Woodward AtlasPC User manual

Hardware Manual
AtlasPC™ Digital Control
Volume 2
Manual 85586 consists of 2 volumes (85586V1 & 85586V2).
Manual 85586V2 (Revision G)

DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential personal
injury hazards. Obey all safety messages that follow this symbol to avoid
possible injury or death.
•DANGER—Indicates a hazardous situation which, if not avoided, will result in death
or serious injury.
•WARNING—Indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
•CAUTION—Indicates a hazardous situation which, if not avoided, could result in
minor or moderate injury.
•NOTICE—Indicates a hazard that could result in property damage only (including
damage to the control).
•IMPORTANT—Designates an operating tip or maintenance suggestion.
The engine, turbine, or other type of prime mover should be equipped with an
overspeed shutdown device to protect against runaway or damage to the prime
mover with possible personal injury, loss of life, or property damage.
The overspeed shutdown device must be totally independent of the prime mover
control system. An overtemperature or overpressure shutdown device may also
be needed for safety, as appropriate.
Read this entire manual and all other publications pertaining to the work to be performed before
installing, operating, or servicing this equipment. Practice all plant and safety instructions and
precautions. Failure to follow instructions can cause personal injury and/or property damage.
This publication may have been revised o
r
updated since this copy was produced. To verify that
you have the latest revision, be sure to check the Woodward website:
www.woodward.com/pubs/current.pdf
The revision level is shown at the bottom of the front cover after the publication number. The latest
version of most publications is available at:
www.woodward.com/publications
If your publication is not there, please contact your customer service representative to get the
latest copy.
Any unauthorized modifications to or use of this equipment outside its specified mechanical,
electrical, or other operating limits may cause personal injury and/or property damage, including
damage to the equipment. Any such unauthorized modifications: (i) constitute "misuse" and/or
"negligence" within the meaning of the product warranty thereby excluding warranty coverage
for any resulting damage, and (ii) invalidate product certifications or listings.
To prevent damage to a control system that uses an alternator or batter
y
-charging
device, make sure the charging device is turned off before disconnecting the battery
from the system.
To prevent damage to electronic components caused by improper handling, read
and observe the precautions in Woodward manual 82715, Guide for Handling and
Protection of Electronic Controls, Printed Circuit Boards, and Modules.
Revisions—Text changes are indicated by a black line alongside the text.
Woodward Governor Company reserves the right to update any portion of this publication at any time. Information
provided by Woodward Governor Company is believed to be correct and reliable. However, no responsibility is assumed
by Woodward Governor Company unless otherwise expressly undertaken.
© Woodward 2000
All Rights Reserved

Manual 85586V2 AtlasPC Digital Control, Vol. II (Distributed I/O)
Woodward i
Contents
Volume II contains the AtlasPC™ detailed Distributed I/O information.
For all other hardware information, see Volume I.
DISTRIBUTED I/O.........................................................................................1
CHAPTER 1. PC104 PROFIBUS INTERFACE..................................................2
Introduction.............................................................................................................2
Profibus Software and Hardware Requirements....................................................2
Hardware for End Users .........................................................................................2
Software for Application Developers ......................................................................7
CHAPTER 2. PC104 DEVICENET INTERFACE..............................................15
Introduction...........................................................................................................15
DeviceNet Software and Hardware Requirements ..............................................15
Hardware for End Users .......................................................................................15
Software for Application Developers ....................................................................22
CHAPTER 3. PC104 ETHERNET INTERFACE ...............................................33
Introduction...........................................................................................................33
Ethernet Software and Hardware Requirements .................................................33
Hardware for End Users .......................................................................................33
Software for Application Developers ....................................................................38
CHAPTER 4. SERIAL (MODBUS)INTERFACE ...............................................40
Introduction...........................................................................................................40
Serial Software and Hardware Requirements......................................................40
Hardware for End Users .......................................................................................40
Software for Application Developers ....................................................................46
CHAPTER 5. PC104 CANOPEN INTERFACE................................................48
CHAPTER 6. DISTRIBUTED I/O EXAMPLES..................................................49
Introduction...........................................................................................................49
Allen-Bradley Flex I/O Example ...........................................................................50
Automation Direct Terminator I/O Example........................................................127

