Wpg Mt1tl6fair User manual

Rev 9.0/5-23 MT1TL6FAIR: #350801

INTENDED FOR USE BY SKILLED

PROFESSIONALS • READ AND

UNDERSTAND BEFORE OPERATING

OPERATING

INSTRUCTIONS 908 W. Main • P.O. Box 368

Laurel, MT USA 59044

800-548-7341 (phone)

406-628-8231 (phone)

406-628-8354 (fax)

www.WPG.com

Record serial number in blank space above (to locate, see serial

label on the product).

MANUAL TILTER,

AIR-POWERED

Model number: MT1TL6FAIR

KEEP FOR FUTURE REFERENCE

MT1TL6FAIR: #35080 Rev 9.0/5-232

Rev 9.0/5-23 MT1TL6FAIR: #350801

SPECIFICATIONS .....................................................................................3

SAFETY...................................................................................................5

OPERATING FEATURES............................................................................6

ASSEMBLY..............................................................................................7

INTENDED USE .....................................................................................10

LOAD CHARACTERISTICS...............................................................................10

INDIRECT LOADING .....................................................................................11

OPERATING ENVIRONMENT..........................................................................11

DISPOSAL OF THE LIFTER .............................................................................11

OPERATION..........................................................................................12

BEFORE USING THE LIFTER...........................................................................12

Taking Safety Precautions .................................................................................................12

Performing Inspections and Tests .....................................................................................12

TOATTACH THE PAD TO ALOAD ...................................................................13

Generating Airflow............................................................................................................13

Positioning the Lifter on the Load.....................................................................................13

Sealing the Pad on the Load .............................................................................................14

Reading the Vacuum Gauge..............................................................................................14

TOLIFT AND MOVE THE LOAD......................................................................15

Interpreting the Vacuum Gauge .......................................................................................15

Monitoring the Vacuum Gauge.........................................................................................15

Controlling the Lifter and Load .........................................................................................15

In Case of a Power Failure.................................................................................................16

TOTILT THE LOAD ......................................................................................16

TOLAND THE LOAD ....................................................................................16

TORELEASE THE PAD FROM THE LOAD ...........................................................17

AFTER USING THE LIFTER.............................................................................18

Storing the Lifter ...............................................................................................................18

Transporting the Lifter ......................................................................................................18

INSPECTIONS AND TESTS......................................................................19

INSPECTION SCHEDULE ................................................................................19

TESTING ...................................................................................................20

TABLE OF CONTENTS

MT1TL6FAIR: #35080 Rev 9.0/5-232

Lifter/Load Compatibility Test...........................................................................................20

Operational Tests ..............................................................................................................21

Vacuum Test......................................................................................................................21

Rated Load Test.................................................................................................................22

MAINTENANCE ....................................................................................23

VACUUM PAD MAINTENANCE.......................................................................23

Pad-to-Load Friction Coefficient .......................................................................................23

Pad Inspection ..................................................................................................................23

Pad Cleaning .....................................................................................................................24

REPLACEMENT PARTS...........................................................................25

REGISTRATION AND LIMITED WARRANTY ............................................26

TOREGISTER THIS WPG PRODUCT ...............................................................26

ABOUT THE LIMITED WARRANTY ..................................................................26

Obtaining Warranty Service or Repair Service..................................................................26

TABLE OF CONTENTS

Rev 9.0/5-23 MT1TL6FAIR: #350803

SPECIFICATIONS

Product

Description

Designed for use with hoisting equipment, the MT1TL6FAIR lifter supports loads using vacuum and

manipulates loads using manual 90° tilt motions.

Model

Number MT1TL6FAIR

Vacuum Pad /

Pad Spread

(standard rubber1

1...... Available with other rubber compounds for special purposes (see wpg.com).

)

6" [15 cm] nominal diameter, concave (Model TL6F)

Maximum Load

Capacity2

2...... The Maximum Load Capacity is rated at a vacuum of 16" Hg [-54 kPa] on clean, smooth, nonporous flat surfaces with a friction coefficient of 1. Pad

compound, load rigidity, strength, surface conditions, overhang, angle, center of gravity and temperature can also affect the lifting capacity. A “qualified

person” should evaluate the effective lifting capacity for each use (see definition under “Rated Load Test”).

