Wonwoo PS-M032 Installation instructions

P/N : 388059105
PRINTED IN KOREA
Distributed by
INSTALLATION / OPERATING MANUAL
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use
3x Mega pixel HD-SDI
Mini Speed Dome camera

02
High Speed Mini PTZ Camera
03
High Speed Mini PTZ Camera
1. 1 Important Safety Instruction
• Read these instructions.
• Pay attention on all the warnings.
• Follow all instructions.
• Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
• Do not dissemble or insert foreign objects.
• Do not install near any heat sources such as radiation, beat registers, stoves, or other apparatus.
(Including amplifiers) that produce heat.
• Do not aim the camera at the sun or any other strong light source.
• Do not install the camera in intermittent lighting environments.
• Only use attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
• Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
• Installation should be done only by qualified personnel and conform to all local codes.
• Installation should be done in a place strong enough to hold it.
• Use only installation methods and materials capable of supporting four times the maximum specified load.
• It is designed for indoor use only and it must not be installed where exposed to rain and moisture
without additional outdoor housing and bracket.
• To prevent damage from water leakage when installing a mount outdoors on a roof or wall,
apply sealant around the bolt holes between the mount and mounting surface.
• These instructions are for use by qualified service personnel only. To reduce the risk of electric shock
do not perform any servicing other that contained in the operating instructions unless you are qualified
to do so.
• Only use replacement parts recommended by manufacturer. ad these instructions.
1. PRECAUTIONSTABLE OF CONTENTS
3p.
4p.
4p.
5p.
6p.
6p.
7p.
8p.
9p.
10p.
11p.
11p.
22p.
28p.
37p.
37p.
38p.
39p.
1. PRECAUTIONS
1. 1 Important Safety Instruction ...................................................................................
2. GETTING STARTED
2. 1 Features ................................................................................................................
2. 2 Unpacking ..............................................................................................................
2. 3 Selection Flow ........................................................................................................
3. INSTALLATION
3. 1 Address / communication setting ...........................................................................
3. 2 Cable Connection ...................................................................................................
3. 3 Indoor Ceiling .......................................................................................................
3. 4 Indoor In Ceiling ....................................................................................................
3. 5 Outdoor (Ceiling Bracket) ......................................................................................
3. 6 Outdoor (Wall Bracket) ..........................................................................................
4. MAIN SETUP MENU
4. 1 Initialize .................................................................................................................
4. 2 Motion Menu ..........................................................................................................
4. 3 Dome Menu ...........................................................................................................
4. 4 Camera Menu ........................................................................................................
4. 5 Clear Setting ..........................................................................................................
4. 6 PTZ Reset ..............................................................................................................
5. SPECIFICATION
5. 1 Camera Specification..............................................................................................
6. DIMENSION
6. 1 Dimension .............................................................................................................

04
High Speed Mini PTZ Camera
05
High Speed Mini PTZ Camera
2. 3 Selection Flow2. 1 Features
2. 2 Unpacking
2. GETTING STARTED
Auto-Focus
- The camera adjusts the focus automatically while monitoring the screen continuously
in the auto mode. It built in 3x zoom lens, when used in combination with its 6x
digital zoom, the camera achieves a zooming capability of up to 18x.
ICR
- These cameras offer optimal sensitivity in both day- and night-shootingapplications.
AUTO Flip
- You can observe the moving object without reversing of the screen, by using this
AUTO FLIP function.
Wide Range Auto functions
- PRESET : Up to 255 programmable presets.
- TOUR : Up to 8 programmable Tours consisting of presets with individual dwell time.
- SCAN : Repeatedly pan & tilt operating betweentwo positions. (Max.8)
- PATTERN : Up to 4 programmable Patterns memorizing the PTZ movement.
- AREA : Up to 16 programmable Area display sets.
- ALARM : Move the camera to programmed Presetposition with Alarm trigger.(Max.2)
- PRIVACY : Up to 8 programmable Privacy masking.
Multi protocol and communication method
- RS 422, RS485 support
- PELCO-D 5.0, PELCO-P, WTX, 2400 ~ 57600 Baudrate
WDR
- The Camera delivers clear, high quality pictureseven in backlight, by increasing
exposure in darkareas while decreasing it in bright areas a corrected image with clear
details results
Programmable zoom speed
- Zoom speed can be set and decide using of digital zoom function.
When this function is ON, the pan/tilt speed is inversely adjusted to the zoom ratio.
IndoorType
Surface
Ceiling
In-Ceiling
Wall
Outdoor
Indoor Ceiling
Indoor In Ceiling
Outdoor Ceiling
Outdoor Ceiling_Pipe
(Pipe 200mm)
Outdoor Wall
Indoor In CeilingIndoor Ceiling / Outdoor Ceiling MAIN CABLE Manual
SCREW #8*38
(Ceiling Type)
SCREW #8*38
(Surface Type)
STICKER
(In-Ceiling Type)
HD Format function
- Select digital video out signal.
※ Please see page 26, dome menu of PTZ to change the digital video out signal.

06
High Speed Mini PTZ Camera
07
High Speed Mini PTZ Camera
3. 1 Address / communication setting
3. 2 Cable Connection
3.Installtion
3. 3 Indoor Ceiling
Pull out the main cable through the hole.
The following steps of installation and connection work should be done by qualified service personnel
or system installers and should conform to all local codes.
▶ADDRESS( ID) setting
▶SETTING
▶Baudrate setting
▶NTSC/PAL setting ▶Communication
PROTOCOL setting
1286432168421HEX 87654321S/W NO
ONOFFONOFFONOFF5
OFFOFFONONOFFOFF4
ONONOFFOFFOFFOFF3
576003840019200960048002400S/W NO
ONOFF6
PALNTSCS/W NO
ONOFF7
RS485RS422S/W NO
＊No.8 SWITCH : For program input
Make a Ø70 hole in the ceiling and install the bracket
by usning enclosed screws.(#8*38)
1. Connect the safety wire of mout bracket to the
camera base.
2. Connect the main cable.
1. Aline the mount bracket and position of the
body.
2. Attach the camera to the mount bracket by turning
CLOSE direction and tighten (up) a screw.
ONOFFOFF1
OFFONOFF2
S/W NO PELCO-D V5.0 PELCO-P WTX
* If you want to pull out the cable to the side,
cut the part and pull out the cable.
12
34
BLACK
BROWN
RED
ORANGE
YELLOW
PURPLE
GRAY
GND
ALARM1
ALARM2
RY1 NO
RY2 NO
RY1 COM
RY2 COM
1) Power cable connecting
- DC 12V type should be connected with + and - .correctly.
- AC24V type can be connected with any direction.
* AC 24V 3A(OUTDOOR)
AC 24V 1A(INDOOR)
* DC 12V 1.5A(INDOOR)
* ALARM /AUX CABLE

08
High Speed Mini PTZ Camera
09
High Speed Mini PTZ Camera
3. 4 Indoor In Ceiling
The mounting has to be installed onto a firm and stable location where all the parts may be completely
secured. The installation needs to be performed by a trained and experienced professional.
The mounting has to be installed onto a firm and stable location where all the parts may be completely
secured. The installation needs to be performed by a trained and experienced professional.
12
34
12
34
56
3. 5 Outdoor (Ceiling Bracket)
1. Make a Ø165 hole in the ceiling.
2. Pull out the main cable through the hole.
1. Make a hole in the ceiling and pull out the main
cable through the hole.
2. Fix the plate ceiling by using #8x38 screws.
1. Connect the cable with the connector of the base.
2. Set the body into the hole.
1. Connect the cable with the connector of the base.
1. Fix the PTZ using the M4x7 bolts. 1.Assemble the dome cover on the PTZ and fix it
by using the M3x6 screws.
2. Cover the rubber stopper after fixe the screws.
1. Pull out the main cable through the pipe ceiling.
2. Fix the pipe ceiling in the plate ceiling.
1.Fix the adapter flange in the pipe ceiling. 1. Fix the adaptor in the adapter flange by using
M4x10 screws.
1. Align with the “ ” mark on the PTZ body and fix
the screw.

