Woodward MicroNet TMR 5009FT User manual

Product Manual 26518V4
(Revision A)
Original Instructions
MicroNet TMR®5009FT
Fault-Tolerant Steam Turbine Control
HMI Interface Manual
Manual 26518 consists of 4 volumes (26518V1, 26518V2, 26518V3, 26518V4).
Volume 4

General
Precautions
Read this entire manual and all other publications pertaining to the work to be
performed before installing, operating, or servicing this equipment.
Practice all plant and safety instructions and precautions.
Failure to follow instructions can cause personal injury and/or property damage.
Revisions
This publication may have been revised or updated since this copy was produced.
To verify that you have the latest revision, check manual 26311 , Revision Status &
Distribution Restrictions of Woodward Technical Publications, on the publications
page of the Woodward website:
www.woodward.com/publications
The latest version of most publications is available on the publications page. If
your publication is not there, please contact your customer service representative
to get the latest copy.
Proper Use
Any unauthorized modifications to or use of this equipment outside its specified
mechanical, electrical, or other operating limits may cause personal injury and/or
property damage, including damage to the equipment. Any such unauthorized
modifications: (i) constitute "misuse" and/or "negligence" within the meaning of
the product warranty thereby excluding warranty coverage for any resulting
damage, and (ii) invalidate product certifications or listings.
Translated
Publications
If the cover of this publication states "Translation of the Original Instructions"
please note:
The original source of this publication may have been updated since this
translation was made. Be sure to check manual 26311 , Revision Status &
Distribution Restrictions of Woodward Technical Publications, to verify whether
this translation is up to date. Out-of-date translations are marked with . Always
compare with the original for technical specifications and for proper and safe
installation and operation procedures.
Woodward reserves the right to update any portion of this publication at any time. Information provided by Woodward is
believed to be correct and reliable. However, no responsibility is assumed by Woodward unless otherwise expressly
undertaken. Copyright © Woodward 2010
All Rights Reserved

Manual 26518V4 MicroNet TMR 5009FT
Woodward i
Contents
WARNINGS AND NOTICES............................................................................III
ELECTROSTATIC DISCHARGE AWARENESS ................................................. IV
REGULATORY COMPLIANCE ........................................................................V
CHAPTER 1. GENERAL INFORMATION...........................................................1
CHAPTER 2. DESCRIPTION...........................................................................2
CHAPTER 3. INSTALLATION PROCEDURE .....................................................4
Introduction.............................................................................................................4
TouchPanel Hardware............................................................................................4
Communications.....................................................................................................5
Printer Setup...........................................................................................................6
Initial Setup.............................................................................................................6
Setting the Time and Date..............................................................................6
CHAPTER 4. OPERATING PROCEDURES .......................................................7
General Operating Procedures ..............................................................................7
General Screen Functions..............................................................................8
Detailed Operating Procedures..............................................................................9
Main Menu......................................................................................................9
Startup Curve Screen...................................................................................10
Sequence Graphics......................................................................................10
Turbine Run Screen......................................................................................11
Monster View Screen....................................................................................12
Analog Input/Output Screen.........................................................................13
Controlled Shutdown ....................................................................................14
Speed Control Screen ..................................................................................14
Speed Dynamics...........................................................................................15
Contact Input Screen....................................................................................15
Actuator Service Screen...............................................................................16
Actuator Status Screen.................................................................................16
PID Control Screen.......................................................................................17
Relay Output Status Screen.........................................................................18
Steam Map Screen.......................................................................................18
Extraction, Admission, EXTR/ADM Control Screen.....................................19
Auxiliary Control Screen...............................................................................20
Cascade Control Screen...............................................................................21
Decoupling Control Screen...........................................................................22
Generator Screen.........................................................................................22
Overspeed Test Screen................................................................................23
Main Trends Screen .....................................................................................23
Trend Screens..............................................................................................24
Alarm Screen................................................................................................25
Historical Alarm Screen................................................................................26