50 lbs [25 kg]

Lifter

Weight3

3...... Total product weight (ie, including vacuum system) is 5.4 lbs [2.45 kg]

3.25 lbs [1.47 kg]

Power

Source Compressed air, 80-150 psi [550-1035 kPa] line pressure, 2 SCFM [57 liters/minute] @ 80 psi [550 kPa]

Tilt

Capability Manual, 90°

Operating

Elevation Up to 6,000' [1,828 m]

Operating

Temperatures 32° — 120° F [0° — 49° C]

Service

Life 20,000 lifting cycles, when used and maintained as intended4

4...... Vacuum pad, filter elements and other wear-out items are excluded.

ASME Standard

BTH-1 Design Category "B", Service Class "0"

Troubleshooting

Guide5

5...... To view this guide, click the link at right. Additionally, you can search for your lifter's Model Number at wpg.com and select the “Troubleshooting” link on

the product page.

TST-016_GENERIC_LEAK_TEST_rev_2014-086

MT1TL6FAIR: #35080 Rev 9.0/5-234

SPECIFICATIONS

Rev 9.0/5-23 MT1TL6FAIR: #350805

SAFETY

Wear personal protective equipment

that is appropriate for the load

material. Follow trade association

guidelines.

Do not remove or obscure safety

labels.

Do not make any modifications to the

lifter (see “LIMITED WARRANTY”).

Use the lifter only in an approved

“OPERATING ENVIRONMENT” (see

“INTENDED USE”).

Make sure to consider all possible

effects of “INDIRECT LOADING” on lifting

capacity (see “INTENDED USE”).

Do not use a lifter that is damaged,

malfunctioning, or missing parts.

Do not use a lifter if the sealing edge

of any vacuum pad is cut or otherwise

damaged.

Do not use a lifter to lift cracked or

broken glass.

Do not exceed the Maximum

Load Capacity or lift loads the

lifter is not designed for (see

“INTENDED USE”).

Do not use a lifter if the

Maximum Load Capacity or any

safety label appears to be

missing or obscured.

Make sure the contact surfaces of the

load and vacuum pad are clean before

attaching the lifter (see

“MAINTENANCE”).

Position the vacuum pad correctly on

the load before lifting (see

“OPERATION”).

Do not lift a load if any vacuum

indicator shows inadequate vacuum.

Keep unauthorized personnel away

from the lifter, to avoid injury in case

of an unintended load release.

Do not touch the vacuum release

controls during a lift.

Do not allow people to ride on the

lifter or the load.

Do not lift a load higher than

necessary or leave suspended loads

unattended.

Do not position a loaded or unloaded

lifter over people.

Before servicing a powered lifter, place

the power control in the inactive

position and, when possible,

disconnect the power source.

MT1TL6FAIR: #35080 Rev 9.0/5-236

OPERATING FEATURES

Features shown here are underlined on their first appearance in each section following.

1 AIR SUPPLY VALVE 2 LIFT BRACKET 3 VACUUM GAUGE

4 CONTROL HANDLE 5 VACUUM PAD 6 PRESSURE GAUGE

7 AIR FILTERS 8 VACUUM PUMP 9 AIR PRESSURE REGULATOR

Note: A standard MT1TL6FAIR is shown. Although some of the following photos do not show this

specific lifter, they all illustrate how this kind of lifter functions.

For information about specific parts, see “REPLACEMENT PARTS” and/or any separate

instructions for Product Options.

Rev 9.0/5-23 MT1TL6FAIR: #350807

ASSEMBLY

1) Remove all shipping materials and save them with the shipping container for future use.

2) Suspend the lifter from appropriate hoisting equipment:

2.1) Select a crane and/or hoist rated for the Maximum Load Capacity plus

the Lifter Weight.

Note: Any lifter use must comply with all statutory or regulatory standards for

hoisting equipment in your region.