AtlasPC Digital Control, Vol. II (Distributed I/O) Manual 85586V2
ii Woodward
Illustrations and Tables
Figure 2-1. Typical CAN Network Example..........................................................19
Figure 6-1. Allen-Bradley Flex I/O Configuration..................................................51
Figure 6-2. AtlasPC Chassis GAP Block..............................................................54
Figure 6-3. Example of GAP Application FB_Module ..........................................54
Figure 6-4. FB_EQUIP Block Example ................................................................55
Figure 6-5. 3170-PDP Network Interface Memory Map .......................................59
Figure 6-6. Example of 3170-PDP Memory Map Read GAP Block .....................60
Figure 6-7. Example of 1794-IB16 Module Wiring ...............................................61
Figure 6-8. 1794-IB16 Memory Map.....................................................................62
Figure 6-9. 1794-IB16 Input Filter Time Bit Map ..................................................62
Figure 6-10. Example of 1794-IB16 Write GAP Block..........................................63
Figure 6-11. Example of 1794-IB16 Discrete Input Read GAP Blocks ................63
Figure 6-12. Example of 1794-OV16 Module Wiring............................................65
Figure 6-13. 1794-OV16 Module Memory Map....................................................65
Figure 6-14. Example of 1794-OV16 GAP Write Blocks......................................66
Figure 6-15. Example of 1794-OW8 Module Wiring.............................................67
Figure 6-16. 1794-OW8 Module Memory Map.....................................................68
Figure 6-17. Example of 1794-OW8 GAP Write Blocks.......................................68
Figure 6-18. Example of 1794-IE8/B Module Wiring............................................69
Figure 6-19. 1794-IE8/B Input Module Memory Map ...........................................70
Figure 6-20. 1794-IE8/B Output Module Memory Map ........................................70
Figure 6-21. Example of 1794-IE8/B Read and Write GAP Blocks......................71
Figure 6-22. 1794-IE8/B and 1794-OE4/B Analog Data Format Table................72
Figure 6-23. Example of 1794-IE8/B GAP Analog Write Blocks ..........................72
Figure 6-24. Example of 1794-OE4/B Module Wiring ..........................................73
Figure 6-25. 1794-OE4/B Module Input Memory Map .........................................74
Figure 6-26. 1794-OE4/B Module Output Memory Map.......................................74
Figure 6-27. 1794-OE4/B Write Range Selection Bits .........................................75
Figure 6-28. Example of 1794-OE4/B Read and Write GAP Blocks....................75
Figure 6-29. Example of 1794-OE4/B GAP Analog Write Blocks ........................76
Figure 6-30. Example of 1794-IT8 Module Wiring................................................77
Figure 6-31. 1794-IT8 Module Input Memory Map...............................................78
Figure 6-32. 1794-IT8 Module Output Memory Map ............................................78
Figure 6-33. 1794-IT8 Write Word 0.....................................................................79
Figure 6-34. 1794-IT8 Hardware First Notch Filter...............................................79
Figure 6-35. 1794-IT8 Write Word 1 and 2...........................................................80
Figure 6-36. Example of 1794-IT8 Read and Write GAP Blocks .........................81
Figure 6-37. 1794-IT8 Input Scaling.....................................................................82
Figure 6-38. Example of 1794-IT8 GAP Analog Read Blocks .............................83
Figure 6-39. Example of 1794-IR8 Module Wiring ...............................................84
Figure 6-40. 1794-IR8 Module Input Memory Map ..............................................85
Figure 6-41. 1794-IR8 Module Output Memory Map............................................85
Figure 6-42. 1794-IR8 Write Word 0 ....................................................................86
Figure 6-43. 1794-IT8 Hardware First Notch Filter...............................................86
Figure 6-44. 1794-IT8 Write Word 1 and 2...........................................................87
Figure 6-45. Example of 1794-IR8 Read and Write GAP Blocks.........................88
Figure 6-46.1794-IR8 Input Scaling......................................................................88
Figure 6-47. Example of 1794-IR8 GAP Analog Read Blocks .............................89
Figure 6-48. Allen-Bradley Flex I/O Configuration................................................90
Figure 6-49. MODBUS_M Block Example ...........................................................92
Figure 6-50. MODBUS_M Block RPT Window Example .....................................94
Figure 6-51. MODBUS_M Block Group 1 Analog Read RPT Example ...............95
Figure 6-52. MODBUS_M Block Group 2 Analog Read RPT Example ...............96
Figure 6-53. MODBUS_M Block Group 2 Analog Write RPT Example ...............96

