Woodward 8200-225 User manual

Product Manual 26236
(Revision W, 4/2020)
Original Instructions
SPC
Servo Position Controller
Installation and Operation Manual
Released

General
Precautions
Read this
entire manual and all other publications pertaining to the work to be
performed before installing, operating, or servicing this equipment.
Practice all plant and safety instructions and precautions.
Failure to follow instructions can cause personal injury and/or property damage.
Revisions
This publication may have been revised or updated since this copy was produced.
To verify that you have the latest revision, check manual 26455 , Customer
Publication Cross Reference and Revision Status & Distribution Restrictions, on
the publications page of the Woodward website:
www.woodward.com/publications
The latest version of most publications is available on the publications page. If
your publication is not there, please contact your customer service representative
to get the latest copy.
Proper Use
Any unauthorized modifications to or use of this equipment outside its specified
mechanical, electrical, or other operating limits may cause personal injury and/or
property damage, including damage to the equipment. Any such unauthorized
modifications: (i) constitute "misuse" and/or "negligence" within the meaning of
the product warranty thereby excluding warranty coverage for any resulting
damage, and (ii) invalidate product certifications or listings.
Translated
Publications
If the cover of this publication states "Translation of the Original Instructions"
please note:
The original source of this publication may have been updated since this
translation was made. Be sure to check manual 26455 , Customer Publication
Cross Reference and Revision Status & Distribution Restrictions, to verify whether
this translation is up to date. Out-of-date translations are marked with . Always
compare with the original for technical specifications and for proper and safe
installation and operation procedures.
Revisions— A bold, black line alongside the text identifies changes in this publication since the
last revision.
Woodward reserves the right to update any portion of this publication at any time. Information provided by Woodward is
believed to be correct and reliable. However, no responsibility is assumed by Woodward unless otherwise expressly
undertaken.
Manual 26236
Copyright © Woodward, Inc. 2001 - 2020
All Rights Reserved
Released

Manual 26236 SPC Servo Position Controller
Woodward 1
Contents
W ARNINGS AND N OTICES ..............................................................................................................4
E LECTROSTATIC D ISCHARGE A WARENESS ....................................................................................5
R EGULATORY C OMPLIANCE ..........................................................................................................6
C HAPTER 1. G ENERAL I NFORMATION .............................................................................................8
C HAPTER 2. I NSTALLATION ...........................................................................................................9
Power Requirements.....................................................................................................................................9
Location Considerations................................................................................................................................9
Optional SPC Mounting Kit ...........................................................................................................................9
Shields and Grounding................................................................................................................................10
Terminal Block Connections .......................................................................................................................13
C HAPTER 3. SPC S PECIFICATIONS ..............................................................................................25
Diagnostics..................................................................................................................................................27
C HAPTER 4. SPC U SER ’ S G UIDE .................................................................................................28
Introduction..................................................................................................................................................28
Operating Modes.........................................................................................................................................28
Using the SPC Service Tool........................................................................................................................28
Loading the Configuration File to the SPC..................................................................................................36
SPC Calibration...........................................................................................................................................63
Working with a Running SPC......................................................................................................................69
Quick Reference—Alarms & Shutdowns ....................................................................................................80
C HAPTER 5. P RODUCT S UPPORT AND S ERVICE O PTIONS .............................................................85
Product Support Options.............................................................................................................................85
Product Service Options .............................................................................................................................85
Returning Equipment for Repair .................................................................................................................86
Replacement Parts......................................................................................................................................87
Engineering Services..................................................................................................................................87
Contacting Woodward’s Support Organization...........................................................................................87
Technical Assistance ..................................................................................................................................88
A PPENDIX A. DRFD TO SPC C ROSS R EFERENCE ........................................................................89
A PPENDIX B. SPC D EVICE N ET A DDRESS I NFORMATION ...............................................................91
A PPENDIX C. SPC D RIVER WITH P OLLUTION R ESISTANCE ............................................................93
A PPENDIX D. CAN OPEN C OMMUNICATION ...................................................................................94
Introduction..................................................................................................................................................94
Network Architecture...................................................................................................................................94
NMT Master Functions................................................................................................................................94
R EVISION H ISTORY ...................................................................................................................109
D ECLARATIONS ........................................................................................................................110
The following are trademarks of Woodward, Inc.:
GAP
Woodward
The following are trademarks of their respective companies:
DeviceNet (Open DeviceNet Vendor Association, Inc. [ODVA])
Windows (Microsoft Corporation)
Released

