woundwo TRENDLINE SMARTBOX User manual

JOINTED ARM AWNING
INSTRUCTIONS FOR USE
JOINTED ARM
AWNING
INSTRUCTIONS FOR USE
800281_EN

3
2
Last updated: October 2016 Print errors excepted. We reserve the right to make technical changes. © WOUNDWO Item no.: 800281_EN
WWW.WOUNDWO.COM
JOINTED ARM AWNINGS
INSTRUCTIONS FOR USE
JOINTED ARM AWNINGS
INSTRUCTIONS FOR USE
Page
1. BASIC INFORMATION............................................................................................................................................................ 2
2. EXPLANATION OF THE NOTICES ...........................................................................................................................................2
3. VALIDITY...............................................................................................................................................................................2
4. SAFETY ..........................................................................................................................................................................2 – 3
5. INTENDED USE.....................................................................................................................................................................3
6. PRODUCT INFORMATION ............................................................................................................................................... 3 – 4
7. OPERATION .........................................................................................................................................................................5
7.1 GENERAL SAFETY NOTICES ..................................................................................................................................................5
7.2 OPERATING THE CRANK DRIVE .............................................................................................................................................5
7.3 OPERATING THE ELECTRIC DRIVE ...........................................................................................................................................6
8. CLEANING / CARE...............................................................................................................................................................6
9. MAINTENANCE ...................................................................................................................................................................6
10. DISASSEMBLY .......................................................................................................................................................................6
11. EC CONFORMITY.................................................................................................................................................................6
12. DECLARATION OF PERFORMANCE ........................................................................................................................................7
13. PRODUCT IDENTIFICATION ...................................................................................................................................................8
All WOUNDWO awnings are designed and manufactured in line with the provisions set forth in the EN 13561 standard.
Nonetheless, dangers can arise for the people involved and/or the product can be impaired or other property damaged.
These instructions for use are valid for the following WOUNDWO standard jointed arm awnings:
SWINGLINE, SWINGLINE CASSETTE, FIRSTLINE, BASICLINE,
TOPLINE, TOPLINE PLUS, TOPLINE CASSETTE, WINGLINE, TRENDLINE, TRENDLINE SUNBOX, TRENDLINE SMARTBOX, TRENDLINE CASSETTE
Thank you for purchasing this WOUNDWO product.
You must have read and understood these instructions for use before commissioning the products to ensure failure-free permanent operation. The
notices in the instructions for use must be observed. Non-compliance shall release the manufacturer from its liability. Please also observe the
notices on the product and on the packaging.
We request that you keep all the instructions (instructions for assembly and use) and hand them over to the new owner should you sell the awning.
TABLE OF CONTENTS
1. BASIC INFORMATION
2. EXPLANATION OF THE NOTICES
3. VALIDITY
4. SAFETY
It is important to follow these instructions for people‘s safety. These instructions must be kept.
This symbol indicates notices that are important for people‘s safety or for the awning‘s function.
This symbol indicates important product information for the user.

3
2
Last updated: October 2016 Print errors excepted. We reserve the right to make technical changes. © WOUNDWO Item no.: 800281_EN
WWW.WOUNDWO.COM
JOINTED ARM AWNINGS
INSTRUCTIONS FOR USE
JOINTED ARM AWNINGS
INSTRUCTIONS FOR USE
WOUNDWO jointed arm awnings are primarily designed to protect against solar radiation. They can also be used as rain protection to a limi-
ted extent (see 7.1. for details). Any other use or use that extends beyond this shall be deemed improper. The manufacturer assumes no liability
for any resultant damages.
No changes, additions or conversions may be made to the jointed arm awnings without the manufacturer‘s consent. Jointed arm awning parts in
an imperfect condition must be replaced immediately. Only genuine spare parts specified by the manufacturer may be used. In the case of parts
sourced from third parties, there is no guarantee that these have been designed and manufactured in line with safety and loading requirements.
If the jointed arm awnings suffer additional loading as a result of suspended objects or the cord slackening, this can lead to the jointed arm
awnings malfunctioning and becoming damaged. Such actions are therefore impermissible.
Assembly and maintenance work may only be performed by qualified staff.
The connection must be fused and de-energised whilst inspecting or maintaining electrical parts.
WO&WO Sonnenlichtdesign GmbH & Co KG assumes no liability for damages caused by improper use.
5. INTENDED USE
Operating motorised operation awnings:
Do not allow children to play with the awning‘s control unit. Keep remote controls out of the reach of children.
Examine the equipment regularly for signs of wear or damage on the cables.
Observe the programming instructions of the supplied control units.
Do not use if a repair is required.
The product may only be operated as intended, in a technically perfect condition, in a safety- and risk-conscious manner and in
accordance with these instructions for use. Faults that could compromise safety are to be rectified immediately.
Manually operating awnings using a crank handle:
Take care when manually operating the retracted awning, as it can fall down quickly due to springs that are too weak or broken.
The electric motor is not designed for permanent operation. After approx. 4 minutes of operation, the thermal protection starts and
the motor switches off. The motor is ready for operation again after 15 – 30 minutes. However, the new actuation time is consi-
derably reduced, lasting 1 – 2 minutes.
PARAMETER VALUE
Mains voltage 230 V AC
Current consumption 0.45 – 2.1 A (depending on the drive)
Power consumption 90 – 460 W (depending on the drive)
Protection class – electric drive IP 44
Permanent operation – motor Approx. 4 minutes
DATA FOR THE ELECTRIC DRIVE
TECHNICAL DATA
The dimensions and technical details of jointed arm awnings can be found in the current catalogue available from specialist dealers, in the
instructions for assembly or in the WOUNDWO partner area at www.woundwo.com.
6. PRODUCT INFORMATION

