WORKSWELL BB 200 User manual

WORKSWELL
BB 200
QUICK START GUIDE
Release date: 8th June, 2020
Revision : 1.0 EN

Standard Package Content
Confirm that the package contains the items listed below:
BB200
Black mounng stand
Power supply adapter
Transport box
Download card
Calibraon cerficate
This Quick Start guide
System Assembly
To prepare the system please follow these steps:
1. Mount the system to a mounng stand.
2. Connect the power supply adapter.
3. The black body will load firmware and start heang up shortly aer.
Figure 1 – Power supply adapter (24 VDC) connected to the BB200.
E-mail and Web
[e-mail]
www.workswell.eu
Mobile:
[phone]
ID:
Reg. No.: 29048575
VAT No.: CZ29048575
Headquarters
U Albrechtova vrchu 12
155 00, Prague 13
Czech Republic
Revision 1.0 EN, 8th Jun, 2020
All pictures are only for illustraon.
Real values may vary.
1

LED behavior
The black body LED will start eming light right aer the power supply adapter is connected. The color of the
LED signalizes the state of the black body:
RED - Red blinking is signalizes that the black body is heang up.
GREEN - constant green color signalizes that the set black body temperature is achieved and stable.
BLUE - Blue blinking signalizes that the black body is cooling down.
Black Body control
The BB200 operates in two modes - locked and unlocked mode. In the locked mode the preset temperature is
strictly held and you can not change it. In the unlocked mode, you can freely set desired temperature and change
it during the operaon of the black body.
To change the mode, follow these steps:
Make sure the black body is powered and running
Press and hold both buons on the back of the black body for 5 seconds. During this me, you will see
text ”Please release the buons and follow user manual instrucons”
Release both buons when the text ”Follow user manual instrucons” appears.
In quick succession within 1 second press and hold both buons unl text ”Temperature locked” or ”Tem-
perature unlocked” appears.
In the unlocked state, you can freely control the temperature with the two buons. Le buon decreases the
set temperature, right buon increases the set temperature. Both buons have two posions:
First posion changes the temperature by 0.1°C.
Second posion changes the temperature by 1°C.
Aer you restart the black body in the locked mode, the temperature will return to the previously locked tem-
perature. Aer you restart the black body in the unlocked mode, the default temperature will be 30°C.
Changing the temperature unit
While powering the black body and during the startup, press and hold both buons to change the temperature
units of the black body:
From °C to °F.
From °F to °C.
Black Body user manual
Please read the BB200 user manual for the descripons of the other funcons.
