Worx L1300 User manual

Owner’s manual

MANUAL

EN
D
F
I
ES
NL
PL
CZ
SK
SL
PT
HU
RO
HR
DK
FIN
NOR
SV
Original Instructions
Übersetzung der Originalbetriebsanleitung
Traduction de l’instruction originale
Traduzione dell’istruzione originale
Traducción del manual original
Vertaling van de oorspronkelijke gebruiksaanwijzing
Tłumaczenie oryginalnej instrukcji
Překlad originálního návodu
Preklad originálneho návodu
Prevod izvirnih navodil
Tradução da instrução original
Fordítás az eredeti utasítások
Traducerea instrucțiunilor originale
Prijevod originalnih uputa
Oversættelse af den originale brugsanvisning
Käännös alkuperäisestä ohjeiden
Oversettelse av den opprinnelige beskrivelsen
Översättning av originalinstruktioner
Owner's manual
Benutzerhandbuch
Mode d’emploi
Manuale d’uso
Manual del propietario
Gebruikershandleiding
Instrukcja obsługi
Návod k použití
Návod na použitie
Navodila za uporabo
Manual de utilizador
Felhasználói kézikönyv
Manual utilizator
Priručnik za upotrebu
Ejerens instruktionsbog
Käyttäjänopas
Brukermanuel
Bruksanvisning
P04
P24
P44
P64
P84
P104
P124
P144
P164
P184
P204
P224
P244
P264
P284
P304
P322
P340
EN
D
F
I
ES
NL
PL
CZ
SK
SL
PT
HU
RO
HR
DK
FIN
NOR
SV

4
EN
Users can view the electronic instructions at https://eu.worx.com/en/landroid/
vision-technology/.
PRODUCT SAFETY
GENERAL SAFETY WARNINGS
WARNING: Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Carefully read the instructions for the safe operation of the machine.
Save all warnings and instructions for future reference.
-This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
-Children should be supervised to ensure that they do not play with the appliance.
WARNING: For the purposes of recharging the battery, only use the detachable supply unit
provided with this appliance.
WARNING: To reduce the risk of injury to persons and damage to the machine, do not remove
battery pack before switching off the machine.
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
Safe operation practices
Training
a) Read the instructions carefully. Make sure you understand the instructions and be familiar with
the controls and the proper use of the appliance.
b) Never allow people unfamiliar with these instructions or children to use the appliance. Local
regulations can restrict the age of the operator.
c) The operator or user is responsible for accidents or hazards occurring to other people or their
property.
Preparation
a) Ensure the correct installation of the automatic perimeter delineation system as instructed.
This machine works without boundary wire or virtual boundary. It can automatically identify the
working area and non-working area through the camera. Once the machine is turned on, the
camera will automatically turn on and work at the same time. The machine recognizes that the
lawn is the working area through the camera, and the non-working area that is not the lawn.
When the machine walks to the boundary between lawn and non-lawn, it will automatically turn
to return to the working area.
Add a magnetic strip to separate it from the neighbor’s lawn. The machine returns when it
encounters a magnetic strip while mowing. Return along the magnetic strip when returning.
b) Periodically inspect the area where the appliance is to be used and remove all stones, sticks,
wires, bones, and other foreign objects. Periodically inspect and clean the boundaries between
grass and non-grass. Clearing boundaries helps the lawnmower to identify the working area.
c) Periodically visually inspect to see that the blades, blade bolts and cutter assembly are not
worn or damaged. Replace worn or damaged blades and bolts in sets to preserve balance.
d) On multi-spindle appliances, take care as rotating one blade can cause other blades to rotate.
e) WARNING! The lawnmower shall not be operated without the guard in place.
Operation
1. General
a) Never operate the appliance with defective guards, or without safety devices, for example