MicroNet TMR 5009FT Manual 26518V4
ii Woodward
Illustrations and Tables
Figure 2-1. 5009FT System....................................................................................2
Figure 4-1. General Functions................................................................................8
Figure 4-2. Main Menu ...........................................................................................9
Figure 4-3. Startup Curve Screen.........................................................................10
Figure 4-4. Start Sequence Screen......................................................................10
Figure 4-5. Turbine Run (Generator Unit)............................................................11
Figure 4-6. Monster View Screen.........................................................................12
Figure 4-7. Analog In/Out.....................................................................................13
Figure 4-8. Speed Control....................................................................................14
Figure 4-9. Contact Input......................................................................................15
Figure 4-10. Actuator Service...............................................................................16
Figure 4-11. Actuator Status.................................................................................16
Figure 4-12. PID Control.......................................................................................17
Figure 4-13. Relay Outputs ..................................................................................18
Figure 4-14. Steam Map Screen ..........................................................................18
Figure 4-15. Extraction/Admission Control Screen ..............................................19
Figure 4-16. Auxiliary Control Screen ..................................................................20
Figure 4-17. Cascade Control Screen..................................................................21
Figure 4-18. DCPL Control Screen.......................................................................22
Figure 4-19. Generator Screen.............................................................................22
Figure 4-20. Overspeed Test................................................................................23
Figure 4-21. Trend Menu......................................................................................23
Figure 4-22. Extraction Trend Screen ..................................................................24
Figure 4-23a. Alarm Screen .................................................................................25
Figure 4-23b. Alarm Screen .................................................................................26
Table 3-1. iFix TCP/IP Address Configuration .......................................................5

Manual 26518V4 MicroNet TMR 5009FT
Woodward iii
Warnings and Notices
Important Definitions
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death.
DANGER—Indicates a hazardous situation which, if not avoided, will result
in death or serious injury.
WARNING—Indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION—Indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
NOTICE—Indicates a hazard that could result in property damage only
(including damage to the control).
IMPORTANT—Designates an operating tip or maintenance suggestion.
Overspeed /
Overtemperature /
Overpressure
The engine, turbine, or other type of prime mover should be
equipped with an overspeed shutdown device to protect against
runaway or damage to the prime mover with possible personal injury,
loss of life, or property damage.
The overspeed shutdown device must be totally independent of the
prime mover control system. An overtemperature or overpressure
shutdown device may also be needed for safety, as appropriate.
Personal Protective
Equipment
The products described in this publication may present risks that
could lead to personal injury, loss of life, or property damage. Always
wear the appropriate personal protective equipment (PPE) for the job
at hand. Equipment that should be considered includes but is not
limited to:
Eye Protection
Hearing Protection
Hard Hat
Gloves
Safety Boots
Respirator
Always read the proper Material Safety Data Sheet (MSDS) for any
working fluid(s) and comply with recommended safety equipment.
Start-up
Be prepared to make an emergency shutdown when starting the
engine, turbine, or other type of prime mover, to protect against
runaway or overspeed with possible personal injury, loss of life, or
property damage.
Automotive
Applications
On- and off-highway Mobile Applications: Unless Woodward's control
functions as the supervisory control, customer should install a
system totally independent of the prime mover control system that
monitors for supervisory control of engine (and takes appropriate
action if supervisory control is lost) to protect against loss of engine
control with possible personal injury, loss of life, or property damage.

