Woxcon MUH88A-H2 User manual

MUH88A-H2
4K 8x8 HDMI2.0 Matrix Switcher
All Rights Reserved
Version: MUH88A-H2_2018V1.2
User Manual

4K 8x8 HDMI2.0 Matrix Switcher
Preface
Read this user manual carefully before using the product. Pictures shown in this
manual is for reference only. Different models and specifications are subject to real
product.
This manual is only for operation instruction only. The functions described in this
version are updated till December 11, 2016. In the constant effort to improve our
product, we reserve the right to make functions or parameters changes without notice
or obligation. Please refer to the dealers for the latest details.
Trademarks
Any other trademarks mentioned in this manual are acknowledged as the properties of
the trademark owner. No part of this publication may be copied or reproduced without
the prior written consent.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a commercial
installation.
Operation of this equipment in a residential area is likely to cause interference, in which
case the user at their own expense will be required to take whatever measures may be
necessary to correct the interference
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.

4K 8x8 HDMI2.0 Matrix Switcher
SAFETY PRECAUTIONS
To i n s u r e t h e best from the product , p l e a s e read all instr u c t i o n s carefully before u s i n g
the device. Save this manual for further reference.
l Unpack the equipment carefully and save the original box and packing material for
possible future shipment
l Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
l Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
l Using supplies or parts not meeting the products’ specifications may cause
damage, deterioration or malfunction.
l Refer all servicing to qualified service personnel.
l To prevent f i r e o r shock hazard, do not e x p o s e t h e un it to rain, m o i s t u r e or install
this product near water.
l Do not put any heavy items on the extension cable in case of extrusion.
l Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
l Install the device in a place with fine ventilation to avoid damage caused by
overheat.
l Keep the module away from liquids.
l Spillage into the housing may result in fire, electrical shock, or equipment damage.
If an object or liquid falls or spills on to the housing, unplug the module immediately.
l Do not twist or pull by force ends of the optical cable. It can cause malfunction.
l Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
l Unplug the power cord when left unused for a long period of time.
l Information on disposal for scrapped devices: do not burn or mix with general
household waste, please treat them as normal electrical wastes.

4K 8x8 HDMI2.0 Matrix Switcher
Contents
1. Introduction .................................................................................................................. 1
1.1 Brief Introduction ................................................................................................ 1
1.2 Features ............................................................................................................. 1
1.3 Package List ....................................................................................................... 1
2. Panel Description ........................................................................................................ 2
2.1 Front Panel ......................................................................................................... 2
2.2 Rear Panel ......................................................................................................... 3
3. System Connection ..................................................................................................... 4
3.1 Usage Precautions ............................................................................................. 4
3.2 Connection Diagram ........................................................................................... 4
3.3 Connection Procedure ........................................................................................ 4
3.4 System Applications ........................................................................................... 5
4. Panel Button Control ................................................................................................... 6
4.1 I/O connection switching .................................................................................... 6
4.2 EDID Configuration ............................................................................................ 6
4.3 I/O connection Inquiry ........................................................................................ 7
5. IR Control .................................................................................................................... 8
6. RS232 Control ............................................................................................................. 9
6.1 Installation/uninstallation of RS232 Control Software ........................................ 9
6.2 Basic Settings ..................................................................................................... 9
6.3 RS232 Communication Commands ................................................................. 11
6.3.1 System Commands ................................................................................ 11
6.3.2 Lock/unlock Commands ......................................................................... 12
6.3.3 Switching Commands ............................................................................ 12
6.3.4 Scene Commands .................................................................................. 14
6.3.5 HDCP Compliance ................................................................................. 15
6.3.6 EDID Configuration ................................................................................ 16
6.3.7 Enable/disable Digital Audio ................................................................... 18
7. TCP/IP Control ........................................................................................................... 19