5
EN
deflectors, in place.
b) Do not put hands or feet near or under rotating parts. Keep clear of the discharge opening at
all times.
c) Never pick up or carry an appliance while the motor is running.
d) Operate the disabling device from the appliance.
- Before clearing a blockage;
- Before checking, cleaning or working on the appliance;
- After striking a foreign object to inspect the machine for damage;
- If the machine starts to vibrate abnormally, and to check for damage before restarting.
e) It is not permitted to modify the original design of robotic lawnmower. All modifications are
made at your own risk.
f) Start robotic lawnmower according to the instructions. When the power key is switched on,
make sure you keep your hands and feet away from the rotating blades. Never put your hands
and feet under the mower.
g) Never lift up robotic lawnmower or carry it when the power key is switched on.
h) Do not let persons who do not know how robotic lawnmower works and behaves use the
mower.
i) Do not put anything on top of robotic lawnmower or its charging base.
j) Do not allow robotic lawnmower to be used with a defective blade disc or body. Neither should
it be used with defective blades, screws, nuts or cables.
k) Always switch off robotic lawnmower when you do not intend to use the mower. Robotic
lawnmower can only start when the power key is switched on and the correct PIN code has
been entered.
l) Keep your hands and feet away from the rotating blades. Never place your hands or feet close
to or under the body when robotic lawnmower is in operation.
m) To avoid using the machine and its peripherals in bad weather conditions especially when there
is a risk of lightning.
n) Do not touch moving hazardous parts before these have come to a complete stop.
o) For machines used in public areas, that warning signs shall be placed around the working area
of the machine. They shall show the substance of the following text:
Warning! Automatic lawnmower! Keep away from the machine! Supervise children!
2. Additionally when the appliance is operating automatically
a) Do not leave the machine to operate unattended if you know that there are pets, children or
people in the vicinity.
Maintenance and storage
WARNING! When the mower is turned upside down the power key must always
be switched off.
The power key should be switched off during all work on the mower’s
underframe, such as cleaning or replacing the blades.
a) Keep all nuts, bolts and screws tight to be sure the appliance is in safe working condition.
b) Inspect the robotic lawnmower each week and replace worn or damaged parts for safety.
c) Check especially that the blades and blade disc are not damaged. Replace all blades and
screws at the same time if necessary so that the rotating parts are balanced.
d) Ensure that only replacement cutting means of the right type are used.
e) Ensure that batteries are charged using the correct charger recommended by the
manufacturer. Incorrect use may result in electric shock, overheating or leakage of corrosive
liquid from the battery.
f) In the event of leakage of electrolyte flush with water/neutralizing agent, seek medical help if it
comes into contact with the eyes etc.

6
EN
g) Servicing of the appliance should be according to manufacturers’ instructions.
h) In order to obtain the best performance, please pay attention to the following ambient
temperature range, do not charge, use, or store in the case of exceeding the following
temperature range:
a) Charging temperature range: 4°C~45°C
b) Discharge temperature range: -20°C~55°C
c) Storage temperature range: -20°C~75°C
i) Leaking battery fluid can cause skin and eye irritation or chemical burns.
a) Avoid contact with skin and eyes.
b) If liquid gets in eyes: Do not rub. Flush open eyes with water for at least 15 minutes, and
seek medical advice.
c) In case of accidental contact, wash the contact area immediately and thoroughly with mild
soap and water.
d) Use an inert absorbent such as sand on spilled liquid.
Recommendation
To connect the machine and/or its peripherals only to a supply circuit protected by a residual
current device (RCD) with a tripping current of not more than 30 mA.
Residual risks
To avoid injuries, wear protective gloves when replacing the blades.
Transport
The original packaging should be used when transporting robotic lawnmower over long distances.
To safely move form or within the working area:
a) Press the STOP button to stop the mower.
You select the four digit PIN code when you start the mower for the first time.
b) Always switch off robotic lawnmower if you intend to carry the mower.
c) Carry the mower by the handle at the front under the mower. Carry the mower with the blade
disc away from the body.
RF exposure requirements
To satisfy RF exposure requirements, a separation distance of 200mm or more should be
maintained between this device and persons during device operation.
To ensure compliance, operations at closer than this distance is not recommended. The antenna
used for this transmitter must not be co-located in conjunction with any other antenna or
transmitter.
This is a class III appliances and it must only be supplied at safety extra low voltage
corresponding to the marking on the appliance.
WARNING: For the purposes of recharging the battery, only use the detachable supply unit
provided with this appliance.
Safety Warnings for battery pack
a) Do not dismantle, open or shred cells or battery pack.
b) Do not short-circuit a battery pack. Do not store battery packs haphazardly in
a box or drawer where they may short-circuit each other or be short-circuited
by conductive materials. When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make
a connection from one terminal to another. Shorting the battery terminals together may cause
burns or a fire.

