Wonwoo ms 101 User manual

Before installing, operating or adjusting this
product, please read this instruction booklet
carefully and completely.
INSTRUCTION MANUAL
Distributed by
PRINTED IN KOREA
P/N : 38801K655
Full HD Mega pixel
Box Camera

The lightning flash with an arrowhead symbol
within an equilateral triangle is intended to alert
the user to the presence of uninsulated
dangerous voltage within the product's enclosure
that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying
the product.
REGULATORY INFORMATION : FCC Part 15 WARNING -
Do not install this equipment in a confined
space such as a bookcase or similar unit.
Disposal of your old appliance
1.
When this crossed-out wheeled bin symbol
is attached to a product it means the product
is covered by the European Directive
2002/96/EC
2.
All electrical and electronic products should
be disposed of separately from the municipal
waste stream via designated collection fafilities
appointed by the government or the local
authorities
3. The correct disposal of your old appliance
will help prevent potential negative conse-
quences for the environment and human
health
4.
For more detailed information about disposal
of your old appliance, please contact your
city office, waste disposal service or the shop
where you purchased the product.
To disconnect power from the mains, pull out the mains
cord plug. When install the product, ensure that the plug
is easily accessible.
WARNING - Wiring methods shall be in accordance with
the National Electric Code, ANSI/NFPA 70.
WARNING - To reduce a risk of fire or electric shock, do
not expose this product to rain or moisture.
CAUTION - This installation should be made by a qualified
service person and should conform to all local codes.
CAUTION - To avoid electrocal shock, do not open the
cabinet. Refer servicing to qualified personnel only.
CAUTION -
To apparatus should not be exposed to
water (dripping or splashing) and no objects filled with
liquids, such as vases, should be placed on the apparatus.
WARNING - This is a class A product. In a domestic
environment this product may cause radio interference
in which case the user may be required to take adequate
measures.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION :
FCC WARING - This equipment may generate or use
radio frequency energy. Changes or modifications to
this equipment may cause harmful interference unless
the modifications are expressly approved in the instruction
manual. The user could lose the authority to operate this
equipment if an unauthorized change or modification is made.
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference
in which case the user will be required to correct the
interference at his own expense.
- A suitable conduit entries, knock-outs or glands shall
be provided in the cable entries of this product in the
end use
- Caution : Danger of explosion if battery is incorrectly
replaced. Replaced only with the same or equivalent
type recommended by the manufacturer. Dispose of
used batteries according to the manufacturer’s
instructions.
- Holes in metal, through which insulated wires pass,
shall have smooth well rounded surfaces or shall
be provided with brushings.
03

1. Read these instructions - All these safety and operating
instructions should be read before the product is operated.
2. Keep these instructions - The safety, operating and user
instructions should be retained for future reference.
3. Heed all warnings - All warnings on the product and in
the operating instructions should be adhered to.
5. Do not use this apparatus near water - For example :
near a bath tub, wash bowl, kitchen sink, laundry tub,
in a wet basement; near a swimming pool; etc.
6. Clean only with dry cloth - Unplug this product from
the wall outlet before cleaning. Do not use liquid cleaners.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions. -
Slots and openings in the cabinet are provided for
ventilation, to ensure reliable operation of the product,
and to protect it from overheating. The openings should
never be blocked by placing the product on a bed, sofa,
rug or other similar surface. This product should not
be placed in a built-in installation such as a bookcase
or rack unless proper ventilation is provided and the
manufacturer’s instructions have been adhered to.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
4.
Follow all instructions - All operating and user instructions
should be followed.
9.
Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety.
If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11.
Only use attachments/accessories specified by the
manufacturer.
12.
Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as powersupply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
04 05
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS

FEATURES...................................................................................................................................
CAUTION FOR SAFE OPERATION..................................................................................................
PART NAMES AND FUNCTIONS....................................................................................................
MOUNTING THE LENS.................................................................................................................
FLANGE-BACK ADJUSTMENT.......................................................................................................
MAIN MENU................................................................................................................................
EXPOSURE .................................................................................................................................
WHITE BALANCE.........................................................................................................................
IMAGE.........................................................................................................................................
INTELLIGENCE............................................................................................................................
SPECIAL FUNCTION....................................................................................................................
DISPLAY.......................................................................................................................................
SPECIFICATIONS..........................................................................................................................
DIMENSIONS................................................................................................................................
7p
8p
9p
12p
14p
15p
16p
18p
19p
21p
23p
24p
26p
29p
06 07
CONTENTS FEATURES
• 1/3" Panasonic CMOS sensor
• Full HD Resolution
• DAY & NIGHT
• WDR (Wide Dynamic Range)
• DNR (Digital Noise Reduction, 2D+3D)
• Privacy mask Function
• On Screen Display
• Intelligent motion detection
• Output
• Protocol

【1】Camera Cover
Used to protect the camera, please remove
the cover before you install the camera.
【2】Camera holder holes
Used when you mount the camera onto
the bracket.
【3】Auto iris lens Connector
Used to supply power and output signal to
control the iris of the lens.
08 09
CAUTIONS FOR SAFE OPERATION PART NAMES AND FUNCTIONS
Power Supply
Use DC12V
Note : Be careful of AC frequency when the camera is
operated with Line lock mode.
Handling of unit
Be careful not to spill water or other liquids on the unit.
Be cautious not to get combustible or metallic material
inside the body. If used with foreign matter inside, the camera
is liable to fail or cause a fire or an electric shock.
Operating and storage
Avoid viewing a very bright object (such as light fittings)
during an extended period. Avoid operating or storing the
unit in the following locations.
·Extemely hot or cold places (operating temperature
-10℃ ~ 50℃, however, we recommend that the
unit be used within a temperature range of 0℃ ~ 45℃)
·Damp or dusty place
·Places exposed to rain
·Places subject to strong vibration
·Close to generators with powerful electromagnetic
radiation such as radio or TV transmitters.
Cleaning of the unit
·Remove dust or dirt on the surface of the lens with
a blower.
·
Use a dry soft cloth to clean the body. If it is very dirty,
use a cloth dampened with a small quantity of neutral
detergent, then wipe dry.
·Avoid the use of volatile solvents such as thinners,
alcohol, benzene, and insecticides.
They may damage the surface finish and / or impair
the operation of the camera.
【1】 【2】
【3】

【4】Setup Switch
The switch is used for setting and adjusting
the camera’s functions and properties.
【5】HDMI out Terminal
HDMI terminal for HD-SDI video signal output.
【6】HD-SDI Video out Terminal
BNC terminal for HD-SDI video signal output.
【7】Power LED
This lamp turns on when the proper power is
applied to the camera.
【8】Main cable terminal
6 pin main cable connector. 【9】 C Video
Analogue video output terminal of C-Video.
【10】Power port
Used to plug the power cable.
【11】RS-485 cable
Signal port for RS-485 communication (Yellow +/ Green -)
10 11
PART NAMES AND FUNCTIONS PART NAMES AND FUNCTIONS
【5】
【6】【7】【8】
【4】
CVBS(Analog)
POWER
RS485(+)
RS485(-)
【9】
【10】
【11】

Pin layout for the lens iris output connector
No.
1
2
3
4
DC type lenses
Damping -
Damping +
Drive +
Drive -
Rewire the lens iris plug
1. Cut off the plug of the lens cable, cut off approximately
8mm
of the insulation, and then strip approximately
2mm of the ends of the cable sheaths.
2.
Solder the ends of the cable wires to the ends of the
pins, and then attach the cover of the lens iris plug.
12 13
1. Remove the lens mount cap from the camera.
2. Install the auto-iris lens.
CS Mount Lens
Install the CS Mount Lens by attaching the lens
straight to the camera lens holder then slowly turn
the lens until it is in place.
3.
Connect the lens plug to the lens iris output connector
(LENS) on the side of the camera.
When using lenses from other makers, the plug shape
may not correspond to the terminal on the camera.
In such a case, remove the original plug and using a
soldering iron, connect a lens iris plug according to the
diagram. (Refer to next page.)
MOUNTING THE LENS
8mm
2mm
MOUNTING THE LENS

