WORKMASTER GO-E2 Manual

GO-E2 Gate Opener
OPERATOR'S GUIDE

PH: 866.476.9217 1
WORKMASTER disclaims any liability for injuries, death or damages arising directly or
indirectly, from the use, operation or application of this product not in accordance with
the procedures, specifications and recommendations contained in this owner’s manual.
The user of this product is responsible to install, maintain and operate the product and
parts or components manufactured or supplied by WORKMASTER in such a manner as to
comply with all federal, state and local rules, ordinances, regulations and laws, including
the Williams-Steiger Occupational Safety Act, and the American National Standards
Institute Safety Code.

PH: 866.476.9217 2
SYMBOLS
The following symbols are found throughout this Operator's Guide to alert the reader to
the relative danger that may result from non-observance.
This indicates a situation in which a hazard is
imminent and will result in a high probability of serious
injury or death.
This indicates a potentially hazardous situation, which
could result in minor to moderate injury.
CAUTION
This indicates a potentially hazardous situation or
unsafe practice which could result in product or
property damaged.
IMPORTANT
This symbol indicates a general statement to assist the
user in the operation or maintenance of the
equipment.

PH: 866.476.9217 3
TABLE OF CONTENTS
SECTION PAGE
I. Introduction 1
II. OperationSafety 3
III. Specifications
IV. Installation
V. OpeningCarGates
VI. ClosingCarGates
VII. TravelingCapstans
VIII. Changing Voltage Setting
IX. Maintaining the GO-E2 Opener
X. Phasing
XI. Electrical Control Package
APPENDIX A: Beam Mount Assembly
APPENDIX B: Motor Parts List
APPENDIX C: Drive Shaft Exploded View
LIST OF FIGURES
FIGURE PAGE
Figure 1 Component Layout
Figure 2 Gear Motor Placement
Figure 3 Traveling Capstan Diagram
Figure4PhaseDiagram

PH: 866.476.9217 4
I. INTRODUCTION
Fast, safe and economical unloading of covered hopper cars continues to be a problem
at most unloading sites. One of the biggest contributors to this problem is the often
time-consuming and difficult job of opening and closing bottom gates or doors of these
hopper cars. Lading compaction, weather conditions, age, abuse or corrosive or gritty
bulk materials can combine to prevent gate mechanisms from operating smoothly.
Regardless of cause, the costs associated with the problem are significant. Delays in
emptying the cars means slow car turnaround, increased demurrage costs and
interrupted production schedules. And, even more importantly, the chance of worker
injury is high since at many unloading sites clumsy or dangerous makeshift or wrong
tools are used during the "fight" to open a stubborn gate.
WORKMASTER has developed a line of Hopper Car Gate Openers and accessories
which provides a safe, efficient and economical solution to the problem of opening
easy, medium and hard-to-open hopper car gates.
There are pneumatic, electric and manual units available producing 1,000 to
13,000 ft-lbs of torque to eliminate the need for "cheater" bars, sledge hammers, jacks,
and other improper tools sometimes used on this difficult job.
This Operator's Guide details the installation, use, and maintenance of our GO-E2
Electric Hopper Car Gate Opener. Experience has shown that the GO-E2 Opener will
open easy to moderately difficult car gates. However, that same experience
demonstrates that total satisfaction in use depends on attention to detail in installing,
using, and maintaining the Unit.
The operating principle is simple. The GO-E2 Opener uses the high-speed reversing
action of an electric Gear Motor to provide an abrupt, forward-backward rocking (or
twisting action) to jog stubborn gates loose.
IMPORTANT
All persons involved in the installation,
operation, and maintenance of this equipment
should be thoroughly familiar with the contents
of this manual.

PH: 866.476.9217 5
When equipped with the Rolling Carriage option, the GO-E2 Opener can be mounted to
a steel W-Beam parallel to the track so the operator can roll the GO-E2 Opener from
gate to gate, and car to car. With the Rotating Platform option, the Opener can be
swung 180° to open the gates of rail cars on parallel tracks.
For hazardous atmospheres, ask your WORKMASTER Dealer about special models.