2.2)

Make sure hook has restraining latch

(arrow in fig. 2B).

Only use rigging rated for Maximum

Load Capacity plus Lifter Weight.

Attach the hoisting hook to the eye

of the lift bracket (arrow in fig. 2A).

Use a clevis if the eye is too small

for the hook.

Note: Use rigging (figs. 2B-C) as

needed tomake sure the hook does not interfere with the load.

Remove the pad cover (fig. 3A) and save it for future use.

Mount the vacuum generating system in a location suitable

for operating both the lifter and the hoisting equipment

(mounting hardware not supplied; mounting holes are

shown in fig. 4A).

Securely position vacuum hose to avoid damage

during lifter operation.

Note: Consult the hoisting equipment manufacturer to determine how to mount the

vacuum generating system in a safe location that will not interfere with hoisting.

MT1TL6FAIR: #35080 Rev 9.0/5-238

Qualified service personnel should install female

quick connector (supplied) on air line, when

needed.

Securely position air line to avoid damage during

lifter operation.

5A 5B

Connect the lifter to an

appropriate compressed air

supply (see Power Source

under “SPECIFICATIONS”):

Then connect the female

quick connector to the male

quick connector mounted

on the air supply valve (figs.

5A-B).

6) Adjust the air pressure regulator to supply 80 psi [550 kPa]:1

Note: Vacuum pad must not be attached to any surface while adjusting the regulator.

6.1)

6A 6B 6C

Place the air

supply valve

lever parallel

with the

vacuum line

(ie, in the

“on”position

— fig. 6A).

6.2) Pull up the

adjustment

collar on top

of the

regulator

(fig. 6B), and turn the collar clockwise to increase pressure or counter-clockwise to

decrease pressure (fig. 6C).

1..... Exceeding this pressure consumes more air and does not improve lifter performance.

ASSEMBLY

Rev 9.0/5-23 MT1TL6FAIR: #350809

6.3)

When the pressure gauge registers a

minimum air pressure of 80 psi [550 kPa],

push down the collar to lock it in place

(fig. 6D).

Note:

Place the air supply valve lever perpendicular to the air

line (ie, in the “off” position — fig. 6E) when the lifter is not in

use; otherwise, the air compressor will cycle frequently.

7) Perform tests as required under “TESTING”.

ASSEMBLY

MT1TL6FAIR: #35080 Rev 9.0/5-2310

INTENDED USE

LOAD CHARACTERISTICS

Do NOT lift explosives, radioactive

substances or other hazardous materials.

Make sure the vacuum lifter is intended

to handle each load according to these

requirements:

• The load weight must not exceed the Maximum Load Capacity.

• The load must be a single piece of relatively nonporous material with a flat and

relatively smooth contact surface.1, 2To determine whether the load is too porous or

rough, perform the “Lifter/Load Compatibility Test”.

• The load's contact surface must be able to obtain a friction coefficient of 1 with the lifter's

vacuum pad (see “Pad-to-Load Friction Coefficient”). Otherwise, the capacity should be

derated appropriately.

• The load's surface temperature must not exceed the Operating Temperatures.3

• The load's minimum length and width are determined by the current Pad Spread

(see “SPECIFICATIONS”).

• The load's maximum length and width are determined by its allowable overhang.4

• Although load thickness is not restricted, it may affect the lifter’s hang angle and the

amount of operator effort required for handling loads.

Note: Standard vacuum pads can stain or deform load surfaces with light colors or soft

coatings. Test such surfaces for damaging effects before using the lifter on them.5

1..... Although concave vacuum pads can also attach to some curved loads, curvature can reduce lifting capacity. Contact WPG for more information.

2..... A “single piece” of material includes curtainwall assemblies, unitized glazing systems and similar construction units.

3..... Vacuum pads made from a heat-resistant rubber compound can enable you to lift loads with higher surface temperatures. Contact WPG or an

authorized dealer for more information.

4..... The allowable overhang is the amount of load material that can extend sideways beyond the vacuum pad without breaking or otherwise being

damaged. This depends on the load material, its thickness, and the angle of handling (if any). Since every material has different physical

properties, the allowable overhang must be evaluated separately for each load type. Contact WPG or an authorized dealer for more

information.

