WT sensor PC33 User manual

Version No. V12 1www.wtsensor.com
PC33 Monocrystalline Silicon Pressure Sensor
Features
■Imported MEMS
monocrystalline silicon
pressure die
■High accuracy and excellent
overpressure resistance
■High performance, all solid
state, high reliability
■316L stainless steel all welded
integrated structure
■Gauge pressure type applicable
to negative pressure
measurement
Applications
■Provide OEM for industrial
transmitter manufacturers
Notes:
1 Do not touch the diaphragm with
hard objects, which may cause
damage to the diaphragm.
2 Please read the Instruction Manual of
the product carefully before installation
and check the relevant information of
the product.
3 Strictly follow the wiring method for
wiring; otherwise it may cause product
damage or other potential faults.
4 Misuse of the product may cause
danger or personal injury.
Overview
PC33 High-Stability Pressure Sensor adopts monocrystalline
silicon sensor die with advanced MEMS technology, achieves
international leading overpressure performance and ensures the
excellent stability of signal. It is assembled in all-welded seal
structure and filled with silicon oil in high vacuum. Diaphragm of
different materials isolates measuring medium and pressure die,
meanwhile, the sensor performs long-term reliable measurement
of differential pressure signals of various strong corrosive media.
PC33 High-Stability Pressure Sensor allows measured pressure
to act directly on the diaphragm of sensor. Then the diaphragm
produces a micro displacement proportional to the pressure,
which can be detected with the integrated electronic circuit and
be converted to output a standard measurement signal of the
corresponding pressure.
Notes:
1 Do not misuse documentation.
2 The information presented in this product sheet is for reference only.
Do not use this document as a product installation guide.
3
Complete installation, operation, and maintenance information is
provided in the instructions of the product.
4 Misuse of the product may cause danger or personal injury.
Performance parameters
Supply Constant voltage 5V
Operating temp.
-40
～
85
℃
Storage temp.
-50
～
125
℃
Output voltage
60
～
140mV
Zero temp. coefficient
±0.3%FS/
℃
Temp. hysteresis ±0.1%FS(Range≥10kPa); ±0.5%FS(Range<10kPa)
Pressure hysteresis ±0.05%FS
Long-term drift ±0.05%FS / Year
Nonlinearity ±0.3%FS(Range≥10kPa); ±3.5%FS(Range<10kPa)
Max. overpressure See “Pressure range selection” below.
Diaphragm material Stainless steel 316L, Hastelloy C

Version No. V12 2www.wtsensor.com
Structure & dimensions
Unit: mm
Electrical connection
Electrical schematic diagram
Wire color Definition
Red IN+
Blue IN-
Yellow OUT+
White OUT-
GreenDiode+
Black Diode-
Pressure range selection
Code Min. pressure Pressure
reference
Pressure
reference Overpressure
6kG 1.5kPa Gauge -10～10kPa 200kPa
40kG 10kPa Gauge -40～40kPa 400Pa
100kG 25kPa Gauge -100～100kPa 1MPa
250kG 60kPa Gauge -100～250kPa 2MPa
1MG 250kPa Gauge -0.1～1MPa 6MPa
3MG 0.8MPa Gauge -0.1～3MPa 15MPa
How to order
PC33 - 250kG - M1 -6W
Pressure range
selection:
6kG=6kPa G
40kG=40kPa G
100kG=100kPa G
250kG=250kPa G
1MG=1MPa G
3MG=3MPa G
Diaphragm material:
M1: Hastelloy C
Default: Stainless
steel 316L
Connection:
6w: 6 wires
L: 2×4P terminal
Z: 1×7P terminal

Version No. V12 3www.wtsensor.com
Example: PC33-250kG-M1-6w
Refer to product model PC33, with pressure range 250kPa, pressure reference gauge pressure,
and diaphragm material Hastelloy C, 6 wires.
Ordering tips
Wotian reserves the right to make any change in this publication without notice. The information
provided is believed to be accurate and reliable as of this product sheet.
