Workhorse LG05SSG2 Parts list manual

— 5 GALLON SPOT SPRAYER —
MODEL # LG05SSG2
•5 Gallon Polyethylene Tank
•1.0 GPM Demand Pump
•Lever Handgun
•Rechargeable 12V Battery
•AC Charger w/built in Storage
Compartment
•Telescoping Handle
•Large 8 Inch Wheels
Assembly / Operation Instructions / Parts
LG05SSG2
5 gal. 12V
Rechargeable
Sprayer
WORKHORSE
WORKHORSE
S P RA Y ER S
by PSE®, a Division of Green Leaf, Inc®a Division of Green Leaf, Inc®
WORKHORSE SPRAYERS®, a division of Green Leaf, Inc. 9490 N BALDWIN STFONTANET, IN 47851 www.workhorsesprayers.com 888-433-6631

— GENERAL INFORMATION
— WARRANTY / PARTS / SERVICE
— ASSEMBLY
— BATTERY CHARGING
— AFTER SPRAYING
— WINTER STORAGE
After use fill the sprayer part way with water. Start the sprayer
and allow clear water to be pumped through the plumbing
system and out through the spray wand. Refill the tank about
half full with plain water and use a chemical neutralizer such
as Nutra-Sol® or equivalent and repeat cleaning instructions.
Flush the entire sprayer with the neutralizing agent. Follow the
chemical manufacturer’s disposal instructions of all wash or
rinsing water.
Drain all water and chemical out of sprayer, paying special
attention to pump and valves. These items are especially
prone to damage from chemicals and freezing weather. The
sprayer should be winterized before storage by pumping
a solution of RV antifreeze through the entire plumbing.
Untreated fluid retained in wand will freeze and cause
permanent damage to the wand.
FREEZE DAMAGE IS NOT COVERED BY
PRODUCT WARRANTY
Proper care and maintenance will prolong the life of the
sprayer.
— TROUBLE SHOOTING
Pump will not run:
1. Insure the battery is fully charged
2. Insure that battery is plugged into pump
3. Check that the on/off switch is in the on position
4. Insure that strainer located on bottom of tank is free of debris.
5. Insure there are NO kinks in the inlet/outlet hoses.
This unit comes fully assembled
— OPERATION
This sprayer is designed to be pulled or pushed by hand.
Pour solution into the tank and stir to mix. For liquid chemicals
it is possible to mix by spraying the handgun into the tank.
Turn the switch on pump to the “ON” position and spray by
squeezing the lever on the handgun. The unit is supplied
with a demand pump that will only operate while the lever
on the handgun is depressed.
It is recommended to charge the battery for 8-10 hours before
using, or if the battery has been stored for 6 or more months
without usage. Once fully charged you should be able to
spray 30 gallons of fluid, or 6consecutive tanks.
To charge the battery…
1. Plug the charger into a 110 Volt AC electrical receptacle.
2. Unplug battery from pump.
3. Plug charger into lead from battery
4. Unplug charger and insert plug into pump to use sprayer
CAUTION: Never leave the charger connected to the battery
for more the 20 hours, as this may damage the battery.
The purpose of this manual is to assist you in assembling,
operating and maintaining your sprayer. Please read it carefully
as it furnishes information which will help you achieve years of
dependable trouble-free operation.
Workhorse products are warranted for one year from the date
of purchase against manufacture or workmanship defects for
personal or homeowner usage with proof of purchase. Work-
horse products are warranted for 90 days for commercial users.
Any unauthorized modification of a Workhorse brand sprayer
will void warranty.
Your authorized dealer or www.workhorsesprayers.com are the
best sourcesof replacement parts and service. To obtain
prompt, efficient service, always remember to give the following
information:
1. Correct part description and part number.
2. Model number of your sprayer.
Part description and part numbers can be obtained from the
illustrated parts list section of this manual.
Whenever you need parts or repair service, contact your
distributor / dealer first. For warranty work always take your
original sales slip, or other evidence of purchase date, to your
distributor / dealer.
Operation Precautions
1. Do not operate pump in an explosive environment.
Arcing from the motor brushes, switch or excessive
heat from an improperly cycled motor may cause an
explosion.
2.
3
Do not assume fluid compatibility. If the fluid is
improperly matched to the pumps’ elastomers, a leak
may occur.
Do not pump gasoline or other flammable liquids.
* Important return safety instructions:
When you return your pump for warranty or repair,
you must always do the following:
1. Flush chemical residue from the unit
2. Tag unit with type of chemicals having been sprayed.
3. Include complete description of operation problem,
such as how unit was used, symptoms of
malfunction, etc.
Since unit can contain residues of toxic chemicals
these steps are necessary to protect all the people who
handle return shipments, and to help pinpoint the
reason for the breakdown.
WARNING: This product can expose you to chemicals
including lead, which is known to the State of California
to cause cancer.
www.P65Warnings.ca.gov
!
WORKHORSE SPRAYERS®, a division of GreenLeaf, Inc. 9490 N BALDWIN STFONTANET, IN 47851 www.workhorsesprayers.com 888-433-6631

DESCRIPTION
PART#
QTY
ITEM
3/8" Hose Clamp
6001202
1
Spray Wand Clip
60015122
10-24 x 3/8" Pan Head
Screw
60015223
#8-3/4" Self Tapping
Screw
6001992
4
Relief Hose Assembly
600213
15
5 Gallon Tank
610000
1
6
5 Gallon Tank Lid
610001
17
Charger Panel Door
610003
1
8
Wheel
61000429
Retractable Handle
Assembly
610006
1
10
1/4-20 x 1/2" Pan Head
Screw
6100176
11
W 406
610023
1
12
Lithium Ion Battery
610039213
Economy Wand
Assembly
610047
114
Lithium Ion Battery
Charger
610048
115
3/8-16 x 5" Hex Head
Bolt
6100492
16
Back Panel 2022
610050
117
1.0 GPM Barbed Pump
w/ Intigrated Switch
640455
1
18
5/16-18 Locknut
640469219
10 6
8
11
7
2
3
9
16
16
9
19
4
17
14
18
13
1
1
5
12
Not Shown
Note: Battery plugs directly into the lead
exiting the rear of the pump.
Unplug the battery from the pump to
plug into charger to charge battery