Manual 85586V2 AtlasPC Digital Control, Vol. II (Distributed I/O)
Woodward iii
Illustrations and Tables
Figure 6-54. MODBUS_M Block Group 3 Analog Write RPT Example ...............97
Figure 6-55. MODBUS_M Block Group 4 Analog Write RPT Example ...............97
Figure 6-56. 3170-MBS Status Information Addresses........................................99
Figure 6-57. Example of 3170-MBS Memory Map Discrete Read GAP Blocks...99
Figure 6-58. Example of 3170-MBS Memory Map Analog Read GAP Blocks...100
Figure 6-59. Example of 1794-IB16 Module Wiring ...........................................101
Figure 6-60. 1794-IB16 Memory Map ................................................................101
Figure 6-61. 1794-IB16 Input Filter Time Bit Map ..............................................102
Figure 6-62. Example of 1794-IB16 Read and Write GAP Blocks.....................102
Figure 6-63. Example of 1794-OV16 Module Wiring .........................................103
Figure 6-64. 1794-OV16 Module Memory Map..................................................104
Figure 6-65. Example of 1794-OV16 GAP Write Blocks....................................104
Figure 6-66. Example of 1794-OW8 Module Wiring ..........................................105
Figure 6-67. 1794-OW8 Module Memory Map...................................................106
Figure 6-68. Example of 1794-OW8 GAP Write Blocks.....................................106
Figure 6-69. Example of 1794-IE8/B Module Wiring..........................................107
Figure 6-70. 1794-IE8/B Input Module Memory Map .........................................108
Figure 6-71. 1794-IE8/B Output Module Memory Map ......................................108
Figure 6-72. Example of 1794-IE8/B Read and Write GAP Blocks ...................109
Figure 6-73. 1794-IE8/B and 1794-OE4/B Analog Data Format Table..............110
Figure 6-74. Example of 1794-IE8/B GAP CALCULATE Scaling Blocks ..........110
Figure 6-75. Example of 1794-OE4/B Module Wiring ........................................111
Figure 6-76. 1794-OE4/B Module Input Memory Map .......................................112
Figure 6-77. 1794-OE4/B Module Output Memory Map ....................................112
Figure 6-78. 1794-OE4/B Write Range Selection Bits .......................................113
Figure 6-79. Example of 1794-OE4/B Read and Write GAP Blocks..................113
Figure 6-80. Example of 1794-OE4/B GAP Analog Write Blocks ......................114
Figure 6-81. Example of 1794-IT8 Module Wiring .............................................115
Figure 6-82. 1794-IT8 Module Input Memory Map.............................................116
Figure 6-83. 1794-IT8 Module Output Memory Map..........................................116
Figure 6-84. 1794-IT8 Write Word 0...................................................................117
Figure 6-85. 1794-IT8 Hardware First Notch Filter ............................................117
Figure 6-86. 1794-IT8 Write Word 1 and 2.........................................................118
Figure 6-87. Example of 1794-IT8 Read and Write GAP Blocks .......................119
Figure 6-88. 1794-IT8 Input Scaling...................................................................120
Figure 6-89. Example of 1794-IT8 GAP Analog Read Blocks ...........................121
Figure 6-90. Example of 1794-IR8 Module Wiring .............................................122
Figure 6-91. 1794-IR8 Module Input Memory Map ............................................123
Figure 6-92. 1794-IR8 Module Output Memory Map .........................................123
Figure 6-93. 1794-IR8 Write Word 0 ..................................................................124
Figure 6-94. 1794-IT8 Hardware First Notch Filter ............................................124
Figure 6-95. 1794-IT8 Write Word 1 and 2.........................................................125
Figure 6-96. Example of 1794-IR8 Read and Write GAP Blocks.......................126
Figure 6-97. 1794-IR8 Input Scaling ..................................................................126
Figure 6-98. Example of 1794-IR8 GAP Analog Read Blocks...........................127
Figure 6-99. Automation Direct Terminator I/O Configuration............................128
Figure 6-100. MODBUS_M Block Example .......................................................130
Figure 6-101. T1K-MODBUS Adapter Addressing Table...................................132
Figure 6-102. MODBUS_M Block RPT Example ...............................................133
Figure 6-103. MODBUS_M Block Boolean Write RPT Example .......................134
Figure 6-104. MODBUS_M Block Boolean Read RPT Example .......................134
Figure 6-105. MODBUS_M Block Analog Read RPT Example .........................135
Figure 6-106. MODBUS_M Block Analog Write RPT Example .........................136
Figure 6-107. T1K-MODBUS Dip Switch Settings .............................................137