10
High Speed Mini PTZ Camera
11
High Speed Mini PTZ Camera
4. MAIN SETUP MENU
4. 1 Initialize
4. 2 Motion Menu
When the device is powered on, you can check the address,
version, protocol and video setting values.
MOTION MENU
The preset function is that the camera memorizes positions
of the pan/tilt and zoom. This function is a representative
function of the speed dome which can find memorized
preset positions just by selecting the preset number.
MAIN MENU
MOTION
DOME
CAMERA
CLEAR
PTZ RESET
EXIT
< NEAR / RIGHT MOTION >
1) Set preset.
SAVE CLR BACK EXIT
PRESET MENU
PRESET NO
LABEL
POSIRION
FOCUS
: 001 UNDEFINE
: PRESET 001
: 019.9, 005.4
: AUTO
< NEAR / RIGHT PRESET NO >
- Set PRESET Number
The mounting has to be installed onto a firm and stable location where all the parts may be completely
secured. The installation needs to be performed by a trained and experienced professional.
PRESET SELECT 1
< SEL NEAR/MOVE JOYSTICK >
P001
P007
013
019
025
031
037
043
049
P002
P008
014
020
026
032
038
044
050
P003
009
015
021
027
033
039
045
051
P004
010
016
022
028
034
040
046
052
P005
011
017
023
029
035
041
047
053
P006
012
018
024
030
036
042
048
054
Preset No. : Max. 255 positions can be stored and the each
position can be assigned as a defined Preset No.
Label : Each Preset can have its own label name.
Position : It displays the coordinates to position the assigned
Preset.
Focus : It enables to set the camera focus for each Preset
position.
NEAR
NEAR
Press key.
Select number by using joystick and press key.
12
3
5
4
3. 6 Outdoor (Wall Bracket)
1. Connect the cable with the connector of the base.
1. Align with the “ ” mark on the PTZ body and fix
the screw.
1. Attach the rubber adapter on the adapter and fix it
with wall bracket by using M4x10 screws.
1. Attached the rubber on the adapter wall and fix it
on the wall by using #8x38 screws.
2. Pull out the main cable and cover the hole by using
‘bolt mount B type’.
1. Attached the rubber on the bracket wall and fix it
with adapter wall by using security M5x20 screws.
2. Pull out the main cable through the bracket hole.
INITIALIZE
PTZ ID
FIRMWARE
V-FORMAT
CVBS
PROTOCOL
BAUDRATE
CAMERA
: 001
: 2.01
: 1080p30
: NTSC
: PELCO D V5
: 2400, N, 1
: EMC MM032..OK
CAM VER : 01.03
NORMAL SETTING WAIT...
PAN POS . . . . . . . PASS
TILT POS . . . . . . . PASS
※When preset is set, the number is shown as “Pxxx”.

12
High Speed Mini PTZ Camera
13
High Speed Mini PTZ Camera
- LABEL Setting
- POSITION Setting
PRESET POSITION
LABEL : PRESET 001
POSITION : 019 .9, 005.4
< EXIT FOCUS NEAR >
- FOCUS Setting
SAVE CLR BACK EXIT
PRESET MENU
PRESET NO
LABEL
POSIRION
FOCUS
: 001 DEFINE
: PRESET 001
: 019.9, 005.4
: AUTO
< CHANGE UP/DN SEL NEAR >
2) TOUR
The Tour function consists of several presets run by turn.
Maximum of 8 Tour functions are toured in order.
MOTION MENU
PRESET
TOUR
SCAN
PATTERN
AREA
ALARM
PRIVACY
EXIT BACK
< NEAR / RIGHT TOUR >
- TOUR EDIT
NO
01
02
03
04
05
06
07
08
PRESET
P001
P002
P003
P004
P005
P006
P007
P008
SPEED
63
63
63
63
63
63
63
63
DWELL
02
02
02
02
02
02
02
02
TOUR MENU
SAVE CLR BACK EXIT
< SEL NEAR PRESET LEFT >
PRESET LABEL EDIT <001>
)
L
X
0
A
M
Y
1
B
N
Z
2
C
O
.
3
D
P
/
4
E
Q
,
5
F
R
+
6
G
S
-
7
H
T
=
8
I
U
<
9
J
V
>
(
K
W
@
LABEL : PRESET 001
<STORE TELE MOVE JOY>
<DEL WIDE BACK NEAR>
Define the Preset position
a. Move to the set-up window
or
b. Move and set the position c. Set & Back
NEAR NEAR
TOUR MENU
< SEL NEAR/MOVE JOYSTICK >
P001
P007
013
019
025
031
037
043
049
P002
P008
014
020
026
032
038
044
050
P003
009
015
021
027
033
039
045
051
P004
010
016
022
028
034
040
046
052
P005
011
017
023
029
035
041
047
053
P006
012
018
024
030
036
042
048
054
NEAR
NEAR
Press key.
Select focus by using joystick and press key.
NEAR
NEAR
Press key.
Select number by using joystick and press key.
NEAR
NEAR
Press key.
Select character by using joystick and press key.
- TOUR NO
- LABEL
TOUR MENU
TOUR NO
LABEL
TOUR EDIT
: 01 DEFINE
:
SAVE CLR BACK EXIT
< NEAR / RIGHT TOUR NO >
TOUR MENU
TOUR NO
LABEL
TOUR EDIT
: 01 DEFINE
:
SAVE CLR BACK EXIT
< NEAR / RIGHT LABEL EDIT >
TOUR LABEL EDIT <01>
)
L
X
0
A
M
Y
1
B
N
Z
2
C
O
.
3
D
P
/
4
E
Q
,
5
F
R
+
6
G
S
-
7
H
T
=
8
I
U
<
9
J
V
>
(
K
W
@
LABEL
<STORE TELE MOVE JOY>
<DEL WIDE BACK NEAR>
It’s available to set the desired label, displayed on the executing screen of Tour.
After the label is set, push the NEAR button to exit.
Select the Tour number
Move : Select :
NEAR
Set the Tour Label
Move : Select : or or Delete : or
JOYSTICK JOYSTICK
TELE WIDE
03 04 05 06
T02
08
T01
07
TOUR MENU
< SEL NEAR/MOVE JOYSTICK >
AUTO / MANUAL / ONE SHOT