4K 8x8 HDMI2.0 Matrix Switcher
7.1 Control Modes .................................................................................................. 19
7.2 TCP/IP Communication Software Control ........................................................ 20
7.3 Web-based GUI Control ................................................................................... 23
7.3.1 Scene Setting ......................................................................................... 25
7.3.2 I/O connection switching ........................................................................ 26
7.3.3 EDID Configuration ................................................................................ 27
7.3.4 Audio Output .......................................................................................... 28
7.3.5 Status Setting ......................................................................................... 29
7.3.6 Network Configuration ............................................................................ 30
7.3.7 Password Modification ........................................................................... 31
7.4 TCP/IP Configuration ....................................................................................... 31
7.5 GUI Update ...................................................................................................... 32
8. Firmware Upgrade through USB port ........................................................................ 33
9. Specification .............................................................................................................. 34
10. Panel Drawing ......................................................................................................... 35
11. Troubleshooting & Maintenance .............................................................................. 36
12. Customer Service .................................................................................................... 38

4K 8x8 HDMI2.0 Matrix Switcher
1
1. Introduction
1.1 Brief Introduction
This product is a professional 4K 8x8 HDMI2.0 Matrix Switcher with 8 HDMI inputs, 8
HDMI outputs, and 8 SPDIF audio outputs, which is designed for switching four
HDMI2.0 and HDCP2.2 compliant signals. It also provides powerful EDID management
to ensure reliable AV distribution and routing.
You can control t he unit via the front pa nel , IR, RS232, TCP/IP and web-based GUI.
1.2 Features
l 8 SPDIF ports provide de-embedded HDMI audio output;
l Supports 4Kx2K@60Hz 4:4:4 & 1080p 3D signals;
l Supports HDMI 2.0, HDCP2.2 compatible, and is backward compatible to the earlier
versions;
l Transmits 4Kx2K@60Hz 4:4:4 signal up to 16.4 feet (5m) via HDMI port;
l Provides powerful EDID management, built-in EDID can be invoked via DIP
switcher on rear panel, RS232 command or web-based GUI;
l Controllable via front panel button, IR, RS232, TCP/IP or web-based GUI;
l LCD screen shows real-time I/O connection status;
l Convenient firmware upgrade through Micro USB port;
l Easy installation with rack-mounting design.
1.3 Package List
l 1 x 8x8 HDMI2.0 Matrix Switcher
l 2 x Mounting ears
l 6 x Screws
l 4 x Plastic cushions
l 1 x RS232 cable (3-pin to DB9)
l 1 x IR receiver
l 1 x IR remote
l 1 x Power adaptor(DC 24V 2.71A)
l 1 x User manual
&
Confirm if the product and the accessories are all included, if not, please contact
with the dealers.

4K 8x8 HDMI2.0 Matrix Switcher
2
2. Panel Description
2.1 Front Panel
Figure 2- 1 Front Panel
No.
Name
Description
①
Firmware
Micro USB port for updating firmware.
②
Power Indicator
l Illuminates red when power on;
l Turns green in standby mode;
l Blinks red when upgrading.
③
IR sensor
Built-in IR sensor, receive IR signal sent from IR
remote.
④
LCD Screen
Displays real-time operation status.
⑤
INPUT selector button
Total 8 input selector buttons, press one of
buttons to switch input source.
⑥
OUTPUT selector button
Total 8 output selector buttons, press the
buttons to select output channel.
&
Pictures shown in this manual are for reference only.
INPUTS
OUTPUTS
FIRMWARE
1 2 3 4 56 7 8
1 2 4 6
35

4K 8x8 HDMI2.0 Matrix Switcher
3
2.2 Rear Panel
Figure 2- 2 Rear Panel
No.
Name
Description
①
INPUTS
HDMI input ports, 8 in total, connect with HDMI
sources.
②
OUTPUTS
SPDIF: audio output ports for de-embedded HDMI
audio, 8 in total.
HDMI: 8 in total, connect with HDMI displays.
③
Control
EDID: 4-pin EDID DIP switchers to set EDID data, “1”
stands for “On”, “0” stands for “Off”. Refer to 4. 2 EDID
Configurarion for more detials.
RS232: Serial control port, connect with control device.
IR IN: Connects with external IR receiver for using the
IR remote to control the Matrix Switcher.
TCP/IP: TCP/IP port for unit control.
④
DC 24V
Connect with 24VDC 2.71A power adaptor.
⑤
Ground
Connect to ground.
&
Pictures shown in this manual are for reference only.
ON DIP
TCP/IP IR IN R S 2 3 2
Tx Rx
On
Off
1 2 34
1
0
EDID
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
SPDIF SPDIF SPDIF SPDIF SPDIF SPDIF SPDIF SPDIF
DC 2 4V
INPUTS OUTPUTS
CONTROL
124
3