MicroNet TMR 5009FT Manual 26518V4
iv Woodward
Battery Charging
Device
To prevent damage to a control system that uses an alternator or
battery-charging device, make sure the charging device is turned off
before disconnecting the battery from the system.
Electrostatic Discharge Awareness
Electrostatic
Precautions
Electronic controls contain static-sensitive parts. Observe the
following precautions to prevent damage to these parts:
Discharge body static before handling the control (with power to
the control turned off, contact a grounded surface and maintain
contact while handling the control).
Avoid all plastic, vinyl, and Styrofoam (except antistatic versions)
around printed circuit boards.
Do not touch the components or conductors on a printed circuit
board with your hands or with conductive devices.
To prevent damage to electronic components caused by improper
handling, read and observe the precautions in Woodward manual
82715, Guide for Handling and Protection of Electronic Controls,
Printed Circuit Boards, and Modules.
Follow these precautions when working with or near the control.
1. Avoid the build-up of static electricity on your body by not wearing clothing
made of synthetic materials. Wear cotton or cotton-blend materials as much
as possible because these do not store static electric charges as much as
synthetics.
2. Do not remove the printed circuit board (PCB) from the control cabinet
unless absolutely necessary. If you must remove the PCB from the control
cabinet, follow these precautions:
Do not touch any part of the PCB except the edges.
Do not touch the electrical conductors, the connectors, or the
components with conductive devices or with your hands.
When replacing a PCB, keep the new PCB in the plastic antistatic
protective bag it comes in until you are ready to install it. Immediately
after removing the old PCB from the control cabinet, place it in the
antistatic protective bag.

Manual 26518V4 MicroNet TMR 5009FT
Woodward v
Regulatory Compliance
Part number 8269-1012 is suitable for use in ordinary (non-hazardous) locations
only.
Field wiring must be rated at least 75 °C for operating ambient temperatures
expected to exceed 50 °C.
Peripheral equipment must be suitable for the location in which it is used.
Wiring must be in accordance with Ordinary (non-hazardous) wiring methods and
in accordance with the authority having jurisdiction.
EXPLOSION HAZARD—This equipment is not suitable for use in
Class I, Division 2 hazardous locations. It is to be used in Ordinary or
non-hazardous locations only.
Do not remove or install power supply, modules, or other equipment
while the circuit is live unless area is known to be non-hazardous.
Do not connect or disconnect equipment while circuit is live, unless
area is known to be non-hazardous.
If the equipment is used or applied in a manner not specified here-in,
the protection provided by the equipment may be impaired.
HIGH VOLTAGE—If 125 Vdc is present on the DTM terminal blocks,
there will be 125 Vdc on the discrete module cables. If power cannot
be removed from the DTM, extreme care must be taken to avoid
contact with the cables.
To comply with CE Marking under the European Low Voltage
Directive (LVD), the maximum external circuit voltage for both the
Discrete Inputs and Relay Output circuit are limited to 18–32 Vdc
maximum.

MicroNet TMR 5009FT Manual 26518V4
vi Woodward

Manual 26518V4 MicroNet TMR 5009FT
Woodward 1
Chapter 1.
General Information
The technical documentation for the 5009FT Control System consists of the
following volumes:
Volume 1—provides information on system application, control functionality, fault
tolerant logic, control logic, PID setting instructions, and system operation
procedures.
Volume 2—provides hardware descriptions, mechanical and electrical
installation instructions, hardware specifications, hardware troubleshooting help,
and basic repair procedures.
Volume 3—provides installation procedures for the 5009FT control’s personal
computer based configuration & commissioning tool software program (CCT),
information on all CCT features and modes (Configuration, Service and Run),
and a lists of the control’s Modbus®* registers and DDE tag names.
*—Modbus is a registered trademark of Schneider Automation Inc.
Volume 4—provides details on installation and operation of the HMI operator
control station, if provided with your system.
The Woodward HMI™ Operator Interface was developed for use with the
MicroNet TMR®5009FT Digital Governor for steam turbines, generators, and
compressors. This manual includes installation instructions, description and
operating procedures.
This manual does not contain instructions for the operation of the complete
turbine generator/compressor system. For turbine, generator/compressor or plant
operating instructions, contact the plant- equipment manufacturer.
The following part numbers are covered in this manual:
8269-1012 Computer-Optional iFix Operator Interface (HMI)

