply within opening may require additional cabinet depth.
Dashed line represents profile of unit
.
591 mm
OPENING
DEPTH
TOP VIEW
699 mm
OPENING
HEIGHT
W
OPENING WIDTH
OPENING WIDTH W
76 cm Model 724 mm
BUILT-IN OVENS COOKTOPS | COFFEE RANGES | RANGETOPS VENTILATION

10 | English
M SERIES OVENS
M Series Double Oven
STANDARD INSTALLATION
E
127
mm
102
mm
E
E
FRONT VIEW
SIDE
VIEW
NOTE: Location of electrical supply within opening may require additional cabinet depth.
Dashed line represents profile of unit
.
1267 mm
OPENING
HEIGHT
591 mm
OPENING
DEPTH
W
OPENING WIDTH
432 mm
TYPICAL
TOP VIEW
OPENING WIDTH W
76 cm Model 724 mm
VENTILATION RANGES | RANGETOPS COOKTOPS | COFFEE BUILT-IN OVENS

wolfappliance.com | 11
M SERIES OVENS
M Series Single Oven
FLUSH INSET INSTALLATION
E
127
mm
102
mm
FRONT VIEW
SIDE
VIEW
*
25 mm minimum depth. Shaded areas will be visible and should be finished to match cabinetry.
**
22 mm for professional and transitional models and 25 mm for contemporary model.
***Dimension provides minimum reveals.
NOTE: Location of electrical supply within opening may require additional cabinet depth.
Dashed line represents profile of unit.
730 mm
FLUSH INSET
HEIGHT***
29 mm
3 mm
21 mm
610 mm
FLUSH INSET
DEPTH
22 mm
OR
25 mm**
FINISHED
CLEATS*
W
FLUSH INSET WIDTH***
TOP VIEW
E
E
FLUSH INSET WIDTH W
76 cm Model 765 mm
BUILT-IN OVENS COOKTOPS | COFFEE RANGES | RANGETOPS VENTILATION

12 | English
M SERIES OVENS
M Series Double Oven
FLUSH INSET INSTALLATION
E
127
mm
102
mm
FRONT VIEW
SIDE
VIEW
*
25 mm minimum depth. Shaded areas will be visible and should be finished to match cabinetry.
**
22 mm for professional and transitional models and 25 mm for contemporary model.
***Dimension provides minimum reveals.
NOTE: Location of electrical supply within opening may require additional cabinet depth.
Dashed line represents profile of unit.
1299 mm
FLUSH INSET
HEIGHT***
29 mm
3 mm
21 mm
610 mm
FLUSH INSET
DEPTH
22 mm
OR
25 mm**
FINISHED
CLEATS*
W
FLUSH INSET WIDTH***
432 mm
TYPICAL
TOP VIEW
E
E
FLUSH INSET WIDTH W
76 cm Model 765 mm
VENTILATION RANGES | RANGETOPS COOKTOPS | COFFEE BUILT-IN OVENS

wolfappliance.com | 13
E Series Built-In Ovens
Stainless models feature a redesigned stainless steel
touch-action control panel, helping to create great meals
with ease, as well as adding a striking design feature to the
kitchen. Smart technology gives the E series ten cooking
modes, with Wolf’s innovative dual convection in single
ovens and in the upper unit of double ovens. Wolf E series
ovens are crafted of stainless steel. Tubular handles have
been updated to match the rest of the new Wolf cooking
appliance offering, providing a more cohesive look. E series
ovens can be installed in a standard or ush inset application.
ICBSO30CE/B/TH
ICBSO30TE/S/TH
ICBDO30TE/S/TH
ICBDO30CE/B/TH
ICBSO30PE/S/PH
ICBDO30PE/S/PH
E SERIES OVENS
E SERIES OVENS
TRANSITIONAL
PROFESSIONAL
CONTEMPORARY
WARM LIGHTTEMPMODETIMER TIME OFF
OK
ICBSO24TE/S/TH
WATERLIGHT TEMP MODE TIMERTIMEOFF
OK
ICBSO2418TE/S/TH
BUILT-IN OVENS COOKTOPS | COFFEE RANGES | RANGETOPS VENTILATION

14 | English
E SERIES OVENS
60 cm E Series Ovens
MODEL ICBSO2418TE/S/TH TRANSITIONAL SINGLE OVEN
MODEL ICBSO24TE/S/TH TRANSITIONAL SINGLE OVEN
OPEN OVEN DOOR
546 mm
BEHIND FRAME
597
mm 591
mm
64
mm
559 mm
460
mm
22 mm
597 mm
WARM LIGHT TEMPMODETIMER TIME OFF
OK
OPEN OVEN DOOR
454
mm 446
mm
64
mm
538 mm
360
mm
22 mm
597 mm 546 mm
BEHIND FRAME
WATERLIGHT TEMP MODE TIMERTIMEOFF
OK
VENTILATION RANGES | RANGETOPS COOKTOPS | COFFEE BUILT-IN OVENS

wolfappliance.com | 15
E SERIES OVENS
76 cm E Series Ovens
TRANSITIONAL SINGLE OVEN
603 mm
BEHIND FRAME
708
mm
759 mm
CONDUIT
CHANNEL 689
mm
70
mm
76 mm
718 mm
559
mm
244
mm
225
mm
25 mm
OPEN OVEN DOOR
OPEN OVEN DOOR
603 mm
BEHIND FRAME
1280
mm 1261 mm
759 mm 70
mm
CONDUIT
CHANNEL
718 mm
559
mm
244
mm
225
mm
76 mm
25 mm
TRANSITIONAL DOUBLE OVEN
BUILT-IN OVENS COOKTOPS | COFFEE RANGES | RANGETOPS VENTILATION