5
4
Last updated: October 2016 Print errors excepted. We reserve the right to make technical changes. © WOUNDWO Item no.: 800281_EN
WWW.WOUNDWO.COM
JOINTED ARM AWNINGS
INSTRUCTIONS FOR USE
JOINTED ARM AWNINGS
INSTRUCTIONS FOR USE
The jointed arm awnings may only be used up to the wind resistance class declared by the manufacturer. The wind class may
only be downgraded due to poor assembly conditions in exceptional cases and with the end user‘s consent.
NOISE EMISSION
The sound pressure level of this awning when disassembled is less than 70 dB(A) when measured pursuant to EN ISO 12100-2:2003.
ACCESSORIES
The following accessories are available for WOUNDWO jointed arm awnings:
- Wireless remote control
- Automatic sun / wind / rain control
- Room thermostat
- Vario valance
- Light strip
- Radiant heater
Detailed information about the right accessories and how to integrate them is available from all WOUNDWO specialist dealers.
Depending on the product quality, awnings are divided into wind resistance classes to EN 13561 Section 4.1. The higher the class the higher the
product quality.
Wind resistance class Wind strength Wind speed
Class 0 undefined; product untested or unsuitable
Class 1 4 (on the Beaufort scale) 20 - 28 km/h
Class 2 5 (on the Beaufort scale) 29 - 38 km/h
WOUNDWO-Awnings and their components are designed and made to the provisions of EN 13561.
The different awning types are classified in different wind classes. The allocations of the products are defined as followed.
Classification of WOUNDWO awnings:
Projection in mm
Vario valance 1500 2000 2500 3000 3500 4000 4500
TOPLINE CASSETTE –2* 2* 2* 2* 2* 2 –
mit 2* 2* 2* 2 2 – –
TOPLINE PLUS –2* 2* 2* 2* 2* 2* 2
mit 2* 2* 2* 2* 2* 2 –
TOPLINE –2* 2* 2* 2* 2* 2* 2
mit 2* 2* 2* 2* 2* 2 –
TRENDLINE CASSETTE –2* 2* 2* 2 2 – –
TRENDLINE SUNBOX –22222– –
TRENDLINE SMARTBOX –22221– –
TRENDLINE –2* 2* 2* 2 2 – –
SWINGLINE CASSETTE –2* 2* 2 2 – – –
SWINGLINE –2* 2* 2 2 – – –
WINGLINE –2222222
FIRSTLINE –2 2 1 – – – –
BASICLINE –2 2 1 – – – –
FREELINE –2 valid up to 5000 mm projection
* Wind resistance class 3 until revision of the classification under DIN EN 13561 with effect from 01.07.2015.