MicroNet TMR 5009FT Manual 26518V4
2 Woodward
Chapter 2.
Description
The HMI Operator Interface is a touch screen workstation that functions as an
enunciator and operator control panel for Woodward’s MicroNet TMR®5009FT
digital control. This workstation allows an operator to remotely view operating
points, vary control setpoints, and issue run mode commands. The HMI is
comprised of an industrialized touch screen hardware package and Proficy iFix
running on a Windows XP Embedded operating system. This standard software
program allows the HMI to automatically select the correct interface screens
based on how the 5009FT control has been configured. No field configuration is
necessary. The hardware package selected is the Phoenix Contact ValueLine
industrial PC. Even though the computer is fully tested and programmed before it
is packaged with the 5009FT, the manual contains basic maintenance
information and a user’s guide.
The HMI is connected to the 5009FT control via two redundant Ethernet switches
mounted in the control panel: ETH1 and ETH2. Once communications between
the HMI and the 5009FT control have been established, the HMI will
automatically configure its screens to match the configuration of the control.
Depending on how the 5009FT control is configured, all 5009FT run mode
operations can be monitored and performed through the HMI.
Figure 2-1. 5009FT System

Manual 26518V4 MicroNet TMR 5009FT
Woodward 3
A selection of screens allows operators to monitor, control, and troubleshoot a
system. These screens display:
All controlling parameters
Starting sequence status
Turbine related information
Generator related information
Compressor related information
Speed, Extraction, Aux, Casc, and Limiter information
Analog input/output information
Discrete input status
Discrete output status
System alarm and shutdown information
These screens also allow access to:
Valve stroking
Various turbine functions such as startup, shut down, and speed/process
controllers.
The HMI provides an alarm log that displays and timestamps all 5009FT alarms
and trips with one second resolution. Connection to an optional serial printer
provides a hard-copy of the alarm/trip log. Refer to Figure 2-2 for port locations.

MicroNet TMR 5009FT Manual 26518V4
4 Woodward
Chapter 3.
Installation Procedure
Introduction
This touch screen workstation is designed for industrial applications for panel
mounting. The front has an IP65 rating. The ambient temperature for operation is
5 to 55 °C (41 to 131 °F) and humidity conditions ranging 5 to 95% relative
humidity (non-condensing).
The HMI can be secured with mounting bolts and clamps provided. The
recommended cutout dimensions are 329.5 x 424.0 mm (12.972 x 16.693 in.).
The unit must be installed in an enclosure or panel mounted so that the back shell
of the unit is protected from airborne contaminates. The installation must also
provide adequate air flow for the unit. To provide for this, a minimum of two inches
must be provided around the sides of the unit to insure proper air flow. When
installing the unit, enough room should be left in the back for ease of wiring.
For more information, consult the Phoenix Contact ValueLine Industrial PC User
Manual.
TouchPanel Hardware
Technical Data
Ambient temperature (operating) 5 to 55 °C
Ambient temperature (storage/transport) –40 to +70 °C
Permissible humidity (relative) 5 to 95%
Display, 17-inch (dimensions/weight) 452 x 356.5 x 50 mm / 5.85 kg
Degree of protection IP65 (front), IP20 (back)
Panel Mounting / LED indicators Power, HDD, Run, Error
Electrical Data
Power supply nominal 24 Vdc
Power supply range 19.2—28.8 Vdc
Current draw, typical 1.0—1.5 A
Current draw, maximum 2.0—5.2 A
Power consumption, typical 36.0 W
Power consumption, maximum 124.8 W
RTC battery, typical life 5 years
NOTE: Protective earth ground and circuit ground (return) are connected.
Computer Data
Operating system Windows®XP
Processor 1.5 GHz Intel Core2™ Duo, 667 FSB, 4 MB L2 Cache
RAM 2 GB
Data memory 2.5 inch SATA solid state drive 32GB
Interfaces USB 4x Type A, USB 1.1/2.0
Serial RS-232 (configurable option) DB-9, male
Video (configurable option) VGA (DB-15, female)
NVRAM size 128 kB
Number of Ethernet ports Two RJ45 Ethernet ports (10/100/1000 Mbps)