AtlasPC Digital Control, Vol. II (Distributed I/O) Manual 85586V2
iv Woodward
Illustrations and Tables
Figure 6-108. Automation Direct Modbus RS-232 Serial Connection................137
Figure 6-109. T1K-08ND3 Sink/External Power Configuration ..........................138
Figure 6-110 Example of T1K-08ND3 Module Wiring ........................................139
Figure 6-111. T1K-08ND3 Memory Map ............................................................139
Figure 6-112. Example of T1K-08ND3 Read GAP Blocks .................................139
Figure 6-113. T1K-16ND3 Sink/External Power Configuration ..........................140
Figure 6-114 Example of T1K-16ND3 Module Wiring ........................................141
Figure 6-115. T1K-16ND3 Memory Map ............................................................141
Figure 6-116. Example of T1K-16ND3 Read GAP Blocks .................................142
Figure 6-117. Example of T1K-16ND3 Module to Relay Module Wiring............143
Figure 6-118. T1K-16TD1 Module Memory Map................................................143
Figure 6-119. Example of T1K-16TD1 GAP Write Blocks..................................144
Figure 6-120. Example of T1K-08TRS Module Wiring .......................................145
Figure 6-121. T1K-08TRS Module Memory Map ...............................................145
Figure 6-122. Example of T1K-08TRS GAP Write Blocks .................................146
Figure 6-123. Example of T1F-16AD-1 Module Wiring ......................................147
Figure 6-124. T1F-16AD-1 Analog Input Module Memory Map .........................148
Figure 6-125. T1F-16AD-1 Current Input Module Resolution ............................149
Figure 6-126. Example of T1F-16AD-1 GAP CURVE_2D Scaling Blocks.........149
Figure 6-127. Example of T1F-16DA-1 Module Wiring ......................................150
Figure 6-128. T1F-16DA-1 Module Memory Map ..............................................151
Figure 6-129. T1F-16DA-1 Control Byte Table ..................................................152
Figure 6-130. Example of T1F-16DA-1 Control Byte GAP Block.......................152
Figure 6-131. T1F-16DA-1 Current Output Module Resolution .........................153
Figure 6-132. Example of T1F-16DA-1 GAP Analog Write Blocks ....................153
Figure 6-133. Example of T1F-14THM Module Wiring.......................................154
Figure 6-134. T1F-14THM Thermocouple Module Memory Map.......................155
Figure 6-135 for T1F-14THM Jumper configuration Tables...............................156
Figure 6-136 for T1F-14THM Jumper Locations ................................................156
Figure 6-137. Example of T1F-14THM GAP DIVIDE Blocks .............................157
Table 1-1. Profibus—Type A Cable........................................................................3
Table 1-2. Profibus—Type B Cable........................................................................3
Table 1-3. Belden Profibus cable ...........................................................................4
Table 1-4. Profibus—Siemens RS-485 Bus Connector / Plastic............................4
Table 1-5. Profibus—Siemens RS-485 Bus Connector / Metal .............................5
Table 1-6. I/O Connector Pinout.............................................................................5
Table 2-1. Thick Cable Requirements..................................................................16
Table 2-2. Belden DeviceNet cable......................................................................17
Table 3-1. Category 5 Cable Requirements.........................................................34
Table 3-2. Belden Ethernet cable.........................................................................35
Table 3-3. RJ45 10/100 Base-TX Pinout..............................................................36
Table 6-1. Profibus Bit Address Spreadsheet ......................................................53
Table 6-2. Applicom Error Num Table Definition..................................................56
Table 6-3. Example of Boolean Address Order....................................................58
Table 6-4. Modbus Word Address Spreadsheet ..................................................91
Table 6-5. MODBUS_M Exception Errors............................................................93
Table 6-6. Modbus Word Address Spreadsheet ................................................129
Table 6-7. MODBUS_M Exception Errors..........................................................131