7
EN
c) Do not expose battery pack to heat or fire. Avoid storage in direct sunlight.
d) Do not subject battery pack to mechanical shock.
e) In the event of battery leaking, do not allow the liquid to come into contact
with the skin or eyes. If contact has been made, wash the affected area with
copious amounts of water and seek medical advice.
f) Keep battery pack clean and dry.
g) Wipe the battery pack terminals with a clean dry cloth if they become dirty.
h) Battery pack needs to be charged before use. Always refer to this instruction
and use the correct charging procedure.
i) Do not maintain battery pack on charge when not in use.
j) After extended periods of storage, it may be necessary to charge and
discharge the battery pack several times to obtain maximum performance.
k) Recharge only with the charger specified by Worx. Do not use any charger
other than that specifically provided for use with the equipment.
l) Do not use any battery pack which is not designed for use with the
equipment.
m)Keep battery pack out of the reach of children.
n) Retain the original product literature for future reference.
o) Remove the battery from the equipment when not in use.
p) Dispose of properly.
q) Do not mix cells of different manufacture, capacity, size or type within a
device.
r) Keep the battery away from microwaves and high pressure.
s) Warning! Do not use non-rechargeable batteries.
User manual requirements for wireless product
a) Operation of this device is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
b) Caution: Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
c) NOTE: This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
Band application caution (for Wi Fi 5G device)
Legal Information This device may be operated in all member states of the EU. Observe national
and local regulations where the device is used.
This device is restricted to indoor use only when operating in 5150 to 5350 MHz frequency range
in following countries:
AT BE BG HR CY CZ DK

8
EN
EE FI FR DE EL HU IE
IT LV LT LU MT NL PL
PT RO SK SI ES SE UK

9
EN
INFORMATION ON LANDROID VISION
WARNING – robotic lawn mower can be dangerous if incorrectly used. Read through the Operator’s
manual carefully and understand the content before using your robotic lawn mower.
WARNING - Keep a safe distance from the machine when operating.
WARNING – Operate the disabling device before working on or lifting the machine.
WARNING - Do not ride on the machine.
Li-Ion battery. This product has been marked with a symbol relating to ‘separate collection’ for all
battery packs and battery pack. It will then be recycled or dismantled in order to reduce the impact on
the environment. Battery packs can be hazardous for the environment and for human health since they
contain hazardous substances.
Do not burn
Batteries may enter water cycle if disposed improperly, which can be hazardous for ecosystem. Do not
dispose of waste batteries as unsorted municipal waste.
Prohibit disassembling the machine without authorization.
Waste electrical products must not be disposed of with household waste. Please recycle where facilities
exist. Check with your local authorities or retailer for recycling advice.
Class III appliance
Read operator's manual
Detachable supply unit
Your Landroid Vision can be used with other Worx functional accessories. Visit https://eu.worx.com/en/
landroid/vision-technology/ to learn more about these available accessory options.

