Wolf ICBDF304 Guide

ICB REVISED 4/ 2018
DUAL FUEL DESIGN GUIDE

TABLE OF CONTENTS
3RANGES
Features and specications are subject to change at any
time without notice.
Throughout this guide, dimensions may vary by ± 3 mm.

subzero-wolf.com.au | 3
Dual Fuel Ranges
Discover a new world of cooking—the best of two worlds,
actually—with a Wolf dual fuel range. Topside, gas cooking
in all its glory, with the ne control of dual-stacked, sealed
burners and options that include the remarkable French top.
Below, that marvel of culinary technology, the Wolf convec-
tion electric oven. Its two fans and four heating elements let
you select from 10 cooking modes so you can choose the
one precisely suited to the dish you’re preparing. Ovens are
self-cleaning. With a variety of range widths to choose from,
kitchens large and small become gateways to the exciting
new world of dual fuel cooking. All models are constructed
of stainless steel and can be ordered in natural or LP gas.
DUAL FUEL RANGES
CONFIGURATIONS
91 cm RANGE
ICBDF366
ICBDF364C
ICBDF364G
ICBDF304
76 cm RANGE
ICBDF606CG
ICBDF604CF
152 cm RANGE
ICBDF486C
ICBDF486G
ICBDF484CG
ICBDF484F
122 cm RANGE
RANGES |

4
| English
Dual Fuel Ranges
76 cm RANGE 91 cm RANGE
DUAL FUEL RANGES
122 cm RANGE
1527 mm
235
mm
937
mm*
1165 mm
1419 mm
1038 mm
1194 mm
664 mm
635 mm
613 mm
699 mm
749 mm
911
mm
937
mm*
152 cm RANGE
759 mm
235
mm
937
mm*
1165 mm
1419 mm
1038 mm
1194 mm
664 mm
635 mm
613 mm
699 mm
749 mm
*929 mm MIN TO 983 mm MAX.
911
mm
937
mm*
911 mm
235
mm
937
mm*
1165 mm
1419 mm
1038 mm
1194 mm
664 mm
635 mm
613 mm
699 mm
749 mm
*929 mm MIN TO 983 mm MAX.
911
mm
937
mm*
1216 mm
235
mm
937
mm*
1165 mm
1419 mm
1038 mm
47" (1194)
664 mm
635 mm
613 mm
699 mm
749 mm
*929 mm MIN TO 983 mm MAX.
911
mm
937
mm*
*937 mm MIN TO 991 mm MAX.
SIDE VIEW—ALL RANGES
RANGES |

subzero-wolf.com.au | 5
DUAL FUEL RANGES
Dual Fuel Ranges
BURNER RATING—Mj/h
SURFACE BURNER NG
Large 16
Small 9
FEATURE NG
Charbroiler 15
Griddle 15
French Top 15
RANGES |

6 | English
Single phase 220-240V AC, 50/60 Hz
3phase 380-415V AC, 50 Hz
MAXIMUM CONNECTED LOAD
DUAL FUEL RANGES SINGLE PHASE 3PHASE
762 mm and 914 mm 19 amps 18 amps
1219 mm 35 amps 18 amps
1524 mm 38 amps 18 amps
GAS SUPPLY
Installation must conform with all applicable gas codes.
A gas supply line of 19 mm rigid pipe is advisable to be
provided to the range. If local codes permit, a certified, .9 m
long, 13 mm or 19 mm ID flexible appliance connector is
recommended to connect the units ISO 7/1-14 female inlet
to the gas supply line.
Wolf natural gas ranges will function up to 3124 m in
altitude without adjustment and LP gas ranges will function
up to 2621 m. If the installation exceeds these elevations,
contact an authorized Wolf dealer for a high altitude
conversion kit.
GAS REQUIREMENTS
NATURAL GAS
Supply Pressure 1 Kpa
LP GAS
Supply Pressure 2.75Kpa
DUAL FUEL RANGES
Planning Information
When installing against a combustible surface, a minimum
254 mm riser is required for a 91 cm dual fuel range with
charbroiler or griddle and all 122 cm and 152 cm models.
Follow all minimum clearances to combustible surfaces
shown in the illustration on the following page.
A Wolf pro ventilation hood is recommended with the dual
fuel range.
ELECTRICAL
Installation must comply with all applicable electrical codes
and be properly grounded (earthed).
Locate the electrical supply ush with the wall or oor and
within the shaded area shown in the illustration on the fol-
lowing page. A separate circuit, servicing only this appliance
is required.
Wolf dual fuel ranges have a terminal block that allows for a
3-wire or 4-wire installation.
Performance may be compromised if the electrical supply is
less than 220 volts.
The range is supplied with a single phase and 3-phase
convertible power inlet box. The wiring diagram covering the
control circuit is provided with the oven.
REQUIRED POWER SUPPLY
RANGES |

subzero-wolf.com.au | 7
DUAL FUEL RANGES
Dual Fuel Range
INSTALLATION
FRONT VIEWSIDE VIEW
*The rangehood fitted above the cooktop must be installed according to the installation instructions for the
rangehoods.
A minimum clearance of 650mm from the top of the burner port to a grease filter/range hood/combustible
surface and 750mm to an Exhaust fan. For models with Char Grill burner a minimum clearance of 1200mm
to a grease filter/range hood/combustible surface from the top of the burner ports of the Char Grill burner
NOTE:
For island installation, 305 mm minimum clearance back of range to combustible rear wall above countertop.
330
mm 457 mm
152
mm
57
mm
LOCATION OF GAS AND
ELECTRICAL EXTENDS
ON FLOOR A
83 mm
254 mm
GAS
330 mm
ELECTRICAL
937 mm
TO COOKING
SURFACE
W
OPENING WIDTH
min 650mm to 1200mm
TO BOTTOM OF
VENTILATION HOOD*
G E
OPENING WIDTH W A
76 cm Model 762 mm 216 mm
91 cm Model 914 mm 343 mm
122 cm Model 1219 mm 610 mm
152 cm Model 1530 mm 787 mm
RANGES |

Wolf Appliance International Limited Warranty
FOR RESIDENTIAL USE
FULL TWO YEAR WARRANTY*
For two years from the date of original installation, this Wolf Appliance product warranty covers all parts
and labor to repair or replace, under normal residential use, any part of the product that proves to be
defective in materials or workmanship. All service provided by Wolf Appliance under the above warranty
must be performed by Wolf factory certied service, unless otherwise specied by Wolf Appliance, Inc.
Service will be provided during normal business hours.
LIMITED THIRD THROUGH FIFTH YEAR WARRANTY
For ve years from the date of original installation, Wolf Appliance will repair or replace the following parts
that prove to be defective in materials or workmanship: gas burners (excluding appearance), electric
heating elements, blower motors (ventilation hoods), electronic control boards, magnetron tubes and
induction generators. The part(s) will be repaired or replaced, free of charge, with the owner paying for
all other costs including labor. All service provided by Wolf Appliance under the above warranty must be
performed by Wolf factory certied service, unless otherwise specied by Wolf Appliance, Inc. Service will
be provided during normal business hours.
For more information regarding your Wolf product warranty, contact your authorized Wolf dealer. Warran-
ties must comply to all country, state, city, local and or ordinance.
*Stainless steel (doors, panels, handles, product frames and interior surfaces) are covered by a limited
60-day parts and labor warranty for cosmetic defects.