Manual 85586V2 AtlasPC Digital Control, Vol. II (Distributed I/O)
Woodward 1
Distributed I/O
The AtlasPC™ control supports industry standard field bus protocols to take
advantage of distributed I/O products from alternate manufacturers. Through
various networking options, expansion of the AtlasPC system is virtually
unlimited. Currently, the AtlasPC control supports:
•PC104 Profibus Interface (Chapter 1)
•PC104 DeviceNet Interface (Chapter 2)
•PC104 Ethernet Interface (Chapter 3)
•Serial (Modbus) Interface (Chapter 4)
•PC104 CanOpen Interface (Chapter 5)
855-744
00-05-30 KDW
Profibus-DP, DeviceNet, Ethernet TCP/IP Modbus, Serial Modbus
Chapter 6 contains examples of Distributed I/O.

AtlasPC Digital Control, Vol. II (Distributed I/O) Manual 85586V2
2 Woodward
Chapter 1.
PC104 Profibus Interface
Introduction
This chapter has been divided into two sections, Hardware for End Users, and
Software for Application Developers. The hardware section is aimed at
customers that are applying the Atlas in a permanent installation. The software
section is for customers that are developing software for the AtlasPC™ control.
Profibus Software and Hardware Requirements
•Atlas with Profibus Module
•Profibus Master Configuration Tool
•Profibus Diagnostic Utilities
•Profibus slave device GSD file(s)
•GAP Programming Tool 3.03 or later
•Profibus Cables and Connectors
•Slave Interface and Modules
•Device Memory Maps and Scaling (Manuals)
•Woodward Interface Tools
Hardware for End Users
Profibus Module
The Profibus hardware module used on the AtlasPC control system is a PC/104
form factor ApplicomIO PC104-DPIO board, equipped with one Profibus port,
capable of handling Profibus-DP (Distributed Peripherals) protocol in both Master
(Class1, Class2) and Slave modes up to 12Mbps. This module operates on the
PC104 bus and has a PC104 pass through connector to allow use with other
PC104 modules depending on the Atlas configuration.
Electrical and Technical Specifications
Processor: Intel 80386EX, 24 MHz
Memory: 4 Mbyte DRAM, 512 K flash memory
Network Speeds Supported: 9600 kbps to 12 Mbps
Interface: RS-485 with 500 Vdc galvanic isolation
Interface Connector: Isolated DB9F I/O connector
Power: 4.0 W max (3.75 W typical)

Manual 85586V2 AtlasPC Digital Control, Vol. II (Distributed I/O)
Woodward 3
Interface Cables and Connectors
The Profibus network is a balanced transmission line corresponding to the
standard EIA RS-485, terminated at both ends. The Profibus standard EN50170
defines two variations of the bus cable for Profibus-FMS and Profibus-DP.
Profibus Type A cable is preferred and recommended for all uses.
•Type A—recommended for high transmission speeds (> 500 kBaud) and
permits doubling of the network distance in comparison to Type B.
•Type B—should only be used at low baud rates and low requirements on
the network distances.
Impedance: 135 up to 165 Ωat a frequency of 3 to 20 MHz
Cable capacitance: < 30 pF/m
Core diameter: > 0.34 mm², corresponds to 22 AWG
Cable type: twisted pair cable. 1x2 or 2x2 or 1x4 lines
Resistance: < 110 Ω/km
Signal attenuation: max. 9 dB over total length of line section
Shielding: CU shielding braid or shielding braid and foil
Table 1-1. Profibus—Type A Cable
Impedance: 135 up to 165 Ωat a frequency of > 100 kHz
Cable capacitance: typ. < 60 pF/m
Core diameter: > 0.22 mm², corresponds to 24 AWG
Cable type: twisted pair cable. 1x2 or 2x2 or 1x4 lines
Signal attenuation: max. 9 dB over total length of line section
Shielding: CU shielding braid or shielding braid and foil
Table 1-2. Profibus—Type B Cable
Recommended Bulk Cable
Cable manufacturer Belden is widely available in North America, and Siemens is
available in Europe. These manufacturers are listed in the table below. Neither
manufacturer has any exclusive rights to Profibus cable, and other suitable
alternatives are available from other manufacturers. Both cables below are rated
as suitable for Profibus cabling and may also be used for drop cabling.
Alternative cables may not use the same color coding on the individual
conductors.
Manufacture
r
Part Numbe
r
Website
Belden 3079A Profibus Cable www.belden.com
Siemens Profibus-DP, STD, 6XV1830-
0EH10
www.ad.siemens.de/simatic