14
High Speed Mini PTZ Camera
15
High Speed Mini PTZ Camera
By using Scan function, the camera moves between 2 positions if there is no PTZ command after
passing the assigned Dwell time. When there is no camera movement, the Scan function
runs and the
camera moves from the position assigned as the start point to the position
assigned as the end point
in CW (Clockwise) direction.
3) Scan
MOTION MENU
PRESET
TOUR
SCAN
PATTERN
AREA
ALARM
PRIVACY
EXIT BACK
< NEAR / RIGHT SCAN >
< NEAR / RIGHT SCAN >
SCAN MENU
SCAN NO
LABEL
START POS
END POS
SPEED
DWELL
FOCUS
: 01 UNDEFINE
:
: XXX.X, XXX.X
: XXX.X, ---
: XX
: XX
: NONE
SAVE CLR BACK EXIT
- SCAN NO
It’s available to set the desired label, displayed on the executing screen of Scan.
After the label is set, push NEAR button to go out.
- LABEL
< NEAR / RIGHT LABEL SEL>
SCAN MENU
SCAN NO
LABEL
START POS
END POS
SPEED
DWELL
FOCUS
: 01 UNDEFINE
:
: XXX.X, XXX.X
: XXX.X, ---
: XX
: XX
: NONE
SAVE CLR BACK EXIT
- END POSITIION
- Start POSITIION
< NEAR / RIGHT END POS >
SCAN MENU
SCAN NO
LABEL
START POS
END POS
SPEED
DWELL
FOCUS
: 01 DEFINE
:
: 000.0, 000.0
: 000.0, ---
: 60
: 02
: AUTO
SAVE CLR BACK EXIT
SCAN END POSITION
POSITION : 000 .0
< EXIT FOCUS NEAR >
- SPEED
< NEAR / RIGHT MOVE SPEED >
SCAN MENU
SCAN NO
LABEL
START POS
END POS
SPEED
DWELL
FOCUS
: 01 DEFINE
:
: 000.0, 000.0
: 000.0, ---
: 60
: 02
: AUTO
SAVE CLR BACK EXIT
Set the Scan speed
Increase : or
Decrease : or
JOYSTICK
JOYSTICK
It adjusts the moving speed from 0~63 steps.
SCAN LABEL EDIT <01>
)
L
X
0
A
M
Y
1
B
N
Z
2
C
O
.
3
D
P
/
4
E
Q
,
5
F
R
+
6
G
S
-
7
H
T
=
8
I
U
<
9
J
V
>
(
K
W
@
LABEL :
<STORE TELE MOVE JOY>
<DEL WIDE BACK NEAR>
Move : Select : or or
JOYSTICK
Delete : or
JOYSTICK
TELE WIDE
or
Define the End pan position
① Select End Pos menu ② Move and set the position ③ Go back
NEAR NEAR
Define the Start pan position
① Select Start Pos menu ② Move and set the position ③ Go back
or
NEAR NEAR
TELE
WIDE
- Scan No. : Max. 8 Scans can be stored.
- Label : The each Tour can have its own label name.
- Start position : Assign the coordinate of the Scan starting
position.
- End position : Assign the coordinate of the Scan ending position.
- Speed : It enables to set the running speed in the each
coordinate.(1~63)
- Dwell : The Scan function runs after the Dwell time without any
camera movement.
- Focus : It enables to set the camera Focus.
< NEAR / RIGHT START POS >
SCAN MENU
SCAN NO
LABEL
START POS
END POS
SPEED
DWELL
FOCUS
: 01 DEFINE
:
: 000.0, 000.0
: 000.0, ---
: 60
: 02
: AUTO
SAVE CLR BACK EXIT
SCAN START POSITION
POSITION : 000 .0, 000 .0
< EXIT FOCUS NEAR >
SCAN MENU
01 02 03 04 05 06
07 08
< SEL NEAR/MOVE JOYSTICK >

16
High Speed Mini PTZ Camera
17
High Speed Mini PTZ Camera
- DWELL
< NEAR / RIGHT DWELL >
SCAN MENU
SCAN NO
LABEL
START POS
END POS
SPEED
DWELL
FOCUS
: 01 DEFINE
:
: 000.0, 000.0
: 000.0, ---
: 60
: 02
: AUTO
SAVE CLR BACK EXIT
- FOCUS
< NEAR / RIGHT FOCUS MODE >
SCAN MENU
SCAN NO
LABEL
START POS
END POS
SPEED
DWELL
FOCUS
: 01 DEFINE
:
: 000.0, 000.0
: 000.0, ---
: 60
: 02
: AUTO
SAVE CLR BACK EXIT
The Pattern function memorizes User’s random moving path and zoom ratio.
Total recording time limit is 90secs and maximum 2 Pattern functions are toured in order.
4) PATTERN
＊PATTERN NO : 1~4 Patterns can be stored in Keyboard menu.
＊LABEL : The each Pattern can have its own label name.
＊RECORD : Movement by joystick and preset movement can be
memorized in a pattern.
＊PLAY : To revive the Pattern during the recorded time.
MOTION MENU
PRESET
TOUR
SCAN
PATTERN
AREA
ALARM
PRIVACY
EXIT BACK
< NEAR / RIGHT PATTERN >
- PATTERN NO
PATTERN MENU
PATTERN NO
LABEL
RECORD
PLAY
: 01 UNDEFINE
:
< NEAR / RIGHT PATTNO >
SAVE CLR BACK EXIT
01 02 03 04
PATTERN MENU
< SEL NEAR/MOVE JOYSTICK >
Select the Pattern number
Move : Select :
- LABEL
PATTERN MENU
PATTERN NO
LABEL
RECORD
PLAY
: 01 UNDEFINE
:
< NEAR / RIGHT LABEL SEL>
SAVE CLR BACK EXIT
- RECORDING
PATTERN MENU
PATTERN NO
LABEL
RECORD
PLAY
: 01 DEFINE
: <00SEC>
< NEAR / RIGHT RECORD >
SAVE CLR BACK EXIT
03/60
EXIT : NEAR 005 .8,000 .0
PATTERN RECORD
- PLAY
PATTERN MENU
PATTERN NO
LABEL
RECORD
PLAY
: 01 DEFINE
: <00SEC>
< NEAR / RIGHT PLAY >
SAVE CLR BACK EXIT
Play back the recorded Pattern data
PATTERN LABEL EDIT <01>
)
L
X
0
A
M
Y
1
B
N
Z
2
C
O
.
3
D
P
/
4
E
Q
,
5
F
R
+
6
G
S
-
7
H
T
=
8
I
U
<
9
J
V
>
(
K
W
@
LABEL :
<STORE TELE MOVE JOY>
<DEL WIDE BACK NEAR>
NEAR
Set the Pattern Label
Move : Select : or or
JOYSTICK JOYSTICK
Delete : or
It’s available to set the desired label, displayed on the executing screen of Pattern.
After the label set, push NEAR button to go out.
TELE WIDE
Record and Save the User’s random Pattern data
① Select the “Record” Menu
or
② Move and record the pattern ③ Set & Back
NEAR NEAR
NEAR
Select ON/OFF by using joystick and press key.
NEAR
Select ON/OFF by using joystick and press key.
The Scan function runs after the Dwell time without any camera
movement.
It enables to set the camera Focus.
(Set from 00 to 59)