PH: 866.476.9217 6
II. OPERATION SAFETY
Safety must be considered a basic factor in machinery operation at all times. All rotating
power transmission products are potentially dangerous. Most accidents are the result of
carelessness or negligence.
It is the responsibility of the owner and operator to install, maintain, and operate the
parts or components manufactured and supplied by WORKMASTER, in such a manner
as to comply with the Williams-Steiger Occupational Safety Act and with all state and
local laws, ordinances, regulations, and the American National Standards Institute
Safety Code (ANSI).
To prevent injury to yourself or others and/or damage to the equipment you should
adhere to the following basic safety instructions:
GENERAL SAFETY INFORMATION
1. Read carefully all Owner-Operator Guides and Manuals, Service Manuals,
and/or other instructions.
2. Always follow proper procedures and use proper tools and safety equipment.
3. Be sure to receive proper training.
4. Always use proper components in applications for which they are approved.
5. Be sure to assemble components properly.
6. Never use worn-out, defective or damaged components.
7. Practice good housekeeping at all times, and maintain good lighting around
all equipment.
8. Hand tools, although commonly used, are specialized for particular jobs.
Always use the right size and type of tool for the job being performed. Keep
tools in proper working condition, and discard any tools that are worn or used
beyond their useful life.

PH: 866.476.9217 7
GO-E2 OPENER SAFETY INFORMATION
1. If the GO-E2 Gate Opener is to be inspected, lubricated or serviced, the Gear
Motor is to be locked-out electrically in such a manner that it cannot be
restarted by anyone, however remote from the area.
2. Know the location and operation of all emergency controls and devices.
Maintain clear, direct access to these controls and devices.
3. Frequently inspect these controls and devices, the Gear Motor, Driveshaft and
components to ensure proper working order and correct mounting and
alignment.
4. Do not place hands, feet, or any part of the body, or clothing in any opening.
5. Maintain a safe distance from the Telescoping Driveshaft while it is operating.
6. Do not overload the GO-E2 Opener, or attempt to use it for other than its
intended use.
7. Perform a pre-start-up check before power is connected to ensure the
equipment and area are safe for operations.

PH: 866.476.9217 8
III. SPECIFICATIONS
To operate the GO-E2 efficiently the user should be familiar with each of the Gate
Opener's Components. See Figure 1 for component Layout and the following pages for
item descriptions.
The GO-E2 Gate Opener consists of a heavy-duty, 5 HP. Gear Motor; a Telescoping
Driveshaft (TDS) with universal joints on each end to enable the TDS to angle up to 20°
off-center on either end; an electrical Control Package in a NEMA-4 watertight enclosure
which contains a reversible starter, transformer and overload protection, and a hand
held, watertight, momentary contact, Forward/Reverse, Pushbutton Pendant Control
with 50' L cord. Also, included is a tapered Capstan Drive Fitting which is attached to
the Driveshaft and a Capstan Swage to clean-out and square-up the capstan sockets on
hopper car gate spindles.
Figure 1: Component Layout
1
2
3
4
5
6
7

