Wolf ICBWWD30 Owner's manual

WARMING DRAWER
USE & CARE INFORMATION
CAJÓN CALENTADOR GUÍA DE USO Y MANTENIMIENTO
TIROIR CHAUFFANT UTILISATION ET ENTRETIEN
CASSETTO SCALDAVIVANDE INFORMAZIONI SU USO E MANUTENZIONE

3
ENGLISH
Introducing the Wolf Warming Drawer 5
Safety Instructions and Precautions 6
Wolf Warming Drawer Features 8
Wolf Warming Drawer Use & Care 10
Wolf Troubleshooting Guide 15
Wolf Service Information 16
ESP NOL
Presentación del cajón calentador de Wolf 19
Precauciones e instrucciones de seguridad 20
Características del cajón calentador de Wolf 22
Uso y mantenimiento del cajón
calentador de Wolf 24
Guía de localización y solución
de problemas de Wolf 29
Información de mantenimiento de Wolf 30
F R A N Ç A I S
Présentation du tiroir chauffant Wolf 33
Instructions et mesures de sécurité 34
Caractéristiques du tiroir chauffant Wolf 36
Utilisation et entretien du tiroir chauffant Wolf 38
Guide de dépistage des pannes Wolf 43
Service après-vente Wolf 44
I TA L I A N O
Presentazione del cassetto
scaldavivande Wolf 47
Precauzioni e istruzioni di sicurezza 48
Funzioni del cassetto scaldavivande Wolf 50
Uso e manutenzione del cassetto
scaldavivande Wolf 52
Guida alla soluzione dei problemi Wolf 57
Informazioni per il servizio di
assistenza Wolf 58

As you read this Use & Care Information,
take particular note of the CAUTION and
WARNING symbols when they appear.
This information is important for safe and
efficient use of the Wolf equipment.
In addition, this Use & Care Information may
signal an IMPORTANT NOTE which highlights
information that is especially important.
signals a situation where minor injury or
product damage may occur if you do not
follow instructions.
states a hazard that may cause serious
injury or death if precautions are not
followed.
WOLF®is a registered trademark of Wolf Appliance, Inc.

5
T H A N K YO U
Your purchase of a Wolf warming drawer
attests to the importance you place upon the
quality and performance of your cooking
equipment. We understand this importance
and have designed and built your warming
drawer with quality materials and workman-
ship to give you years of dependable service.
Before you begin using your warming drawer,
please take some time to read this Use & Care
Information. It will be to your benefit to
familiarize yourself with the safety practices,
features, operation and care recommendations
of the Wolf warming drawer.
If service is necessary, refer to the model and
serial number of the warming drawer. Both
numbers are listed on the product rating plate
located on the left front floor area of the inner
cabinet.To access the rating plate, the drawer
must be fully open. Refer to the illustration
below.
INTRODUCING THE W O L F WA R M I N G D R AW E R
CONTACT
INFORMATION
Website:
wolfappliance.com
Rating plate location
Location of
rating plate

6
W H AT TO D O
IMPORTANT NOTE: Read all
instructions before using this
appliance.
Read this Use & Care Information
carefully before using your new
warming drawer to reduce the risk
of fire, electric shock or injury to
persons.
Ensure proper installation and
servicing. This appliance must be
properly installed and grounded by
a qualified technician. Have the
installer show you the location of
the circuit breaker or fuse so that
you know where to turn off power.
Before performing any service,
unplug or disconnect the power
supply for the warming drawer by
switching off the circuit breaker or
removing the fuse.
Ensure that towels are stacked only
as high as the sides of the drawer
pan. Any higher may result in discol-
oration of the towels.
SAFETY INSTRUCTIONS AND PRECAUTIONS
The purpose of the warming drawer
is to hold hot cooked foods at
serving temperature and proof yeast
dough. Cold food cannot be heated
thoroughly or cooked in the
warming drawer.
Make sure the warming drawer is
securely installed in a firmly
attached cabinet.
Use care when opening the
warming drawer. Partially open the
warming drawer and let warm air
escape prior to removing or
replacing food.
Always place the rack in the desired
location while the warming drawer
is cool.
Always use dry pot holders when
removing items from the warming
drawer. Wet or damp pot holders can
cause burns. Do not use a towel or
bulky cloth in place of pot holders.