AtlasPC Digital Control, Vol. II (Distributed I/O) Manual 85586V2
4 Woodward
The cable specification below is provided for convenience and is typical for the
Profibus industry.
Belden 3079A Profibus
Cable
Weight: 57 lbs/1,000 ft (~85 kg/1000 m)
Ratings: NEC PLTC CL2 CMG CEC CMG
Conductor: #22 AWG solid high conductivity Cu (~0.3 mm²)
Insulation: Cellular Polyethylene
Tested: 300 MHz
Nom. O.D.: 0.315" (8.00 mm)
Shield: Beldfoil®, 100% coverage
Jacket: Purple or Gray, PVC, optional blue intrinsically safe
Impedance: 150 Ω
V
elocity Of Prop. : 78% (nom.)
Mutual Capacitance: 9.0pF/ft (nom.) (~30 pF/m)
Attenuation: 0.27 dB/100 ft @ 0.2 MHz (~0.89 dB/100 m)
0.67 dB/100 ft @ 4.0 MHz (~2.20 dB/100 m)
1.37 dB/100 ft @ 16.0 MHz (~4.49 dB/100 m)
3.75 dB/100 ft @ 100 MHz (~12.30 dB/100 m)
6.52 dB/100 ft @ 300 MHz (~21.39 dB/100 m)
Standard Lengths: 1000, 2000, and 3600 ft (~305, 610, and 1097 m)
Table 1-3. Belden Profibus cable
Profibus Cable Connectors
The typical Profibus cable connector is a sub-D 9-pin male connector. The
following products are provided for reference.
Recommended Connector
Manufacture
r
Part Numbe
r
Website
Siemens Bus Connector 6ES7 972-0BA11-0XA0 www.ad.siemens.de/simatic
Alternate Connectors
Manufacture
r
Part Numbe
r
Website
ERNI Erbic PROFIBUS Connectors www.erni.com
Siemens Bus Connector 6GK1500-0EA02 www.ad.siemens.de/simatic
Phoenix Contact SUBCON Profibus Connector–2744348 www.phoenixcon.com
Profibus Connector Specifications
The following connectors are typical for Profibus and are provided for reference.
Name: Bus Connecto
r
www.ad.siemens.de/simatic
Mfr:
P/N:
Connector:
Transmission Rate:
Shielding:
Bus Termination:
Cable Ports:
Cable Connection:
Dim (WxHxD):
Siemens
6ES7 972-0BA11-0XA0
DB9M
12 Mbits/sec
Plastic case with internal shld clamp
Terminating resistor slide switch
(2) for daisy chain use, 90°exit
4 Internal screw terminal blocks
15.8 mm x 54 mm x 34 mm
Table 1-4. Profibus—Siemens RS-485 Bus Connector / Plastic