4K 8x8 HDMI2.0 Matrix Switcher
4
3. System Connection
3.1 Usage Precautions
l System should be installed in a clean environment with prop temperature and
humidity.
l All of the power switches, plugs, sockets and power cords should be insulated.
l All devices should be connected before power on.
3.2 Connection Diagram
Figure 3- 1 Connection diagram
3.3 Connection Procedure
Step1. Connect HDMI sources (e.g. DVD/PS4/Laptop) to HDMI input ports with HDMI
cables;
Step2. Connect HDMI displays (e.g. HDTV/Projector) to HDMI output ports with HDMI
cables;
Step3. Connect speakers/ amplifiers to the SPDIF audio outputs with Toslink cables;
Step4. Connect the RS232 ports of the control device (e.g. Central Control System, PC)
and the Matrix Switcher to enable serial control.
ON DIP
TCP/IP IR IN R S 2 3 2
Tx Rx
On
Off
1 2 3 4
1
0
EDID
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
SPD IF S PDIF SPD IF SPDI F SPDI F SPD IF SP DI F SPD IF
DC 24 V
INPUTS OUTPUTS
CONTROL
Central Co ntr ol Sy stem
Router
Speaker
DVD Laptop
Laptop
HDTV
INPUTS
OUTPUTS
MENU
123
4 5 6
7 8
1 2 3
4 5 6
7 8
ALL EDID
CLEAR ENTER
Projector
HDMI:
IR Contr ol:
RS232:
Ethernet:
Audio:

4K 8x8 HDMI2.0 Matrix Switcher
5
Step5. Insert an IR receiver to the IR IN port to control this switcher via IR Remote.
Step6. Connect the TCP/IP ports of the control device (e.g. Laptop) and the Matrix
Switcher to enable TCP/IP control.
Step7. Plug a 24VDC power adapter to the DC24V power port.
&
l When connecting to HDMI2.0 sources, make sure the HDMI cable is compliant with
HDMI2.0 to ensure reliable transmission;
l Connect amplifiers that are capable to decode HDMI audio to the SPDIF ports, or
there will be no output on the amplifiers.
3.4 System Applications
As its good performance in control and transmission, the Matrix Switcher can be widely
used in computer realm, monitoring, large screen displaying, conference system,
television education and bank securities institutions etc.

4K 8x8 HDMI2.0 Matrix Switcher
6
4. Panel Button Control
4.1 I/O connection switching
The front panel features four input selection buttons and four output selection buttons
for switching I/O connection.
1) To convert one input to an output:
Example: Input 1 to Output 3
→ Press INPUTS 1 + OUTPUTS 3
2) To convert an input to several outputs:
Example: Convert Input 2 to Output 3 and 4
→ Press INPUTS 2 + OUTPUTS 3 + OUTPUTS 4
NOTE: Indicators of the pressed buttons will blink green for three times if the
conversion is done, then it will be off. If the conversion failed, they will be off
immediately.
4.2 EDID Configuration
The rear panel boasts a 4-pin EDID DIP switcher to manage EDID. The EDID data and
its corresponding DIP switcher status are shown in the below list.
DIP Switcher
NO.
Status
EDID
0
0000
Pass though (default)
1
0001
720P 2D Pass-through CH
2
0010
720P 3D Pass-through CH
3
0011
1080P 2D Pass-through CH
4
0100
1080P 3D Pass-through CH
5
0101
4K@30HZ Pass-through CH
6
0110
4K@30HZ 2.0CH
7
0111
4K@30HZ 7.1CH
8
1000
4K@60HZ 4:2:0 Pass-through CH
9
1001
4K@60HZ 4:2:0 7.1CH
10
1010
4K@60HZ 4:4:4 Pass-through CH
11
1011
4K@60HZ 4:4:4 7.1CH