PH: 866.476.9217 9
1. GEAR MOTOR
The GO-E2’s gear motor is an electrically powered unit with a cast iron housing
that can be mounted to a stationary object or to our Rolling Carriage. The GO-
E2’s drive shaft slides onto the motor’s keyed output drive.
2. ROTATING PLATFORM AND ROLLING CARRIAGE (RPRC)
The GO-E2’s RPRC is used in conjunction with a customer supplied W-Beam
(W8). The RPRC slides along the beam’s flange to better align the drive shaft
with the Railcars Capstan Socket. The RPRC also allows the operator to rotate
the motor and drive shaft 360 degrees for storage purposes or for opening on
both sides of the beam.
3. W-BEAM
We recommend a W8 Beam, as long as practical, to be mounted securely to the
ground roughly 7 feet from the inside edge of the inner rail. Although not
required to operate the GO-E2 (the motor can be mounted to a permanent
structure), the beam, in conjunction with the RPRC will maximize the Gate
Opener’s versatility.
4. ELECTRICAL CONTROL PACKAGE
The Electrical Control Package is wired for 480 V/3Ph/60Hz Operation. The
Package is specifically designed for remote operation and control of electric
motors in high voltage applications.
The Control Box features a NEMA-4 steel enclosure with continuous hinge and
cover clamps. This provides watertight protection of electrical controls.
The Terminal Board, mounted inside the control box serves as the central station
where power supply leads are connected.
The Reversing Magnetic Contactor, electrically and mechanically interlocked,
reverse the motor by electrically reconnecting the motor windings.
The Overload Relays trips power off when the motor stalls, or when it
experiences sustained overload or rapid cycling; the switch is manually reset
inside the control box.
A 120V, 2 AMP fused circuit runs from the control box to the hand-held pendant
control switch. This helps protect the operator by lowering the voltage in the
pendant control switch.

PH: 866.476.9217 10
A complete vinyl wiring diagram with adhesive backing, showing the motor
circuit and the control circuit, is permanently attached inside the control box.
The diagram offers a convenient reference for connecting circuits or
troubleshooting electrical problems.
5. PENDANT CONTROL
The Pendant Control is in a NEMA-4 (watertight) box and is operated by 2
momentary contact type pushbuttons. Wired to the Electrical Package with a
50ft cord, the Pendant Control allows the user to operate in both the clockwise
and counter-clockwise directions all while standing at a safe distance from the
railcar.
The Pendant Control is also equipped with a 2-position switch to energize and
de-energize the GO-E2’s motor
6. DRIVE TIP
The Drive Tip is secured to the Telescoping Drive Shaft (TDS) with a heavy-duty
set screw. The tapered end of the Drive Tip will firmly seat into the Railcar’s
Capstan Socket
REPLACEMENT DRIVE TIP PART # 33-10001
7. TELESCOPING DRIVE SHAFT (TDS)
The TDS connects the Drive Tip to the Gear Motor. By extending and
compressing the TDS allows the GO-E2 to accommodate traveling Capstan
Barrels. The U-Joint and Yoke design allows the Drive Tip to make full contact
with the Capstan Barrel at all angles.

PH: 866.476.9217 11
IV. INSTALLATION
1. Position the GO-E2's Gear Motor 7-feet from the inside edge of the inner rail.
If you have purchased the Beam Mount Assembly (BMA), secure a W-Beam
with at least a 6” width (W8 x 24) to the floor, 7-feet from the inside edge of
the inner rail. See Figure 1.
2. If you did not purchase the BMA, the Gear Motor to a base with enough
rigidity to prevent torsional or lateral vibratory flexure caused by dynamic
loading. The mounting surface should be flat, and clean, so stresses are not
induced during the mounting of the Gear Motor to its foundation.
Figure 2: Gear Motor Placement
3. The W-Beam should run parallel to the rails, along its entire length. The
GO-E2 will slide along this beam so the length is determined by your specific
application.
The W-Beam must be secured to the floor. If
not properly bolted the W-Beam and the
GO-E2 could topple over.
GEAR MOTO
R
INNER RAIL
W-BEAM
7 FEET

PH: 866.476.9217 12
4. Once the W-Beam is secured, slide the BMA onto the beam so that the
beam's top flange fits into the t-slot on the bottom of the BMA.
5. Slide the carriage to a spot on the W-Beam where it will be convenient to
mount the Gear Motor. Once in position, lock the carriage in place by turning
the t-handle set screws clockwise.
6. Place the gear motor on top of the BMA and using the hardware supplied,
bolt the gear motor to the BMA.
7. With the Gear Motor completely secured, loosen the BMA's t-handle set
screws and slide the unit back and forth along the beam to verify ease of
movement.
8. Check the Gear Motor nameplate to verify that the phase, hertz and voltage
agree with the available power source.
CAUTION
The E2 Opener's Gear Motor is designed to
operate with the base mounted floor-
horizontal. Other special mountings require
modifications to the lubrication system and
seals. Consult your WORKMASTER Sales
Representative on special mountings.
CAUTION
Although the control package includes overload
protection, wiring the incorrect power supply
could still damage the Gear Motor. Ratings
cannot be exceeded.
It is the purchaser's responsibility to determine
the applicable local, state and national codes
related to electrical wiring of this unit.