Manual 85586V2 AtlasPC Digital Control, Vol. II (Distributed I/O)
Woodward 5
Name: Bus Connecto
r
www.ad.siemens.de/simatic
Mfr:
P/N:
Connector:
Transmission Rate:
Shielding:
Bus Termination:
Cable Ports:
Cable Connection:
Dim (WxHxD):
Siemens
6GK1500-0EA02
DB9M
12 Mbits/sec
Metal case with internal shld clamp
Terminating resistor slide switch
(2) for daisy chain use
4 Internal screw terminal blocks
15 mm x 57 mm x 39 mm
Table 1-5. Profibus—Siemens RS-485 Bus Connector / Metal
Profibus Connector Pinout
Connecto
r
Signal Mnemonic
DB9F Shielded DB9 female receptacle
1 --
2 --
3 RxD/TxD—P
4 --
5 GND
6 +5 V
7 --
8 RxD/TxD—N
9 --
Shield AC coupled to Earth Ground
Table 1-6. I/O Connector Pinout
Profibus Slave Hardware
The AtlasPC control system can control Profibus slave modules from many
different manufacturers. With the exception of Woodward-manufactured devices,
Woodward makes no expressed or implied statement of suitability of these
devices. It is the user’s responsibility to ensure EMC compliance of their system,
if necessary, by using distributed modules that are CE compliant. The following
Profibus slave hardware has been tested with the AtlasPC control to confirm
functionality.
1) All Woodward devices designed for Profibus

AtlasPC Digital Control, Vol. II (Distributed I/O) Manual 85586V2
6 Woodward
2) Allen-Bradley Flex I/O
Part Numbe
r
Description
3170-PDP I/O Network Interface for Profibus (Slave) (ProSoft Technologies)
1794-IB16 Discrete Input (Sink)
1794-OV16 Discrete Output (Sink)
1794-OW8 Discrete Output (Relay)
1794-IE8/B Analog Input (Current)
1794-OE4/B Analog Output (Current)
1794-IT8 Thermocouple Input
1794-CJC2 Cold Junction
1794-IR8 RTD Input
1794-TB3S Terminal Base
1794-TB3TS Terminal Base
3) Automation Direct Terminator I/O
Part Numbe
r
Description
T1K-01AC Power Supply
T1K-01DC Power Supply
T1H-PBC Profibus Interface
T1K-08ND3 Discrete Input (Sink)
T1K-16ND3 Discrete Input (Sink)
T1K-16TD1 Discrete Output
T1K-08TRS Discrete Output (Relay)
T1F-16AD-1 Analog Input (Current)
T1F-16DA-1 Analog Output (Current)
T1F-14THM Thermocouple Input
T1K-08B-1 Terminal Base
T1K-16B-1 Terminal Base

Manual 85586V2 AtlasPC Digital Control, Vol. II (Distributed I/O)
Woodward 7
Software for Application Developers
It is possible to disrupt an existing Profibus network by attaching an
improperly configured device. To prevent problems on your existing
Profibus network, read this chapter before connecting the AtlasPC
Profibus port to a network.
Many end users will be purchasing pre-programmed AtlasPC units
and will not need the information in this section. The information
below is aimed at programmers using the GAP programming tool
provided by Woodward. The information provided here covers the
basics. For more detail, refer to Woodward software manual 26103,
Woodward NT Real Time Operating System Service and Interface
Tools or software manual 26199, Woodward VxWorks Real Time
Operating System.
The information in this section is intended for customers that create their own
GAP programs for the AtlasPC platform and who are using a Profibus network.
Programmers will need the following:
•ApplicomIO configuration software CD-ROM (supplied with the AtlasPC
control)
•GSD file(s) for slave module(s)
•Device memory maps and scaling (manuals)
•GAP™ Programming Tool 3.03 or later to create the application (This can
be downloaded from our website: www.woodward.com/ic/software)
•For more information on these and additional software tools mentioned in
this chapter, see Woodward software manual 26103 (NT RTOS) or 26199
(VxWorks RTOS).
The AtlasPC control is configured to communicate with a Profibus network by
performing the following steps:
1. Verify that the Atlas contains a Profibus module.
2. Determine slave and I/O modules to be used.
3. Determine order of I/O modules.
4. Obtain GSD file(s).
5. Create Profibus Configuration using the Profibus Configuration Tool.
6. Review the Profibus slave manuals and understand the hardware
addressing.
7. Create GAP application which reads and writes to the Profibus I/O.
8. Transfer Configuration files and GAP application to AtlasPC control.
9. Start GAP application.
Profibus Software Configuration (Configuration)
The Profibus network is configured using a Profibus Configuration Tool provided
on CD-ROM with the AtlasPC control (ApplicomIO 2.1 Console). This tool
supports defining the AtlasPC Profibus board as a master or slave device. For
master operation, the slave devices are defined and configured by importing their
GSD files and assigning network addresses. Once the Profibus I/O configuration
is completed, it must be downloaded to the AtlasPC control and stored with the
GAP application.