4K 8x8 HDMI2.0 Matrix Switcher
7
-
1111
Enable Software EDID
management mode: RS232 control
or Web-based GUI control.
4.3 I/O connection Inquiry
Press OUTPUTS button 1, 2, 3, 4,5,6,7 or 8 to inquiry its corresponding input, and then
the indicator of the input button will turn green.

4K 8x8 HDMI2.0 Matrix Switcher
8
5. IR Control
The Matrix Switcher features one built-in IR receiver to receive IR signal from IR remote
to enable IR control. If the external IR receiver or other IR control device need to be
used, the IR IN port on rear panel can be connected.
① Standby button:
Press it to enter/ exit standby mode.
② INPUTS:
Input channel selection buttons, same with the
corresponding front panel buttons
③ OUTPUTS:
Output channel selection buttons, same with the
corresponding front panel buttons.
④ Menu buttons:
l ALL: Select all inputs/outputs.
To convert an input to all outputs:
Example: Input 1 to all Outputs:
→ Press INPUTS 1 + ALL + ENTER
l EDID management button:
1) One input port learns the EDID data from one
output port.
Example: Input 2 learns EDID data from output 4:
→ Press EDID + INPUTS 2 + OUTPUTS 4+ ENTER
2) All input ports learn EDID data from one output
port.
Example: All input ports learn EDID data from output
3:
→ Press EDID + ALL + OUTPUTS 3 + ENTER
l CLEAR: Withdraw button.
l ENTER: Confirm operation.
INPUTS
OUTPUTS
MENU
1 2 3
456
7 8
1 2 3
456
7 8
ALL EDID
CLEAR ENTER
1
2
3
4

4K 8x8 HDMI2.0 Matrix Switcher
9
6. RS232 Control
6.1 Installation/uninstallation of RS232 Control Software
l Installation Copy the control software file to the computer connected with the
Matrix Switcher.
l Uninstallation Delete all the control software files in corresponding file path.
6.2 Basic Settings
Firstly, connect the Matrix Switcher with necessary input devices and output devices.
Then, connect it with a PC installed RS232 control software. Double-click the software
icon to run this software.
Here we take the software CommWatch.exe as example. The icon is showed as
below:
Figure 6-1 Icon of CommWatch
The interface of the control software is showed as below:
Parameter Configuration
area
Monitoring area, indicates
whether the command
sent works.
Command Sending area

4K 8x8 HDMI2.0 Matrix Switcher
10
Figure 6-2 Control Interface of CommWatch

4K 8x8 HDMI2.0 Matrix Switcher
11
Set the parameters (baud rate, data bit, stop bit and parity bit) correctly to ensure
reliable RS232 control.
6.3 RS232 Communication Commands
&
l Case-sensitive.
l “[“, “]” in the commands are for easy recognition only and not necessary in real
operations. Other symbols including “.”, “,”, “/”, “%”, “;”, “^”. are parts of the
commands.
l Feedbacks listed in the column “Feedback Example” are only for reference,
feedbacks may vary according to different operations.
l Dial the EDID switcher to “1111” before sending commands pertaining to software
EDID management (with grey background)
Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none
6.3.1 System Commands
Command
Function
Feedback Example
/*Type;
Query the model.
XXXXX
/^Version;
Query the version of firmware
VX.X.X
Demo.
Switch to the “demo” mode, convert
input and output in turn like1B1,
1B2, …4B3, 4B4, 1B1… and so
on .The switching interval is 2
seconds.
Demo Mode
AV:01->01
AV:01->02
AV:01->03
AV:01->04
AV:02->01
…
Normal Mode
Undo.
To cancel t h e current operation.
Undo Ok!
PWON.
Work in normal mode.
PWON
PWOFF.
Enter into standby mode, send the
PWOFF