10
EN
COMPONENT LIST
WHAT’S IN THE BOX
The picture is only for reference
Worx Landroid Vision
Charging tower
Charging base plate
Spare blades kits
Hex key
Screws
Magnetic strip pegs
Power supply
20V battery
Magnetic strip
Manuals
RFID
A
B
C
D
E
F
G
H
I
J
K
L
AD
E
B
F
C
G
H
L
J
I
K

11
EN
A
B
Find My Landroid
GETTING TO KNOW
LANDROID VISION
The picture is only for reference
Rain sensor
Charge contact
Cutting height adjustment
Interface
Battery slot
Battery cover button
Safety stop
Camera
High Pitched Alarm Slot
USB port

12
EN
TECHNICAL DATA
Type WR206E WR208E WR213E WR216E (200-299 - designation of machinery, representative of Robotic
lawn mower with Vision technology)
WR206E WR208E WR213E WR216E
No load speed (/min) 2800 /min 2600 /min 2200 /min
Cutting area (m2) 600 m2800 m21300 m21600 m2
Cutting diameter (cm) 18 cm 19 cm 22 cm
Cutting height (mm) 30-60 mm
Cutting system 3 pivoting razor blades
Cutting height positions 4 7
Slope (%) 30%
Battery type Lithium-ion
Battery Capacity (Ah) 2 Ah 4 Ah
Battery model WA3551.1 WA3014
Charging time approx. (mins.) 85 mins. 75 mins. 45 mins.
Charger model WA3750.1/
WA3755.1 WA3775/WA3776 WA3796/WA3798
Charger rating
Input: 100-240
V~50/60 Hz, 38 W,
Output: 20V
,1.5 A
Input:100-240 V~50/60 Hz, 90 W,
Output: 20 V , 3.0 A
Input:100-240
V~50/60 Hz, 190W,
Output: 20 V ,
5.0 A
Machinery weight (kg) 14.4 kg 14.6 kg 15.1 kg
Protection degree III
App (Wifi/Bluetooth) Y
Frequency bands for Bluetooth (MHz) 2400-2483.5 MHz
Maximum Transmitted Power for Bluetooth
(dBm) 8 dBm
Frequency bands for WIFI (MHz) 2400-2483.5 MHz
Maximum Transmitted Power for WIFI
(dBm) 20 dBm
Frequency bands for WIFI (MHz) 5150-5725 MHz
Maximum Transmitted Power for WIFI
(dBm) 20 dBm
Waterproof level IPX 5
*Voltage measured at no load. Initial battery voltage reaches maximum of 20 volts. Nominal voltage is 18 volts.

13
EN
NOISE DATA
WR206E WR208E WR213E WR216E
A weighted sound pressure
LpA = 46.45 dB(A) LpA = 46.46 dB(A) LpA = 46.73 dB(A)
KPA = 1.58 dB(A) KPA = 1.11 dB(A) KPA = 1.68 dB(A)
A weighted sound power
LwA = 57.45 dB(A) LwA = 57.46 dB(A) LwA = 57.73 dB(A)
KwA = 1.58 dB(A) KwA = 1.11 dB(A) KwA = 1.68 dB(A)
Wear ear protection when sound pressure is over 80 dB (A).
A degree of noise from the machine is not avoidable. Route noisy work is to be licensed and limits for certain periods. Keep rest
periods and they may need to restrict the working hours to a minimum. For their personal protection and protection of people
working nearby, an appropriate hearing protection shall be worn.
ACCESSORIES
WR206E WR208E WR213E WR216E
Screw 14 14 14 14
Charging tower 1 1 1 1
Charging base plate 1 1 1 1
Magnetic strip pegs 16 16 16 16
Hex key 1 1 1 1
Blade (WA0190) 9 9 9 9
RFID 2 2 2 2
Magnetic strip (5m) 2 2 2 2
Battery pack (WA3551.1) 1 / / /
Battery pack (WA3014) / 1 1 1
Charger (WA3750.1/WA3755.1) 1 / / /
Charger (WA3775/WA3776) / 1 1 /
Charger (WA3796/WA3798) / / / 1
We recommend that you purchase genuine accessories listed in the above list from the same store that sold you the tool. Refer to
the accessory packaging for further details. Store personnel can assist you and offer advice.
INTENDED USE
The garden product is intended for domestic lawn mowing. It is designed to mow often, maintaining a healthier and better looking
lawn than ever before. Depending on the size of your lawn, your Landroid Vision may be programmed to operate at any time or
frequency. It is impossible for digging, sweeping or snow cleaning.