14 15
The adjustment is required only when a lens without
focus-adjusting mechanism is mounted, or when a lens
with adjusting mechanism is mounted and focus that is
more accurate is needed.
1. With the included Wrench unscrew the Set Screws
on the right and bottom of the camera.
2. Adjust the focus while watching the video by adjusting
the Mount Adapter.
3. After adjusting to the desired focus level use the included
Wrench to fasten the Set Screws.
Note :
The object may be out of focus when using a source of
near-infrared light than using the visible light.
FLANGE-BACK ADJUSTMENT MAIN MENU
Wrench
MAIN MENU
Functions can be setup using “Menu Key Command” of Visca protocol.
The menu consists of the “Main Menu” and “Sub Menu”.
The main menu is displayed where 7 camera functions can be selected.
To the push of each main menu selection, the sub-menu is displayed
If you want save the menu, select [SAVE].
If you want not save the menu, select [EXIT] (After select, Power off -> on)
If you want default the menu, select [DFLT]
MENU
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]

16 17
EXPOSURE EXPOSURE
EXPOSURE
◈LENS : Select LENS type
►DC
▷MODE : INDOOR, OUTDOOR, DEBLUR
►MANUAL
▷MODE : NORMAL, DEBLUR
◈BRIGHTNESS : Adjust brightness level
►0(dark) ~ 20(bright) steps
◈SHUT SPEED : Can be set in AUTO or MANUAL
►AUTO / x2, x3, x4, 1/30(25),1/60(50),1/120(100),1/240,1/500, 1/1000,1/2000,1/4000,1/8000,
1/16000,1/30000,1/60000 sec
◈DSS : Select maximum DSS(Digital Slow Shutter)
►OFF / x2, x3, x4
◈AGC : Select Auto Gain Control
►OFF / ON
◈FLICKERLESS : Select Flickerless mode
►OFF / ON (remove screen flicker)
◈WDR/BLC : Select WDR(Wide Dynamic Range) or BLC(Back Light Compensation)
►WDR↲
▷LEVEL : Adjust WDR level.
►LOW, MID-LOW, MIDDLE, MID-HIGH, HIGH
※WDR doesn’t work in Shutter Manual Mode.
►BLC↲
▷POSITION : Adjust the window position
▷SIZE : Adjust the window size
※Can’t use WDR and BLC at the same time.
(When WDR On, BLC is Off. And when BLC is On, WDR is Off)
◈DAY&NIGHT : Select Day&Night
▷MODE : AUTO / EXT-IN / DAY / NIGHT
►AUTO↲
►EXT-IN↲
▷POLARITY : ACTIVE LOW / HIGH
▷DELAY : 0 ~ 255 sec
▷THRS : 0 ~ 28
Day↔Night switching level in Auto Mode. Switching in lower lux with higher threshold level.
▷GAP : LOW, MID-LOW, MIDDLE, MID-HIGH, HIGH
Margin between Day →Night switching level and Night →Day switching level.
▷ANTI-SAT : LED saturation improves. (0~20)
▷BURST : OFF / ON
EXPOSURE
EXPOSURE
MODE
BRIGHTNESS
SHUT SPEED
DSS
AGC
FLICKERLESS
WDR/BLC
DAY&NIGHT
[BACK] [SAVE]
MENU
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]