18
High Speed Mini PTZ Camera
19
High Speed Mini PTZ Camera
MOTION MENU
PRESET
TOUR
SCAN
PATTERN
AREA
ALARM
PRIVACY
EXIT BACK
< NEAR / RIGHT AREA >
The Area function means that it displays the Area name between two programmed pan positions.
Maximun 16 Area functions are toured in order.
5) AREA
- AREA NO
AREA MENU
AREA NO
LABEL
START PAN POS
STOP PAN POS
: 01 UNDEFINE
:
: XXX.X
: XXX.X
< NEAR / RIGHT AREA NO >
SAVE CLR BACK EXIT
- LABEL
AREA MENU
AREA NO
LABEL
START PAN POS
STOP PAN POS
: 01 UNDEFINE
:
: XXX.X
: XXX.X
< NEAR / RIGHT LABEL EDIT >
SAVE CLR BACK EXIT
AREA LABEL EDIT <01>
)
L
X
0
A
M
Y
1
B
N
Z
2
C
O
.
3
D
P
/
4
E
Q
,
5
F
R
+
6
G
S
-
7
H
T
=
8
I
U
<
9
J
V
>
(
K
W
@
LABEL :
<STORE TELE MOVE JOY>
<DEL WIDE BACK NEAR>
- STOP PAN POSION
AREA START POSITION
POSITION : 000 .0, 000 .0
< EXIT FOCUS NEAR >
- START PAN POSION
AREA MENU
AREA NO
LABEL
START PAN POS
STOP PAN POS
: 01 DEFINE
:
: 000.0
: 000.0
< MOVE NEAR / JOYSTICK>
SAVE CLR BACK EXIT
AREA STOP POSITION
POSITION : 000 .0, 000 .0
< EXIT FOCUS NEAR >
AREA MENU
AREA NO
LABEL
START PAN POS
STOP PAN POS
: 01 DEFINE
:
: 000.0
: 000.0
< MOVE NEAR / JOYSTICK>
SAVE CLR BACK EXIT
※“Save” above setting Area data to the memory.
- "Save" above setting data to the memory.
- "CLR" means above setting Pattern data will not be saved and be cleared.
- "BACK" means it goes back to the previous menu.
- "EXIT" means it goes out of the MENU
Define the Start pan position
① Select the “Start Pan Pos” menu
or
② Move and set the position ③ Set & Back
※ Camera will move to clockwise direction only when START setting.
Define the Stop pan position
① Select the “Start Pan Pos” Menu ② Move and set the position ③ Set & Back
＊ALARM NO : 1~2 Alarms can be stored.
＊LABEL : The each Alarm can have its own label name.
＊PRESET NO : Assign the Preset No. to run when alarm is triggered.
MOTION MENU
PRESET
TOUR
SCAN
PATTEN
AREA
ALARM
PRIVACY
EXIT BACK
< NEAR / RIGHT ALARM >
The Alarm function means that the camera moves to the programmed Preset position by the Alarm
trigger. Maximum 2 Alarm functions are toured in order.
6) ALARM
Select the Area number
Move : Select :
NEAR
Set the Area Label
Move : Select : or or
JOYSTICK
Delete : or
JOYSTICK
After the label set, push NEAR button to go out.
TELE WIDE
NEAR NEAR
or
NEAR NEAR
01 02 03 04 05
06 07 08 09 10
11 12 13 14 15
16
AREA SELECT
< SEL NEAR/MOVE JOYSTICK >

20
High Speed Mini PTZ Camera
21
High Speed Mini PTZ Camera
- ALARM NO
02
ALARM SELECT
< SEL NEAR/MOVE JOYSTICK >
AREA MENU
ALARM NO
LABEL
PRESET NO
: 01 UNDEFINE
:
: XXX
< NEAR / RIGHT ALRAM NO >
SAVE CLR BACK EXIT
01
The Alarm function means that the camera moves to the programmed Preset position by the Alarm trigger.
Maximum 2 Alarm functions are toured in order.
Move : Select :
- LABEL
AREA MENU
ALARM NO
LABEL
PRESET NO
: 01 UNDEFINE
:
: XXX
< NEAR / RIGHT LABEL EDIT >
SAVE CLR BACK EXIT
ALARM LABEL EDIT <01>
)
L
X
0
A
M
Y
1
B
N
Z
2
C
O
.
3
D
P
/
4
E
Q
,
5
F
R
+
6
G
S
-
7
H
T
=
8
I
U
<
9
J
V
>
(
K
W
@
LABEL :
<STORE TELE MOVE JOY>
<DEL WIDE BACK NEAR>
Set the Alarm Label
Move : Select : or or Delete : or
JOYSTICK JOYSTICK
It’s available to set the desired label, displayed on the executing screen of Alarm.
After the label is set, push the NEAR button to exit.
- PRESET NO
ALARM MENU
ALARM NO
LABEL
PRESET NO
: 01 DEFINE
:
: 001
SAVE CLR BACK EXIT
< MOVE NEAR / JOYSTICK>
P001P002P003P004P005P006
P007P008 009 010 011 012
013 014 015 016 017 018
019 020 021 022 023 024
025 026 027 028 029 030
031 032 033 034 035 036
037 038 039 040 041 042
043 044 045 046 047 048
049 050 051 052 053 054
PRESET SELECT 1
< SEL NEAR/MOVE JOYSTICK >
※ “Save” above setting Alarm data to the memory.
- "Save" above setting data to the memory.
- "CLR" means above setting Pattern data will not be saved and be cleared.
- "BACK" means it goes back to the previous menu.
- "EXIT" means it goes out of the MENU
Define the Preset position with Alarm trigger
① Select the “Preset No”
or
② Move and set the position ③ Set & Back
- PRIVACY NO
7) PRIVACY setting
＊PRIVACY NO : To protect privacy, Max. 8 Privacy can be created
on the arbitrary position to hide objects such as windows, shops
or private house. With spherical coordinates system, powerful
privacy zone masking function is possible.
＊POSION : Adjust the mask position
MOTION MENU
PRESET
TOUR
SCAN
PATTERN
AREA
ALARM
PRIVACY
EXIT BACK
< NEAR / RIGHT PRIVACY >
PRIVACY MENU
PRIVACY NO
POSITION : 01 UNDEFINE : XXX .X, XXX .X
< NEAR / RIGHT PRIVACY NO >
SAVE CLR BACK EXIT
01 02 03 04 05
06 07 08
PRIVACY SELECT
< SEL NEAR/MOVE JOYSTICK >
- POSITION
PRIVACY MENU
PRIVACY NO
POSITION : 01 DEFINE : 000 .0, 000 .0
< NEAR / RIGHT PRIVACY NO >
SAVE CLR BACK EXIT
PRIVACY POSITION
POSITION : 000 .0, 000 .0
< EXIT FOCUS NEAR >
MASK SIZE <OPEN/CLOSE>
NEAR
TELE WIDE
NEAR NEAR
* Press key to set privacy number and press key again to go out the menu.
NEAR NEAR
OPEN CLOSE NEAR
*Ajust masking size by using , keys and press key to go out and save the menu.