Manual 26518V4 MicroNet TMR 5009FT
Woodward 5
Display - 17 in.
Screen size, diagonal 430 mm (16.93 in.)
Screen size, horizontal x vertical 337.92 x 270.34 mm
Resolution 1280 x 1024
Type Resistive touch screen with
serial/USB interface
Brightness 350 Cd/m²
Number of colors 16.7 million
Contrast ratio 1000:1
View angle, horizontal/vertical (CR=10) 170°/160°
Installation cutout dimensions (width x height) 424.0 x 329.5 mm
Outside bezel dimensions (width x height x depth)
452.0 x 356.5 x 10 mm
Backlight life minimum 50000 hours
Interface (configurable option) USB 1.1/2.0, Type A
Mechanical Tests
Shock test according to IEC 60068-2-27 15 g, 11 ms impulse
Vibration resistance according to IEC 61131-2 Hard Drive: 0.5g
Conformance With EMC Directives
Developed according to IEC 61000-6-2
IEC 61000-4-2 (ESD) Criterion B
IEC 61000-4-3 (radiated-noise immunity) Criterion A
IEC 61000-4-4 (burst) Criterion B
IEC 61000-4-5 (surge) Criterion B
IEC 61000-4-6 (conducted noise immunity) Criterion A
IEC 61000-4-8 (noise immunity against magnetic fields) Criterion A
EN 55022 (noise emission) Class A
Approvals
CE
UL, cUL UL 508
UL, cUL Class I, Division 2, Groups A, B, C, D
UL 1604
For more information, consult the Phoenix Contact ValueLine Industrial PC User
Manual.
Communications
The HMI has multiple communication ports. The HMI’s “Ethernet 1” communication
port is used for 5009FT to HMI communications. The “Ethernet 2” communication
port is used for backup communications in case the Eth 1 network fails.
As shipped, the 5009FT system should begin communicating once the
appropriate network cable(s) have been connected. The default configuration for
the HMI will communicate with either port and either network on MicroNet TMR
CPU’s in Kernel A or B. The following are the default HMI computer and
MicroNet TMR CPU IP addresses that are programmed for iFix communications:
Ethernet Ports HMI Computer Kernel A CPU Kernel B CPU
Primary
Subnet 172.16.100.45 255.255.0.0 172.16.100.47 255.255.0.0 172.16.100.48 255.255.0.0
Secondary
Subnet 192.168.128.27 255.255.255.0 192.168.128.21 255.255.255.0 192.168.128.22 255.255.255.0
Table 3-1. iFix TCP/IP Address Configuration

MicroNet TMR 5009FT Manual 26518V4
6 Woodward
If the 5009FT port/IP settings have been changed from the defaults, the HMI will
not communicate unless the MicroNet TMR IP addresses as well as related iFix
settings on the HMI computer have been modified as well.
The HMI communicates via Modbus slave ID/numbers 1 and 2. There are 4 more
Modbus slave ports available, which are defaulted to Modbus slave or device
numbers 3, 4, 5, and 6. Note that changing some communication protocol
settings and device numbers may require a control reboot in order for those
communications to resume properly. This can be achieved via AppManager or by
going into and then out of the “Full Configuration Menu” on the CCT.
Any 5009FT control serial port configured for Modbus communications can be
used to communicate with a user DCS. For successful Modbus communications
the respective 5009FT Modbus port’s settings must configured to match the DCS’s
communication port settings. Special care must be taken to ensure there is no
conflict of Modbus slave numbers from devices connected to the 5009FT networks.
Printer Setup
If a printer is to be used with the HMI to print out the alarm log, it must be
connected to the HMI’s port.
Initial Setup
Upon power up, the HMI performs a set of diagnostic tests before it switches to
its Run mode and is ready for operation. These diagnostic tests take several
minutes to perform, in which time the application screens will not be visible. If the
HMI is not communicating with the 5009FT control, it may take up to 2 minutes
before application screens are visible.
After all diagnostic tests are passed the application’s Main Menu screen will
appear. If a “COMMUNICATION FAULT” message is displayed across the top of
the screen verify that the 5009FT to HMI communications cable connections are
correct and that the 5009FT ports settings are correctly set.
When the HMI is in the Run Mode, the operator can then go to any of the
operational screens and view and/or change the 5009FT controls running
parameters. If the 5009FT is not communicating to the HMI, the operator will still
be able to go to the screens, but will not be able to issue any commands or view
5009FT parameters.
It is recommended that the HMI’s time and date be set as part of the HMI’s initial
setup. Refer to the “Setting Time and Date” procedure below for setting
instructions.
Setting the Time and Date
The HMI uses the computers clock for its time and date information for display
throughout the HMI screens. The time and date on the HMI can be set via the
windows operating system as would typically be set on a Windows computer.