5
4
Last updated: October 2016 Print errors excepted. We reserve the right to make technical changes. © WOUNDWO Item no.: 800281_EN
WWW.WOUNDWO.COM
JOINTED ARM AWNINGS
INSTRUCTIONS FOR USE
JOINTED ARM AWNINGS
INSTRUCTIONS FOR USE
When working in the area surrounding the jointed arm awning‘s deployment area, the automatic control (wind, sun control) must be switched
off with a monitored, priority switching locking device (e.g. key switch), such that the jointed arm awning cannot be extended when control-
led automatically.
Jointed arm awnings should be retracted at night and before leaving home.
Do not extend jointed arm awnings in freezing, snowy or very windy conditions. Jointed arm awnings can be used as rain protection to a
limited extent. For this, the awning must be fully extended and the minimum incline is 14° (25%). Unsupervised use as rain protection is not
permissible, as it is not entirely possible to exclude the formation of water pockets.
Jointed arm awnings may only be operated by persons who have received instruction from specialist staff. Ensure that children do not operate
the awning unattended. Keep remote controls out of the reach of children.
Fixed objects must be at least 40 cm away from the extension area of the drop profile.
The Vario valance (an optional accessory) must be rolled up before the jointed arm awning is retracted.
7. OPERATION
7.1 GENERAL SAFETY NOTICES FOR OPERATING JOINTED ARM AWNINGS
a) Series TOPLINE (TOPLINE, TOPLINE PLUS, TOPLINE CASSETTE):
TRENDLINE (TRENDLINE, TRENDLINE CASSETTE):
EXTENDING THE AWNING: Hook the crank handle into the gearbox eye and extend the awning by turning the crank anti-clockwise until the aw-
ning reaches either the desired or the end position. The awning‘s end position (fully extended) is permanently set in the factory. The awning cloth re-
mains tensioned at all times during this process. If the awning cloth loses tension, the tension should be restored by retracting the jointed arm awning.
RETRACTING THE AWNING: Turn the crank handle anti-clockwise until the awning is closed.
When the inside and outside end positions have been reached, do not continue to forcibly turn the crank handle. There is the risk of
damages to the gearbox and of the cloth overexpanding or folding.
b) Series SWINGLINE (SWINGLINE, SWINGLINE CASSETTE)
EXTENDING THE AWNING: Hook the crank handle into the gearbox eye and extend the awning by turning the crank anti-clockwise until the free-
wheel reaches the end point and the cloth is relieved of tension. Briefly turning back achieves the best cloth tension.
RETRACTING THE AWNING: Turn the crank handle anti-clockwise until the awning is closed.
c) Series FIRSTLINE, BASICLINE
EXTENDING THE AWNING: Hook the crank handle into the gearbox eye and extend the awning by turning the crank anti-clockwise until the end
point is reached and the cloth is tensioned.
RETRACTING THE AWNING: Turn the crank handle anti-clockwise until the awning is closed.
The crank gearboxes of the SWINGLINE series of awnings have no end stop on the front, but a freewheel to prevent
incorrect cloth winding. At this point, however, the cloth can sag without any tension.
These crank gearboxes have no end stop on the front to prevent incorrect cloth winding. At this point, however, the cloth can sag
without any tension.
Do not continue to forcibly turn the crank handle when it reaches the end positions inside. There is a risk of damages to the gearbox
and of the cloth overexpanding or folding. This is prevented on the outside by the freewheel.
Do not continue to forcibly turn the crank handle when it reaches the end positions inside. There is a risk of damages to the gearbox
and of the cloth overexpanding or folding.
7.2 OPERATING JOINTED ARM AWNINGS WITH A CRANK DRIVE

7
6
Last updated: October 2016 Print errors excepted. We reserve the right to make technical changes. © WOUNDWO Item no.: 800281_EN
WWW.WOUNDWO.COM
JOINTED ARM AWNINGS
INSTRUCTIONS FOR USE
JOINTED ARM AWNINGS
INSTRUCTIONS FOR USE
Product: Terrace awnings
Intended purpose: Awnings for outdoor use
Corresponds to the provisions set forth in the Machinery Directive 2006/42/EC if featuring a motor drive.
The following harmonised standards were applied:
EN 13561 External blinds – Performance requirements including safety
EN 60335-2-97 Household and similar electrical appliances – Safety
EN 12045 Shutters and blinds, power-operated
Conformity with the following Directives:
Electromagnetic Compatibility Directive 2004/108/EC
Compliance with the safety objectives set forth in the Low Voltage Directive 2006/95/EC was ensured according to Annex I, No. 1.5.1 of the
Machinery Directive 2006/42/EC.
Manufacturer: WO&WO Sonnenlichtdesign GmbH & Co KG, Hafnerstraße 193, 8054 Graz, Austria
Prok. Martin Seifert Graz, July 2014
Authorised representative
EXTENDING THE AWNING: Press (and hold) the operating element and extend the jointed arm awning until it reaches either the desired or the end
shading position. The end position is reached when the motor switches off.
RETRACTING THE AWNING: Press (and hold) the operating element and retract the jointed arm awning until it reaches either the desired or the
end shading position. The end position is reached when the motor switches off. Please refer to the documentation for control and operating units for
additional notices about special functions.
CLEANING THE PRODUCT: Dirt can be removed from the jointed arm awning using a soft brush or hand brush. Clean the awning cloth using a fine
liquid detergent and rinse thoroughly with cold water. The frame of the jointed arm awning can be cleaned using a commercially available cleaner and
wiped with a damp cloth. The awning cloth must be left to dry after cleaning.
No high-pressure cleaners, scouring agents or scouring pads should be used for cleaning!
Solvents such as alcohol or benzine must not be used!
Use suitable climbing aids and de-energise the drive motor!
Remove the cover for the lateral part from the cassette before cleaning the TRENDLINE SMARTBOX!
Reliable and safe use of the jointed arm awning can only be guaranteed if the system is checked and maintained on a regular basis.
The jointed arm awning is to be checked regularly for signs of wear and damage on the cover and frame. If damages are found, the specialist dealer
or a suitable servicing company is to be tasked with the repair work. Jointed arm awnings needing repair must not be operated.
7.3 OPERATING JOINTED ARM AWNINGS WITH AN ELECTRIC DRIVE
8. CLEANING AND CARE
9. MAINTENANCE
Improper assembly activities can result in personal injury or property damage.
Only have a WOUNDWO specialist dealer perform disassembly work.
Please refer to the product instructions for assembly for specifications / notices.
10. DISASSEMBLY
When the system is being handed over, specialist staff must provide instruction on operating the electric drive. During this process, an
explanation of how the operating elements are assigned is provided.
11. EC DECLARATION OF CONFORMITY PURSUANT TO THE MACHINERY DIRECTIVE 2006/42/EC
(APPLIES TO MOTORISED OPERATION ONLY)

