Woodpeckers STABILMAX TRIM ROUTER BASE User manual

TRIM ROUTER BASE
OWNER ’ S MANUAL
Scan the QR code above
to watch the video
or visit woodpeck.com
under the video tab towards
the bottom o the product page.
I you think you ’ re missing anything, email us at [e-mail] .
You can also call us at 800-752-0725 rom 9:00 a.m. to 4:00 p.m. EST Monday - Friday.
DIAGRAM
NUMBER
(QTY) PART NAME
1
(1) Base
2
(1) Handle
3
(1)
(1)
(4)
Centering Pin
Handle Screw, 1/4-20 x 5/8 ”
Pan Head Screws, M4 x .7mm
Woodpeckers

1. Secure the Handle 2 to the top o the
Base 1 with the Handle Screw.
FIGURE A.
2. Align your router with the
corresponding holes in the StabilMax
Base. FIGURE B .
3. Secure your router to the Base using
the (4) Pan Head Screws.
If Using a Template Guide Bushing
1. Loosen but do not remove the Pan
Head screws that secure the StabilMax
Base to your router.
2. Place the template guide bushing in
base plate and tighten securely.
3. Insert Centering Pin 3 into router
collet and tighten.
4. Adjust depth o cut until cone o
Centering Pin contacts the inside o
the template guide bushing.
5. Adjust position o base until cone is
contacting template guide bushing
uni ormly around its circum erence.
6. Tighten the (4) Pan Head Screws.
7. Remove Centering Pin.
NOTE: Centering Pin requires template
guide bushing between 1/4 " and 9/16 ". I
your project requires a larger template guide
bushing, use one in this range to center, then
change be ore proceeding.

• Align router so switch aces away rom Handle (except Milwaukee) .
• Actual size to aid in alignment FIGURE B .
A - DEWALT
DWP611, DCW600B
B - MAKITA
RT0701C, XTR01Z
D - RIDGID
R2401, R860443B
C
- POR RTER CABLE
PCE6430
D - RYOBI
P601
E
-
BOSCH
GKF125CEN
F - BO SCH COLT
PR20EVS
G -
MILWAUKEE
2723-20

WARNING! To reduce the risk o
injury keep hands away rom moving
parts. Re er to your power tool manual
or proper setup and use.
WARNING! To reduce the risk o
injury, wear sa ety goggles or glasses
with side shields, ear protection
& a dust mask.