22
High Speed Mini PTZ Camera
23
High Speed Mini PTZ Camera
4. 3 Dome Menu
Pan, Tilt, Zoom motion is adjustable in the “Dome Setting” Menu.
MAIN MENU
MOTION
DOME
CAMERA
CLEAR
PTZ RESET
EXIT
< NEAR / RIGHT DOME >
Move : Select : or or Delete : or
JOYSTICK JOYSTICK
After the label set, push NEAR button to go out.
<STORE TELE MOVE JOY>
<DEL WIDE BACK NEAR>
TITLE SET
LABEL :
2) POWER UP ACTION
When this function is ON, the camera memorize the latest action
and restore it from sudden power failure.
TELE WIDE
＊TIME (MIN) : The Park time can be assigned from 10 sec to
60sec. (Max. 2min./ by 10 sec.)
※When MOTION is operating, PARK ACTION is not working. (without AREA and PRIVACY )
: This function enables to locate the camera to specific position
automatically if operator doesn’t operate the controller for a while.
- TIME
3) PARK ACTION
< NEAR / RIGHT PARK TIME >
BACK
PARK MENU
TIME
FUNCTION
NUMBER
: 02MIN
: PRESET
: 01
: Can select one of the motion functions, Preset, Tour, Pattern
and Scan.
- FUNCTION
< NEAR / RIGHT FUNCTION >
BACK
PARK MENU
TIME
FUNCTION
NUMBER
: 02MIN
: PRESET
: 01
: The number of selected motion function.
- PRESET : 01~255
- TOUR : 01~08
- SCAN :01 ~ 08
- PATTERN : 01 ~ 02
- NUMBER
< NEAR / RIGHT NUMBER >
BACK
PARK MENU
TIME
FUNCTION
NUMBER
: 02MIN
: PRESET
: 01
4) DISPLAY ON/OFF
DISPLAY ON/OFF SET
TITLE
ZOOM
PRESET
TOUR
SCAN
PRIVACY
PATTERN
AREA
ALARM
POSITION
ACTION
*
< * >
< * >
< * >
< * >
< * >
< * >
< * >
< * >
< * >
< >
<ON TELE MOVE JOY >
<OFF WIDE BACK NEAR>
You can select the OSD ON to shown on the screen or clear by selecting OFF in this function.
OSD ON : OSD OFF: Select :
NEARTELE WIDE
1) Set the Dome camera title
NEAR
Select ON/OFF by using joystick and press key.
NEAR
Select ON/OFF by using joystick and press key.
< NEAR / RIGHT TITLE SET >
SAVE BACK EXIT
DOME MENU
TITLE :
POWER UPACTION : ON
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
TEMP SET MENU
DIGITAL OUT
FACTORY SET : 1080i30
< NEAR / RIGHT FUNCTION >
SAVE BACK EXIT
DOME MENU
TITLE :
POWER UPACTION : ON
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
TEMP SET MENU
DIGITAL OUT
FACTORY SET : 1080i30
< NEAR / RIGHT SUB MENU >
SAVE BACK EXIT
DOME MENU
TITLE :
POWER UPACTION : ON
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
TEMP SET MENU
DIGITAL OUT
FACTORY SET : 1080i30
< NEAR / RIGHT SUB MENU >
SAVE BACK EXIT
DOME MENU
TITLE :
POWER UPACTION : ON
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
TEMP SET MENU
DIGITAL OUT
FACTORY SET : 1080i30

24
High Speed Mini PTZ Camera
25
High Speed Mini PTZ Camera
5) DOME SUB MENU
< NEAR / RIGHT SUB MENU >
BACK
DOME MENU
TILT LIMIT
SPEED BY ZOOM
AUTO FLIP
RESPONSE TXD
: OFF
: OFF
: OFF
: OFF
Set tilt stop angle. : off ~15°
- TILT LIMIT
< NEAR / RIGHT FUNCTION >
BACK
DOME MENU
TILT LIMIT
SPEED BY ZOOM
AUTO FLIP
RESPONSE TXD
: OFF
: OFF
: OFF
: OFF
In the Max zoom-in, Pan and Tilt speed can be changed depending
on zoom magnification. ON will slow down the speed of Pan/Tilt
and OFF will increase the Pan/Tilt speed.
- SPEED BY ZOOM
< NEAR / RIGHT FUNCTION >
BACK
DOME MENU
TILT LIMIT
SPEED BY ZOOM
AUTO FLIP
RESPONSE TXD
: OFF
: OFF
: OFF
: OFF
- AUTO FLIP
< NEAR / RIGHT FUNCTION >
BACK
DOME MENU
TILT LIMIT
SPEED BY ZOOM
AUTO FLIP
RESPONSE TXD
: OFF
: OFF
: OFF
: OFF
- RESPONSE
6) TEMP SET
It shows you the current temperature and you can also set
the value manually. The compulsory Fan & Heater operation
is a useful function to remove humidity.
< NEAR / RIGHT ON TEMP >
BACK
DOME MENU
HEATER ON TEMP
HEATER ON TIME
HEATER OFF TEMP
FAN ON TEMP
FAN OFF TEMP
: 5 C
: 30 MIN
: 3O C
: 50 C
: 40 C
CURRENT TEMPER 50.06C
- HEATER ON TEMP
< NEAR / RIGHT ON TIME >
BACK
DOME MENU
HEATER ON TEMP
HEATER ON TIME
HEATER OFF TEMP
FAN ON TEMP
FAN OFF TEMP
: 5 C
: 30 MIN
: 3O C
: 50 C
: 40 C
CURRENT TEMPER 50.06C
- HEATER ON TIME
＊Set the operating temperature of the heater.(0~70℃)
＊Set the operating time of the heater.
- By 10min. (10~60 min.)
- AUTO FLIP : In case that tilt angle arrives at the top of tilt orbit (90°),
zoom module camera keep moving to opposite tilt direction (180°) to
keep tracing targets. As soon as zoom module camera passes through
the top of tilt direction (90°), images should be reversed automatically and
appears in screen. If this function is set to OFF, tilt movement range is
0~90°
NEAR
Select ON/OFF by using joystick and press key.
NEAR
Select ON/OFF by using joystick and press key.
NEAR
Select ON/OFF by using joystick and press key.
NEAR
Select ON/OFF by using joystick and press key.
*Send the intrinsic protocol value to the Tx line. (Only for Pelco-D 5.0)
※Support outdoor product only.
< NEAR / RIGHT SUB MENU >
SAVE BACK EXIT
DOME MENU
TITLE :
POWER UPACTION : ON
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
TEMP SET MENU
DIGITAL OUT
FACTORY SET : 1080i30
< NEAR / RIGHT SUB MENU >
SAVE BACK EXIT
DOME MENU
TITLE :
POWER UPACTION : ON
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
TEMP SET MENU
DIGITAL OUT
FACTORY SET : 1080i30