7
W H AT N OT TO D O
Do not operate the warming drawer
if the front panel has not been
installed.
Do not repair or replace any part of
the warming drawer unless specifi-
cally recommended in literature
accompanying this appliance. All
service should be referred to a Wolf
authorized service center.
Do not leave children alone or
unattended in the area when the
warming drawer is in use. Never
allow children to sit, stand or hide in
the appliance. Do not let children
play with the warming drawer.
Never leave the warming drawer
open when you are not attending to
the warming drawer.
Never use the warming drawer or
other appliances for warming or
heating the room.
Do not wear loose fitting or hanging
garments while using this appliance.
Do not place more than 34 kg
into the warming drawer.
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
Do not touch the heating element or
the interior surface of the warming
drawer. These surfaces may be hot
enough to burn. Remember:The
inside surfaces of the warming
drawer may be hot when opened.
Do not heat unopened food contain-
ers. Pressure could build up and the
container could burst and cause
serious injury.
Do not use aluminum foil to line the
warming drawer.This may cause
damage to interior surfaces of the
warming drawer.
Do not overfill the warming drawer.
This may lead to difficulty in
opening or closing the drawer, as
well as items falling out of the
drawer or behind the drawer.
Do not use the warming drawer
to dry paper products. If over-
heated, paper products can catch
fire.

8
WARMING DRAWER F E AT U R E S
Stainless steel drawer front and handle
available in classic stainless steel finish
Integrated drawer front allows for custom
wood panel application
850-watt heating element
Hidden electronic touch control panel
Preset and variable temperature control
Preset automatic shut-off or extended
operation in Sabbath Mode
Stainless steel interior
Rack for stacking food
Removable stainless steel drawer pan
Full-extension, ball bearing drawer glides
Certified by Star- to meet religious
regulations
CE certified
W O L F WA R M I N G D R AW E R FEATURES
OPTIONAL A C C E S S O R I E S
These accessories are available through your
Wolf dealer.
WWDFRONT/S – Classic stainless steel
drawer front (with handle)
WWDFRONT/I – Integrated drawer front
(accepts custom wood panel)
WDHAN/S – Classic stainless steel handle
(for integrated drawer front)
WWDPANS – Six-piece containers set with
lids and pan rack

MODEL ICBWWD30
shown with Stainless Steel Drawer Front
W O L F WA R M I N G D R AW E R FEATURES
Rack for stacking
food
Galvanized exterior
Stainless steel
drawer front shown
(sold as an accessory)
Ball bearing
drawer glides
Stainless steel
interior
Removable stainless
steel drawer pan
This appliance is certified by Star-
to meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.
Hidden electronic
touch control panel
Location of
rating plate
9