Manual 26518V4 MicroNet TMR 5009FT
Woodward 7
Chapter 4.
Operating Procedures
General Operating Procedures
This chapter describes the options and features that are available through the
HMI. This manual should not be used as an operational manual for the turbine
control. Refer to Volume 1 of the MicroNet TMR®5009FT manual for more
information on the operation and control functions of the 5009FT control.
The HMI is an industrial hardened touch screen workstation. Several “screens”
with graphics, monitor boxes, and push buttons have been set up for ease of
turbine operation. The graphics are self describing and show pictures of valves,
turbines and other standard plant equipment. The monitor boxes show
references, inputs, outputs and other measurements in easy to read numerical
format. The push buttons are used to raise or lower setpoints, enable or disable
functions, or to move from one screen to another. The push buttons will change
intensity or color when selected to inform the operator when they have been
received by the touch screen of the HMI.
If the 5009FT control is configured to receive commands from the HMI, all control
operations can be performed through the HMI. If not, the HMI can serve as a
system monitor.
Notes Regarding This Chapter
Visibility—This term is used to reference when a gauge or function is displayed
on the HMI (such as enable / disable buttons). Visibility largely depends on how
the 5009FT is configured. For example, if configured for a single valve turbine, no
extraction data or gauges will appear.
Modbus Data Written to the Control—Modbus data sent to the control can be
limited via the configuration. Using the CCT, any link’s Write capability can be
disabled by selections made on the Communications page. See the 5009FT
manual Volume 3 for more details.
ENABLE/DISABLE buttons—These are 'active' buttons which change once
they are pressed. i.e. If the button says ENABLE the function will be enabled
when pressed, the button will then change to DISABLE.
Note that commands written to the control via Modbus are pulsed signals. The
control will respond to the last input received whether from a discrete input, the
CTT, the OpView™, or another Modbus source.
Lost Communication
If the HMI is not communicating to the 5009FT, a COMMUNICATION FAULT'
message will appear on every screen. Screens can still be paged through,
however, all control variables will be corrupt and gauges that were previously
hidden will appear.
Upon loss of communications between the HMI and the 5009FT control, the
5009FT will generate an alarm. Turbine control will not be affected. No commands
from the HMI will be executed until the communications link is restored.