26
High Speed Mini PTZ Camera
27
High Speed Mini PTZ Camera
< NEAR / RIGHT OFF TEMP >
BACK
DOME MENU
HEATER ON TEMP
HEATER ON TIME
HEATER OFF TEMP
FAN ON TEMP
FAN OFF TEMP
: 5 C
: 30 MIN
: 3O C
: 50 C
: 40 C
CURRENT TEMPER 50.06C
- HEATER OFF TEMP
< NEAR / RIGHT FAN ON >
BACK
DOME MENU
HEATER ON TEMP
HEATER ON TIME
HEATER OFF TEMP
FAN ON TEMP
FAN OFF TEMP
: 5 C
: 30 MIN
: 3O C
: 50 C
: 40 C
CURRENT TEMPER 50.06C
- FAN ON TEMP
＊Set the temerature of heater OFF. (0~70℃)
< NEAR / RIGHT FAN OFF >
BACK
DOME MENU
HEATER ON TEMP
HEATER ON TIME
HEATER OFF TEMP
FAN ON TEMP
FAN OFF TEMP
: 5 C
: 30 MIN
: 3O C
: 50 C
: 40 C
CURRENT TEMPER 50.06C
- FAN OFF TEMP
7) DIGITAL OUT
NEAR
NEAR
*Set the operating temperature of the Fan. (0~70℃)
Press key and select the temperrature by using
and press key again to go out the menu.
NEAR
Press key and select video out signal by using
joystick.
NEAR
NEAR
* Set the temperature of Fan OFF. (0~70℃)
Press key and select the temperrature by using
and press key again to go out the menu.
8) FATORY SET
Restore all of setting value to the factory default.
All of existing setting value would be erased.
< NEAR / RIGHT FUNCTION >
SAVE BACK EXIT
DOME MENU
TITLE :
POWER UPACTION : ON
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
TEMP SET MENU
DIGITAL OUT
FACTORY SET : 1080i30
Set digital video signal.
(1080p30, 1080i60, 720p60, 1080i59)
Reset the PTZ after change the video out signal.
< NEAR / RIGHT D OUT SEL >
SAVE BACK EXIT
DOME MENU
TITLE :
POWER UPACTION : ON
PARK ACTION
DISPLAY ON/OFF
DOME SUB MENU
TEMP SET MENU
DIGITAL OUT
FACTORY SET : 1080i30

28
High Speed Mini PTZ Camera
29
High Speed Mini PTZ Camera
4. 4 Camera Menu
Camera menu is subject to be changed without prior notice to upgrade and quality increase
and we may use slip sheet for the change.
Please check the camera version and the slip sheet if the camera menu and this manual
menu is not matched.
CAMERA MENU
- Functions can be set-up using the Camera menu.
In this menu, user can set the zoom, focus, white balance, auto exposure...etc functions.
Decide using of digital zoom function and select zoom speed.
＊ZOOM SPD : 0 ~ 7steps, USER(standard)
＊D-ZOOM : ON / OFF
1) ZOOM MODE
- ZOOM SPD
- D-ZOOM
ZOOM SPD : Select from 0sept to 7 steps,
USER (Standard speed)
Decide using of digital zoom function.
D-ZOOM: ON/ OFF
Select : or Set ON : Set OFF :
NEAR NEAR
Select : or Set ON : Set OFF :
NEAR NEAR
0$,10(18
027,21
'20(
&$0(5$
&/($5
37=5(6(7
(;,7
1($55,*+7୅027,21!
▷
▷
▷
▷
୅
&$0(5$0(18
=22002'(
)2&8602'(
:+,7(%$/
$872(;3
:'502'(
63(&,$/
&$0(5$5(6(7
6$9(%$&.(;,7
୅
1($55,*+7୅=22002'(!
୅
୅
୅
୅
୅
୅
୅
&$0(5$0(18
=22002'(
)2&8602'(
:+,7(%$/
$872(;3
:'502'(
63(&,$/
&$0(5$5(6(7
6$9(%$&.(;,7
୅
1($55,*+7୅=22002'(!
୅
୅
୅
୅
୅
୅
୅
=2200(18
=22063'86(5
'=22021
%$&.
୅
1($55,*+7୅=22063'!
=2200(18
=22063'86(5
'=22021
%$&.
୅
1($55,*+7୅'=220!
Select : or Set ON : Set OFF :
NEAR NEAR
2) FOCUS MODE
- FOCUS SPD
- FOCUS MODE
In Focus menu, you can set up the focus speed, focus mode,
near limit, AF mode and sensitivity.
Set the speed for camera focusing.
AUTO: The camera adjusts the focus automatically while
monitoring the screen continuously in the auto mode. In the auto
focusing mode, zoom key operation is not recognized as the input
of the focus key.
Manual: In the manual mode, users can adjust the camera focus
manually.
One Push: It will be focused in about 5 seconds after zooming,
panning, and return to MANUAL mode automatically. This is for
focusing accurately after zooming.
Infinity: infinity focus is the state where a lens forms an image of
an object an infinite distance away. This corresponds to the point
of focus for parallel rays.
&$0(5$0(18
=22002'(
)2&8602'(
:+,7(%$/
$872(;3
:'502'(
63(&,$/
&$0(5$5(6(7
6$9(%$&.(;,7
୅
1($55,*+7୅)2&8602'(!
୅
୅
୅
୅
୅
୅
୅
86(5
$872
&0
1250$/
)2&860(18
)2&8663'
)2&8602'(
1($5/,0,7
$)02'(
%$&.
୅
1($55,*+7୅)2&8663'!
86(5
$872
&0
1250$/
)2&860(18
)2&8663'
)2&8602'(
1($5/,0,7
$)02'(
%$&.
୅
1($55,*+7୅)2&8602'(!
Select : or Set ON : Set OFF :
NEAR NEAR