10
W O L F WA R M I N G D R AW E R U S E & C A R E
ACCESSORIES
Optional
accessories are
available
through your
Wolf dealer.
Warming drawer control panel
ON/OFF
control
Display Preset
temperature
controls
Variable
temperature
controls
(UP and DOWN)
Automatic
shut-off timer
adjustment
(UP and DOWN)
ELECTRONIC C O N T R O LS
The electronic touch control panel is hidden
when the warming drawer is closed. With the
warming drawer open, the controls can be
accessed at the top of the drawer just behind
the drawer front.
PRESETS
Your warming drawer features four preset
temperatures settings; and
. Using the PRESETS eliminates the need
to manually set the temperature and time.
Temperature Settings for Presets:
30˚C
50˚C
70˚C
95˚C
SETTING TEMPERATURE
Touch . Select one of the
PRESETS or
touch the temperature, or arrow
pad. Touch the arrow to increase the
temperature and the arrow to decrease
the temperature.Two seconds after selecting
the temperature/time, the ON indicator will
illuminate as well as a beep indicating that the
unit is on. One of the
PRESETS or the temper-
ature, or arrow pad must be
pressed within 20 seconds of turning unit on,
or the unit will automatically shut off.
Two seconds after selecting the temperature,
the ON indicator will illuminate as well as a
beep, indicating the unit is on.
P R E H E AT
During preheat, the temperature read-out in
the display alternates between the setpoint
and the actual temperature.The word ”
Lo ” will
appear in the display until the temperature
reaches 30˚C. The unit will beep once to signal
preheat is complete.
A U TO M AT I C S H U T- O F F
Your Wolf warming drawer has a factory
preset automatic shut-off time of four hours.
The time interval of the automatic shut-off can
be adjusted from one minute to 24 hours.
To Set Automatic Shut-Off Time:
Warming drawer must be OFF.
Touch .
Touch one of the PRESETS;
or or touch the temperature, or
arrow pad. Touch the arrow to
increase the temperature and the
arrow to decrease the temperature.
Touch and hold the arrow to
increase the shut-off time or the arrow
to decrease the shut-off time.
The wordTIMER will illuminate and the
automatic shut-off time will appear in the
display.

ELECTRONIC C O N T R O LS
PRESET PROGRAMMING
Preset temperatures and time settings can be
adjusted for the and
PRESETS.
The PROOF temperature range is 25–40˚C.
The and PRESETS can be
adjusted from 25–95˚C.
To Adjust Preset Temperature and Time
Settings:
Warming drawer must be OFF.
Touch .
Touch and hold the desired PRESET,
or for 5 seconds. The word
TIMER will illuminate and ”
4:00 ” will flash
in the display along with the temperature.
Adjustments to the settings should be made
within 30 seconds.The unit will exit the
preset programming mode if no adjustment
is made within this time.
To adjust the temperature, touch and hold
the temperature, arrow to increase
or the arrow to decrease the tempera-
ture until the desired preset temperature is
shown in the display.
To adjust the time setting, touch and hold
the arrow to increase or the
arrow to decrease the time until the desired
preset time setting is shown in the display.
Touch and hold the adjusted PRESET again
for 5 seconds. Three quick tones will signify
that settings for the PRESET have been
changed. If 30 seconds elapse before you
touch and hold the PRESET, the unit will
exit the preset programming mode with no
adjustments made.
11
S A B BAT H MODE
Sabbath Mode is for certain religious obser-
vances where some of the warming drawer
functions need to be turned off. In Sabbath
Mode, the automatic shut-off feature is
disabled, allowing the warming drawer to
operate continuously.
To Initiate Sabbath Mode:
Warming drawer must be OFF.
Touch and hold for 5 seconds. The
word ”
Sab ” will flash in the display after
5 seconds.
While ”
Sab ” is flashing, select one of the
PRESETS or set the temperature with the
temperature, or arrow pads.
Touch the arrow to increase the
temperature and the arrow to decrease
the temperature.Two tones will signify that
the Sabbath Mode has been initiated.
In Sabbath Mode, the warming drawer will
operate continuously until is touched.
The word ON will remain illuminated in the
display all the while the unit is in Sabbath
Mode. No other read-outs will appear in the
display.
Touch to shut off the warming drawer
and exit Sabbath Mode.
W O L F WA R M I N G D R AW E R U S E & C A R E
When the Sabbath Mode is initiated,
the automatic shut-off is disabled,
requiring the unit to be turned off
manually by touching.