Manual 26236 SPC Servo Position Controller
Woodward 2
Illustrations and Tables
Figure 1-1. SPC Connections .......................................................................................................................8
Figure 2-1. Optional SPC Mounting Bracket...............................................................................................10
Figure 2-2. SPC DiviceNet Outline Drawing ...............................................................................................11
Figure 2-3. SPC CANopen Outline Drawing...............................................................................................12
Figure 2-4. Status Relay Driver Output Wiring............................................................................................14
Figure 2-5a. SPC Wiring Diagram ..............................................................................................................17
Figure 2-5b. SPC Wiring Diagram ..............................................................................................................18
Figure 2-5c. SPC Wiring Diagram...............................................................................................................19
Figure 2-5d. SPC Wiring Diagram ..............................................................................................................20
Figure 2-5e. SPC Wiring Diagram ..............................................................................................................21
Figure 2-5f. SPC Wiring Diagram ...............................................................................................................22
Figure 2-5g. SPC Wiring Diagram ..............................................................................................................23
Figure 2-5h. SPC Wiring Diagram ..............................................................................................................24
Figure 4-1. Selecting Communication Port .................................................................................................30
Figure 4-2. Connecting to the SPC.............................................................................................................31
Figure 4-3. Service Tool Status Bar............................................................................................................31
Figure 4-4. Selecting Configuration Options...............................................................................................33
Figure 4-5. Determining Service Interface Version.....................................................................................33
Figure 4-6. Selecting Service Interface Version..........................................................................................34
Figure 4-7. Configuration Editing Tabs .......................................................................................................35
Figure 4-8. Saving the Configuration File ...................................................................................................35
Figure 4-9. Loading Configuration File to the Control.................................................................................36
Figure 4-10. Identifying the Configuration File in the Control .....................................................................36
Figure 4-11. Selecting Type of Control .......................................................................................................37
Figure 4-12. Proportional-Control Configuration Settings...........................................................................39
Figure 4-13. Proportional Control Structure................................................................................................40
Figure 4-14. P-Control Configuration Settings............................................................................................41
Figure 4-15. P Control Structure.................................................................................................................42
Figure 4-16. PI-Control Configuration Settings...........................................................................................43
Figure 4-17. PI Control Structure................................................................................................................44
Figure 4-18. PI with Lag-Control Configuration Settings ............................................................................45
Figure 4-19. PI w/Lag Control Structure .....................................................................................................47
Figure 4-20. PI with Lead-Lag Control Configuration Settings ...................................................................48
Figure 4-21. PI w/Lead-Lag Structure.........................................................................................................49
Figure 4-22. Position Demand DiviceNet or CANopen Only ......................................................................51
Figure 4-23. Position Demand DiviceNet or CANopen Primary .................................................................52
Figure 4-24. Position Demand Analog Only................................................................................................53
Figure 4-25. Position Demand Analog Primary...........................................................................................54
Figure 4-26. Position Feedback Configuration............................................................................................56
Figure 4-27. 3-wire Device..........................................................................................................................57
Figure 4-28. 4-wire Device..........................................................................................................................57
Figure 4-29. 5-wire Device..........................................................................................................................58
Figure 4-30. 6-wire Device..........................................................................................................................58
Figure 4-31. Position Error Settings............................................................................................................60
Figure 4-32. Driver Configuration................................................................................................................61
Figure 4-33. DeviceNet Configuration.........................................................................................................62
Figure 4-33a. CANopen Configuration........................................................................................................63
Figure 4-34. Introduction.............................................................................................................................64
Figure 4-35. Minimum Position Adjustment................................................................................................65
Figure 4-36. Maximum Position Adjustment...............................................................................................66
Figure 4-37. Calibration Verification............................................................................................................67
Figure 4-38. Saving the Calibration Settings ..............................................................................................68
Figure 4-39. Selecting “Run”.......................................................................................................................68
Figure 4-40. SPC Service Tool Overview Tab............................................................................................70
Figure 4-41. Calibration will be performed through DeviceNet or CANopen..............................................71
Figure 4-42. Alarm Structure.......................................................................................................................72
Released