5..... Alternative rubber compounds are available for these purposes. Contact WPG or an authorized dealer for more information.

Indirect loading

can reduce

lifting capacity.

Rev 9.0/5-23 MT1TL6FAIR: #3508011

INDIRECT LOADING

Make sure to account for dynamic loading or other inadvertent

loading that can negatively affect lifting capacity, such as:

• Weight amplification that results when a loaded vacuum lifter

abruptly starts/stops moving, changes direction or bounces up

and down (eg, when a telehandler transports a loaded lifter across rough terrain).

• External force that effectively increases the weight of a lifter’s attached load (eg, when a

load of sheet material reacts to wind gusts).

OPERATING ENVIRONMENT

Make sure the lifter is suitable for each work environment, given the following restrictions:

•

Never use lifter

in dangerous

environments.

This lifter is not intended for any environment that is

dangerous to the operator or damaging to the lifter. Avoid

environments containing explosives, caustic chemicals and

other dangerous substances.

• The work environment is limited by the Operating Elevation and Operating

Temperatures.1, 2

• The lifter is not designed to be watertight.

Moisture can reduce

lifting capacity.

Do not use it

in rain or other unsuitable conditions.

CE/UKCA — A secondary positive holding device is required to lift loads on construction sites.

DISPOSAL OF THE LIFTER

After the Service Life of the lifter has ended (see “SPECIFICATIONS”), dispose of it in compliance

with all local codes and applicable regulatory standards.

1..... Although lifter use may be possible at higher elevation, lifting capacity is reduced whenever the lifter is unable to attain vacuum in the green

range on the vacuum gauge. Contact WPG for more information.

2..... Special provisions may allow the lifter to operate outside the specified temperature range. Contact WPG for more information.

INTENDED USE

MT1TL6FAIR: #35080 Rev 9.0/5-2312

OPERATION

BEFORE USING THE LIFTER

Determine whether the vacuum lifter is capable of each intended task (see “SPECIFICATIONS”

and “INTENDED USE”). Then complete the following preparations:

Taking Safety Precautions

•

Read all directions and safety rules before using

lifter.

Always wear appropriate personal protective

equipment.

Be trained in all industry

and regulatory standards

for lifter operation in your

region.

• Follow trade association

guidelines about precautions needed for each load material.

Performing Inspections and Tests

• Follow the “INSPECTION SCHEDULE”and “TESTING”.

•

Examine air filters regularly

and service when needed.

Service each air filter whenever its bowl contains

liquid or other contaminants or its element

appears dirty (see “AIR FILTER MAINTENANCE” in

SERVICE MANUAL).

Rev 9.0/5-23 MT1TL6FAIR: #3508013

TOATTACH THE PAD TO ALOAD

Generating Airflow

Place the air supply valve lever in the “on” position (fig. 1A — see ).

Never place air supply valve lever in “off” position while

operating lifter.

The vacuum pump is designed to run continuously. Any interruption of

airflow during lifter operation could result in an unintentional load release

and personal injury (see “In Case of a Power Failure”).

Positioning the Lifter on the Load

Make sure the contact surfaces of the load and vacuum pad

are clean (fig. 1B — see “Pad Cleaning”).

Determine which will be

the top edge of the load

while lifting, and position

the vacuum pad near that

edge, centering the pad

from left to right (fig. 2B).

Make sure the pad will fit

entirely on the load.

OPERATION

MT1TL6FAIR: #35080 Rev 9.0/5-2314

Sealing the Pad on the Load

Place the vacuum pad in contact with the load

surface. Then press the lifter firmly against the load

to help the vacuum pad begin to seal (fig. 1A).1

Reading the Vacuum Gauge

A vacuum gauge shows the current vacuum level in positive inches of Hg and negative kPa:

•

1B 2B

Green range (>16" Hg [-54 kPa]): Vacuum

level is sufficient to lift the maximum load

weight (fig. 1B).