12
W O L F WA R M I N G D R AW E R U S E & C A R E
CONTROL PANEL B A C K L I G H T IN G
The Wolf warming drawer has three options for
control panel backlighting; backlight off in
Sabbath, backlight on in Sabbath and backlight
off in all modes.The backlight defaults to ON in
normal use and OFF in Sabbath Mode.
To Change Control Panel Backlighting:
Warming drawer must be OFF.
Touch and hold temperature, arrow
and arrow for 5 seconds. The
current backlight setting will appear in the
display.
Use the arrow to scroll through the
three backlight options;
backlight off
in Sabbath, backlight on in Sabbath
(50% power), and backlight off in all
modes.
A selection should be made within
30 seconds. The unit will default to the
current backlight setting if a new selection
is not made within this time.
With the desired backlight setting selected,
touch to save the setting.
T E M P E R AT U R E D I S P L AY
The warming drawer temperature display can
be changed from Fahrenheit (F) to Celsius (C)
or vice versa.
To Change Temperature Display:
Warming drawer must be OFF.
Touch and hold both the temperature,
and arrows for 5 seconds.
After 5 seconds, the unit will beep, the
backlighting will turn on, and either F or C
will appear, depending on the current
display setting.
Touch the temperature, or
arrow to select either Fahrenheit (F) or
Celsius (C).
With the desired temperature display
selected, touch to save the setting.
BEFORE USING FOR THE FIRST
T I M E
Remove all literature and packaging
materials from inside the warming drawer.
Clean your warming drawer thoroughly
with hot water and a mild detergent. Rinse
and dry with a soft cloth.This removes
residual oil and grease left on the surface
from the manufacturing process.
Apply a stainless steel polish to protect the
finish and add luster to the exterior of your
warming drawer. Refer to Care Recommen-
dations on page 14.

13
WARMING DRAWER R A C K
The rack will fit in the warming drawer front to
back and allows you to double stack items.
When holding hot, cooked foods and warming
empty serving dishes at the same time, place
the serving dishes on the bottom of the
warming drawer and place food on the rack.
IMPORTANT NOTE: Always preheat the
warming drawer with the rack in position.
WARMING DRAWER PA N
The stainless steel warming drawer pan is
removable for cleaning.To remove, pull the
warming drawer completely open. Slide finger-
tips under the right and left side edges of the
pan. Firmly pull the pan upward, making sure
that all edges are clear from the interior of the
unit.
To replace the warming drawer pan, pull the
warming drawer completely open.The pan
should be inserted so that the rear wall has the
holes for the fan. Place pan edges on the side
rails of the drawer frame. Open and close the
drawer completely to check operation.
WARMING DRAWER O P E R AT I O N
Always start with hot food. The warming
drawer will keep hot food at serving
temperature. Do not use the warming
drawer to heat cold food other than for
proofing yeast dough and crisping crackers,
chips or dry cereal.
Always preheat the warming drawer. Allow
the following preheat times:
• 4 minutes for
• 7 minutes for
• 13 minutes for
NOTE: It is not necessary to preheat the
warming drawer for proofing.
Food in heat-safe glass and glass ceramic
containers may need higher temperature
settings as compared to food in metal
containers.
Repeated opening of the warming drawer
will allow hot air to escape and the food to
cool.
With large loads, it may be necessary to
use a higher temperature setting and to
cover some of the cooked food items.
Food should be kept hot in the cooking
container or transferred to a heat-safe
serving dish prior to being placed into the
warming drawer.
Remove serving spoons, etc., before placing
food containers in warming drawer.
Aluminum foil may be used to cover food
to increase moisture content.
Plastic containers or plastic wrap will melt if
placed in contact with the warming drawer
or hot utensils from the warming drawer.
Melted plastic may be difficult to remove
and is not considered a warranty repair.
W O L F WA R M I N G D R AW E R U S E & C A R E