Manual 26236 SPC Servo Position Controller
Woodward 3
Figure 4-43. Alarms.....................................................................................................................................73
Figure 4-44. Driver Fault Error Shutdown...................................................................................................74
Figure 4-45. Dynamic Settings....................................................................................................................75
Figure 4-46. Position Error Alarms..............................................................................................................76
Figure 4-47. Driver Fault Error Alarms........................................................................................................77
Figure 4-48. SPC Service Tool Identification Tab.......................................................................................78
Figure 4-49. Selecting Manual Stroking......................................................................................................78
Figure 4-50. SPC Service Tool Manual Stroking........................................................................................79
Figure D-1. Network Architecture................................................................................................................94
Figure D-2. NMT Block Diagram.................................................................................................................94
Figure D-3. CANopen Slave State Diagram ...............................................................................................95
Figure D-4. Process Timing Diagram..........................................................................................................96
Figure D-5 SDO Process Timing Diagram..................................................................................................97
Figure D-6 Fast Message Process Timing Diagram...................................................................................98
Figure D-7 Slow Message Process Timing Diagram..................................................................................99
Figure D-8 Frame Time Diagram..............................................................................................................101
Table 2-1. Recommended Maximum Cable Lengths and Number of Units ...............................................15
Table 2-2. CANopen Terminal Wiring.........................................................................................................16
Table 3-1. System Accuracy.......................................................................................................................25
Table 4-1. Network Status LED ..................................................................................................................29
Table 4-2. Module Status LED....................................................................................................................29
Table A-1. DRFD to SPC Cross Reference................................................................................................89
Table D-1. Transmit PDO Summary.........................................................................................................101
Table D-2. Receive PDO Summary..........................................................................................................102
Released

Manual 26236 SPC Servo Position Controller
Woodward 4
Warnings and Notices
Important Definitions
This is the safety alert symbol used to alert you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid possible injury or death.
•DANGER - Indicates a hazardous situation, which if not avoided, will result in death or serious injury.
•WARNING - Indicates a hazardous situation, which if not avoided, could result in death or serious
injury.
•CAUTION - Indicates a hazardous situation, which if not avoided, could result in minor or moderate
injury.
•NOTICE - Indicates a hazard that could result in property damage only (including damage to the
control).
•IMPORTANT - Designates an operating tip or maintenance suggestion.
•IMPORTANT - Designates an operating tip or maintenance suggestion.
Overspeed /
Overtemperature /
Overpressure
The engine, turbine, or other type of prime mover should be
equipped with an overspeed shutdown device to protect against
runaway or damage to the prime mover with possible personal injury,
loss of life, or property damage.
The overspeed shutdown device must be totally independent of the
prime mover control system. An overtemperature or overpressure
shutdown device may also be needed for safety, as appropriate.
Personal Protective
Equipment
The products described in this publication may present risks that
could lead to personal injury, loss of life, or property damage.
Always wear the appropriate personal protective equipment (PPE) for
the job at hand. Equipment that should be considered includes but is
not limited to:
•Eye Protection
•Hearing Protection
•Hard Hat
•Gloves
•Safety Boots
•Respirator
Always read the proper Material Safety Data Sheet (MSDS) for any
working fluid(s) and comply with recommended safety equipment.
Lockout/Tagout
Ensure that personnel are fully trained on LOTO procedures prior to
attempting to replace or service the SPC on a “live” running Turbine.
All safety protective systems (overspeed, over temperature,
overpressure, etc.) must be in proper operational condition prior to
the start or operation of a running Turbine. Personnel should be
equipped with appropriate personal protective equipment to
minimize the potential for injury due to release of hot gases or fluids,
exposure to hot surfaces, hazardous voltage, and/or moving parts, or
any moving parts that may be activated and are located in the area of
control of the SPC.
Released