30
High Speed Mini PTZ Camera
31
High Speed Mini PTZ Camera
Select : or Set ON : Set OFF :
NEAR NEAR
- NEAR LIMIT
Infinity focus is the state where a lens from an image of
an object an infinite distance away.
This corresponds to the point of focus for
parallel rays.
( Over Infinity~ 1.0CM)
86(5
$872
&0
1250$/
)2&860(18
)2&8663'
)2&8602'(
1($5/,0,7
$)02'(
%$&.
୅
1($55,*+7୅1($5/,0,7!
Select : or Set ON : Set OFF :
NEAR NEAR
Set the AUTO FOCUS MODE position
- AF MODE
86(5
$872
&0
1250$/
)2&860(18
)2&8663'
)2&8602'(
1($5/,0,7
$)02'(
%$&.
୅
1($55,*+7୅$)02'(6(/!
3) WHTE BALANCE : Set the white balance of camera.
- WB MODE
White balance setting is a function revising color temperature to
resolve the problem that screen’s colors change by the color
temperature’s difference arrcording to time.
RED GAIN: Adjust red color level from 0~20.
BLUE GAIN: Adjust blue color level from 0~20.
WB MODE: Set the color depend on white balacne.
WB MODE : Select AUTO, INDOOR, OUTDOOR, ONEPUSHAWG
ONEPUSHTRG or MANUAL.
&$0(5$0(18
=22002'(
)2&8602'(
:+,7(%$/
$872(;3
:'502'(
63(&,$/
&$0(5$5(6(7
6$9(%$&.(;,7
୅
1($55,*+7୅:%6(77,1*!
୅
୅
୅
୅
୅
୅
୅
$872
;;;
;;;
:+,7(%$/$1&(02'(
:%02'(
5('*$,1
%/8(*$,1
%$&.
୅
1($55,*+7୅:%02'(6(/!
Select : or Set ON : Set OFF :
NEAR NEAR
Select : or Set ON : Set OFF :
NEAR NEAR
4) AUTO EXPO
Adjust color leverl (RED, BLUE : 00~ 20)
Standard level : RED -> 10 BLUE->110
- RED, BLUE MODE
AE setting is a function adjusting shutter speed according to
subject’s brightness to get standard amount of exposed light.
AE MODE: Select AUTO, MANUAL, SHUTTER or IRIS.
EXPOSURE : 00 ~ 20 (Standard 10)
SLOW SHUTTER: Select AUTO, MANUAL, SHUTTER or IRIS.
SHUTTER: If you set SHUTTER in AE mode, you can control the level
value
IRIS LEVEL: If you set IRIS in AE mode, you can control the level value
(00~20)
DSS LEVEL: Control digital show shutter speed.
0$18$/


:+,7(%$/$1&(02'(
:%02'(
5('*$,1
%/8(*$,1
%$&.
୅
1($55,*+7୅:%02'(6(/!
Select : or Set ON : Set OFF :
NEAR NEAR
&$0(5$0(18
=22002'(
)2&8602'(
:+,7(%$/
$872(;3
:'502'(
63(&,$/
&$0(5$5(6(7
6$9(%$&.(;,7
୅
1($55,*+7୅$(6(77,1*!
୅
୅
୅
୅
୅
୅
୅
- AE MODE
- EXPO MODE
Select AUTO, MANUAL, SHUTTER or IRIS.
Set the exposure.(00 ~20)
$872

2))
$872
$872
;
$872(;320(18
$(02'(
(;32685(
6/2:6+877(5
6+877(5
,5,6/(9(/
'66/(9(/
%$&.
୅
1($55,*+7୅$(02'(6(/!
$872

2))
$872
$872
;
$872(;320(18
$(02'(
(;32685(
6/2:6+877(5
6+877(5
,5,6/(9(/
'66/(9(/
%$&.
୅
1($55,*+7୅(;326(/!
Select : or Set ON : Set OFF :
NEAR NEAR
Select : or Set ON : Set OFF :
NEAR NEAR

32
High Speed Mini PTZ Camera
33
High Speed Mini PTZ Camera
- SHUTTER
- SLOW SHUTTER
Select AUTO, MANUAL, SHUTTER or IRIS.
If you set SHUTTER in the AE MODE, you can control shutter
speed.
(1/30, 1/60, 1/120, 1/240, 1/500, 1/1000, 1/2000, 1/4000,
1/8000, 1/16000, 1/30000, 1/60000)
6+877(5

2))

$872
;
$872(;320(18
$(02'(
(;32685(
6/2:6+877(5
6+877(5
,5,6/(9(/
'66/(9(/
%$&.
୅
1($55,*+7୅6+877(5!
$872

2))
$872
$872
;
$872(;320(18
$(02'(
(;32685(
6/2:6+877(5
6+877(5
,5,6/(9(/
'66/(9(/
%$&.
୅
1($55,*+7୅6/2:6+877(5!
Select : or Set ON : Set OFF :
NEAR NEAR
Select : or Set ON : Set OFF :
NEAR NEAR
- IRIS LEVEL
,5,6

2))
$872

;
$872(;320(18
$(02'(
(;32685(
6/2:6+877(5
6+877(5
,5,6/(9(/
'66/(9(/
%$&.
୅
1($55,*+7୅,5,6/(9(/!
Select : or Set ON : Set OFF :
NEAR NEAR
Select : or Set ON : Set OFF :
NEAR NEAR
,5,6

2))
$872

;
$872(;320(18
$(02'(
(;32685(
6/2:6+877(5
6+877(5
,5,6/(9(/
'66/(9(/
%$&.
୅
1($55,*+7୅'66/(9(/!
- DSS LEVEL
If you set IRIS in the AE MODE, you can set the IRIS level
from 00 to 20
Digital Slow Shutter: Control digital show shutter speed.
(X2, X3, X4)
Select : or Set ON : Set OFF :
NEAR NEAR
Select : or Set ON : Set OFF :
NEAR NEAR
Select : or Set ON : Set OFF :
NEAR NEAR
Set WDR funtion
WDR(Wide Dynamic Range)
5) WDR MODE
&$0(5$0(18
=22002'(
)2&8602'(
:+,7(%$/
$872(;3
:'502'(
63(&,$/
&$0(5$5(6(7
6$9(%$&.(;,7
୅
1($55,*+7୅:'502'(!
୅
୅
୅
୅
୅
୅
୅
Select ON or OFF.
2))

))
:'502'(0(18
:'502'(
:'5/(9(/
$75/(9(/
%$&.
୅
1($55,*+7୅:'502'(!
- WDR MODE
Select from 00 to 03.
2))

))
:'502'(0(18
:'502'(
:'5/(9(/
$75/(9(/
%$&.
୅
1($55,*+7୅:'5/(9(/!
- WDR LEVEL
Select ON or OFF
2))

21
:'502'(0(18
:'502'(
:'5/(9(/
$75/(9(/
%$&.
୅
1($55,*+7୅$75/(9(/!
- ATR LEVEL

34
High Speed Mini PTZ Camera
35
High Speed Mini PTZ Camera
6) SPECIAL
In the Special menu, it’s available to set special function
of the camera
Select : or Set ON : Set OFF :
NEAR NEAR
Select : or Set ON : Set OFF :
NEAR NEAR
&$0(5$0(18
=22002'(
)2&8602'(
:+,7(%$/
$872(;3
:'502'(
63(&,$/
&$0(5$5(6(7
6$9(%$&.(;,7
୅
1($55,*+7୅63(&,$/!
୅
୅
୅
୅
୅
୅
୅

2))
2))
$872
2))
2))
63(&,$/0(18
,&502'(ୄ
$3(5785(*$,1
%$&./,*+7
35(6(7)5((=(
'15/(9(/
)/,&.(5/(66
'()2*

%$&.
୅
1($55,*+7୅68%0(18!