14
W O L F WA R M I N G D R AW E R U S E & C A R E
C A R E RECOMMENDATIONS
COMPONENT CARE RECOMMENDATION
Drawer Front
(stainless steel)
Although stainless steel is resistant to most stains, it is not totally
impervious to damage. Salt and some cooking liquids may pit and stain
the surface. Always remove these spills immediately.
Exterior Cleaning: To clean the exterior of a classic or platinum stainless
steel model, use a soft, nonabrasive stainless steel cleaner like Signature
Polish (see side note) and apply with a soft lint-free cloth.
To bring out the natural luster of all three finishes, lightly wipe the surface
with a water-dampened microfiber cloth, followed with a dry microfiber
cloth. All work should follow the grain direction of the finish. Better results
are obtained by keeping the cloth in continuous contact with the metal.
Spray degreasers: Remove fingerprints and greasy spatters. Spray on a
cloth and wipe surface. Buff dry immediately to avoid streaking.
Hard water stains: Use white vinegar and water.
Do not use abrasive cleaners (e.g., Comet or Soft Scrub); they will perma-
nently scratch the surface. Do not use steel wool pads.
Although stainless steel is resistant to most stains, it is not totally
impervious to damage. Salt and some cooking liquids may pit and stain
the surface. Always remove these spills immediately.
Spray degreasers: Remove fingerprints and greasy spatters. Spray on a
cloth and wipe surface. Buff dry immediately to avoid streaking.
Hard water stains: Use white vinegar and water.
Do not use abrasive cleaners (e.g., Comet or Soft Scrub); they will perma-
nently scratch the surface. Do not use steel wool pads.
General Care: Clean the rack with a mild detergent and water. After
cleaning, rinse with clean water and dry thoroughly with a clean cloth.
General Care: Be careful not to soak the control panel. Although they are
sealed, excessive moisture may still cause damage to the controls.
Use a glass cleaner to remove fingerprints, spills, etc. from the surface of
the control panel. Spray first on a cloth before wiping panel.
Drawer Pan
(stainless steel)
Drawer Rack
(chrome)
Control Panel
(polycarbonate)
IMPORTANT NOTE: Make sure the warming drawer is off and all surfaces
are cool before cleaning any part of the unit.

15
W O L F TROUBLESHOOTING
GUIDE
T R O U B L E S H O OT I N G GUIDE
PROBLEM POSSIBLE SOLUTION
Warming drawer A fuse may be blown or the circuit breaker tripped. Replace the
does not operate fuse or reset the circuit breaker.
Warming drawer may not be plugged in. Plug it in.
Warming drawer Ball bearings are out of alignment. Fully extend the drawer and
does not slide smoothly close completely to realign.
Warming drawer is overloaded or the load is unbalanced. Reduce
weight to less than 34 kg or redistribute contents.
Excessive condensation Liquid is in the warming drawer pan. Remove the liquid.
Foods are uncovered. Cover food with a lid or aluminum foil.
Temperature setting is too high. Reduce the temperature setting.
No heat in the Room temperature may prevent the thermostat from turning on.
proof setting Verify that PROOF is illuminated in the display on the control
panel.
Food dries out in the Cover food with a lid or aluminum foil.
proof setting
CONTACT
INFORMATION
Website:
wolfappliance.com

16
S E R V I C E INFORMATION
When requesting information, literature,
replacement parts or service, always refer to
the model and serial number of your warming
drawer. Both numbers are listed on the
product rating plate located on the left front
floor area of the inner cabinet. To access the
rating plate, the drawer must be fully open.
Refer to the illustration on page 5. Record
the rating plate information below for future
reference.
Model Number
Serial Number
Installation Date
Wolf Dealer and Phone
B E F O R E C A L L I N G F O R S E RV I C E
Before calling your Wolf dealer or regional
distributor, refer to the Troubleshooting Guide
on page 15. Check the household fuse or
circuit breaker to see if it has been blown or
tripped and that the electrical connection
to the appliance has not been disconnected.
A power outage may also have caused a
disruption in service.
W O L F S E R V I C E INFORMATION
CONTACT
INFORMATION
Website:
wolfappliance.com
The information and images are the copyright
property of Wolf Appliance, Inc., an affiliate of
Sub-Zero, Inc. Neither this book nor any infor-
mation or images contained herein may be
copied or used in whole or in part without the
express written permission of Wolf Appliance,
Inc., an affiliate of Sub-Zero, Inc.
©Wolf Appliance, Inc. all rights reserved.