Manual 26236 SPC Servo Position Controller
Woodward 5
Start-up
Be prepared to make an emergency shutdown when starting the
engine, turbine, or other type of prime mover, to protect against
runaway or overspeed with possible personal injury, loss of life, or
property damage.
Electrostatic Discharge Awareness
Electrostatic
Precautions
Electronic controls contain static
-
sensitive parts. Observe the
following precautions to prevent damage to these parts:
•Discharge body static before handling the control (with power to
the control turned off, contact a grounded surface and maintain
contact while handling the control).
•Avoid all plastic, vinyl, and Styrofoam (except antistatic
versions) around printed circuit boards.
•Do not touch the components or conductors on a printed circuit
board with your hands or with conductive devices.
To prevent damage to electronic components caused by improper
handling, read and observe the precautions in Woodward manual
82715 , Guide for Handling and Protection of Electronic Controls,
Printed Circuit Boards, and Modules.
Follow these precautions when working with or near the control.
1. Avoid the build-up of static electricity on your body by not wearing clothing made of synthetic
materials. Wear cotton or cotton-blend materials as much as possible because these do not store
static electric charges as much as synthetics.
2. Do not remove the printed circuit board (PCB) from the control cabinet unless absolutely necessary.
If you must remove the PCB from the control cabinet, follow these precautions:
•Do not touch any part of the PCB except the edges.
•Do not touch the electrical conductors, the connectors, or the components with conductive
devices or with your hands.
•When replacing a PCB, keep the new PCB in the plastic antistatic protective bag it comes in
until you are ready to install it. Immediately after removing the old PCB from the control cabinet,
place it in the antistatic protective bag.
External wiring
connections for reverse
-
acting controls are identical
to those for direct-acting controls.
Released

Manual 26236 SPC Servo Position Controller
Woodward 6
Regulatory Compliance
European Compliance for CE Marking:
EMC Directive:
Declared to Directive 2014/30/EU of the European Parliament and the
Council of 26 February 2014 on the harmonization of the laws of the
Member States relating to electromagnetic compatibility (EMC)
ATEX Explosive
Atmospheres Directive:
Directive 2014/34/EU on the harmonization of the laws of the Member
States relating to equipment and protective systems intended for use in
potentially explosive atmospheres
Zone 2, Category 3, Group IIC Ex nA IIC T4 Gc X IP20
North American Compliance:
CSA:
CSA Certified for Class I, Division 2, Groups A, B, C, & D, T4 at 70 °C
Ambient for use in Canada and the United States.
Certificate 1250622
This product is certified as a component to be used within a suitable
enclosure. The final assembly is subject to acceptance by CSA
International or the authority having jurisdiction.
Marine:
Models 8200-225 & 8200-226 American Bureau of Shipping, Steel Vessel
Rules 4-9-7/13, 1-1-4/3.7, 2003
Det Norske Veritas, Rules for Classification of Ships, High Speed and
Light Craft and Mobile Offshore Units
Lloyd’s Register for ENV1, ENV2, and ENV3 as specified in Test
Specification No.1, 1996
This equipment is considered indicator equipment and is not to be
used as metrology equipment. All measurements need to be verified
using calibrated equipment.
General Installation and Operation Notes and Requirements:
•The Servo Position Controller is suitable for use in Class I, Division 2, Groups A, B, C, and D per
CSA for Canada and US or non-hazardous locations only.
•Wiring must be in accordance with North American Class I, Division 2 or European Zone 2 wiring
methods as applicable, and in accordance with the authority having jurisdiction.
•Per EN 60079-15:2010: Device meets ATEX Zone 2 requirements when installed in an ATEX
compliant IP54 or better enclosure.
•The SPC chassis must be connected to PE Ground (Potential Earth) using the ground lug. The wire
used for the PE Ground must be the same size used for the input wire.
Models 8200-225 and 8200-226 are suitable for marine applications per:
•American Bureau of Shipping, Steel Vessel Rules 4-9-7/13, 1-1-4/3.7, 2003
•Det Norske Veritas, Rules for Classification of Ships, High Speed and Light Craft and Mobile
Offshore Units
•Lloyd’s Register for ENV1, ENV2, and ENV3 as specified in Test Specification No.1, 1996.
Released

Manual 26236 SPC Servo Position Controller
Woodward 7
EXPLOSION HAZARD
—
Do not remove covers or connect/disconne
ct
electrical connectors unless power has been switched off or the area
is known to be non-hazardous.
Substitution of components may impair suitability for Class I,
Division 2 or Zone 2.
RISQUE D’EXPLOSION
—
Ne pas enlever les couvercles, ni
raccorder / débrancher les prises électriques, sans vous en
assurez auparavant que le système a bien été mis hors
tension; ou que vous vous situez bien dans une zone non
explosive.
La substitution de composants peut rendre ce matériel
inacceptable pour les emplacements de Classe I, Division 2
ou Zone 2.
Released