•Red range (<16" Hg [-54 kPa]): Vacuum level

is not sufficient to lift the maximum load

weight (fig. 2B).

If it takes more than 5 seconds for the vacuum level to reach 5" Hg [-17 kPa], press on the

vacuum pad until it seals completely.

Once the pad has sealed, the lifter should be able to maintain sufficient vacuum for lifting,

except when used above the maximum Operating Elevation.2If it does not, perform the

“Vacuum Test”.

1..... Although a vacuum pad may become distorted during shipping or storage, this condition should correct itself with continued use.

2..... If the lifter is used above the maximum Operating Elevation (see “SPECIFICATIONS”), it may not be able to maintain sufficient vacuum for lifting.

Contact WPG for more information.

OPERATION

Rev 9.0/5-23 MT1TL6FAIR: #3508015

TOLIFT AND MOVE THE LOAD

Interpreting the Vacuum Gauge

Never lift load unless vacuum gauge registers

in the green range, because premature lifting

could result in load release and personal injury.

Vacuum is sufficient to lift the

Maximum Load Capacity

whenever the vacuum gauge registers

in the green range.

Monitoring the Vacuum Gauge

Monitor the vacuum gauge (fig. 1A) throughout the

entire lift.

Make sure the vacuum gauge remains

completely visible.

The vacuum pump runs continuously to maintain

sufficient vacuum for lifting the maximum load

weight. However, if the vacuum gauge shows a

level less than 16" Hg [-54 kPa]:

Stay clear of any suspended load while

gauge warns of insufficient vacuum.

Keep everyone away from a

suspended load until it can be safely

lowered to a stable support.

2) Stop using the lifter until the cause of the vacuum loss can be identified: Conduct the

“Pad Inspection” and perform the “Vacuum Test”.

3) Correct any faults before resuming normal operation of the lifter.

Controlling the Lifter and Load

When the lifter is ready, use the hoisting equipment to raise

the lifter and load as needed.

Use the control handle (fig. 1B) to keep the lifter and load in

the required position.

Once there is enough clearance, you may move the load as

required.

OPERATION

MT1TL6FAIR: #35080 Rev 9.0/5-2316

In Case of a Power Failure

Although the lifter is designed to support the load for at least 5 minutes without power, this

depends on many factors, including the “LOAD CHARACTERISTICS”and the condition of the vacuum

pad (see “VACUUM PAD MAINTENANCE”).

Stay clear of any suspended

load during power failure.

If a power failure occurs, keep everyone away from a

suspended load until it can be safely lowered to a stable

support. Correct any faults before resuming normal

operation of the lifter.

TOTILT THE LOAD

1) Make sure the load has enough

clearance to tilt without

contacting anyone or anything.

2) Tilt the load tothe position needed:

• Tilting the load to the upright position

happens automatically when it is lifted

(fig. 1A).

• Tilting the load to the flat position is

accomplished during the landing (see

section below).

TOLAND THE LOAD

•

For a landing in the upright position,

simply lower the load onto an

appropriate support.

• For a landing in the flat position, lower

the lifter until the bottom edge of the

load is supported.

Then continue to lower the lifter, carefully

allowing the load and lifter to tilt forward

and downward (fig. 1B and inset) until the

entire load rests on the support.

OPERATION

Rev 9.0/5-23 MT1TL6FAIR: #3508017

TORELEASE THE PAD FROM THE LOAD

Make sure load is at rest and fully supported before releasing

vacuum pad.

Do not move lifter until pad releases completely, because such movement could

result in load damage or personal injury.

1) Initiate release of the vacuum pad:

• P

ull a release tab on the pad (circled

in fig. 1A), or;

•

Place the air supply valve lever in the “off” position (fig. 1B).

2) Make sure the pad releases completely from the load.

3) Perform the Every-Lift Inspection (see “INSPECTION SCHEDULE”).

Now, the lifter can be attached immediately to another load.1

1..... If you released the vacuum pad by pulling its tab and the next lift is not imminent, place the air supply valve lever to the “release” position until

you are ready to lift another load.

OPERATION