14
EN
MAINTENANCE
Your Landroid Vision, works hard and needs to be cleaned and checked from time to time. This section of our guide helps you
keep Landroid Vision in good shape so it can last for years without trouble. Here’s how to take care of your Landroid Vision.
Switch off the machine before carrying out any service or maintenance.
1. Keep it sharp
Landroid Vision does not cut grass like other mowers. Its cutting blades are razor sharp on 2 edges and rotate in both directions
for maximum cutting capacity.
A. The blade turning disc makes a clockwise and counterclockwise rotation at random to use both cutting edges and minimize the
frequency of replacing the blades.
B. Each cutting blade will last up to 2 months when it is programmed to mow every day.
C. Always check to see if the blades are chipped or damaged and replace them if they are.
D. When the cutting blades are dull and worn out, they should be replaced with the spare blades provided with your Landroid
Vision. Spare blades are also available at your nearest Landroid Vision retailer.
WARNING! Before cleaning, adjusting, or replacing the blades, turn your Landroid Vision OFF and remove
the battery. Always wear protective gloves.
1.1 Replacing the Blades
Remove the battery (See Fig. 1) and gently flip the Landroid Vision over (See Fig. 2).
Take the screws off the blades with a screwdriver (See Fig. 3 - Fig. 4).
Firmly screw on the new blades (See Fig. 5 - Fig. 6).
1 2
3 4
5 6

15
EN
Attention: When fitting new blades, make sure you replace ALL the blades.
Always use new screws when fitting blades. This is important to ensure blade retention and balance the blade turning disc. Failure
to use new screws could cause serious injury.
Important: After screwing the blade to the blade disc, make sure the blade is able to spin freely.
2. Keep it clean
Your Landroid Vision should be cleaned regularly. This helps keep it in good conditions, especially removing dirt, debris and the
build-up of grass clippings from daily mowing. Turn Landroid Vision off before cleaning it. For extra safety, remove the battery.
Attention: Make sure the battery pack cover is closed when washing your Landroid Vision.
WARNING! YOUR Landroid Vision can only be washed by using a hose! DO NOT use high pressure washer
on your Landroid Vision. High pressure water can go inside the sealings and damage electronic and mecha-
nical parts.
2.1 Cleaning the upper body
A. Clean with a spray bottle filled with water. Don’t use solvents or polishers.
B. Use a brush or a clean cloth to remove built-up dirt.
2.2 Cleaning the Bottom
A. Flip Landroid Vision upside down.
B. Remove debris and grass clippings using a brush to remove.
C. Be careful not to touch the blades with your hands. Wear gloves for protection.
D. Clean the blade disc, the chassis and the front wheel(s) thoroughly with a soft brush or moist rag.
E. Rotate the blade disc to ensure it rotates freely. Remove any obstructions. Remove any lodged debris so that they don’t cause
a crack in the blade disk. Even the tiniest crack effects mowing performance.
F. Check the blades spin freely around the fixing screws. Remove any obstructions.
2.3 Cleaning the drive wheels
A. Remove mud from wheels with a brush in order to ensure good grip of the tread.
2.4 Cleaning the camera
A. We recommend that users regularly wipe the camera with a rag.
2.5 Clearing the charging contacts
A. Clean the contact pins located on the charging pile and the charging contacts located on the Landroid Vision using a cloth.
B. Periodically remove any build-up of grass clippings or debris around the contact pins and the charging strips to ensure Landroid
Vision successfully charges each time.
3. Keep it charged
The heart of Landroid Vision is its 20V Li-Ion Worx Powershare Battery.
A. For the proper storage of the battery, make sure it is fully charged and kept in a cool dry place.
B. The recommended Landroid Vision operation temperature is between 0-55°C.
C. The life-span of Landroid Vision’s battery depends on hours of usage and the length of use per day during the mowing season.
3.1 Landroid Vision can be charged manually
A. Connect the charging base to a suitable power supply. The green light on the charging base will turn on.
B. Manually dock Landroid Vision into the charging base while Landroid Vision is powered off.
C. The green light on the charging base will flash and Landroid Vision will begin to charge.