Manual 26236 SPC Servo Position Controller
Woodward 8
Chapter 1.
General Information
The SPC (Servo Position Controller) is available in two model configurations:
8200-226: DeviceNet Control with Analog Backup (or Analog primary demand)
8200-227: CANopen Control with Analog Backup (or Analog primary demand)
Models 8200-224 & 8200-225 are inactive and replaced by above item numbers.
The SPC positions a hydraulic or pneumatic actuator based on a position demand signal received from a
control. The SPC positions a single-coil actuator using single or dual position feedback devices. The
position demand signal can be sent to the SPC via DiviceNet or CANopen, (4 to 20) mA, or both. A
software program running on a Personal Computer (PC) allows the user to easily configure and calibrate
the SPC.
Figure 1-1. SPC Connections
The SPC Service Tool is used to configure, calibrate, adjust, monitor, and troubleshoot an SPC. The
service tool runs on a PC and communicates with the SPC through a serial connection. The serial port
connector is a 9-pin sub-D socket and uses a straight-through cable to connect to the PC. Woodward
offers a USB to 9-pin Serial Adapter kit if needed for new computers that do not have a 9-pin serial
connector (P/N 8928-463). This kit contains a USB adapter, software, and a 1.8 m (6 feet) serial cable.
(See Chapter 4 for SPC Service Tool installation instructions.)
The SPC is configured by using the SPC Service Tool's configuration file editor to create a file that is then
loaded into the SPC. The SPC Service Tool can also read an existing configuration from an SPC into the
configuration file editor.
See Chapter 4, SPC User’s Guide, for detailed instructions on using the SPC Service Tool.
The first time an SPC is connected to an actuator, it must be calibrated to the actuator's position feedback
transducer. The user is guided through the calibration process by the service tool. Calibration can also be
performed by the control via the Digital Control link (DiviceNet or CANopen). The calibration procedure
can be found in the GAP help file.
Control SPC Actuator
Laptop computer
Power
Released

Manual 26236 SPC Servo Position Controller
Woodward 9
Chapter 2.
Installation
Power Requirements
The SPC requires a voltage source of (18 to 32) V (dc), with a current capacity of 1.1 A max. If a battery
is used for operating power, a battery charger is necessary to maintain a stable supply voltage. The
power line should be protected with a 5 A, 125 V fuse capable of withstanding a 20 A, 100 ms in-rush
when power is applied.
The SPC is not equipped with input power switches. For this reason,
some means of switching input power must be provided for
installation and servicing.
To prevent damage to the control, make sure that the alternator or
other battery-charging device is turned off or disconnected before
disconnecting the battery from the control.
Location Considerations
Consider these requirements when selecting a mounting location for the SPC:
•Adequate ventilation for cooling
•Space for servicing and repair
•Protection from direct exposure to water
•Protection from high-voltage or high-current devices, or devices which produce electromagnetic
interference
•Avoidance of vibration
•Selection of a location that will provide an operating temperature range of
(–40 to +70) °C / (–40 to +158) °F
This product is intended for installation in an enclose
d industrial
control cabinet. In order to meet the requirements for Zone 2
Hazardous Location, the SPC must be mounted in an enclosure with
ingress protection of IP54 or greater.
Optional SPC Mounting Kit
Optionally, SPC mounting bracket kit #8928-7334 is available for use in reducing required panel mounting
space within a cabinet. Ideal for applications where multiple SPCs are utilized, this bracket allows SPCs
to be mounted such that they protrude vertically into the cabinet, reducing the required panel mounting
area. This bracket’s design allows users to first attach the SPC to the bracket, then install the entire
assembly onto a cabinet side panel. Please refer to
Figure 2-1.
Released

Manual 26236 SPC Servo Position Controller
Woodward 10
Figure 2-1. Optional SPC Mounting Bracket
Shields and Grounding
A shield termination is provided at the terminal block for each of the signals. All of these inputs should be
wired using shielded, twisted-pair wiring. The exposed wire length beyond the shield should be limited to
one 25 mm (1 inch). The shield should be terminated at only one end in order to avoid creating a ground
loop.
Mounting Bracket
(8928-7334)
New SPC
Old SPCs with
no mounting
bracket
Released