Cuando lea esta guía de uso y mantenimiento,
deberá prestar especial atención cuando
aparezcan los símbolos de PRECAUCIÓN
y ADVERTENCIA. Esta información es
importante para utilizar de forma segura
y eficaz el equipo de Wolf.
Además, esta guía de uso y mantenimiento
puede incluir una NOTA IMPORTANTE
para resaltar información especialmente
importante.
indica una situación en la que pueden
producirse daños leves o secundarios
en el producto si no se siguen las
instrucciones.
indica que existe peligro de que se
produzcan heridas personales graves
o incluso puede provocar la muerte si
no se siguen las instrucciones.
WOLF®es una marca comercial registrada de Wolf Appliance, Inc.

19
GR A C I A S
La compra de un cajón calentador de Wolf
confirma la importancia que usted da a la
calidad y al rendimiento de su equipo de
cocina. Entendemos esta importancia y hemos
diseñado y creado el cajón calentador con
materiales y mano de obra de primera calidad
para proporcionarle muchos años de servicio
seguro y eficaz.
Antes de comenzar a utilizar el cajón calenta-
dor, lea con detenimiento esta Guía de uso y
mantenimiento. Le recomendamos que se
familiarice con las prácticas de seguridad, las
características, el funcionamiento y las
recomendaciones de mantenimiento del cajón
calentador de Wolf.
Cuando necesite solicitar asistencia técnica
deberá proporcionar la referencia del modelo y
el número de serie del cajón calentador. Esta
información se muestra en la placa de datos
del producto situada en la parte izquierda
delantera del armario interior. Para ver la placa
de datos, es necesario abrir el cajón total-
mente. Observe la siguiente ilustración.
PRESENTACIÓN DEL C A J Ó N C A L E N TA D O R D E WOLF
INFORMACIÓN
D E C O N TA C T O
Página Web:
www.wolfappliance
.com
Ubicación de la placa de datos
Ubicación
de la placa
de datos

20
Q U É D E B E H A C E R
NOTA IMPORTANTE: Lea las
instrucciones antes de utilizar
este aparato.
Lea con detenimiento esta guía
de uso y mantenimiento antes de
utilizar el nuevo cajón calentador
para reducir el riesgo de que
se produzca un incendio, una
descarga eléctrica o de sufrir
lesiones personales.
Asegúrese de que la instalación y
el mantenimiento se llevan a cabo
de manera correcta. Este aparato
debe ser instalado y conectado a
tierra de manera correcta por un
técnico cualificado Solicite al instala-
dor que le indique la ubicación del
cortacircuitos o fusible para que
sepa donde debe desconectar el
aparato.
Antes de llevar a cabo cualquier
tarea de mantenimiento, desenchufe
o desconecte el cajón calentador de
la red eléctrica apagando el cortacir-
cuitos o quitando el fusible.
Asegúrese de que los paños de
cocina están apilados a la misma
altura que los laterales de la cubeta
del cajón. Cualquier altura superior
puede hacer que los paños se deco-
loren.
PRECAUCIONES E INSTRUCCIONES DE SEGURIDAD
Los cajones calentadores tienen una
función principal: conservar bien los
alimentos a la temperatura adecuada
hasta que sea hora de tomarlos y
comprobar el estado de la masa con
levadura. Los alimentos fríos no se
pueden calentar ni cocinar en el
cajón calentador.
Compruebe que el cajón calentador
está bien instalado en un mueble
bien sujeto.
Tenga cuidado al abrir el cajón
calentador. Abra parcialmente el
cajón calentador y deje que salga
el aire caliente antes de sacar los
alimentos o de introducir otros.
Coloque la bandeja de rejillas en la
posición que desee cuando el cajón
calentador esté frío.
Utilice siempre elementos aislantes
secos cuando quite los alimentos del
cajón calentador. Si los elementos
aislantes están húmedos o mojados
pueden producirle quemaduras. No
utilice un paño acolchado en lugar
de un elemento aislante.