18 19
WHITE BALANCE IMAGE
WHITE BALANCE
◈AWB : Select WHITE BALANCE mode
►AUTO / ONE PUSH / MANUAL / INDOOR / OUTDOOR
▷AUTO : Automatically adjusts color according to the available lighting.
▷ONE PUSH : It is a fixed white balance mode that may be automatically
readjusted only by pressing ONE PUSH
▷MANUAL↲: Color can be corrected when the user increases or decreases
“RED GAIN” or “BLUE GAIN”.
▷INDOOR : Set color temperature to be Indoor light (3700°K)
▷OUTDOOR : Set color temperature to be Outdoor light (5100°K)
◈RED GAIN : Adjust R gain value
►0 ~ 20 steps
◈BLUE GAIN : Adjust B gain value
►0 ~ 20 steps
◈CHROMA : Adjust CHROMA gain value
►0 ~ 20 steps
◈HLC : Select High Light Compensation.
When extremely bright light is projected to the camera masking is used on
the portion to prevent partial saturation on the monitor.
▷MODE : OFF / ON / NIGHT
▷LEVEL : 0 ~ 20 steps
▷COLOUR : 0 ~ 13 steps
◈DNR : Select Digital Noise Reduction
►AUTO / OFF / LOW / MIDDLE / HIGH
◈MIRROR : Select a flip mode
►OFF / H / V / H&V
▷H : You can flip the picture horizontally on the screen
▷V : You can flip the picture vertically on the screen
▷H&V : You can flip the picture horizontally & vertically on the screen
WHITE BAL
MODE
RED GAIN
BLUE GAIN
CHROMA
[BACK] [SAVE] [DFLT]
AUTO
---
--- 10
MENU
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]
HLC
DNR
MIRROR
SHARPNESS
ACE
DEFOG
FREEZE
GAMMA
E.ZOOM
[BACK] [SAVE] [DFLT]
5
OFF
OFF
OFF
0.55
OFF
AUTO
OFF
MENU
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]

20 21
IMAGE INTELLIGENCE
◈SHARPNESS : Adjust sharpness level
►0 ~ 10 steps
◈ACE : Select Digital WDR (Wide Dynamic Range)
►OFF / LOW / MIDDLE / HIGH
◈DEFOG : Carry out defog function
►OFF / ON↲
▷MODE : AUTO / MANUAL
▷LEVEL : LOW / MIDDLE / HIGH
※Can’t use DEFOG and ACE at the same time
(When ACE On, DEFOG is Off. And when DEFOG is On, ACE is Off)
◈Freeze : Select real or still mode
►OFF / ON
◈GAMMA : Select GAMMA
►0.45 / 0.50 / 0.55 / 0.60 / 0.65
◈E.ZOOM
►OFF / ON
▷LIMIT : Max x2 ~ x19, x21, x23, x25, x28, x32
▷POSITION : Select maximum digital zoom magnification.
※Can’t use Digital Zoom when the motion detection is turned on.
◈PRIVACY : Hide an area you want to hide on the screen
►OFF / ON↲
▷MASK# : Select mask area number (1 ~ 24)
▷MODE : Mask enable or disable (OFF / ON)
▷POSITION : Adjust the mask position
▷SIZE : Adjust the mask size
▷COLOR : Select mask color (0 ~ 13)
▷TRANS : Select mask transparency level (0 ~ 4)
INTELLIGENCE
INTELLIGENCE
PRIVACY
MOTION
[BACK] [SAVE] [DFLT]
OFF
OFF
MENU
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]

2322
INTELLIGENCE
SPECIAL FUNCTION
◈MOTION : When there is movement of the subject in the screen, there will be an motion detection
►OFF / ON↲
▷AREA# : Setting 3 areas(1~3) of motion detection
▷MODE : OFF / ON (Limit and define areas of motion detection)
▷SENSITIVITY : Adjust sensitivity of MD (0 ~ 20 steps)
More sensitive to setting to low step with sensitivity
▷POSITION : Adjust the Area position
▷SIZE : Adjust the Area size
▷INTERVAL TIME :Select the alarm interval time (0 ~ 255sec)
▷DWELL TIME : Select the duration time about changing MD mode (0 ~ 255sec)
INTELLIGENCE
◈DEFECT : Compensates for bad pixels that may occur. Occurs when the whole screen is
in full black or if there is bad pixelation and it changes the THRS values until
the screen is fixed.
◈SYSTEM : Select NTSC(30fps) or PAL(25fps). (NTSC / PAL)
◈HD FORMAT : Select Digital output 1080P or 720P. (1080P / 720P)
◈COMM : Set up the camera ID, baud rate, protocol
▷ID : Select the camera ID
►1 ~ 255
▷BAUD RATE : Select serial communication speed
►2400 / 4800 / 9600 / 19200 / 38400 / 57600 / 115200bps
▷PROTOCOL : Select operating protocol
►VISCA / PELCO-D / PELCO-P / UPDATE
SPECIAL FUNC
SPECIAL FUNC
DEFECT
SYSTEM
HD FORMAT
COMM
[BACK] [SAVE] [DFLT]
NTSC
1080P
MENU
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]