MicroNet TMR 5009FT Manual 26518V4
8 Woodward
Once communications have been re-established all commands from the HMI will
be accepted except 'entered' values (see Turbine control Screen Description).
The 5009FT alarm (communications failed) must be reset before 'entered' values
are accepted.
Units
The HMI will display the units of measure that have been configured in the
Program Mode of the 5009FT control for each function.
Local/Remote
The 5009FT's Local / Remote function allows an operator to disable some or all
remote operator panels.
If the 5009FT is configured to accept a Local/Remote input from the HMI, a
Local/Remote push button will appear on the MAIN MENU and DYNAMICS /
TREND MENU screen. It displays the action which will take place if the button is
pressed (same as enable / disable buttons). There is also a status indication on
all screens (except Trend screens) signifying Local/Remote status.
Refer to 'Local / Remote' of Volume 1 and 'CPU Communications' of Volume 3 of
the MicroNet TMR 5009FT manuals for more information.
Emergency Trip
The 5009FT control is defaulted to not accept an emergency shutdown (ESD)
command from the HMI. If the 5009FT is configured to accept an ESD from the
HMI, the ESD command button is displayed in the top right corner of all screens.
The HMI emergency trip utilizes a two step process to avoid accidental
shutdowns. The following procedure explains the two step emergency trip. Refer
to Figure 4-2 for location of the ESD buttons.
1. Press the Emergency Trip (ESD) button.
2. Press the continue button to verify the emergency trip or the cancel button
to cancel (a popup window will appear).
3. The 5009FT will shut down immediately.
General Screen Functions
Depending on how the 5009FT is configured, complete system control to simple
monitoring can be accomplished at the touch screen. There are basic functions
which can be performed or viewed from all of the HMI screens (except where
noted):
Figure 4-1. General Functions

Manual 26518V4 MicroNet TMR 5009FT
Woodward 9
General Functions
1 Alarm button for alarm screen display.
2 Alarm/Trip Status.
3 HMI close (only on the Main Menu screen).
4 SD button for an emergency shutdown.
5 Norm SD button for a controlled shutdown.
6 Time, Speed, HP valve, LP valve, and controlling parameters 1 and 2
are always available.
Detailed Operating Procedures
The following section describes HMI buttons and status indications, their
function, and when they appear on the HMI (visibility). Items contained under
General Screen Functions in the previous chapter are not described in this
section. Visibility for all command buttons (buttons which communicate to the
5009FT control to perform a function) is dependent on the Modbus being
enabled. Refer to volume 1 and volume 3 of this manual series for additional
information on Modbus addresses and enabling / disabling the Modbus (local /
remote).
Main Menu
The Main Menu screen is used as a focal point to access the other screens. In
most cases it is required to return to the Main Menu to proceed to another
screen. It contains push buttons to access the other screens and the Trend
menu.
Figure 4-2. Main Menu

MicroNet TMR 5009FT Manual 26518V4
10 Woodward
Startup Curve Screen
This screen is used to start the turbine and ramp to rated speed or the minimum
controlling speed. The Startup screen displayed will be different depending upon
the configured values in the 5009FT control. Speed raise/lower buttons as well
as a Go To button are available on this screen to control speed.
Figure 4-3. Startup Curve Screen
Sequence Graphics
This screen allows the user to immediately see which part of a sequence the
control is currently in. This is indicated by the green light as shown in Figure 4-4.
Figure 4-4. Start Sequence Screen

Manual 26518V4 MicroNet TMR 5009FT
Woodward 11
In addition to sequence step status and the typical header functions, the elapsed
time for any sequence step can be view in the bottom right corner of each sequence.
Turbine Run Screen
A graphic representation is displayed according to turbine type and application as
configured in the 5009FT. Setpoints can be adjusted and control functions may
be enabled / disabled from this screen. This screen gives indication of all
configured setpoints and inputs as well as breaker status (generator config.),
valve demand(s).
Figure 4-5. Turbine Run (Generator Unit)
Remote Setpoints will display for each feature as configured. Basic information
for each controller is displayed on this screen. More detailed information can be
found on the page for each individual controller.
Dynamics Adjustment
Adjustment to each controller's PID settings can only be performed through the
CCT.
To learn more on how to dynamically tune a steam turbine, reference Volume 1,
of the MicroNet TMR 5009FT Control - Dynamic Adjustments.

MicroNet TMR 5009FT Manual 26518V4
12 Woodward
Monster View Screen
(accessed from Turbine Run screen only)
The Monster View Screen is a monitor only screen. This screen is provided for
large views of the basic control parameters.
Figure 4-6. Monster View Screen