7
6
Last updated: October 2016 Print errors excepted. We reserve the right to make technical changes. © WOUNDWO Item no.: 800281_EN
WWW.WOUNDWO.COM
JOINTED ARM AWNINGS
INSTRUCTIONS FOR USE
JOINTED ARM AWNINGS
INSTRUCTIONS FOR USE
12. DECLARATION OF PERFORMANCE (DOP NO. 210011306)
Identification code
for the product type: JOINTED ARM AWNING
(TOPLINE CASSETTE, TOPLINE PLUS, TOPLINE;
TRENDLINE CASSETTE, TRENDLINE SUNBOX, TRENDLINE, TRENDLINE SMARTBOX;
SWINGLINE CASSETTE, SWINGLINE; FIRSTLINE; BASICLINE; WINGLINE)
Intended purpose: Awning for outdoor use
Manufacturer: WO&WO Sonnenlichtdesign GmbH & Co KG, Hafnerstraße 193, 8054 Graz, Austria
Authorised representative: Prok. Martin Seifert
Certification: According to Rating System 4 of the Construction Products Regulation 305/2011/EC
Declared performance: Wind resistance class 0 – 2 pursuant to EN 13561
The order‘s delivery slip, on which the product-specific wind resistance classes per order item are printed, serves as a supplement to this Declaration of
Performance. When used as intended, the product satisfies the essential properties defined in the following standards.
Harmonised standard: EN 13561 External blinds – Performance requirements including safety
Prok. Martin Seifert Graz, July 2014
Authorised representative
Wind resistance class Wind strength Wind speed
Class 0 Undefined; product unchecked or unsuitable
Class 1 4 (according to the Beaufort scale) 20 – 28 km/h
Class 2 5 (according to the Beaufort scale) 29 – 38 km/h

Publisher: WO&WO Sonnenlichtdesign GmbH & Co KG, content: WO&WO Sonnenlichtdesign GmbH & Co KG, place of publication: 8054 Graz, Austria.
Print errors excepted.
We reserve the right to make technical changes.
WWW.WOUNDWO.COM
Österreich
Tel [phone] - 0
Fax [phone] - 8100
Deutschland
Tel [phone] - 0
WO&WO Sonnenlichtdesign GmbH & Co KG
Hafnerstraße 193, 8054 Graz, AUSTRIA
[email protected]
To make subsequent enquiries or suggestions about the product easier, the product data should be documented by the specialist
dealer.
Product description
mFIRSTLINE
mBASICLINE
mSWINGLINE
mSWINGLINE CASSETTE
mTRENDLINE
mTRENDLINE CASSETTE
mTRENDLINE SUNBOX
mTRENDLINE SMARTBOX
mTOPLINE
mTOPLINE PLUS
mTOPLINE CASSETTE
mWINGLINE
WOUNDWO order number
Assembly date
Handed over by / on:
(Specialist dealer‘s stamp and signature)
13. PRODUCT IDENTIFICATION