24 25
DISPLAY
DISPLAY
◈DISP SEL : Select display item.
►OFF / ON↲
▷ID : OFF / ON
▷TITLE : OFF / ON
▷ZOOM RATIO : OFF / ON
▷SYSTEM MSG : OFF / ON (MD Alarm and Wait message)
◈SET TITLE : Select camera title menu (Text edit)
◈INIT SEL : Select display initial message.
►OFF / ON↲
▷ID : OFF / ON
▷BAUDRATE : OFF / ON
▷PROTOCOL : OFF / ON
▷VERSION : OFF / ON
▷INIT MSG : OFF / ON
DISPLAY DISPLAY
◈SET INIT MSG : modify initial message. (Text edit)
◈LANGUAGE : Select language.
►English / Simplified Chinese / Traditional Chinese / Japanese
※Character Table of Text edit Mode
i
DISPLAY
DISP SEL
SET TITLE
INIT SEL
SET INIT MSG
LANGUAGE
[BACK] [SAVE] [DFLT]
ON
ON
ENGLISH
MENU
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
[EXIT] [SAVE] [DFLT]

26 31
SPECIFICATIONS SPECIFICATIONS
27
Model
Image Sensor
Total Pixels
Active pixels
Scanning system
Resolution
Min. illumination
Video Output
S/N Ratio
LENS
Brigntness
Shutter speed
DSS
AGC
Flickerless
WDR/BLC
DAY&NIGHT
1/3" Panasonic CMOS
2010(H) x 1108(V) = 2,227,080 (pixels)
1944(H) x 1092(V) = 2,122,848 (pixels)
Progressive
Digital ; 1920x1080p(1080p/30fps) , 1280x720p(720p/30fps)
Analog : 700TVL
Color : 1.0 lux , BW : 0.5lux
Color DSS : 0.002 lux , BW DSS : 0.001 lux
HD : HD-SDI, BT.1120
Analog : NTSC / PAL (without WDR)
more than 50dB (AGC off)
DC / Manual
0 ~ 20
Auto / Manual (x2, x3, x4, 1/30(1/25) ~ 1/60000)
Off / x2 / x3 / x4
Off / On
Off / On
Off / WDR / BLC
Auto / Ext-in / Day / Night
Model
WHITE BAL
HLC
DNR
Mirror
Sharpness
ACE
Defog
Freeze
GAMMA
E.Zoom
PRIVACY
MOTION
Defect
System
HD Format
Comm
Disp Sel (Off / On)
Set Title
Auto / One Push / Manual / Indoor / Outdoor
Off / On / Night
Off / Low / Middle / High / Auto
Off / H / V / H&V
0 ~ 10
Off / Low / Middle / High
Off / On (Auto / Manual)
Off / On
0.45 / 0.50 / 0.55 / 0.60 / 0.65
Off / Max x2 ~ x32
Off / On (24 points)
Off / On (3 points)
One Push
NTSC / PAL
1080P / 720P
Baud Rate : 2400 / 4800 / 9600 / 19200 / 38400 / 57600 / 115200
Protocol : VISCA / Pelco-D / Pelco-P / Update
ID / Title / Zoom Ratio / System Message
Text Edit

28 29
SPECIFICATIONS DIMENSIONS
59.00
59.00 63.00
503
63
6 6
Model
Init Sel (Off / On)
Set Init Msg
Language
OSD Text
Power Source
Power Consumption
Power Input
Video Output(HD-SDI)
Operating Temperature
Storage Temperature
ID / Baud Rate / Protocol / Version / Init. Message
Text Edit
English / Simplified Chinese / Traditional Chinese / Japanese
0 ~ 9 , A ~ Z , a ~ z
DC12V±10%
150mA
Connector
MMCX Connector
-10℃~ +50℃(Humidity : 0%RH ~ 80%RH)
-20℃~ +60℃(Humidity : 0%RH ~ 90%RH)

30 31
MEMO MEMO