Manual 26236 SPC Servo Position Controller
Woodward 11
Figure 2-2. SPC DiviceNet Outline Drawing
Released

Manual 26236 SPC Servo Position Controller
Woodward 12
Figure 2-3. SPC CANopen Outline Drawing
Released

Manual 26236 SPC Servo Position Controller
Woodward 13
The SPC chassis must be connected to
PE Ground (Potential Earth)
using the grounding lug. The wire used for PE ground must be the
same size used for the input wires.
The SPC must be attached to protective earth by a ground strap or
otherwise, and all cables shielded to ensure electromagnetic
immunity integrity.
For best noise immunity, power cables should be run in separate
cable trays or conduits from the low-level I/O cables.
Terminal Block Connections
All inputs and outputs are made through spring-actuated terminal blocks. The spring clamp can be
actuated using the plastic lever included or by a standard 2.5 mm or 3/32 inch flat-bladed screwdriver.
The terminal blocks accept wires from (0.08 to 4) mm² / (26 to 12) AWG. The recommended strip length is
8 mm (0.3 inch).
Do not tin (sol
der) the wires that terminate at the terminal blocks. The
spring-loaded terminal blocks are designed to flatten stranded wire,
and if those strands are tinned together, the connection loses
surface area and is degraded.
See Figure 2-4 for the wiring diagram.
Actuator Driver Output
Connect shielded twisted-pair cable from actuator to ACT DRIVER+(1) and ACT DRIVER–(2). Connect
the cable shield to SHIELD (3) but do not connect the shield at the actuator end. The Actuator Driver
output is software configurable for ±10 mA, ±25 mA, ±50 mA, ±100 mA and ±250 mA ranges.
DC Transducer Input
If a (4 to 20) mA position transducer is used for feedback, connect shielded twisted-pair cable from
transducer to DC XDCR IN+(4) and DC XDCR IN-(5). Connect the cable shield to SHIELD(6) but do not
connect the shield at the transducer end.
Transducer Exciter/Transducer Power Output
If an AC transducer is used for feedback, this output is used as an exciter for the LVDT or RVDT.
Connect a shielded twisted-pair cable from the transducer excitation winding to XDCR EXC/PWR+(7) and
XDCR EXC/PWR-(8). Connect the cable shield to SHIELD (9) but do not connect the shield at the
transducer end.
If a DC transducer is used for feedback, this output is used to supply 18 V (dc) (120 mA max) for the
transducer power. Connect a shielded twisted-pair cable from the transducer power input to XDCR
EXC/PWR+(7) and XDCR EXC/PWR-(8). Connect the cable shield to SHIELD (9) but do not connect the
shield at the transducer end.
LVDT/RVDT Inputs
If an AC transducer is used for feedback, connect a shielded twisted-pair cable from each LVDT or RVDT
secondary to LVDT/RVDT 1A (13 & 14) and LVDT/RVDT 1B (16 & 17). Connect the shields to SHIELD
(15 &18).
If a redundant AC transducer is used, connect a shielded twisted-pair cable from each LVDT or RVDT
secondary to LVDT/RVDT 2A (19 & 20) and LVDT/RVDT 2B (22 & 23). Connect the shields to SHIELD
(21 & 24).
Released