16 | English
E SERIES OVENS
76 cm E Series Ovens
PROFESSIONAL SINGLE OVEN
603 mm
BEHIND FRAME
708
mm
759 mm
CONDUIT
CHANNEL 689
mm
86
mm
76 mm
718 mm
559
mm
244
mm
225
mm
25 mm
OPEN OVEN DOOR
OPEN OVEN DOOR
603 mm
BEHIND FRAME
1280
mm 1261 mm
759 mm
CONDUIT
CHANNEL
718 mm
559
mm
244
mm
225
mm
76 mm
25 mm
86
mm
PROFESSIONAL DOUBLE OVEN
VENTILATION RANGES | RANGETOPS COOKTOPS | COFFEE BUILT-IN OVENS

wolfappliance.com | 17
E SERIES OVENS
OPEN OVEN DOOR
603 mm
BEHIND FRAME
1280
mm 1257 mm
759 mm 76
mm
32 mm
CONDUIT
CHANNEL
76 mm
718 mm
559
mm
244
mm
225
mm
OPEN OVEN DOOR
603 mm
BEHIND FRAME
708
mm
759 mm
32 mm
687
mm
76
mm
CONDUIT
CHANNEL
76 mm
718 mm
559
mm
244
mm
225
mm
76 cm E Series Ovens
CONTEMPORARY SINGLE OVEN
CONTEMPORARY DOUBLE OVEN
BUILT-IN OVENS COOKTOPS | COFFEE RANGES | RANGETOPS VENTILATION

18 | English
Planning Information
The E series oven can be installed in a standard or ush
inset application. If a cooktop is being installed above an
oven, a minimum of 6 mm is required between units. Loca-
tion of the electrical supply within the oven opening may
require additional cabinet depth.
Finish the edges of the opening. They may be visible when
the door is open.
For standard installations, face trim will overlap stiles and
rails. Refer to the chart below.
For ush inset installations, a minimum 6 mm reveal is
required on all sides. To ensure consistent reveals, each
corner of the opening must be exactly 90°.
INSTALLATION REQUIREMENTS
BASE SUPPORT MIN
60 cm Single Oven 68 kg
76 cm Single Oven 115 kg
76 cm Double Oven 181 kg
TRIM OVERLAP 60 cm MODEL 76 cm MODEL
Top 6 mm 13 mm
Bottom 0 mm 3 mm
Sides 17 mm 17 mm
ELECTRICAL
Installation must comply with all applicable electrical codes
and be properly grounded (earthed).
Locate the electrical supply ush with the back wall and
within the shaded area shown in the illustration for your
specic installation on the following pages. For ease of
installation, the electrical supply for the oven can be placed
in an adjacent cabinet within reach of the conduit. The 76 cm
units are supplied with terminal box convertible to single or
3-phase.
The wiring diagram covering the control circuit is provided
with the oven.
ELECTRICAL REQUIREMENTS
60 cm SINGLE OVEN
Electrical Supply 220-240 V AC, 50 Hz
Service 3400 W
Receptacle grounding-type (earthed)
Power Cord 1.8 m
ELECTRICAL REQUIREMENTS
76 cm SINGLE OVEN SINGLE PHASE 3-PHASE
Required Power Supply 220-240 V AC
50/60 Hz
380-415 V AC
50 Hz
Max Connected Load 4.4 kW 4.4 kW
Total Amps 19 19
76 cm DOUBLE OVEN SINGLE PHASE 3-PHASE
Required Power Supply 220-240 V AC
50/60 Hz
380-415 V AC
50 Hz
Max Connected Load 7.4 kW 5.1 kW
Total Amps 32 22
E SERIES OVENS
VENTILATION RANGES | RANGETOPS COOKTOPS | COFFEE BUILT-IN OVENS

wolfappliance.com | 19
E SERIES OVENS
60 cm E Series Oven
STANDARD INSTALLATION
FRONT VIEW
SIDE
VIEW
NOTE: Electrical supply must be located in adjacent cabinet within .9 m of opening.
H
OPENING
HEIGHT
572 mm
OPENING
DEPTH
TOP VIEW
562 mm
OPENING WIDTH
EE
OPENING HEIGHT H
Model ICBSO2418TE/S/TH 449 mm
Model ICBSO24TE/S/TH 591 mm
BUILT-IN OVENS COOKTOPS | COFFEE RANGES | RANGETOPS VENTILATION

20 | English
E SERIES OVENS
76 cm E Series Single Oven
STANDARD INSTALLATION
E
127
mm
E
E
102
mm
FRONT VIEW
SIDE
VIEW
NOTE: Location of electrical supply within opening may require additional cabinet depth.
Dashed line represents profile of unit
.
610 mm
OPENING
DEPTH
TOP VIEW
692 mm
OPENING
HEIGHT
724 mm
OPENING WIDTH
VENTILATION RANGES | RANGETOPS COOKTOPS | COFFEE BUILT-IN OVENS