AtlasPC Digital Control, Vol. II (Distributed I/O) Manual 85586V2
8 Woodward
The Profibus master interface card in the AtlasPC control is manufactured by
Applicom International. All Applicom cards used in AtlasPC systems share IRQ 5.
Even though they can use other IRQ settings, it is necessary that they share IRQ
5 for proper operation and to prevent conflict with other devices in the AtlasPC
system. All IRQs are factory set and must not be changed by the end user.
All Applicom cards used in AtlasPC systems must use the same Base Address of
D4000 when configured in the ApplicomIO Console software. The following
example will show how to use the Applicom configuration tool.
a. Run ApplicomIO 2.1 Console.
b. Under File, select Configuration Manager. Select New if a new
configuration is desired, or select an existing configuration listed. In
this example, the configuration was named Config01. Application will
close and require a restart when a new configuration is selected.
c. Under Board Configuration, select Add Board.
d. Under Add New Board, select Diagnostic and Manual Configuration.

Manual 85586V2 AtlasPC Digital Control, Vol. II (Distributed I/O)
Woodward 9
e. Select DPRAM Base Address D4000, Interrupt Vector IRQ 5, and
PC104/ISA PC104_DPIO.
f. Select OK.

AtlasPC Digital Control, Vol. II (Distributed I/O) Manual 85586V2
10 Woodward
g. Under Protocol, select Properties.
h. Select 12 Mbit in Baud Rate.
i. Select OK.
Before a slave head (Network Interface Module) can be selected, the associated
GSD file must be in the equipment library. If the GSD file doesn’t already exist in
the library, it must be downloaded and saved within the Applicom setup files
(C:\Program Files\ApplicomIO\2.1\Equipment Library\Profibus_gsd). In this
example, the ProSoft 3170-PDP GSD file (psft0882.gsd) is imported using
library, Add.
j. Select the 3170-PDP head under ProSoft Technology Inc. and drag to
the window on the right. This will open a 3170-PDP setup window.

Manual 85586V2 AtlasPC Digital Control, Vol. II (Distributed I/O)
Woodward 11
k. In this example the Station number is selected as 001. (This is what is
referred to as the node number.)
l. Select the Modules Configuration Tab.

AtlasPC Digital Control, Vol. II (Distributed I/O) Manual 85586V2
12 Woodward
m. Build the module configuration by dragging the desired modules from
the Available Module(s) window to the Configured Module(s) window.
n. Select OK when done.
o. This completes the Applicom setup.
Once created, the Profibus configuration files can be found on the
programming station under c:\program
files\applicomIO\2.1\configIO\config_name.

Manual 85586V2 AtlasPC Digital Control, Vol. II (Distributed I/O)
Woodward 13
p. Save the configuration and copy all files from the ConfigIO directory to
the AtlasPC control using AppManager. (C:/Woodward/Applications
directory)
Profibus Software Configuration (GAP)
After creating the Profibus I/O configuration, the GAP application must be
programmed to match. The steps necessary to program the Profibus module in
GAP are as follows:
a. Select FB_MODULE for slot 6 in the GAP application. All FieldBus
modules use the same Parent Block.
b. Select a FB_EQUIP Block for every node in the Network and list it in
the FB_MODULE Parent Block. Every FB_EQUIP block must have its
EQUIP_NO set to the Station number of its respective node.
For examples of a complete GAP setups for Profibus, see the
Distributed I/O Examples later in this chapter.

AtlasPC Digital Control, Vol. II (Distributed I/O) Manual 85586V2
14 Woodward
c. Once completed, the GAP application must be compiled and
downloaded to the AtlasPC control using AppManager.
d. Once the GAP application is started on the AtlasPC control’s PC, the
Profibus module will automatically initialize and start the Profibus
Network. All nodes will be updated from the Applicom module in a
circular queue fashion, once every scan rate. The GAP application will
update its values once every rate group (defined in FB_MODULE).
The timing of the Applicom scan rate will depend on the number of
groups (heads) and the number of nodes (I/O modules) in the
network and will be independent of the rate group structure.
