WT sensor PC12 II User manual

Version：V10 1 www.wtsensor.com
PC12ⅡFlush Diaphragm Pressure Sensor with thread
Features
■Flush diaphragm pressure sensor
with thread structure
■Imported highly reliable pressure
die
■A single time silicon oil isolated
filling technology
■Compensation board filled with
glue for protection against
moisture
■All stainless steel housing
material
■High accuracy, high reliability
■Strong anti-interference, good
long-term stability
■18 months warranty period
Applications
■Medical, food industry
■Environmental protection,
chemical, coating
■Polyurethane equipment
■Industry standards supporting
Product overview
The PC12Ⅱpressure sensor adopts food-grade oil filling
technology. The perceived pressure is transmitted to the
pressure chip through the oil to generate an electrical signal,
and the compensation circuit corrects the pressure signal to
a linear pressure signal. The product adopts flat membrane
structure, easy to clean, high reliability, suitable for pressure
and liquid level measurement of viscous fluids such as glue.
The company can customize products for customers, to
make products of special structure and size. We have mature
batch production lines, which can ensure production tasks be
finished perfectly.
Notes:
1 Do not misuse documentation.
2 The information presented in this product sheet is for
reference only. Do not use this document as a product
installation guide.
3 Complete installation, operation, and maintenance
information is provided in the instructions of the product.
4 Misuse of the product may cause danger or personal
injury.
Notes:
1 Do not touch the diaphragm
with hard objects, which may
cause damage to the diaphragm.
2 Please read the Instruction
manual of the product carefully
before installation and check the
relevant information of the
product.
3 Strictly follow the wiring method
for wiring; otherwise it may cause
product damage or other potential
faults.
4 Misuse of the product may
cause danger or personal injury.

Version：V10 2 www.wtsensor.com
Electrical performance parameters
Pressure range
-100kPa～0～35kPa…25MPa
Pressure reference
Gauge pressure,Absolute pressure, Sealed gauge pressure
Excitation
1.5mA recommended for constant current
Input impedance
Constant current: 2kΩ～5kΩ
Electrical connection
Gold-plated KOVAR pin or silicon soft wire
Compensation temp.
Constant current: 0℃～60℃(≤70kPa),-10℃～70℃(other ranges);
Operating temp.
-40℃～120℃
Storage temp.
-40℃～120℃
Insulation resistance
≥200MΩ/250VDC
Response time
≤1ms (up to 90%FS)
Measured medium
All the liquids and gases compatible with 316L.
Mechanical vibration
20g (20～5000Hz)
Shock
100g (10ms)
Service life
10×106 (cycles)
Structural performance parameters
Diaphragm material
316L
Housing material
316L
Oil filling
M20
Basic parameters
Item
Condition
Min
Nominal
Max
Unit
Note
Nonlinearity
-0.3
±0.25
0.3
%FS
Note⑴
Hysteresis
-0.05
±0.03
0.05
%FS
Repeatability
-0.05
±0.03
0.05
%FS
Zero output
-2
±1
2
mV
Span output
60
90
150
mV
1.5mA
supply
Zero temp.
coefficient
-1.5
±1
1.5
%FS
Note⑵
Span temp.
coefficient
-1.5
±1
1.5
%FS
Note⑵
Thermal
hysteresis
-0.075
±0.05
0.075
%FS
Note⑶
Long term
stability
-0.3
±0.2
0.3
%FS/year
Note:
(1) Calculate according to BFSL least square method.
(2) In the compensation temperature range, refer to 0 ℃~ 60℃and -10 ℃~ 70 ℃, and refer to
30 ℃.
(3)After passing high and low temperature, return to the reference temperature.

Version：V10 3 www.wtsensor.com
Structure and dimensions
Wire color Definition
Red Excitation+(IN+)
Blue Excitation-(IN-)
Yellow Output+(OUT+)
White Output-(OUT-)
Note: G: Gauge pressure,A: Absolute pressure, S: Sealed gauge pressure
Pressure range selection
Code
Pressure
reference
Pressure range
Overpressure
Burst
pressure
O-ring
35k
G
0～35kPa
300％FS
600％FS
ED ring
70k
G
0～70kPa
300％FS
600％FS
ED ring
100k
G、A
0～100kPa
200％FS
500％FS
ED ring
160k
G、A
0～160kPa
200％FS
500％FS
ED ring
250k
G、A
0～250kPa
200％FS
500％FS
ED ring
400k
G
0～400kPa
200％FS
500％FS
ED ring
600k
G
0～600kPa
200％FS
500％FS
ED ring
1M
G、S
0～1MPa
200％FS
500％FS
ED ring
1.6M
G、S
0～1.6MPa
200％FS
500％FS
ED ring
2.5M
G、S
0～2.5MPa
200％FS
500％FS
ED ring
4M
S
0～4MPa
200％FS
400％FS
ED ring
6M
S
0～6MPa
200％FS
400％FS
ED ring
10M
S
0～10MPa
200％FS
400％FS
ED ring
16M
S
0～16MPa
200％FS
400％FS
ED ring
25M
S
0～25MPa
150％FS
400％FS
ED ring

Version：V10 4 www.wtsensor.com
How to order
PC12Ⅱ- 100kPa G 4W I1 C1 H3F
Example：PC12Ⅱ-100kG4wI1C1H3F
Refer to product model PC12Ⅱ, with pressure range 100kPa, pressure reference gauge pressure,
4 wire, 1.5mA constant current excitation, pressure port M20*1.5, housing port: M24×1(Female), without
cooling elements.
Ordering tips:
1 Pressure range can be selected higher or lower than actual conditions but should be within ±30%FS.
2 Pressure reference consists of gauge pressure, absolute pressure and sealed gauge pressure.
⑴Gauge pressure is based on the current atmospheric pressure. Generally, it refers to the
measurement of pressure which is greater than the current atmospheric pressure. Negative
pressure is a special case of gauge pressure. It refers that there is such working condition that the
pressure of work site is lower than the current atmospheric pressure.
⑵Absolute pressure is based on vacuum.
⑶As for sealed gauge pressure, it uses absolute pressure die for gauge pressure product based on
the atmospheric pressure of production site. For pressure range above 6MPa, gauge pressure
cannot be selected, but only sealed gauge pressure.
3 Confirm the maximum overload of the applied system, which should be less than the overload
protection limit of the sensor, otherwise it will affect the product life or even damage the product.
4 The commonly used compensation of the product is1.5mAconstant current compensation. Suggest to
select the option with priority.
5 The material and process for manufacturing negative pressure sensors are different from those of
positive pressure sensors. So gauge pressure sensors cannot be used as substitute of negative
pressure sensors.
6 For special requirements on performance parameters and functions of the product, please contact us.
H3F = M24×1(Female)
C1=M20×1.5 pressure port
C2=G1/2 pressure port
Product model
Pressure range &
Pressure reference
4w = 4 wire
6p = 6 pin
I1 = 1.5mA constant current
excitation
U1= 10V constant voltage
excitation

Version：V10 5 www.wtsensor.com
Wotian reserves the right to make any change in this publication without notice. The information
provided is believed to be accurate and reliable as of this product sheet.