PH: 866.476.9217 13
9. Wire the control package to the Gear Motor.
10. The GO-E2 Opener's Gear Motor is lubricated before shipment. Before start-
up (or prolonged storage), remove the seal from the breather/vent plug. The
lubricant level should be checked with the GO-E2 Opener mounted in its
correct position. Lubricant should be added or removed to bring it to the
correct level.
11. Test the Gear Motor by rotating the output shaft 360°.
12. Attach the motor-end yoke and Driveshaft assembly of the Telescoping
Driveshaft to the Gear Motor; align the connection using the key/keyway
provided on the Gear Motor, and firmly secure both set screws with a 3/16"
Allen wrench.
13. Locate and mount the Electrical Control Box. The Control Console is housed in
a NEMA-4 watertight steel enclosure with continuous hinge and cover clamps.
IMPORTANT
The Pushbutton Pendant Control Switch is
supplied with 50' of 18/4SOOW portable
cordage as standard.
IMPORTANT
A wiring diagram showing the motor circuit and
the control circuit is attached inside the Control
Box.
Branch circuit conductors, disconnects,
protection and grounding are the user's
responsibility. Refer to Article 430 of the
National Electrical Code.

PH: 866.476.9217 14
V. OPENING CAR GATES
1. Using the Rolling Carriage, roll the GO-E2 Opener along the W-Beam until
you "rough spot" position the Gear Motor's output shaft with the hopper car
gate.
2. Once in position use the T-Handle set screws to secure the Gear Motor and
Rolling Carriage in place.
3. Disengage the Car Gate locking mechanism before attempting to open the
gate.
4. Using the Capstan Swage Tool (optional accessory PN: 33-11120), clean-out
and square-up the Capstan Socket on the Car Gate so that the Capstan Drive
Fitting on the GO-E2 Opener's Driveshaft can be properly and fully seated in
the car's Capstan Socket when opening the gate.
5. Extend and adjust the Telescoping Driveshaft until the Capstan Drive Fitting
on the yoke and tube assembly is firmly seated in the car's Capstan Socket.
6. Position yourself away from the Drive Shaft so that fingers, tools or articles of
clothing do not get caught during operation.
7. Press the "Forward" or "Reverse" momentary contact Pushbutton to open the
gate. If the gate is stuck, alternately press the "Forward" and "Reverse"
buttons to rock or jog the gate loose.
The Gear Motor must be securely fastened to its
foundation, and the rolling carriage must be
locked down before operating the GO-E2
Opener.
CAUTION
Failure to disengage the Car Gate locking
mechanism will cause damage to the Car Gate.

PH: 866.476.9217 15
8. Control the opening speed, and the travel of the gate so that it does not slam
against the end of the gate track.
9. If, after repeated attempts at "jogging" the Opener with the Pushbuttons, the
car gate will not move, STOP using the GO-E2 Opener and notify your
supervisor.
10. Remove the Capstan Drive Fitting from the Capstan Socket, collapse the
Telescoping Driveshaft, and secure the GO-E2 Opener for its next use.
Release the Pushbutton the moment the gate
reaches its fully opened position. Prolonged
hold down can cause the Driveshaft to slip from
the car's capstan and bounce uncontrollably
along the ground.
Do not use other opening devices, (pry bars,
multipliers, etc.) in a dangerous attempt to
"help" the GO-E2 Opener.
CAUTION
Do not hold either Pushbutton down for more
than a few seconds. Prolonged hold-down of
either button can cause the Gear Motor to
overheat and stall.
IMPORTANT
Handle the Telescoping Driveshaft carefully.
Repeated dropping or abuse will damage the
bell shaped guard which protects the universal
joint.