Manual 26236 SPC Servo Position Controller
Woodward 14
This input is also
used for dc voltage position transducers.
Reset Contact Input
Connect a shielded twisted-pair cable from a control switch to RESET IN+(25) and RESET IN–(26).
Connect the cable shield to SHIELD (27) but do not connect the shield at the switch end. During normal
operation, the switch is open. Momentarily closing the switch will cause the SPC to reset any alarms or
shutdowns.
Shutdown Contact Input
Connect a shielded twisted-pair cable from a control switch to SHUTDN IN+(28) and SHUTDN IN–(29).
Connect the cable shield to SHIELD (30) but do not connect the shield at the switch end. During normal
operation, the switch is closed. Opening the switch will cause the SPC to disable the Actuator Driver
Output.
Alarm Status Relay Driver Output
Connect a shielded twisted-pair cable from a status relay to ALARM OUT +(31) and ALARM OUT–(32).
Connect the cable shield to SHIELD (33) but do not connect the shield at the relay end. The relay driver is
energized under normal operation and is de-energized during an alarm condition.
Shutdown Status Relay Driver Output
Connect a shielded twisted-pair cable from a status relay to SHUTDN OUT+(34) and SHUTDN OUT–
(35). Connect the cable shield to SHIELD (36) but do not connect the shield at the relay end. The relay
driver is energized under normal operation and is de-energized during a shutdown condition.
The Alarm and Shutdown Status Relay Driver Outputs are
unpowered. External power must be connected in series with the
output and the load. See Figure 2-3.
Figure 2-4. Status Relay Driver Output Wiring
Position Demand Input
Connect a shielded twisted-pair cable from the system controller (4 to 20) mA output to DEMAND IN+(37)
and DEMAND IN–(38). Connect the cable shield to SHIELD (39) unless it is grounded at the system
controller. The mA-to-position scaling is configurable using the SPC Service Tool.
Position Monitor Output
Connect a shielded twisted-pair cable from a (4 to 20) mA meter readout to MONITOR OUT+(40) and
MONITOR OUT–(41). Connect the cable shield to SHIELD (42) unless it is grounded at the meter
readout. A 4 mA signal occurs when the actuator is positioned at 0 %, and a 20 mA signal occurs when
the actuator is positioned at 100 %.
Status
Output
+V
(Preferred)
Status
Output
+V
Released

Manual 26236 SPC Servo Position Controller
Woodward 15
Redundant SPC Interface
These terminals are reserved for a possible future feature and must be left unconnected.
DeviceNet Interface (8200-226 Model)
The SPC can be alternatively controlled via a network interface. The standard DeviceNet 5-pin plug-in
connector allows connection to a DeviceNet network. Red/green indicators are provided to indicate the
module and network status. The SPC conforms to DeviceNet Specification Release 2.0 as a Group II only
slave. This product has been self-tested by Woodward and found to comply with ODVA Protocol
Conformance Test Version 16.
The DeviceNet baud rate and MAC address can be configured using the “DeviceNet” tab under the
Configuration File Editor in the Service Tool.
SPC DeviceNet Electronic Data Sheets (EDS) for selected Woodward products that conform to Group II
on DeviceNet Specification Release 2.0 can be downloaded from the Woodward website. From
www.woodward.com/software, select DeviceNet Electronic Data Sheets (EDS).
The different values are either 4 or 2 bytes long. The entire value must be gathered before the application
can be updated. After each index is received, the index sent must be increased by one with looping back
to zero when the max is reached.
See Appendix B for specific signal addresses.
CANopen Interface (8200-227 Model)
The SPC can be alternatively controlled via a network interface. The standard CANopen 5-pin plug-in
connector allows connection to a CANopen network. Red/green indicators are provided to indicate the
module and network status.
The CANopen baud rate and Node Id can be configured using the “CANopen” tab under the
Configuration File Editor in the Service Tool. The possible options are:
• 125kbps
• 250kbps
• 500kbps
Per CiA DS-102 Standard, the following are the recommended maximum cable lengths. Differences in the
baud rate and the cable length affect the number of units that can be put onto a network.
Table 2-1. Recommended Maximum Cable Lengths and Number of Units
Baud Rate
Cable Length
Number of SPC on link
500kbps 100m 10
250kbps 250m 5
125kbps 500m 2
The use of controlled impedance (120 ohm) cable is recommended
for proper CAN bus operation. See ISO 11898 series standards for
further information.
See Appendix D for specific signal addresses.
Released

Manual 26236 SPC Servo Position Controller
Woodward 16
Table 2-2. CANopen Terminal Wiring
Signal
Terminal
Description
V- (COM) 49 Common
CAN_L 50 Signal Low
SHIELD 51 Shield
CAN_H 52 Signal High
V+ (PWR) 53 Power Supply (Not Used in SPC)
Power Input
Connect an (18 to 32) V (dc) power source to POWER INPUT+(54) and POWER INPUT–(55).
RS-232 Port
The serial port connector (9-pin Sub-D socket) is used for connecting to a PC via an extension cable
(straight through). The wiring must meet the requirements of EIA RS-232. This standard requires a
maximum cable length of 16 m (50 feet) with a total capacitance of less than 2500 pF.
Released

Manual 26236 SPC Servo Position Controller
Woodward 17
Figure 2-5a. SPC Wiring Diagram
Released

Manual 26236 SPC Servo Position Controller
Woodward 18
Figure 2-5b. SPC Wiring Diagram