4K 8x8 HDMI2.0 Matrix Switcher
12
“PWON.” to start.
STANDBY.
Enter into standby mode, press other
buttons or send other commands to
start.)
STANDBY
%9962.
Query the power status
STANDBY/PWOFF/
PWON
%9964.
Query the IP address.
IP:XXX.XXX.X.XXX
%0911.
Reset to factory default.
Factory Default
6.3.2 Lock/unlock Commands
Command
Function
Feedback Example
/%Lock;
Lock the front panel buttons.
System Locked!
/%Unlock;
Unlock the front panel buttons.
System Unlock!
%9961.
Query the system locking status.
System Locked/
Unlock!
6.3.3 Switching Commands
Command
Function
Feedback Example
[x]All.
Transfer signals from the input
channel [x] to all output channels.
(x=1~8)
02 To A l l .
All#.
Transfer all input signals to the
corresponding output channels
respectively like 1->1, 2->2…
All Through.
All$.
Switch off all the output channels.
All Closed.
[x]#.
Transfer signals from the input
channel [x] to the output channel [x].
(x=1~8)
04 Through.
[x]$.
Switch off the output channel [x].
(x=1~8)
02 Closed.
[x]@.
Switch on the output channel [x].
(x=1~8)
02 Open.
All@.
Switch on all output channels.
All Open.
Out 01 02 03 04
In 01 01 01 01
Out 05 06 07 08

4K 8x8 HDMI2.0 Matrix Switcher
13
In 01 01 01 01
[x1]V[x2].
Switch the input channel [x1] to one
or several output channels ([x2],
separate output channels with
comma). (x1/x2=01~08)
AV: X1-> X2
(AV: 02-> 04)
Status[x].
Query the I/O connection status of
output [x]. (x=1~8, y=1~8)
AV: Y-> X
(AV: 04-> 02 )
Status.
Query the input channel to the output
channels one by one.
AV:01->01
AV:01->02
AV:01->03
AV:01->04
AV:01->05
AV:01->06
AV:01->07
AV:01->08
%9971.
Query the connection status of the
inputs.
In 01 02 03 04
Connect Y N Y Y
In 05 06 07 08
Connect Y Y Y N
%9972.
Query the connection status of the
outputs.
Out 01 02 03 04
Connect Y Y Y Y
Out 05 06 07 08
Connect Y Y Y Y
%9975.
Query the I/O connection status.
Out 01 02 03 04
In 03 03 03 03
Out 05 06 07 08
In 03 03 03 03
%9976.
Query the output resolution.
Resolution
Out 1 3840x2160P
Out 2 3840x2160P
Out 3 3840x2160P

4K 8x8 HDMI2.0 Matrix Switcher
14
Out 4 3840x2160P
Out 5 3840x2160P
Out 6 3840x2160P
Out 7 3840x2160P
Out 8 3840x2160P
6.3.4 Scene Commands
Command
Function
Feedback Example
Save[Y].
Save the present operation to the
preset command [Y], ranges from 1 to
10.
Save To F6
Recall[Y].
Recall the preset command [Y].
Recall From F2
Clear[Y].
Clear the preset command [Y].
Clear F8

4K 8x8 HDMI2.0 Matrix Switcher
15
6.3.5 HDCP Compliance
Command
Function
Feedback Example
/%[Y]/[X]:[Z]
.
HDCP management command.
Y=O is for output;
X=1~8 is the number of the port, if the
X=ALL, it means all ports;
Z is for HDCP compliant status, the
value may be 1 (HDCP compliant) or
0 (not HDCP compliant).
/%[Y]/[X]:[Z].
%0801.
Auto HDCP management, activate
carrier native mode
%0801
%9973.
Query the HDCP status of the input
signals.
In 01 02 03 04
HDCP Y N Y N
In 05 06 07 08
HDCP Y Y Y N
%9974.
Query the HDCP status of the output
signals.
Out 01 02 03 04
HDCP Y Y Y Y
Out 05 06 07 08
HDCP Y Y Y Y