PH: 866.476.9217 16
VI. CLOSING CAR GATES
1. Using the Rolling Carriage, roll the GO-E2 Opener along the W-Beam until
you "rough spot" position the Gear Motor's output shaft with the hopper car
gate.
2. Using the Capstan Swage Tool (optional accessory PN: 33-11120), clean-out
and square-up the Capstan Socket on the Car Gate so that the Capstan Drive
Fitting on the GO-E2 Opener's Driveshaft can be properly and fully seated in
the car's Capstan Socket when closing the gate.
3. Disengage the Car Gate locking mechanism before attempting to close the
gate.
4. Extend and adjust the Telescoping Driveshaft until the Capstan Drive Fitting
on the yoke and tube assembly is firmly seated in the car's Capstan Socket.
5. Press the "Forward" or "Reverse" momentary contact Pushbutton to close the
gate. If the gate is stuck, alternately press the "Forward" and "Reverse"
buttons to rock or jog the gate loose.
6. Position yourself away from the Drive Shaft so that fingers, tools or articles of
clothing do not get caught during operation.
The Gear Motor must be securely fastened to its
foundation, and the rolling carriage must be
locked down before operating the GO-E2
Opener.
CAUTION
Failure to disengage the Car Gate locking
mechanism will cause damage to the Car Gate.
CAUTION
Do not hold either Pushbutton down for more
than a few seconds. Prolonged hold-down of
either button can cause the Gear Motor to
overheat and stall.

PH: 866.476.9217 17
7. Control the opening speed, and the travel of the gate so that it does not slam
against the end of the gate track.
8. If, after repeated attempts at "jogging" the Opener with the Pushbuttons, the
car gate will not move, STOP using the GO-E2 Opener and notify your
supervisor.
9. Remove the Capstan Drive Fitting from the Capstan Socket, collapse the
Telescoping Driveshaft, and secure the GO-E2 Opener for its next use.
10. Engage Car Gate locking mechanism.
Release the Pushbutton the moment the gate
reaches its fully closed position. Prolonged hold
down can cause the Driveshaft to slip from the
car's capstan and bounce uncontrollably along
the ground.
IMPORTANT
The GO-E2 Opener will not close ice-bound
gates or gates that are structurally damaged.
Do not use other opening devices, (pry bars,
multipliers, etc.) in a dangerous attempt to
"help" the GO-E2 Opener.
IMPORTANT
Handle the Telescoping Driveshaft carefully.
Repeated dropping or abuse will damage the
bell shaped guard which protects the universal
joint.

PH: 866.476.9217 18
VII. TRAVELING CAPSTANS
The GO-E2 Opener has the ability to open hopper car slide gates with traveling
capstans. The Driveshaft will extend and compress as the slide gate capstan moves
along its length or travel. The Driveshaft's double yoke ensures that the drive fitting will
maintain constant contact with the capstan. See Figure 3 for traveling capstan
depiction.
Figure 3: Traveling Capstan Diagram
MOTOR SIDE
SHAFT
COMPRESSED
SHAFT
EXTENDED

PH: 866.476.9217 19
VIII. CHANGING VOLTAGE SETTING
The electric gate opener is delivered set-up for 440/460/480 VAC, 3PH operation. To
change the voltage to 230/240 VAC, 3PH operation, three tasks must be performed:
1. De-energize all power leading to the gate opener.
2. In gate opener's electric motor's conduit box, change it to 230/240 VAC.
3. In the motor starter's NEMA 4 enclosure:
a. Move the jumpers on the control transformer. As delivered these
jumpers are across H2 and H3. Remove these two jumpers and
place one across H1 and H2, and one across H3 and H4.
b. Change the setting on the overload relay (the motor leads are
connected to the overload relay), from 7.5 AMPS to 15 AMPS.