16
EN
3.2 The battery can be replaced manually
A. Press the button on the battery cover and open the cover.
B. Take out the old battery and install the new battery pack.
C. Close the battery cover.
NOTE: Install the battery pack according to the polarity direction of the battery marked on the physical object.
4. Keep it stored over the winter
Although Landroid Vision is designed and built to survive the most severe weather conditions, we recommend storing it in your
shed or garage during the winter. To prepare it for winter hibernation:
A. Clean it thoroughly.
B. Fully charge the battery.
C. Turn the power off.
4.1 Getting back to work in the Spring
When it is time to re-start Landroid Vision for the new season, please perform the following checks:
A. Update the time and date settings via the app.
B. If you notice signs of oxidation on the charging contacts of Landroid Vision and the charging base, clean these with a fine grade
emery cloth.
C. Full charge Landroid Vision’s battery before operating.
5. Keep it updated
Landroid Vision is always improving and new software versions are made available for free. Always keep Landroid Vision software
updated to make the most of your machine.
5.1 Check which software version you have
The software version number can be seen when the Landroid Vision is powerd-on.
5.2 Over-the-Air (OTA) updates
If your Landroid Vision is connected to your Wi-Fi network, you will be notified that new software is available via the app. Once you
confirm, the update will happen automatically Over-the-Air.
5.3 Manual updates
A. If your Landroid Vision is not connected to your Wi-Fi network, you can still update it to the latest software version with a USB
stick.
B. Regularly visit the Worx Landroid Vision website to check if any new version is available. If you subscribed to Landroid Vision
email list, you will be notified when a new version is available.
C. Download the latest software version at our website.
D. Take a blank USB stick formatted in FAT32.
E. Save the file and extract the content to your USB stick.
F. Make sure your Landroid Vision is getting charged.
G. Turn off Landroid Vision.
H. Open the battery cover of the Landroid Vision to access the USB port.
I. Insert the USB stick in the port.
J. Turn on Landroid Vision.
K. Without lifting Landroid Vision, remove the USB stick when “Please remove the USB key” is displayed.
L. The update will begin automatically and may take a while. Landroid Vision will restart automatically after the update is comple-
ted.
NOTE: Make sure Landroid Vision is charging and the battery capacity has reached 50% prior to starting the firmware update.
6. Remove the charging tower
A. Simultaneously press the two clips on the charging tower cover to remove the charging tower cover. (See Fig. 1)
B. Use a screwdriver against the charging tower pin, then remove the charging tower. (See Fig. 1 - Fig. 2)
NOTE: When Landroid Vision is not in use for a long time, removing and properly storing the charging tower can prolong the
service life of the charging base.

17
EN
1
2
12
OPERATION MESSAGES
MESSAGE LANDROID VISION ACTION
Cutting grass Cutting grass according to the mowing schedule.
Raining
The rain sensor detects water. Landroid Vision will return to the charging base and stay
there for the time you have programmed it to do so. When dry, Landroid Vision will auto-
matically begin the rain delay countdown and then return to mow. If you want Landroid
Vision to mow before this, simply turn it off then on again, but only when the rain sensor is
dry, or you can remove the rain delay completely by setting the rain delay time to zero.
Going home Needs to recharge—during the journey to the base, the cutting blade is stopped in order
to save energy.
Charging ‘Charging’ and charge percentage are displayed.
No working time scheduled Stand-by, needs to be programmed as desired.
Not working today
Stand-by, will start according to mowing schedule.
Work done today
Zone searching According to the setting of “Customize work zone”, Landroid Vision is searching a certain
area to mow.
Charge complete Landroid Vision has completed its charging.
Emergency charge Landroid Vision is charging in a powered-off state.
ERROR MESSAGES
Sometimes things can go wrong. Fortunately Landroid Vision is smart enough to tell you if it is enountering an issue, so you can fix
it. If in doubt, please visit our website where you will find useful videos and further support.
MESSAGE CAUSE ACTION
Battery pack cover is open. Close the battery pack cover.
Outside working
area! Press START to
reset.
Landroid Vision cannot find
the lawn border.
1. If Landroid Vision is actually outside of its working area: turn power
off, take Landroid Vision inside the working area, turn the power on and
press start.
2. If Landroid Vision is inside its working area check if the LED on the
charging pile is solid green.