63(&,$/0(18
,&502'($872
,&5$8727+5(6
,&5$872*$3
,&5$872'(/$<
%$&.
୅
1($55,*+7୅,&502'(!
- ICR MODE
Control DAY & NIGHT funtion.
- ICR MODE



63(&,$/0(18
,&502'($872
,&5$8727+5(6
,&5$872*$3
,&5$872'(/$<
%$&.
୅
1($55,*+7୅7+5(6+2/'!
- ICR AUTO THRESHOLD
Set the ICR THRESHOLD
Select AUTO, DAY and NIGHT. APERTURE GAIN: Select aperture gain
- APERTURE GAIN
- BACK LIGHT
Select ON/OFF in the BACK LIGHT function.
Select : or Set ON : Set OFF :
NEAR NEAR
Select : or Set ON : Set OFF :
NEAR NEAR
Select : or Set ON : Set OFF :
NEAR NEAR
Select : or Set ON : Set OFF :
NEAR NEAR



63(&,$/0(18
,&502'($872
,&5$8727+5(6
,&5$872*$3
,&5$872'(/$<
%$&.
୅
1($55,*+7୅*$3!
- ICR AUTO GAP
Select the ICR level.



63(&,$/0(18
,&502'($872
,&5$8727+5(6
,&5$872*$3
,&5$872'(/$<
%$&.
୅
1($55,*+7୅'(/$<!
- ICR AUTO DELAY

2))
2))
$872
2))
2))
63(&,$/0(18
,&502'(ୄ
$3(5785(*$,1
%$&./,*+7
35(6(7)5((=(
'15/(9(/
)/,&.(5/(66
'()2*
%$&.
୅
1($55,*+7୅$3(5785(!

2))
2))
$872
2))
2))
63(&,$/0(18
,&502'(ୄ
$3(5785(*$,1
%$&./,*+7
35(6(7)5((=(
'15/(9(/
)/,&.(5/(66
'()2*
%$&.
୅
1($55,*+7୅%$&./,*+7!
Set ICR auto delay.

36
High Speed Mini PTZ Camera
37
High Speed Mini PTZ Camera
7) CAMERA RESET
Make initialize the setting value which is set in CAMERA MENU.
Select : or Set ON : Set OFF :
NEAR NEAR
Select : or Set ON : Set OFF :
NEAR NEAR
&$0(5$0(18
=22002'(
)2&8602'(
:+,7(%$/
$872(;3
:'502'(
63(&,$/
&$0(5$5(6(7
6$9(%$&.(;,7
୅
1($55,*+7୅5(6(7!
୅
୅
୅
୅
୅
୅
୅

2))
2))
$872
2))
2))
63(&,$/0(18
,&502'(ୄ
$3(5785(*$,1
%$&./,*+7
35(6(7)5((=(
'15/(9(/
)/,&.(5/(66
'()2*
%$&.
୅
1($55,*+7୅'15/(9(/!
- DNR LEVEL
Select the DNR level from AUTO, LEV1, LEV2, LEV3 and OFF.
Select : or Set ON : Set OFF :
NEAR NEAR

2))
2))
$872
2))
2))
63(&,$/0(18
,&502'(ୄ
$3(5785(*$,1
%$&./,*+7
35(6(7)5((=(
'15/(9(/
)/,&.(5/(66
'()2*
%$&.
୅
1($55,*+7୅)/,&.(5/(66!
- FLICKERLESS
Select ON/OFF in the FLICKERLESS function.
Select : or Set ON : Set OFF :
NEAR NEAR

2))
2))
$872
2))
2))
63(&,$/0(18
,&502'(ୄ
$3(5785(*$,1
%$&./,*+7
35(6(7)5((=(
'15/(9(/
)/,&.(5/(66
'()2*
%$&.
୅
1($55,*+7୅'()2*02'(!
- DEFOG
Defogging foggy video image.
Select ON/OFF.
Select : or Set ON : Set OFF :
NEAR NEAR

2))
2))
$872
2))
2))
63(&,$/0(18
,&502'(ୄ
$3(5785(*$,1
%$&./,*+7
35(6(7)5((=(
'15/(9(/
)/,&.(5/(66
'()2*
%$&.
୅
1($55,*+7୅35(6(7)5((=(!
- PRESET FREEZE
Display start image and finished image only.
Static image on-screen during the camera movement.
4. 5 Clear Setting
MAIN MENU
< NEAR / RIGHT
▶
CLEAR >
MOTION
▶
DOME
▶
CAMERA
▶
CLEAR ▶
PTZ RESET
EXIT
CLEAR MENU
< SEL
▶
NEAR LEFT /RIGHT>
PRESET ▶YES NO
TOUR
▶
SCAN
▶
PATTERN
▶
AREA
▶
PRIVACY
▶
ALARM
▶
▶
PRESET CLEAR:
Select : or Set ON :
Set OFF :
NEAR
NEAR
4. 6 PTZ Reset
MAIN MENU
< NEAR / RIGHT
▶
RESET >
MOTION
▶
DOME
▶
CAMERA
▶
CLEAR
▶
PTZ RESET
EXIT
It is a reset function and is useful when you change the dipswitches for address, protocol and baud rate.
Clears the PTZ position and function value. With this function the camera keeps the accuracy
of the PTZ position value.

38
High Speed Mini PTZ Camera
39
High Speed Mini PTZ Camera
6. DIMENSION
6. 1 Dimension
5. SPECIFICATION
5. 1 Camera Specification
236.7 OPTION
120
150
90
120
Ø8
Ø172
Ø107.5
MODEL 3x Mega pixel camera
Image Sensor
Effective Number of pixels
Aspect Ratio
Lens
Digital Zoom
Resolution
Min. illumination
Video Output
S/N Ratio
Focusing Mode
Shutter Speed
WDR/BLC
White Balance
Rotation Angle
Rotation Speed
Flip
Lens Initialization
Focus Control
Iris Control
Protocols
Communication
Power Consumption
Operating Temperature
Operating Humidity
Certification
1/2.9” Sony "Exmor" CMOS
Approx. 2 Mega Pixels
16 : 9
3x Optical Zoom
f=3.0mm(wide) ~ 9.0mm(tele)
F1.2 to F2.1
Max 6x
1080P/30, 720P/60
Color : 0.5 lux , BW : 0.1 lux
Color DSS : 0.002 lux , BW DSS : 0.001 lux
HD-SDI, CVBS
more than 50dB (AGC off)
Auto / One Push / Manual
1/30(25) ~ 1/60,000 sec
OFF / WDR / BLC
AUTO / One Push / Manual / Indoor / Outdoor
Pan : 360º Endless / Tilt : 0º ~ 180º (Digital flip)
Manual : 100º/sec, Turbo : 180º/sec, Preset : 360º/sec
Digital Flip Support
Built-in
Auto / Manual / One push selectable
Auto / Manual selectable
PELCO-D, PELCO-P, WONWOO
RS-485
AC 24V 3A(OUTDOOR), AC 24V 1A(INDOOR), DC 12V 1.5A(INDOOR)
0ºC ~ +50ºC (Indoor )
-10ºC ~+50ºC (Outdoor ,with Fan&Heater power ON)
20% ~ 75% RH
CE, FCC