18
EN
MESSAGE CAUSE ACTION
WRONG PIN! Please
retry. PIN code is wrong. Input the correct PIN or re-set your PIN.
Blade motor fault!
Press START to
reset.
Blade disc is blocked by an
object, e.g. a branch.
Turn power off.
Turn Landroid Vision upside down and check if there’s anything preven-
ting the blade disc from rotating and remove any obstruction.
Turn Landroid Vision upright.
Turn power on. Press start.
Blade is over-loaded by thick
dense grass.
Turn power off.
Take Landroid Vision to an area with short grass or adjust the cutting
height to a higher setting.
Turn power on. Press start.
Wheels motor fault!
Press START to
reset.
Wheel motor is blocked in
some way.
Turn power off and take Landroid Vision to an area free from obstacles.
Turn power on. Press start.
If the error message is still displayed, turn power off. Turn Landroid
Vision upside-down and check if there’s anything preventing the wheels
from rotating.
Remove any obstruction, turn Landroid Vision upright, turn power on.
Upside down! Press
START to reset.
This could have happened
when Landroid Vision came
into contact with a sloping
surface which made it over-
turn.
Turn Landroid Vision upright and remove any obstacle that might have
caused Landroid Vision to overturn.
Mower trapped!
Press START to
reset.
Landroid Vision is trapped.
Turn power off.
Take Landroid Vision to an area of your lawn free of obstacles, then turn
power on. Press start.
If the error message is still displayed: turn power off, turn Landroid Vision
upside-down. Check if there is anything preventing the wheels from
rotating.
Remove any obstruction, turn the Landroid Vision upright, turn power
on.
Mower lifted! Press
START to reset.
Landroid Vision has been
lifted up.
Turn power off.
Take Landroid Vision to an area clear of obstacles, turn power on. Press
start.
If the error message is still displayed: turn power off, turn Landroid Vision
upside-down and check there’s anything that can cause Landroid Vision
to be lifted up.
Remove any possible object, turn Landroid Vision upright, turn power
on.
Battery voltage too
low! Please change
battery.
Battery exausted, and needs
to be recharged.
In this case you must turn Landroid Vision off and place it in the charging
base, then ‘Emergency charging’ will be displayed and it will start
charging. If the battery error still persist, your battery is damaged and
need to be changed.
Battery temperature
out of range!
Please wait.
Temperature is too high (more
than 450C) or too low (less
than 40C) when charging.
Place the charging base in a shady area or wait until it reaches the nor-
mal temperature.
Can’t find charge
station press START
to reset.
Machine doesn’t have
enough power to go back to
charging base.
Take Landroid Vision to the charging base.

19
EN
MESSAGE CAUSE ACTION
Mower locked!
With the “Lock Function”
enabled, if your Landroid
Vision does not receive a
signal from your Wi-Fi router
for 3 days, then it gets locked
as a security measure.
This could be because
your router lost its power
or because you changed
your Wi-Fi router or network
provider.
Please reconnect Landroid Vision to the Wi-Fi networtk it has been origi-
nally paired with. If this is not possible, contact Cutomer Service.
RFID not found! RFID is not installed correctly. Check if RFID is correctly installed.
RFID signal is weak. Install the RFID with same number beside the original one.
Camera fault! Camera covered by dirty
things. Clean the camera.
NOTES
A. Before turning power on, always check Landroid Vision is inside its working area. If not, the message “Outside working area!
Press START to reset” will be displayed. This message is also displayed when Landroid Vision is partly but not completely inside
its working area.
B. If for any reason—i.e. a party, children playing...—you want to park your Landroid Vision in the charging base: press home then
. Landroid Vision will go to its base and stay there. Please note Landroid Vision will now wait until the next scheduled mowing
session. If you want to re-start it at anytime, press then to start your Landroid Vision.
C. If an error repeatedly occurs in the same area of your lawn, you might have a problem with the working area so please refer to
the installation instructions and check your set up is correct with its help.
D. If your lawn is divided in two separated areas, connected by a corridor less than 1m wide, one of which is not provided with the
charging base: when Landroid Vision runs out of charge, take it manually to the charging base.
E. If Landroid Vision runs abnormally once in a while, please reset it by turning it off and removing the battery for 30 seconds, then
restart it. If the problem cannot be solved, please contact our Customer Service for help.
TROUBLESHOOTING
If your Landroid Vision does not work correctly, follow the trouble shooting guide below. If the fault persists, contact Customer
Service.
SYMPTOM CAUSE SOLUTION
The LED light on the charging
pile does not turn on.
There is no power. Check the charging base is connected properly to the charger
and the charger is connected to a suitable power supply.
Landroid Vision turns on,
but the blade disc does
not spin.
Landroid Vision is searching for
the charging base.
This is normal: when Landroid Vision needs to recharge, the blade
disc does not rotate while it is searching for the charging base
automatically.
Landroid Vision vibrates. The blade disc is unbalanced.
Blades may be damaged.
Check the blades and replace them if damaged.
Remove debris and foreign objects from the blades and blade disc.

20
EN
SYMPTOM CAUSE SOLUTION
Grass is being cut
unevenly.
Landroid Vision does not work
enough hours per day to cut the
grass.
Try adding more hours to the mowing schedule.
Mowing area is too big for the
size of Landroid Vision you have.
Try decreasing the size of the mowing area or increasing working
time.
The blades are dull and not sharp. Change all the blades and screws in order to balance the bade disc.
The cutting height is set too low
for the length of the grass. Raise the cutting height and then gradually lower.
Grass or another object has
wrapped around the blade disc.
Check the blade disc and remove any grass or other objects that
might prevent it spinning.
There is a build-up of grass in the
blade disc or motor frame box.
Make sure the blade disc rotates easily. If need be, you may take
off the blade disc and then remove the debris.
Recognition error Remove the obstacles, such as leaves.
The secondary area is
not mowed.
Programming error Make sure the RFIDs are installed correcly and reprogrammed.
There are obsacles between the
RFIDs in the pathway. Remove the obstacles.
The charging time is
far more than the rated
charging time.
Poor connection caused by
debris on the charging strip.
Clean the contact pins located on the charging pile and the char-
ging strip on Landroid Vision using a cloth.
The charging protection
program is activated due to high
temperature.
Place the charging base in a shady area or wait until the
temperature has cooled down.
The mower does not
charge. There is no power.
Check the power cord is connected properly to the charger and
the charger is connected to a suitable power supply.
Make sure both the charging strips on the mower touch the
center of the charging contacts on the charging pile.
Landroid Vision is starting
to have shorter run-times
between charges.
Something is clogging in the
blade disc creating friction and
increasing power consumption.
Take off the blade disc and clean it. Maybe the grass is too high
and too thick.
Landroid Vision is shaking heavily
because the blade disc is unba-
lanced.
Check the blade disc and blades, remove debris and foreign
objects from the blades and blade disc.
Replace the blades with a new set.
The battery may be exhausted
or old. Replace battery.
The working time is up. Reset the working time.
Landroid Vision is not
operating at the correct
time.
The clock is not set to the cor-
rect time. Set the clock to the correct time.
Programmed cutting times for
Landroid Vision are not correct. Change the time settings for the mower to start and stop.
The percentage of weekly ope-
rating time set through APP has
changed.
Set the correct percentage through APP.
Landroid Vision can not
find the charging base.
The direction of the charging
base is incorrect.
Make sure Landroid Vision dock right towards the charging base
and departures in anti-clockwise direction.
There are obsacles in front of the
charging base.
Please remove the obstacles within the 2m in front of the char-
ging base.
